RF SOLUTIONS TRAP-SHUFFLE Game Simulator User manual

TRAP Remote Control Systems
Disclaimer:
Whilst the information in this document is believed to be correct at the time of issue, RF Solutions Ltd does not accept any liability whatsoever for its accuracy, adequacy or
completeness. No express or implied warranty or representation is given relating to the information contained in this document. RF Solutions Ltd reserves the right to make
changes and improvements to the product(s) described herein without notice. Buyers and other users should determine for themselves the suitability of any such information or
products for their own particular requirements or specification(s). RF Solutions Ltd shall not be liable for any loss or damage caused as a result of user’s own determination of
how to deploy or use R F Solutions Ltd’s products. Use of RF Solutions Ltd products or components in life support and/or safety applications is not authorised except with ex-
press written approval. No licences are created, implicitly or otherwise, under any of RF Solutions Ltd’s intellectual property rights. Liability for loss or damage resulting or
caused by reliance on the information contained herein or from the use of the product (including liability resulting from negligence or where RF Solutions Ltd was aware of
the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict RF Solutions Ltd’s liability for death or personal injury resulting from
its negligence.
RF Solutions Ltd. Recycling Notice
DO NOT Discard with normal waste, please recycle.
Meets the following EC Directives:
ROHS Directive 2011/95/EU and amendment 2015/863/EU
Specifies certain limits for hazardous substances.
WEEE Directive 2012/19/EU
Waste electrical & electronic equipment. This product must be disposed of through a licensed WEEE
collection point. RF Solutions Ltd., fulfils its WEEE obligations by membership of an approved
compliance scheme. Environment Agency producer registration number: WEE/JB0104WV.
Simplified Declaration of Conformity (RED)
BG - С настоящото RF Solutions Limited декларира, че този тип радиосъоръжение дефинирани в този документ е в съответствие с Директива 2014/53/ЕС.
Цялостният текст на ЕС декларацията за съответствие може да се намери на следния интернет адрес: www.rfsolutions.co.uk
CS - Tímto RF Solutions Limited prohlašuje, že typ rádiového zařízení definované v tomto dokumentu je v souladu se směrnicí 2014/53/EU. Úplné znění
EU prohlášení o shoděje k dispozici na této internetové adrese: www.rfsolutions.co.uk
DA - Hermed erklærer RF Solutions Limited , at radioudstyrstypen defineret i dette dokument er i overensstemmelse med direktiv 2014/53/EU. EU-
overensstemmelseserklæringens fulde tekst kan findes på følgende internetadresse: www.rfsolutions.co.uk
DE - Hiermit erklärt RF Solutions Limited , dass der Funkanlagentyp in diesem Dokument definiert der Richtlinie 2014/53/EU entspricht. Der voll-
ständige Text der EU-Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: www.rfsolutions.co.uk
EL - Με την παρούσα ο/ηRF Solutions Limited , δηλώνει ότι οραδιοεξοπλισμός ορίζεται σε αυτό το έγγραφο πληροί την οδηγία 2014/53/ΕΕ. Το πλήρες κείμενο της
δήλωσης συμμόρφωσης ΕΕ διατίθεται στην ακόλουθη ιστοσελίδα στο διαδίκτυο: www.rfsolutions.co.uk
EN - Hereby, RF Solutions Limited declares that the radio equipment type defined within this document is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: www.rfsolutions.co.uk
ES - Por la presente, RF Solutions Limited declara que el tipo de equipo radioeléctrico definido dentro de este documento es conforme con la Direc-
tiva 2014/53/UE. El texto completo de la declaración UE de conformidad está disponible en la dirección Internet siguiente: www.rfsolutions.co.uk
ET - Käesolevaga deklareerib RF Solutions Limited , et käesolev raadioseadme tüüp määratletud selles dokumendis vastab direktiivi 2014/53/EL
nõuetele. ELi vastavusdeklaratsiooni täielik tekst on kättesaadav järgmisel internetiaadressil: www.rfsolutions.co.uk
FI - RF Solutions Limited vakuuttaa, että radiolaitetyyppi määratletud selles dokumendis on direktiivin 2014/53/EU mukainen. EU-
vaatimustenmukaisuusvakuutuksen täysimittainen teksti on saatavilla seuraavassa internetosoitteessa: www.rfsolutions.co.uk
FR - Le soussigné, RF Solutions Limited , déclare que l'équipement radioélectrique du type défini dans ce document est conforme à la directive
2014/53/UE. Le texte complet de la déclaration UE de conformité est disponible à l'adresse internet suivante: www.rfsolutions.co.uk
HR - RF Solutions Limited ovime izjavljuje da je radijska oprema tipa definirani u ovom dokumentu u skladu s Direktivom 2014/53/EU. Cjeloviti tekst
EU izjave o sukladnosti dostupan je na sljedećoj internetskoj adresi: www.rfsolutions.co.uk
HU - RF Solutions Limited igazolja, hogy a dokumentumban meghatározottak szerint típusú rádióberendezés megfelel a 2014/53/EU irányelvnek. Az
EU-megfelelőségi nyilatkozat teljes szövege elérhetőa következőinternetes címen: www.rfsolutions.co.uk
IT - Il fabbricante, RF Solutions Limited , dichiara che il tipo di apparecchiatura radio definito all'interno di questo documento è conforme alla direttiva
2014/53/UE. Il testo completo della dichiarazione di conformità UE è disponibile al seguente indirizzo Internet: www.rfsolutions.co.uk
LT - Aš, RF Solutions Limited , patvirtinu, kad radijo įrenginiųtipas apibrėžta šiame dokumente atitinka Direktyvą2014/53/ES. Visas ES atitikties
deklaracijos tekstas prieinamas šiuo interneto adresu: www.rfsolutions.co.uk
LV - Ar šo RF Solutions Limited deklarē, ka radioiekārta kas definēts šajādokumentāatbilst Direktīvai 2014/53/ES. Pilns ES atbilstības deklarācijas
teksts ir pieejams šādāinterneta vietnē: www.rfsolutions.co.uk
MT - B'dan, RF Solutions Limited , niddikjara li dan it-tip ta' tagħmir tar-radju definit f'dan id-dokument huwa konformi mad-Direttiva 2014/53/UE. It-
test kollu tad-dikjarazzjoni ta' konformità tal-UE huwa disponibbli f'dan l-indirizz tal-Internet li ġej: www.rfsolutions.co.uk
NL - Hierbij verklaar ik, RF Solutions Limited , dat het type radioapparatuur gedefinieerd in dit document conform is met Richtlijn 2014/53/EU. De
volledige tekst van de EU-conformiteitsverklaring kan worden geraadpleegd op het volgende internetadres: www.rfsolutions.co.uk
PL - RF Solutions Limited niniejszym oświadcza, że typ urządzenia radiowego zdefiniowane w tym dokumencie jest zgodny z dyrektywą2014/53/UE.
Pełny tekst deklaracji zgodności UE jest dostępny pod następującym adresem internetowym: www.rfsolutions.co.uk
PT - O(a) abaixo assinado(a) RF Solutions Limited declara que o presente tipo de equipamento de rádio definido neste documento está em conformi-
dade com a Diretiva 2014/53/UE. O texto integral da declaração de conformidade está disponível no seguinte endereço de Internet:
www.rfsolutions.co.uk
RO - Prin prezenta, RF Solutions Limited declarăcătipul de echipamente radio definit în acest document este în conformitate cu Directiva 2014/53/
UE. Textul integral al declarației UE de conformitate este disponibil la următoarea adresăinternet: www.rfsolutions.co.uk
SK - RF Solutions Limited týmto vyhlasuje, že rádiové zariadenie typu definované v tomto dokumente je v súlade so smernicou 2014/53/EÚ. Úplné EÚ
vyhlásenie o zhode je k dispozícii na tejto internetovej adrese: www.rfsolutions.co.uk
SL - RF Solutions Limited potrjuje, da je tip radijske opreme opredeljeno v tem dokumentu skladen z Direktivo 2014/53/EU. Celotno besedilo izjave
EU o skladnosti je na voljo na naslednjem spletnem naslovu: www.rfsolutions.co.uk
SV - Härmed försäkrar RF Solutions Limited att denna typ av radioutrustning definieras i detta dokument överensstämmer med direktiv 2014/53/
EU. Den fullständiga texten till EU-försäkran om överensstämmelse finns på följande webbadress: www.rfsolutions.co.uk
Waste Batteries and Accumulators
Directive 2006/66/EC
Where batteries are fitted, before recycling the
product, the batteries must be removed and
disposed of at a licensed collection point.
RF Solutions battery producer number:
BPRN00060.
QS-TRAP-SHUFFLE-R2
TRAP-SHUFFLE: Game Simulator
Quick Start Guide
SINGLE RELEASE
Switches 1-4 Instant
fire TRAPS
MULTI RELEASE
Fire ALL TRAPS at
the same time
VARIABLE SPEED
Adjust SPEED of the FLUSH.
From 2-7 seconds.
FLUSH RELEASE
Hold the FLUSH button for
two seconds to START
SELECTABLE AMOUNT
Adjust the amount of
CLAYS to be FLUSHED
between 1-99.
12
34
Pairing Transmitter to Receiver: (Note: Systems are supplied pre-paired)
1. First put the Transmitter into pairing mode : press switches 1,4,2, 3 in succession.
2. The LED’s on the transmitter will flash alternately to show the unit is in Pairing mode.
3. To pair a trap select and press the number switch (1-4) you wish to pair to the trap.
4. The LEDs on the transmitter will flash corresponding to the switch pressed, once if switch 1
is pressed, twice for switch 2, three for switch 3 and four for switch 4.
5. Once the LEDs have stopped flashing they will revert to flash alternately again. you may now
press the learn switch on the receiver you wish to pair to the selected transmitter switch.
6. The transmitter LEDs will flash together to confirm pairing then revert to alternating flash.
7. You may now repeat from step 4 to pair another trap to the transmitter.
8. To exit pairing mode press the Grey multi release button.

QS-TRAP-SHUFFLE-R2
TRAP-SHUFFLE: Game Simulator
Erasing the system:
1. First put the Transmitter into pairing mode : press switches 1,4,2, 3 in succession.
2. The LED’s on the transmitter will flash alternately to show the unit is in Pairing mode.
3. Press and hold the Grey multi release switch for around 10 seconds.
4. The 2x LEDs at the top of the transmitter will illuminate together until the button is released.
5. When the switch is released the LEDs will flash together to confirm the erase and exit pairing
mode.
Wiring of the system:
Installation Notes
An ideal installation would be to firmly fix the TRAP-SHUFFLE-RX approx. 2 metres from the
ground, in direct sight of the transmitter. Lowering the height or having obstacles between
transmitter and receiver will reduce range!
Connecting Power to the Receiver unit
The receiver unit requires the following connections to operate:
- 12V supply (Brown wire as supplied)
- OV Supply (Yell/GRN wire as supplied)
When the Receiver unit has power connected the Power LED will illuminate. This must be ‘on’
for the system to operate.
Power in 12-32V
NO/COMM/NC Relay
Terminal
Buzzer
Reed Switch (for easy pairing)
Learn Button
Antenna Connection
Status LEDs
Momentary/ Latching
Jumper Links
Power LED
Receiver Wiring
This diagram shows the
standard wiring configuration.
This may need to be adapted to
fit traps of other switching
types.
QS-TRAP-SHUFFLE-R2
TRAP-SHUFFLE: Game Simulator
Check the Wiring required for your Trap:
The TRAP-SHUFFLE-RX is capable of switching nearly any trap type, however wiring conventions
vary between manufacturers. The relays on the TRAP-SHUFFLE-RX can switch up to 24V DC or
230V AC @ 5A.
Wiring a Plug
The Receiver is supplied with a 3 core cable where:
• BROWN—12V
• GREEN/YELLOW—0V
• BLUE—Trigger Wire
A plug can be wired to the cable to be connected to many TRAP models. The image below
shows wiring examples for two common TRAP manufacturers.
Promatic Hirschmann 4
You can find an instruction video with pairing instructions at the link below or via the QR
code. https://www.youtube.com/watch?v=ihe98aBVF7Y
This system is not compatible with the standard TRAP systems as it uses specifically
designed firmware for the flush functionality in both the transmitters and receivers.
Promatic Duraplug 3 Pin
Laporte 4 Pin
