Retekess TT101 User manual

Transmitter Receiver Charging socket
Model: TT101/TT102
Product Overview
This product uses the wireless technology Stylish appearance, compact and lightweight,
humanized layout design. It consists of transmitters and receivers, can be widely used
in tourism, religious activities, Simultaneous interpreting, reception, meeting, teaching,
and industrial production and so on.
Product Features
● Stylish appearance, compact and lightweight, easy to carry.
● VHF band transmission, less interference, stable signal, good sound quality.
● Large capacity battery and low power design, environmental protection, stability,
durability, safety, can use 40 hours.
● Large screen LCD display, humanized button design, can adjust the power and
channel freely and comfortably.
● The receiver can automatically shut down when it without signal for a period of time.
● Microphone pick-up circuit with high sensitivity, dynamic range is large, plus high
quality clip microphone, easy to use and comfortable, don't need to be close to your
mouth when you're speaking.
● dvanced anti jamming and PLL frequency synthesis technology, with advanced
software algorithm optimization to avoid interference automatically, 99 channels can
be used without interference.
Technical Parameters
Frequency: 195MHz---230MHz
Channel: 99
Voltage: DC3.7V
Receiver working hours: 40 hours
Transmitter working hours: 20 hours
Frequency response:50-18000Hz
Radio-frequency technique: PLL synthesis
Product Formation
Product Name
- Transmitter/Receiver
- LED display screen
Usage method
- Power on / off
Power on: (shutdown state) keep pressing the power button on/off about 2
seconds, release button when the screen appears company logo.
Power off: (shutdown state) keep pressing the power button on/off about 3
seconds, release button when the screen appearsBYE! (Boot state)
Without signal in 3minutes will shut down automatically.
- Volume adjustment
After the receiver is paired with the transmitter signal, you can adjust the volume
size by clicking the left and right buttons about 3S~ 5S, the total volume
is level 10,and the default is level 7.Click the power button to return to the main
interface when you switch to the corresponding level.
- Frequency adjustment
Channel auto pairing: Keep pressing the left button both transmitter and receiver
about 3S, then release the button when the receiver screen shows only the current
channel number CH+, and transmitter screen shows only CH00.Now,adjust the tra-
nsmitter channel to corresponding channel, and release button, when the transmitter
channel number is flashing representing it is paired automatically. After pairing,
click the transmitter power button, you can return to the main interface and use it.
Channel manual pairing: Pressing the left or right button for transmitter and receiver,
you can change the channel, When adjust to the corresponding channel and release
the button to return to the main interface.
- Mute adjustment
In pairing state, click the power button,you can enter the mute, now the screen show
the mute icon , click the power button again you can lift the mute, then enter
the main interface and use it.
- Charging
The charging device includes 10 chargers
and one multiple four Micro_USB line, with
one multiple four Micro_USB line plug into
10 charger, and four Micro_USB plug into
transmitter or receiver one by one. After
that, transmitter or receiver will display the
charging icon and the charging power currently.
- Error Tips
A transmitter / receiver power supply can not open:
Verify whether the transmitter/receiver is electrically：
Verify whether the receiver is in MUTE silent state
Verify whether the receiver volume is too quiet
Excessive noise
Verify whether it is in the surrounding strong interference environment
The receiver cannot match
Verify whether and transmitter in the same channel
Usage considerations
This product will produce noise when there is strong radio interference
The surrounding environment can also cause the distance of use
Product impact will lead to product damage
Please wipe this product with soft cloth
Spraying chemicals into the product can also cause deformation or malfunction
The product cannot water seepage
TOUR GUIDE SYSTEM
1 2
TT102
Degree of distortion:<0.2%
Noise-signal ratio: ≥90Db
Distance: ≤50m
Receiver/Transmitter size: 8.9x4.3x1.32cm
Charging hours: 5~6 hours
Receiver/Transmitter weight: 58g

WARNINGS
RF ENERGY EXPOSURE AND PRODUCT SAFETY GUIDE
This radio uses electromagnetic energy in the radio frequency (RF) spectrum to
provide communications between two or more users over a distance. RF energy,
which when used improperly, can cause biological damage.
All Retekess radios are designed, manufactured, and tested to ensure they meet
government-established RF exposure levels. In addition, manufacturers also
recommend specific operating instructions to users of the radios. These instructions
are important because they inform users about RF energy exposure and provide
simple procedures on how to control it.
Please refer to the following websites for more information on what RF energy
exposure is and how to control your exposure to assure compliance with
established RF exposure limits: http://www.who.int/en/
Local Government Regulations
When radios are used as a consequence of employment, the Local Government
Regulations requires users to be fully aware of and able to control their exposure
to meet occupational requirements. Exposure awareness can be facilitated by the
use of a product label directing users to specific user awareness information. Your
Retekess radio has a RF Exposure Product Label. Also, your Retekess user
manual, or separate safety booklet includes information and operating instructions
required to control your RF exposure and to satisfy compliance requirements.
Radio License (if appropriate)
Governments keep the radios in classification, business radios operate on radio
frequencies that are regulated by the local radio management departments (FCC,
ISED, OFCOM, ANFR, BFTK, Bundesnetzagentur...). To transmit on these freque-
ncies, you are required to have a license issued by them. The detailed classification
and the use of your radios, please contact the local government radio management
departments. Use of this radio outside the country where it was intended to be
distributed is subject to government regulations and may be prohibited.
Unauthorized modification and adjustment
Changes or modifications not expressly approved by the party responsible for
compliance may void the user’s authority granted by the local government radio
management departments to operate this radio and should not be made. To comply
with the corresponding requirements, transmitter adjustments should be made only
by or under the supervision of a person certified as technically qualified to perform
transmitter maintenance and repairs in the private land mobile and fixed services
as certified by an organization representative of the user of those services.
Replacement of any transmitter component (crystal, semiconductor, etc.) not
authorized by the local government radio management departments equipment
authorization for this radio could violate the rules.
FCC Requirements
• This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
• This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that interference
• Turn down the volume before adding headset or earpiece.
• Limit the amount of time you use headsets or earpieces at high volume.
• When using the radio without a headset or earpiece, do not place the
radio's speaker directly against your ear
• Use careful with the earphone maybe possible excessive sound
pressure from earphones and headphones can cause hearing loss
Note: Exposure to loud noises from any source for extended periods of
time may temporarily or permanently affect your hearing. The
louder the radio's volume, the less time is required before your
hearing could be affected. Hearing damage from loud noise is
sometimes undetectable at first and can have a cumulative effect.
Avoid Burns
Antennas
• Do not use any portable radio that has a damaged antenna. If a
damaged antenna comes into contact with the skin when the radio is
in use, a minor burn can result.
Batteries (If appropriate)
• When the conductive material such as jewelry, keys or chains touch
exposed terminals of the batteries, may complete an electrical circuit
(short circuit the battery) and become hot to cause bodily injury such
as burns. Exercise care in handling any battery, particularly when
placing it inside a pocket, purse or other container with metal objects
Long transmission
• When the transceiver is used for long transmissions, the radiator and
chassis will become hot.
Safety Operation
Forbid
• Do not use charger outdoors or in moist environments, use only in dry
locations/conditions.
• Do not disassemble the charger, that may result in risk of electrical
shock or fire.
• Do not operate the charger if it has been broken or damaged in any
way.
• Do not place a portable radio in the area over an air bag or in the air
bag deployment area. The radio may be propelled with great force
and cause serious injury to occupants of the vehicle when the air bag
inflates.
To reduce risk
• Pull by the plug rather than the cord when disconnecting the charger.
• Unplug the charger from the AC outlet before attempting any
maintenance or cleaning.
• Contact Retekess for assistance regarding repairs and service.
• The adapter shall be installed near the equipment and shall be easily
accessible
• Risk of explosion if battery is replaced by an incorrect type. Dispose
of used batteries according to the instructions.
• Adapter shall be installed near the equipment and shall be easily
accessible.
• The plug considered as disconnect device of adapter.
• The operating temperature of the EUT can’t exceed the specified range.
Approved Accessories
• This radio meets the RF exposure guidelines when used with the
Retekess accessories supplied or designated for the product. Use of
other accessories may not ensure compliance with the RF exposure
guidelines and may violate regulations.
• For a list of Retekess-approved accessories for your radio model,
visit the following website: http://www.Retekess.com
will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
CE Requirements
• (Simple EU declaration of conformity) Henan Eshow Electronic Commerce Co.,Ltd
declares that the radio equipment type is in compliance with the essential requirements
and other relevant provisions of RED Directive 2014/53/EU and the ROHS Directive
2011/65/EU and the WEEE Directive 2012/19/EU; the full text of the EU declaration of
conformity is available at the following internet address: www.retekess.com.
• Disposal
The crossed-out wheeled-bin symbol on your product, literature, or packaging
reminds you that in the European Union, all electrical and electronic products,
batteries, and accumulators (rechargeable batteries) must be taken to designa-
ted collection locations at the end of their working life. Do not dispose of these products
as unsorted municipal waste. Dispose of them according to the laws in your area.
IC Requirements
Licence-exempt radio apparatus
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
RF Exposure Information
• DO NOT operate the radio without a proper antenna attached, as this may damage the
radio and may also cause you to exceed RF exposure limits. A proper antenna is the
antenna supplied with this radio by the manufacturer or an antenna specifically
authorized by the manufacturer for use with this radio, and the antenna gain shall not
exceed the specified gain by the manufacturer declared.
• DO NOT transmit for more than 50% of total radio use time, more than 50% of the time
can cause RF exposure compliance requirements to be exceeded.
• During transmissions, your radio generates RF energy that can possibly cause
interference with other devices or systems. To avoid such interference, turn off the
radio in areas where signs are posted to do so.
• The device complies with RF specifications when the device used at 5mm from your
body. Third-party belt-clips, holsters, and similar accessories used by this device should
not contain any metallic components. Body-worn accessories that do not meet these
requirements may not comply with RF exposure requirements and should be avoided.
• DO NOT operate the transmitter in areas that are sensitive to electromagnetic radiation
such as hospitals, aircraft, and blasting sites.
Avoid Choking Hazard
Small Parts. Not for children under 3 years.
Protect your hearing
• Use the lowest volume necessary to do your job.
• Turn up the volume only if you are in noisy surroundings.
WARNING
WARNING
WARNING
WARNING
EU Importer
Name：Germany Retevis Technology GmbH
Address：Uetzenacker 29,38176 wendeburg
Before using this radio, read this guide which contains
important operating instructions for safe usage and RF
energy awareness and control for compliance with
applicable standards and regulations.
4 53
