Revox Re:sound H190
Re:sound H190 – „forward to the roots”:
With this completely newly developed product, Re:sound H190, Revox
is once again setting new standards in the development of high-
quality speaker systems. The combination between breathtaking
design and the highest audio quality guarantees total listening
pleasure.
Great importance was given to achieving a tonal balance across the
whole transmission range during product development. The
specification also called for a particularly luxurious, dark and dry bass
reproduction, a spatial yet discreet mid-range and silken, generous
treble tones.
A further goal was a high linearity, using the best-possible physical
emission characteristics.
The Re:sound H190 is available in veneer cherry or silver varnished and is
manufactured in the Revox factory in Villingen, Southern Germany
and each unit is tested against the most demanding of tolerances, as
part of the company’s stringent quality assurance program.
Tecnical Data
Components
Nominal music power
Frequency response (IEC)
Sensitivity
Nominal impedance
Weight
Dimensions
4x154mm woofers, 1x154mm midrange, 25mm tweeter calotte
180 / 220 watts
28 Hz – 40kHz
87dB (1 W / 1m)
4 Ohm
38.5 kg
Housing including pedestal 1940mm
Housing width 180mm
Housing depth 250mm
Pedestal measuements (width x depth) 395x295mm
Product article number
Re:sound H190 in veneer cherry 1.084.540.00
Re:sound H190 in silver varnished 1.084.541.00

Dominating Entertainment.
Revox of Switzerland.
This all called for some new developments:
1. Bass range: 4 new, long-throw base drivers with powerful
magnets and durable membranes made of high-strength, black
anodised aluminium. Short-circuit rings with internal magnets
prevent distortion very effectively.
2. 154 mm mid-range system with hand-coated paper membranes
and linear, low-distortion magnets.
3. Broad, 25 mm soft calottes in the treble range, which reach far
beyond the audibility limit.
4. Unusually extensive, over-dimensioned, low-distortion crossover
network with high-specification components.
5. Vibration-optimised and internally reinforced housing. The result
is that no sound discolouration caused by partial oscillation of the
housing is audible.
High-quality speaker connections reduce unwanted contact
resistance and other interference to an absolute minimum.
