RF Elements UltraDish UD-TP-21 User manual

DIRECTIONAL PARABOLIC DISH ANTENNA
WITH TWISTPORT™ CONNECTOR
UD-TP-21
UD-TP-24
UD-TP-27
UltraDish™

Overview
UltraDish™
www.rfelements.com
Product ID Dimensions
(mm/inch)
Weight*
(kg/lbs)
Gain
(dBi)
UltraDish™
TP 5-21
UD-TP-21 467 x 344 x 262
18.3 x 13.5 x 10.3
2.2
4.8 21
UltraDish™
TP 5-24
UD-TP-24 505 x 420 x 262
19.8 x 16.5 x 10.3
2.4
5.2 24
UltraDish™
TP 5-27
UD-TP-27 584 x 584 x 285
22.9 x 22.9 x 11.2
3.5
7.7 27
*Estimate based on the pre-production units. Subject to change.

UltraDish™
www.rfelements.com
Number Description Quantity
1UltraDish™ 1x
2Bracket Base UBR 1x
3UltraDish™ Subreector 1x
4Bracket Ring UBR 1x
5Pole Mount Bracket 1x
6M8x80mm DIN 6921 Screw 2x
7M6x20mm DIN 912 Screw 2x
82.9x16mm Lock Screw 1x
4
1
2 3
56
7
8
Model UD-TP-24 shown. Package Contents are identical for UD-TP-21.
Antenna dimensions may dier.
Package Contents for: UD-TP-21 and UD-TP-24 Antennas
To continue installation see Step 4

UltraDish™
www.rfelements.com
Number Description Quantity
1UltraDish™ 27 1x
2Bracket Base UBR 1x
3UltraDish™ Subreector 1x
4Bracket Ring UBR 1x
5Pole Mount Bracket 1x
6M8x80mm DIN 6921 Screw 2x
7M6x20mm DIN 912 Screw 2x
82.9x16mm Lock Screw 1x
9M8x14mm DIN 7991 Screw 6x
10 UltraDish™ Base 1x
11 UltraDish™ Handle 1x
4
12 3
56
7
8
10
9
11
Package Contents for: UD-TP-27 Antenna
To continue installation see Step 1

Pre-Installation Guide
UltraDish™
www.rfelements.com
Step 1
Model UD-TP-27 shown.
Use 5 mm Hex Key when assembling the antenna
To continue installation see Step 4
- This step applies only to the UD-TP-27 Antenna

Pre-Installation Guide
UltraDish™
www.rfelements.com
Step 2
Model UD-TP-27 shown.
Setup for mounting
on the left side of the pole
Setup for mounting
on the right side of the pole
To continue installation see Step 4
- This step applies only to the UD-TP-27 Antenna

Pre-Installation Guide
UltraDish™
www.rfelements.com
Step 3
Use 5 mm Hex Key when assembling the antenna
These instructions are valid when mounting the antenna on the right side of the pole.
Model UD-TP-27 shown.
To continue installation see Step 4
- This step applies only to the UD-TP-27 Antenna

Installation Guide
UltraDish™
www.rfelements.com
Model UD-TP-24 shown. Installation instructions are identical for other UltraDish™ models.
Antenna dimensions may dier.
Step 4
Use 5 mm Hex Key when assembling the antenna
Assembly shown here is for the installation on the right side of the pole.
If you need to swap to use the left side of the pole, see step 12.

Installation Guide
UltraDish™
www.rfelements.com
Model UD-TP-24 shown. Installation instructions are identical for other UltraDish™ models.
Antenna dimensions may dier.
Step 5
Keep twisting the UltraDish™ Subreector in either direction until the spring latch is engaged

Installation Guide
UltraDish™
www.rfelements.com
Model UD-TP-24 shown. Installation instructions are identical for other UltraDish™ models.
Antenna dimensions may dier.
Step 6
Use 13 mm Ratchet Wrench when assembling the bracket

Installation Guide
UltraDish™
www.rfelements.com
Install the Pole Mount Bracket as shown for pole diameter range 40 - 57 mm.
Install the Pole Mount Bracket as shown for pole diameter range 58 - 80 mm.
Model UD-TP-24 shown. Installation instructions are identical for other UltraDish™ models.
Antenna dimensions may dier.
Step 7

Installation Guide
UltraDish™
www.rfelements.com
Model UD-TP-24 shown. Installation instructions are identical for other UltraDish™ models.
Antenna dimensions may dier.
Step 8

Installation Guide
UltraDish™
www.rfelements.com
Model UD-TP-24 shown. Installation instructions are identical for other UltraDish™ models.
Antenna dimensions may dier.
Step 9
Use 13 mm Ratchet Wrench when tightening the azimuth bolts

Installation Guide
UltraDish™
www.rfelements.com
Model UD-TP-24 shown. Installation instructions are identical for other UltraDish™ models.
Antenna dimensions may dier.
Step 10
Use 13 mm Ratchet Wrench when tightening the elevation bolts

Installation Guide
UltraDish™
www.rfelements.com
Model UD-TP-24 shown. Installation instructions are identical for other UltraDish™ models.
Antenna dimensions may dier.
Step 11
*
TwistPort™ Adaptor or SIMPER™ Radio sold separately.
*
Optional: Install the 2.9x16 mm locking screw.
Tighten the locking screw to secure
the TwistPort™ lock mechanism.

Pre-Installation Guide
UltraDish™
www.rfelements.com
Step 12
Use 5 mm Hex Key when disassembling the antenna
Model UD-TP-24 shown. Installation instructions are identical for UD-TP-21 model.
Antenna dimensions may dier.
Optional: Left side of the pole mounting
- This step applies only to the UD-TP-21 and UD-TP-24 Antennas

Pre-Installation Guide
UltraDish™
www.rfelements.com
Step 13
Optional: Left side of the pole mounting
- This step applies only to the UD-TP-21 and UD-TP-24 Antennas
Model UD-TP-24 shown. Installation instructions are identical for UD-TP-21 model.
Antenna dimensions may dier.

Pre-Installation Guide
UltraDish™
www.rfelements.com
Step 14
Optional: Left side of the pole mounting
- This step applies only to the UD-TP-21 and UD-TP-24 Antennas
Model UD-TP-24 shown. Installation instructions are identical for UD-TP-21 model.
Antenna dimensions may dier.
Use 5 mm Hex Key when assembling the antenna

RF elements s.r.o.
Phone: [phone]
[email protected]
www.rfelements.com
User Guide Part Number: UG_ULDG3_v5
RF elements®, TwistPort™, SIMPER™,
and UltraDish™ are trademarks
of RF elements s.r.o., Slovakia.
All rights of trademark owners reserved.
Compatible Devices:
RF elements®
any TwistPort™ Adaptor
any SIMPER™ Radio with TwistPort™ connector
