RF SOLUTIONS ELITE User manual

ELITE / ESPRIT Remote control System
Simplified Declaration of Conformity (RED)
BG - С настоящото RF Solutions Limited декларира, че този тип радиосъоръжение дефинирани в този документ е в съответствие с Директива 2014/53/ЕС.
Цялостният текст на ЕС декларацията за съответствие може да се намери на следния интернет адрес: www.rfsolutions.co.uk
CS - Tímto RF Solutions Limited prohlašuje, že typ rádiového zařízení definované v tomto dokumentu je v souladu se směrnicí 2014/53/EU. Úplné
znění EU prohlášení o shoděje k dispozici na této internetové adrese: www.rfsolutions.co.uk
DA - Hermed erklærer RF Solutions Limited , at radioudstyrstypen defineret i dette dokument er i overensstemmelse med direktiv 2014/53/EU.
EU-overensstemmelseserklæringens fulde tekst kan findes på følgende internetadresse: www.rfsolutions.co.uk
DE - Hiermit erklärt RF Solutions Limited , dass der Funkanlagentyp in diesem Dokument definiert der Richtlinie 2014/53/EU entspricht. Der
vollständige Text der EU-Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: www.rfsolutions.co.uk
EL - Με την παρούσα ο/ηRF Solutions Limited , δηλώνει ότι οραδιοεξοπλισμός ορίζεται σε αυτό το έγγραφο πληροί την οδηγία 2014/53/ΕΕ. Το πλήρες κείμενο
της δήλωσης συμμόρφωσης ΕΕ διατίθεται στην ακόλουθη ιστοσελίδα στο διαδίκτυο: www.rfsolutions.co.uk
EN - Hereby, RF Solutions Limited declares that the radio equipment type defined within this document is in compliance with Directive 2014/53/
EU. The full text of the EU declaration of conformity is available at the following internet address: www.rfsolutions.co.uk
ES - Por la presente, RF Solutions Limited declara que el tipo de equipo radioeléctrico definido dentro de este documento es conforme con la
Directiva 2014/53/UE. El texto completo de la declaración UE de conformidad está disponible en la dirección Internet siguiente:
www.rfsolutions.co.uk
ET - Käesolevaga deklareerib RF Solutions Limited , et käesolev raadioseadme tüüp määratletud selles dokumendis vastab direktiivi 2014/53/EL
nõuetele. ELi vastavusdeklaratsiooni täielik tekst on kättesaadav järgmisel internetiaadressil: www.rfsolutions.co.uk
FI - RF Solutions Limited vakuuttaa, että radiolaitetyyppi määratletud selles dokumendis on direktiivin 2014/53/EU mukainen. EU-
vaatimustenmukaisuusvakuutuksen täysimittainen teksti on saatavilla seuraavassa internetosoitteessa: www.rfsolutions.co.uk
FR - Le soussigné, RF Solutions Limited , déclare que l'équipement radioélectrique du type défini dans ce document est conforme à la directive
2014/53/UE. Le texte complet de la déclaration UE de conformité est disponible à l'adresse internet suivante: www.rfsolutions.co.uk
HR - RF Solutions Limited ovime izjavljuje da je radijska oprema tipa definirani u ovom dokumentu u skladu s Direktivom 2014/53/EU. Cjeloviti tekst
EU izjave o sukladnosti dostupan je na sljedećoj internetskoj adresi: www.rfsolutions.co.uk
HU - RF Solutions Limited igazolja, hogy a dokumentumban meghatározottak szerint típusú rádióberendezés megfelel a 2014/53/EU irányelvnek.
Az EU-megfelelőségi nyilatkozat teljes szövege elérhetőa következőinternetes címen: www.rfsolutions.co.uk
IT - Il fabbricante, RF Solutions Limited , dichiara che il tipo di apparecchiatura radio definito all'interno di questo documento è conforme alla diret-
tiva 2014/53/UE. Il testo completo della dichiarazione di conformità UE è disponibile al seguente indirizzo Internet: www.rfsolutions.co.uk
LT - Aš, RF Solutions Limited , patvirtinu, kad radijo įrenginiųtipas apibrėžta šiame dokumente atitinka Direktyvą2014/53/ES. Visas ES atitikties
deklaracijos tekstas prieinamas šiuo interneto adresu: www.rfsolutions.co.uk
LV - Ar šo RF Solutions Limited deklarē, ka radioiekārta kas definēts šajādokumentāatbilst Direktīvai 2014/53/ES. Pilns ES atbilstības deklarācijas
teksts ir pieejams šādāinterneta vietnē: www.rfsolutions.co.uk
MT - B'dan, RF Solutions Limited , niddikjara li dan it-tip ta' tagħmir tar-radju definit f'dan id-dokument huwa konformi mad-Direttiva 2014/53/UE.
It-test kollu tad-dikjarazzjoni ta' konformità tal-UE huwa disponibbli f'dan l-indirizz tal-Internet li ġej: www.rfsolutions.co.uk
NL - Hierbij verklaar ik, RF Solutions Limited , dat het type radioapparatuur gedefinieerd in dit document conform is met Richtlijn 2014/53/EU. De
volledige tekst van de EU-conformiteitsverklaring kan worden geraadpleegd op het volgende internetadres: www.rfsolutions.co.uk
PL - RF Solutions Limited niniejszym oświadcza, że typ urządzenia radiowego zdefiniowane w tym dokumencie jest zgodny z dyrektywą2014/53/UE.
Pełny tekst deklaracji zgodności UE jest dostępny pod następującym adresem internetowym: www.rfsolutions.co.uk
PT - O(a) abaixo assinado(a) RF Solutions Limited declara que o presente tipo de equipamento de rádio definido neste documento está em con-
formidade com a Diretiva 2014/53/UE. O texto integral da declaração de conformidade está disponível no seguinte endereço de Internet:
www.rfsolutions.co.uk
RO - Prin prezenta, RF Solutions Limited declarăcătipul de echipamente radio definit în acest document este în conformitate cu Directiva
2014/53/UE. Textul integral al declarației UE de conformitate este disponibil la următoarea adresăinternet: www.rfsolutions.co.uk
SK - RF Solutions Limited týmto vyhlasuje, že rádiové zariadenie typu definované v tomto dokumente je v súlade so smernicou 2014/53/EÚ. Úplné
EÚ vyhlásenie o zhode je k dispozícii na tejto internetovej adrese: www.rfsolutions.co.uk
SL - RF Solutions Limited potrjuje, da je tip radijske opreme opredeljeno v tem dokumentu skladen z Direktivo 2014/53/EU. Celotno besedilo izjave
EU o skladnosti je na voljo na naslednjem spletnem naslovu: www.rfsolutions.co.uk
SV - Härmed försäkrar RF Solutions Limited att denna typ av radioutrustning definieras i detta dokument överensstämmer med direktiv 2014/53/
EU. Den fullständiga texten till EU-försäkran om överensstämmelse finns på följande webbadress: www.rfsolutions.co.uk
RF Solutions Ltd. Recycling Notice
Meets the following EC Directives:
DO NOT
Discard with normal waste, please recycle.
ROHS Directive 2011/65/EU and amendment by 2015/863/EU
Specifies certain limits for hazardous substances.
WEEE Directive 2012/19/EU
Waste electrical & electronic equipment. This product must be disposed of through a licensed WEEE collection point. RF
Solutions Ltd., fulfils its WEEE obligations by membership of an approved compliance scheme. Environment agency regis-
tration number WEE/JB0104WV.
Disclaimer:
Whilst the information in this document is believed to be correct at the time of issue, RF Solutions Ltd does not accept any liability whatsoever for its accuracy,
adequacy or completeness. No express or implied warranty or representation is given relating to the information contained in this document. RF Solutions Ltd
reserves the right to make changes and improvements to the product(s) described herein without notice. Buyers and other users should determine for them-
selves the suitability of any such information or products for their own particular requirements or specification(s). RF Solutions Ltd shall not be liable for any loss
or damage caused as a result of user’s own determination of how to deploy or use RF Solutions Ltd’s products. Use of RF Solutions Ltd products or components
in life support and/or safety applications is not authorised except with express written approval. No licences are created, implicitly or otherwise, under any of RF
Solutions Ltd’s intellectual property rights. Liability for loss or damage resulting or caused by reliance on the information contained herein or from the use of the
product (including liability resulting from negligence or where RF Solutions Ltd was aware of the possibility of such loss or damage arising) is excluded. This will not
operate to limit or restrict RF Solutions Ltd’s liability for death or personal injury resulting from its negligence.
QS-ELITEESPRIT-1
ELITE / ESPRIT Remote Controls
Quick Start Guide
What’s in the box?
Supplied ready to go,
1. Attach the receiver to the wall
2. Connect the output screw Terminals
3. Apply power
Full details of programmable features, see the ELITEESPRIT Datasheet at
www.rfsolutions.co.uk
Sales: [phone] Tech Support: [phone]
Receiver
Transmitter
or
2 x FOBBER
Transmitters

ELITE / ESPRIT Remote control System
Receiver Guide
Timer Erase Mode Pair
Supply
Either ac or dc
NOT Both!
~AC DC
Relaxed Active
NO COM NC
NO COM NC
Relay Operation
Link fitted - MOMENTARY
Link Removed - LATCHING
LED’s
Power
Transmit
Receive
RF Signal Strength
LED Indication
Relay
Relay Outputs
Each output relay is an independent isolat-
ed switch. capable of switching 1KW
(5A @ 230V).
Fuse Rating 4A
ELITE / ESPRIT Remote control System
BLANK PAGE

ELITE / ESPRIT Remote control System
BLANK PAGE
ELITE / ESPRIT Remote control System
Pairing a transmitter
Timer Erase Mode Pair
Supply
Either ac or dc
NOT Both!
~AC DC
Relaxed Active
NO COM NC
NO COM NC
Relay Operation
Link fitted - MOMENTARY
Link Removed - LATCHING
LED’s
Power
Transmit
Receive
RF Signal Strength
LED Indication
Relay
Timer (Setting a Timed Output)
1. Repeat press the TIMER Switch to scroll
through output relays until the chosen relay
LED is flashing.
2. Wait for chosen relay LED to be on constantly.
3. Now Each press of the timer button will in-
crease the timer delay in line with the TIMER
OUTPUT Table Displayed on the signal strength
LED’s.
4. When you have selected the required delay,
wait 3 seconds.
5. The Red TIMER LED will Stop flashing to show
that the setting is saved
Note: Settings are saved even if power is cycled.
Note: When zero LED’s are lit the relays will op-
erate as per the Momentary/Latching links
To Erase ALL Timers:
1. Press and hold TIMER button for 10 seconds,
2. When the LED flashes fast release the timer
button the erase is complete
Mode (RF Mode of Operation)
1. Press the MODE button momentarily the
MODE LED will flash.
2. Repeat press the MODE button until the cho-
sen LED / Mode is selected
LED Mode
Typical RF
Transmit
Packet Time
8 LORA 7 1.28 Seconds
7 LORA 6 640 mSecs
6 LORA 5 320 mSecs
5 LORA 4 160 mSecs
4 LORA 3 80 mSecs
3 LORA 2 40 mSecs
2 LORA 1 20 mSecs
1* FSK 20 mSecs
*This is Factory Default
LED Output Time
8 60 mins
7 30 mins
6 10 mins
5 1 mins
4 30 Secs
3 10 Secs
2 5 Secs
1 1/2 Sec
0 Momentary

ELITE / ESPRIT Remote control System
For further assistance please contact
Sales: [phone] Tech Support: [phone]
RELAY 1 RELAY 3 RELAY 4
FUSE
L N E
0Vdc
12-32Vac/dc
NO COM NC NO COM NC NO COM NC NO COM NC
230V INPUT
SUPPLY
AUTO PAIR a new transmitter
(PAIR complete Transmitter to complete Receiver)
1. briefly press PAIR button
2. All relay LEDs Flash at a high rate
3. Press ANY button on the transmitter.
4. All LEDs will go out,
5. Wait 3 secs to confirm
NOTE: Maximum 31 Transmitters can be Paired.
ERASE ALL transmitters:
1. Press and hold the ERASE button for 10 sec-
onds
2. All relay LEDs flash together and then go out
3. Erase complete
MANUAL PAIR a new Transmitter
(PAIR individual Relay output to individual transmitter
switch)
1. Repeat Press the PAIR button until the chosen Relay
LED is flashing
2. Briefly Press the SPECIFIC transmitter Switch you
wish to PAIR with this Relay output.
3. PAIR LED will flash quickly for 2 seconds to confirm.
NOTE: Maximum of 31 SWITCHES can be paired
You cannot mix Auto PAIR and Manual PAIR!
ERASE Individual Transmitters:
1. Press and release the ERASE button
2. The ERASE LED flashes and all relay LEDs will be
flashing
3. Press Switch on the transmitter to be erased
4. When all output LEDs go out transmitter is erased
Application Drawing - Switching a Lamp
