RevJams REV-BTS100 User manual

REV-BTS100
USERS MANUAL
BLUETOOTH
LED SPEAKER

Thank you for choosing the RevJams Satellite
Bluetooth Speaker!
Please take the time to read this manual carefully,
even if you are already familiar with a similar product.
2

PACKAGE CONTENTS
1x RevJams Satellite Bluetooth Speaker
1x Micro USB Cable
1X 3.5mm AUX Audio Cable
1x User Manual
3

SPEAKER CONTROLS AND INDICATOR
1. Microphone
2. Power Button
3. TF/Micro SD Card Slot
4. Mode button / Reset to factory settings
5. Volume – / Previous Track
6. Multi-Function Button- Play/Pause/Answer Call
7. Volume + / Next Track
64
4

GETTING STARTED
To use your RevJams Satellite Bluetooth Speaker, please
follow these steps:
1. Charge your Bluetooth Speaker fully
2. Pair your Bluetooth Speaker to a Bluetooth-enabled
device prior to use.
CHARGING YOUR BLUETOOTH SPEAKER
Your RevJams Satellite Bluetooth Speaker comes with a
built-in rechargeable battery and a Micro USB charging
cable. Charge fully before use. The battery indicator will
turn red when charging and turn o once charging is
complete. Initial charging time is approximately 3-4 hours.
POWERING ON/OFF
Turn the Power Button switch to the right to Power ON, a
Blue LED light with turn on. Turn the Power button switch
to the left to Power OFF, the Blue LED light will turn o.
PAIRING YOUR BLUETOOTH SPEAKER
In order to use your RevJams Satellite Bluetooth Speaker
with a Bluetooth-enabled device, you will rst need to pair
the two.
1. Begin with the Bluetooth Speaker being powered o
and fully charged.
2. Place the Bluetooth Speaker and the Bluetooth enabled
device where they are easily viewable and no more than
3ft. apart.
3. Power ON the speaker. The speaker will automatically
enter Bluetooth Pairing mode once powered on. If it does
not enter pairing mode automatically, press the Mode
button to switch to the Bluetooth Mode. A voice prompt
will indicate that you are in Bluetooth Mode.
4. Activate your mobile phone's Bluetooth pairing
function and select “RevJams Satellite” from the list of
devices shown.
When successfully paired a chime will be heard through the
speaker
5

GETTING STARTED
To use your RevJams Satellite Bluetooth Speaker, please
follow these steps:
1. Charge your Bluetooth Speaker fully
2. Pair your Bluetooth Speaker to a Bluetooth-enabled
device prior to use.
CHARGING YOUR BLUETOOTH SPEAKER
Your RevJams Satellite Bluetooth Speaker comes with a
built-in rechargeable battery and a Micro USB charging
cable. Charge fully before use. The battery indicator will
turn red when charging and turn o once charging is
complete. Initial charging time is approximately 3-4 hours.
POWERING ON/OFF
Turn the Power Button switch to the right to Power ON, a
Blue LED light with turn on. Turn the Power button switch
to the left to Power OFF, the Blue LED light will turn o.
PAIRING YOUR BLUETOOTH SPEAKER
In order to use your RevJams Satellite Bluetooth Speaker
with a Bluetooth-enabled device, you will rst need to pair
the two.
1. Begin with the Bluetooth Speaker being powered o
and fully charged.
2. Place the Bluetooth Speaker and the Bluetooth enabled
device where they are easily viewable and no more than
3ft. apart.
3. Power ON the speaker. The speaker will automatically
enter Bluetooth Pairing mode once powered on. If it does
not enter pairing mode automatically, press the Mode
button to switch to the Bluetooth Mode. A voice prompt
will indicate that you are in Bluetooth Mode.
4. Activate your mobile phone's Bluetooth pairing
function and select “RevJams Satellite” from the list of
devices shown.
When successfully paired a chime will be heard through the
speaker
6

RANGE
Be sure to keep the speaker within 30 feet (10 meters) of
the connected media device at all times for optimal
performance.
MODE FUNCTIONS
The Bluetooth speaker is equipped with a Mode button
that allows you to switch in between modes – Press the M
button to switch between modes
MODES SEQUENCE
Bluetooth Mode →TF/Micro SD card →AUX Audio→FM
Mode
TF/MICRO SD CARD SLOT
Insert your TF/ Micro SD card into the designated slot and
press the M button to select the appropriate mode to play
media
7

AUX AUDIO PORT
The speaker features an AUX audio port, simply connect
the speaker with your non-Bluetooth mobile phone/MP3
player/PC/laptop with the 3.5mm AUX audio cable and
press the Mode button to enter “Line In” audio mode.
FM MODE
In order for the FM Mode to work , the USB cable must be
Connected to the Bluetooth Speaker during use– When
using the FM mode for the rst time, long press the to
scan for available FM stations, and then use the “+” and
“-“to scroll through the available FM radio stations. The
speaker will automatically save all stations for future use.
Please allow 1-2 minutes for the initial scan to be
completed.
8

RESET TO FACTORY SETTINGS
In Bluetooth Mode, long press the M button for 3 seconds
to restore the speaker to factory settings.
LED INDICATOR GUIDE
INDICATOR
Blue light
Red light
Red light turns o
Blue light ashes for
Pairing
STATUS
Power On
Charging
Charging complete
Bluetooth Pairing Mode
9

CALL MODE
Powering ON/OFF Turn the Power Button switch to the
right to Power ON. Switch to the left to
Power OFF
Press and hold the button for 2
seconds to reject the incoming call.
Short Press the button to end the
call or end the call directly from your
mobile phone.
Short Press the button once to accept
the call, or answer the call normally via
your mobile phone. Short Press again
to end the call and resume music
Answering a Call
Rejecting a Call
Ending a Call
10

MUSIC MODE
Adjusting the
Volume
Press and Hold the Volume + to increase
volume or Volume – to decrease volume.
You can also adjust the volume on your
handset or device
Short Press the " -" key to select the
previous track.
Short Press the "+" key to select the
next track.
Once connected, Press the button
once to play music. Short Press the
button to pause music.
Play/Pause Music
Previous Track
Next Track
Press the M to switch between modesDisconnect
Bluetooth
Connection
11

SPECIFICATIONS
Bluetooth version 3.0
Bluetooth range: 30 ft.
Output Power 3W
Speaker Output frequency range: 150Hz-20KHz
Discharge Current: 5V/0.5A
Battery: Built-in lithium battery 400mAh 3.7V
Charging Current: 200mA
Product Size: 2.8 X 2.8 X 1.6 inches
Speaker Weight: 6 oz.
Music Play Time: Up to 2.5 hours
Talk Time: Up to 4.5 hours
Standby time: Up to 20 hours
12

CARE AND MAINTENANCE
1. Please charge your new speaker for at least 3 hours
before rst use.
2. To prevent damage and risk of electrical shock, do not
expose this device to dust, vibration, rain, water or liquids
of any kind.
3. Do not place device in close proximity to open ames or
extreme heat sources.
4. Always place your device on level, at and stable
surfaces.
5. Avoid placing items on top of the speaker.
6. Do not use excessive force when pressing buttons or
handling your speaker.
7. To clean your speaker, use only a dry, soft cloth or
minimally damp cloth without any corrosive solvent or
cleaning agent.
SAFETY
To prevent res, shock or injury, please do not disassemble
or replace any parts of this device. In the event that your
device may be damaged or in need of repair, please
contact a professional maintenance or qualied service
center for assistance. We are not responsible for any
personal injury or property damage caused by improper
use of this product.
Please do not allow the use of this device by small children
without proper adult supervision.
FCC COMPLIANT
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
This device must accept any interference received,
including interference that may cause undesired operation.
13

1. Please charge your new speaker for at least 3 hours
before rst use.
2. To prevent damage and risk of electrical shock, do not
expose this device to dust, vibration, rain, water or liquids
of any kind.
3. Do not place device in close proximity to open ames or
extreme heat sources.
4. Always place your device on level, at and stable
surfaces.
5. Avoid placing items on top of the speaker.
6. Do not use excessive force when pressing buttons or
handling your speaker.
7. To clean your speaker, use only a dry, soft cloth or
minimally damp cloth without any corrosive solvent or
cleaning agent.
SAFETY
To prevent res, shock or injury, please do not disassemble
or replace any parts of this device. In the event that your
device may be damaged or in need of repair, please
contact a professional maintenance or qualied service
center for assistance. We are not responsible for any
personal injury or property damage caused by improper
use of this product.
Please do not allow the use of this device by small children
without proper adult supervision.
FCC COMPLIANT
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
This device must accept any interference received,
including interference that may cause undesired operation.
14

WARRANTY
At RevJams, we are dedicated to making the best quality
product. To back this up, your RevJams Satellite Bluetooth
Speaker is covered by a One (1) Year Limited
Manufacturer’s Warranty.
Details of the warranty are as follows: for a period of one (1)
year from the date of retail purchase, RevJams warrants
that this product is free of any defects in manufacturing,
materials and workmanship. During the warranty period,
we shall, at our sole discretion, repair or replace any
defective parts within a reasonable period of time.
Please visit our website www.revjams.com for more
details
Or Email us at: [e-mail] for any
questions or concerns about your product.
