RF Elements CC Series User manual

CONNECTORIZED ASYMMETRICAL HORN ANTENNA
HG3-CC-A20, HG3-CC-A30, HG3-CC-A60, HG3-CC-A90
Asymmetrical Horn
Antenna CC

Asymmetrical Horn CC
www.rfelements.com
Overview
Product ID Dimensions Weight Gain (dBi)
20° Horn
HG3-CC-A20
HG3-CC-A20 414 x 417 x 254 mm
16.3 x 16.4 x 10.0 inch
6.6 kg
14.6 lbs 20.5
30° Horn
HG3-CC-A30
HG3-CC-A30 414 x 347 x 325 mm
16.3 x 13.7 x 12.8 inch
6.6 kg
14.6 lbs 20.5
60° Horn
HG3-CC-A60
HG3-CC-A60 472 x 342 x 275 mm
18.6 x 13.6 x 10.8 inch
6.7 kg
14.8 lbs 17.0
90° Horn
HG3-CC-A90
HG3-CC-A90 437 x 391 x 302 mm
17.2 x 15.4 x 11.9 inch
7.5 kg
16.5 lbs 16.0
Estimation based on pre-production units. Subject to change.
ALL HARDWARE STAINLESS STEEL
USE ANTISEIZE THREAD LUBRICANT

Asymmetrical Horn CC
www.rfelements.com
Number Description Quantity
1AH-CC Body 1x
2AH-CC Bracket Base 1x
3AH-CC Bracket Arm 1x
4AH-CC Bracket 1x
5M6 x 20mm Screw 6x
6M8 x 75mm Screw 2x
7AH-CC Handle 1x
1
4
6
7
2
3
5
Package Contents for: HG3-CC-A20 Antenna
To continue installation see Step 1
HG3-CC-A20

Asymmetrical Horn CC
www.rfelements.com
Number Description Quantity
1AH-CC Body 1x
2AH-CC Bracket Base 1x
3AH-CC Bracket Arm 1x
4AH-CC Bracket 1x
5M6 x 20mm Screw 6x
6M8 x 75mm Screw 2x
7AH-CC Handle 1x
1
4
6
7
2
3
5
Package Contents for: HG3-CC-A30 Antenna
To continue installation see Step 2
HG3-CC-A30

Asymmetrical Horn CC
www.rfelements.com
1
Number Description Quantity
1AH-CC Body 1x
2AH-CC Bracket Base 1x
3AH-CC Bracket Arm 1x
4AH-CC Bracket 1x
5M6 x 20mm Screw 3x
6M8 x 75mm Screw 2x
4
6
2
3
5
Package Contents for: HG3-CC-A60 Antenna
To continue installation see Step 3
HG3-CC-A60

Asymmetrical Horn CC
www.rfelements.com
1
Number Description Quantity
1AH-CC Body 1x
2AH-CC Bracket Base 1x
3AH-CC Bracket Arm 1x
4AH-CC Bracket 1x
5M6 x 20mm Screw 3x
6M8 x 75mm Screw 2x
6
2
3
Package Contents for: HG3-CC-A90 Antenna
To continue installation see Step 3
HG3-CC-A90
4
5

Asymmetrical Horn CC
www.rfelements.com
Step 1
1 2
Pre - Installation - This step applies only to the HG3-CC-A20 Antenna.
To continue installation see Step 3
USE ANTISEIZE
THREAD LUBRICANT

Asymmetrical Horn CC
www.rfelements.com
Step 2
1 2
Pre - Installation - This step applies only to the HG3-CC-A30 Antenna.
To continue installation see Step 3
USE ANTISEIZE
THREAD LUBRICANT

Asymmetrical Horn CC
www.rfelements.com
Assembly shown here is for the installation on the left side of the pole.
If you want to mount the antenna to the right side of the pole, see step 10 for further instructions.
Model HG3-CC-A60 shown. Installation instructions are identical for other Asymmetrical Horn
models. Antenna dimensions may dier.
Step 3
Pre - Installation
USE ANTISEIZE
THREAD LUBRICANT

Asymmetrical Horn CC
www.rfelements.com
Pre - Installation
Step 4
Model HG3-CC-A60 shown. Installation instructions are identical for other Asymmetrical Horn
models. Antenna dimensions may dier.
USE ANTISEIZE
THREAD LUBRICANT

Installation Guide
Asymmetrical Horn CC
www.rfelements.com
Step 5
USE ANTISEIZE
THREAD LUBRICANT
Model HG3-CC-A60 shown. Installation instructions are identical for other Asymmetrical Horn
models. Antenna dimensions may dier.

Installation Guide
Asymmetrical Horn CC
www.rfelements.com
Model HG3-CC-A60 shown. Installation instructions are identical for other Asymmetrical Horn
models. Antenna dimensions may dier.
Place the AH-CC bracket as shown below for the span of pole diameters 36 - 49 mm.
Place the AH-CC bracket as shown below for the span of pole diameters 50 - 80mm.
Step 6

Installation Guide
Asymmetrical Horn CC
www.rfelements.com
Model HG3-CC-A60 shown. Installation instructions are identical for other Asymmetrical Horn
models. Antenna dimensions may dier.
Step 7

Installation Guide
Asymmetrical Horn CC
www.rfelements.com
Model HG3-CC-A60 shown. Installation instructions are identical for other Asymmetrical Horn
models. Antenna dimensions may dier.
Step 8
USE ANTISEIZE
THREAD LUBRICANT

Installation Guide
Asymmetrical Horn CC
www.rfelements.com
Model HG3-CC-A60 shown. Installation instructions are identical for other Asymmetrical Horn
models. Antenna dimensions may dier.
Step 9
USE ANTISEIZE
THREAD LUBRICANT

Asymmetrical Horn CC
www.rfelements.com
Optional: If you want to mount the antenna on the right side of the pole, ip the bracket parts
as shown below.
Step 10
Pre - Installation
1 2
3 4
Model HG3-CC-A60 shown. Installation instructions are identical for other Asymmetrical Horn
models. Antenna dimensions may dier.
USE ANTISEIZE
THREAD LUBRICANT

Asymmetrical Horn CC
www.rfelements.com
Optional: If you want to mount the antenna on the right side of the pole, install the bracket arm
as shown below.
Step 11
Pre - Installation
Model HG3-CC-A60 shown. Installation instructions are identical for other Asymmetrical Horn
models. Antenna dimensions may dier.
USE ANTISEIZE
THREAD LUBRICANT

Asymmetrical Horn CC
www.rfelements.com
Optional: If you want to mount the antenna on the right side of the pole, install the bracket arm
as shown below.
Step 12
Pre - Installation
Model HG3-CC-A60 shown. Installation instructions are identical for other Asymmetrical Horn
models. Antenna dimensions may dier.
USE ANTISEIZE
THREAD LUBRICANT

Asymmetrical Horn CC
www.rfelements.com
Optional: If you want to mount the antenna on the right side of the pole, ip the bracket parts
as shown below.
Step 13
Pre - Installation
1 2
3 4
Model HG3-CC-A60 shown. Installation instructions are identical for other Asymmetrical Horn
models. Antenna dimensions may dier.
USE ANTISEIZE
THREAD LUBRICANT

RF elements s.r.o.
Phone: [phone]
[email protected]
www.rfelements.com
User Guide Part Number: AH_CC_UG_v2
