Revogi SOW014 Mounting instructions

®
SOW014
Smart Power Strip
Quick Instruction Guide

Power Switch
Protected
Reset Button
5V 3.1A USB
Not Grounded
Wi-FiIndicator
PowerIndicator
Model: SOW014
Input: 100-120VAC 50/60Hz 15A
Output: 100-120VAC 50/60Hz 15A
Wirelessnetwork: 2.4GHz 802.11 b/g/n
Weight: 720g
Dimension: 324X62.5X37mm
Cable length: 1.2m
Revogi Smart Power strip is a simple and exquisite product,
based on cloud service through which users can turn home
devices on/off and monitor power consumption anywhere in the
world with 6 individually controlled sockets.
Specification
Product introduction
Operating Sys: Android: more than 800x480 resolution, Android 4.3+;
iOS: iOS8.0+
Web Browser: IE8+, Safari, Firefox, Chrome and other.
USB Output: DC 5V 3.1A.(each port max 3.1A)
VPR(Vpk): L-N:500, L-G:500, N-G:500.

Not Grounded
Indicator
Surge Protector
Indicator
Manually switch the whole strip power on/off and automatically switch off for
protection when the current is over 16.5 A.
Indicator
Indicator
Reset Button
Other
After keep pressing the button with a pin until the Wi-Fi indicator is off and then
on again, the strip will be reset to factory settings.
The device is grounded
The device is not grounded
Power Off
Power On
Surge protector is invalid
Surge protector is active
Over-current
Protection/Power
Switch
Device lnstallation
Network Linked (device successfully connected)
Quick flashing (device not connected to your network yet)
Slow flashing (device is now connected to your network or the
Wi-Fi password is wrong)

Protected
Not Grounded
Download APP
Operate the APP
Plug into the power outlet
Scan with your smartphone or search theApp Store or Google Play using Revogihomeas the keyword.
The power of Smart Strip will be on and wait till the Wi-Fi indicator flashes slowly.

Reset your password
Sign up/ Log in
1. Tap Log in if you already have a Revogi account or any 3rd party
account: e.g. Facebook, Twitter etc.
2. Tap sign up and create an account. Enter your valid e-mail address
when signing up for a new account.
3. If you forgot your password, reset it with the e-mail that you had used
while registering an account.
Forgot the password to your account? Reset it in these few simple steps:
1. Input the e-mail address that you have used when signing up.
2. Check the verification code with your email.
3. Input the verification code.
4. Set the new password.

Homepage Management
Functionality
Tap to enter App settings:
Language settings
Help and Feedback
Electricity rate
About
Tap to enter Account Settings:
Change your profile picture
Change the name
Check your account information
Reset the password
Log out
Control the plug and check the information about your device.
Long press your Smart Strip to enter the device settings.

Add New Devices
1. Make sure your smart phone has connected to the same Wi-Fi network that you expect the
devices will join!
2. Tap Add New Device on Devices page choose Scan the bar code on the back of the device orAdd
new device manually. Tap on the flashlight icon on the upper right corner if the environment is not
bright enough or the scanning can not be done!
3. Enter the password of your Wi-Fi SSID.

Factory default reset
Control your device via the web
1. Open the web browser and login with your account that you registered in the app.
2. Now you can control your device directly from the browser.
Reset the device by pressing the physical button on your Smart Power Strip until the Wi-Fi indicator
turns off.
You can also reset your device by deleting the device from your devices list in the home menu or in
the device settings (long press the device listed in the devices list, enter Setting and reset to
Factory Settings).

Real-time Power Consumption
Tap to return to device Detail View page.
Tap to enter setting:
Edit product name (edit name of each sockets of power strip) / Check
firmware version / Check product information / Switch on the reboot
function / Turn on the Reboot function.
Real-time power consumption reading of and overall power strip.
Turn the Power Strip on and off.
Tap details to monitor 6 sockets individually.

Individual control over each socket
1. Turn individual socket on or off.
2. Measure real-time power usage of each socket.
3. Tap on the socket to see the power usage of each socket.
4. Tap to enter the device settings:
Edit the socket settings
Enter Master-Slave control panel (see page 10)
Check and update the firmware version of your device
About: the information about your device such as: serial number, IP
address and other
Activate the Socket Reboot function (see page 10)
1. Change the name of the whole Power Strip.
2. Rename each of the sockets.
3. Change the icon of the socket to easily identify the socket you expect to
control.

Socket Reboot
Master-slave control
1. Set your socket(s) to automatically restart your router or other
electrical devices when the internet is down.
2. Choose the socket where the router is plugged in and activate the
Socket Reboot function.
3. The Smart Power Strip will detect when your internet is down and
automatically reboot your router.
1.Choose which socket is the master and which socket(s) will be the
slave sockets.
（E.g. set your TV as a master, and your speakers and DVD player as
its slaves.）
If the Master-Slave function is not working,you might need to set the
threshold of your Master socket measuring from high to medium.

Power Consumption History
Real-time Power Consumption
Tap to return to homepage
Tap to enter setting:
Edit the device name / Check the firmware version / Check the product
information / Turn on.
Socket Reboot: When internet disconnection is detected, the socket
that the router is plugged into will restart your router.
Up to 2400W real-time power usage reading.
1. Check historical power consumption displayed by kWh or the rate.
2. Check historical power consumption displayed by Hours Days Month.
3. Tap “newest” to check current power usage.
4. Check the past statistics even when the device is offline.

Timer
Schedule Setting
1. Slide to set the timer.
2. Set the timer by “quick buttons” of 30s/ 1min/ 5min/ 30min.
1. Set up to 12 schedules for one Smart Power Strip.
2. Schedules are stored in the device, even if the device is
disconnected from the internet or is not controlled by the smart phone.
The schedule will still be active.
3. Cancel the timer after it started when you expect to cancel.

The device has been evaluated to meet general RF exposure requirement.
To maintain compliance with FCC's RF exposure guidelines, this equipment should be
installed and operated with a minimum distance of 20cm between the radiator and your body.
RF Warning Statement:
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Part 15.105 Warning Statement
FCC Part 15.21 Warning Statement
NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT
EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH
MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
FCC Part 15.19 Warning Statement
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,
AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

Or contact us:
For technical support visit:
[email protected]
www.revogi.com/support:
www.revogi.com
