RF SOLUTIONS Scorpion User manual

Scorpion Transmitter
Simplified Declaration of Conformity (RED)
BG - С настоящото RF Solutions Limited декларира, че този тип радиосъоръжение дефинирани в този документ е в съответствие с Директива 2014/53/ЕС.
Цялостният текст на ЕС декларацията за съответствие може да се намери на следния интернет адрес: www.rfsolutions.co.uk
CS - Tímto RF Solutions Limited prohlašuje, že typ rádiového zařízení definované v tomto dokumentu je v souladu se směrnicí 2014/53/EU.
Úplné znění EU prohlášení o shoděje k dispozici na této internetové adrese: www.rfsolutions.co.uk
DA - Hermed erklærer RF Solutions Limited , at radioudstyrstypen defineret i dette dokument er i overensstemmelse med direktiv 2014/53/
EU. EU-overensstemmelseserklæringens fulde tekst kan findes på følgende internetadresse: www.rfsolutions.co.uk
DE - Hiermit erklärt RF Solutions Limited , dass der Funkanlagentyp in diesem Dokument definiert der Richtlinie 2014/53/EU entspricht. Der
vollständige Text der EU-Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: www.rfsolutions.co.uk
EL - Με την παρούσα ο/ηRF Solutions Limited , δηλώνει ότι οραδιοεξοπλισμός ορίζεται σε αυτό το έγγραφο πληροί την οδηγία 2014/53/ΕΕ. Το πλήρες
κείμενο της δήλωσης συμμόρφωσης ΕΕ διατίθεται στην ακόλουθη ιστοσελίδα στο διαδίκτυο: www.rfsolutions.co.uk
EN - Hereby, RF Solutions Limited declares that the radio equipment type defined within this document is in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.rfsolutions.co.uk
ES - Por la presente, RF Solutions Limited declara que el tipo de equipo radioeléctrico definido dentro de este documento es conforme con la
Directiva 2014/53/UE. El texto completo de la declaración UE de conformidad está disponible en la dirección Internet siguiente:
www.rfsolutions.co.uk
ET - Käesolevaga deklareerib RF Solutions Limited , et käesolev raadioseadme tüüp määratletud selles dokumendis vastab direktiivi 2014/53/
EL nõuetele. ELi vastavusdeklaratsiooni täielik tekst on kättesaadav järgmisel internetiaadressil: www.rfsolutions.co.uk
FI - RF Solutions Limited vakuuttaa, että radiolaitetyyppi määratletud selles dokumendis on direktiivin 2014/53/EU mukainen. EU-
vaatimustenmukaisuusvakuutuksen täysimittainen teksti on saatavilla seuraavassa internetosoitteessa: www.rfsolutions.co.uk
FR - Le soussigné, RF Solutions Limited , déclare que l'équipement radioélectrique du type défini dans ce document est conforme à la di-
rective 2014/53/UE. Le texte complet de la déclaration UE de conformité est disponible à l'adresse internet suivante: www.rfsolutions.co.uk
HR - RF Solutions Limited ovime izjavljuje da je radijska oprema tipa definirani u ovom dokumentu u skladu s Direktivom 2014/53/EU. Cjeloviti
tekst EU izjave o sukladnosti dostupan je na sljedećoj internetskoj adresi: www.rfsolutions.co.uk
HU - RF Solutions Limited igazolja, hogy a dokumentumban meghatározottak szerint típusú rádióberendezés megfelel a 2014/53/EU
irányelvnek. Az EU-megfelelőségi nyilatkozat teljes szövege elérhetőa következőinternetes címen: www.rfsolutions.co.uk
IT - Il fabbricante, RF Solutions Limited , dichiara che il tipo di apparecchiatura radio definito all'interno di questo documento è conforme alla
direttiva 2014/53/UE. Il testo completo della dichiarazione di conformità UE è disponibile al seguente indirizzo Internet: www.rfsolutions.co.uk
LT - Aš, RF Solutions Limited , patvirtinu, kad radijo įrenginiųtipas apibrėžta šiame dokumente atitinka Direktyvą2014/53/ES. Visas ES ati-
tikties deklaracijos tekstas prieinamas šiuo interneto adresu: www.rfsolutions.co.uk
LV - Ar šo RF Solutions Limited deklarē, ka radioiekārta kas definēts šajādokumentāatbilst Direktīvai 2014/53/ES. Pilns ES atbilstības
deklarācijas teksts ir pieejams šādāinterneta vietnē: www.rfsolutions.co.uk
MT - B'dan, RF Solutions Limited , niddikjara li dan it-tip ta' tagħmir tar-radju definit f'dan id-dokument huwa konformi mad-Direttiva 2014/53/
UE. It-test kollu tad-dikjarazzjoni ta' konformità tal-UE huwa disponibbli f'dan l-indirizz tal-Internet li ġej: www.rfsolutions.co.uk
NL - Hierbij verklaar ik, RF Solutions Limited , dat het type radioapparatuur gedefinieerd in dit document conform is met Richtlijn 2014/53/
EU. De volledige tekst van de EU-conformiteitsverklaring kan worden geraadpleegd op het volgende internetadres: www.rfsolutions.co.uk
PL - RF Solutions Limited niniejszym oświadcza, że typ urządzenia radiowego zdefiniowane w tym dokumencie jest zgodny z dyrektywą
2014/53/UE. Pełny tekst deklaracji zgodności UE jest dostępny pod następującym adresem internetowym: www.rfsolutions.co.uk
PT - O(a) abaixo assinado(a) RF Solutions Limited declara que o presente tipo de equipamento de rádio definido neste documento está em
conformidade com a Diretiva 2014/53/UE. O texto integral da declaração de conformidade está disponível no seguinte endereço de Internet:
www.rfsolutions.co.uk
RO - Prin prezenta, RF Solutions Limited declarăcătipul de echipamente radio definit în acest document este în conformitate cu Directiva
2014/53/UE. Textul integral al declarației UE de conformitate este disponibil la următoarea adresăinternet: www.rfsolutions.co.uk
SK - RF Solutions Limited týmto vyhlasuje, že rádiové zariadenie typu definované v tomto dokumente je v súlade so smernicou 2014/53/EÚ.
Úplné EÚ vyhlásenie o zhode je k dispozícii na tejto internetovej adrese: www.rfsolutions.co.uk
SL - RF Solutions Limited potrjuje, da je tip radijske opreme opredeljeno v tem dokumentu skladen z Direktivo 2014/53/EU. Celotno besedilo
izjave EU o skladnosti je na voljo na naslednjem spletnem naslovu: www.rfsolutions.co.uk
SV - Härmed försäkrar RF Solutions Limited att denna typ av radioutrustning definieras i detta dokument överensstämmer med direktiv
2014/53/EU. Den fullständiga texten till EU-försäkran om överensstämmelse finns på följande webbadress: www.rfsolutions.co.uk
Disclaimer:
Whilst the information in this document is believed to be correct at the time of issue, RF Solutions Ltd does not accept any liability whatsoever for its
accuracy, adequacy or completeness. No express or implied warranty or representation is given relating to the information contained in this docu-
ment. RF Solutions Ltd reserves the right to make changes and improvements to the product(s) described herein without notice. Buyers and other
users should determine for themselves the suitability of any such information or products for their own particular requirements or specification(s).
RF Solutions Ltd shall not be liable for any loss or damage caused as a result of user’s own determination of how to deploy or use RF Solutions Ltd’s
products. Use of RF Solutions Ltd products or components in life support and/or safety applications is not authorised except with express written
approval. No licences are created, implicitly or otherwise, under any of RF Solutions Ltd’s intellectual property rights. Liability for loss or damage
resulting or caused by reliance on the information contained herein or from the use of the product (including liability resulting from negligence or
where RF Solutions Ltd was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict RF Solutions
RF Solutions Ltd. Recycling Notice
Meets the following EC Directives:
DO NOT Discard with normal waste, please recycle.
ROHS Directive 2011/65/EU and amendment 2015/863/EU
Specifies certain limits for hazardous substances.
WEEE Directive 2012/19/EU
Waste electrical & electronic equipment. This product must be disposed of through a
licensed WEEE collection point. RF Solutions Ltd., fulfils its WEEE obligations by membership of an approved compliance scheme. Environment agency
number: WEE/JB0104WV.
Waste Batteries and Accumulators Directive 2006/66/EC
Where batteries are fitted, before recycling the product,
the batteries must be removed and disposed of at a licensed
collection point. RF Solutions battery producer number:
BPRN00060.
QS-SCORPION-1
Scorpion Transmitter
Quick Start Guide
Operation
Press any of the switches to operate.
The Transmitter will auto sleep between operations
to save power.
RF Transmit GREEN LED operates when Scorpion is
transmitting an RF signal.
RF Acknowledge (if configured):
GREEN LED will Flash at high speed to indicate that
an acknowledgment has successfully been received
back form the receiver.
RED LED will Flash at high speed to indicate that an
acknowledgment has not been received back form
the receiver.
Low Battery: If battery requires recharging Low
Battery LED illuminates for 3 seconds after each
operation.
Recharging the Battery
Remove the Green Overboot and place the
transmitter onto a charging pad
SCORPION is compatible with any QI wireless
charger.
When Charging the Battery RED LED gives a slow
Flash indicates charging is in progress.
When fully charged the GREEN LED is illuminated
Note: If the Battery becomes very depleted it can
take a few minutes before there is adequate charge
to start the RED LED to flash!
LED Flashes while
recharging
Fully charged
(Green LED)
RF Transmit
(Green LED)
RF Acknowledge
from Receiver
(Green/Red LED)
Low Battery

Configuring Scorpion Transmitter
Page: 2
QS-SCORPION-1
Configuring Modes of Operation
To configure the modes of operation, undo the
six enclosure fixing screws to access the
internal circuit board.
The SET switch is used to configure the
operating modes.
Note: Please also see the Video on our website!
SET
Switch
Antenna
LED1 LED2
LED3
Flashes
constantly
in setup
Restore SCORPION to Factory Default Settings
Briefly Press
SET Sw
LED1 ON
Constantly
Press & Hold
SET Sw
For 10 Secs
The Following Modes can be configured using the SET Switch
1. RF Mode of Transmission (FM or LORA Mode)
2. Acknowledgement back from the Receiver
3. Automatic Watchdog Transmissions
4. Continuous or State Change Transmission
SCORPION Transmitters are factory Shipped with the following Settings
RF Transmission FM
Acknowledgment OFF
Watchdog OFF
Transmission Type Continuous
Configuring Scorpion Transmitter
Page: 7
QS-SCORPION-1
LED Status
Continuous Transmission
Operation GREEN LED RED LED
Button is briefly pressed Flashes briefly No-operation
Button is held Down Flashes constantly No-operation
Button is released Flashes briefly No-operation
Continuous Transmission
Acknowledgement ON
Operation GREEN LED RED LED
Button is briefly pressed Flashes briefly (TX then RX ack) Flashes if no Ack received
Button is held Down Flashes continually (TX then RX ack) Flashes if no Ack received
Button is released Flashes briefly (TX then RX ack) Flashes if no Ack received
State Change Transmission
Acknowledgement OFF
Operation GREEN LED RED LED
Button is briefly pressed Flashes 1X (TX) No-operation
Button is held Down No-operation No-operation
Button is released Flashes 1X (TX) No-operation
State Change Transmission
Acknowledgement ON
Operation GREEN LED RED LED
Button is briefly pressed
& Receiver, ack OK Flashes (TX then RX ack) No-operation
Button is briefly pressed
& Receiver, NOK Flashes continually (awaiting Ack) Flashes to show no Ack received
Button is held Down Flashes continually (awaiting Ack) Flashes to show no Ack received
Button is released Flashes 2 - 5X (TX and RX ack) Flashes if no Ack received
RF Transmitting &
Acknowledgement
OK
Acknowledgment
Failed

Configuring Scorpion Transmitter
Page: 6
QS-SCORPION-1
Press SET Sw
4X
LED1 flashes
4x
LED 1 & 2
Flashes 1x
LED1 is either
ON or OFF
indicating current
Status
Repeat Press SET Sw To select
LED1 OFF: State
LED1 ON: Continuous
After selecting wait for timeout
Wait 3
Seconds
Wait 3
Seconds
To Set Continuous or State Change RF Transmissions
When a switch button is operated SCORPION will
transmit a “Button Down” RF Transmission.
When a switch button is released SCORPION will
transmit a “Button Up” RF Transmission.
Continuous Transmit
SCORPION repeat transmits “button Down” in short
bursts for as long as switch button is pressed.
If the Acknowledgment is ON the receiver will reply after
each RF transmission burst.
This is ideally suited to momentary operation where the
receiver output needs to be active as long as the user
presses down a SCORPION Button.
State Change Transmit
SCORPION transmits an RF transmission only when the
switch button is pressed or released (i.e. a state
change).
On each of these “state changes” SCORPION transmits
up to 4 transmissions, or, “RF packets” (which can be
seen by the GREEN LED flashing up to 4 times,
If the Acknowledgment is ON the receiver will reply
immediately.
After receiving an Acknowledgment the SCORPION will
cease sending any remaining of the 4 transmissions.
Configuring Scorpion Transmitter
Page: 3
QS-SCORPION-1
Mode
(No of LED1 Flashes)
Propagation Time
from TX to output
Activated (approx)
Operations from a
Single battery charge
RF Transmission
1 20 mS 1MillionFM
2 20 mS ~550KLoRa Mode 1
3 40 mS 288KLoRa Mode 2
4 80 mS 144KLoRa Mode 3
5 160 mS 72KLoRa Mode 4
6 320 mS 36KLoRa Mode 5
LoRa Mode 6 7 640 mS 18K
LoRa Mode 7 8 1.28 Secs ~9,000
Press SET Sw
1X
LED1
flashes 1x
LED 1 & 2
Flashes 1x
LED 1 Flashes
Indicating
Current MODE
Repeat Press SET Sw
To select Mode
1x = FM
2x = LORA Mode 1
3x = LORA Mode 2
4x = LORA Mode 3
5x = LORA Mode 4
6x = LORA Mode 5
7x = LORA Mode 6
8x = LORA Mode 7
After selecting wait for timeout
Wait 3
Seconds
Wait 3
Seconds
To Set the RF Transmission MODE
Notes
1. Range is dependant on many factors
including the mode of transmission.
Range can be reduced by 75% in built up
areas with poor antenna, and
environmental conditions.
2. Battery life quoted is approximate based
on 30 operations per day.
This sets the type of RF Transmission.
Possible options are FM, or LORA Modes 0 - 7
FM or LORA mode 0 provides the quickest
response; from Transmitter switch (Sw)
pressed to Receiver Relay output.
LORA mode 7 provides the longest operating
range but with the longest time delay of from
button press to receiver relay actuation.

Configuring Scorpion Transmitter
Page: 4
QS-SCORPION-1
RF Acknowledgment from Receiver - Warning!
When Acknowledgement is ON, SCORPION
transmitter requests an RF signal back from the
receiver. Whilst in theory if an RF signal can be
transmitted one way then it can be returned, in
practice occasionally the received
acknowledgement many not penetrate as well as
the SCORPION transmitted signal.
Press SET Sw
2X
LED1 flashes
2x
LED 1 & 2
Flashes 1x
LED1 is either
ON or OFF
indicating current
Status
Press SET Sw To select
LED1 ON:
Acknowledgement
LED1 OFF: NO
Acknowledgement
After selecting wait for
timeout
Wait 3
Seconds
Wait 3
Seconds
To Set Acknowledgement Request
Acknowledgement Feature provides the user with
LED indication that the receiver has successfully
received the transmitters signal.
When activated the SCORPION Transmitter includes
an acknowledgement request from the receiver
within each radio transmission.
The response from the receiver is indicated on the
transmitter via the RED / GREEN LEDs.
Configuring Scorpion Transmitter
Page: 5
QS-SCORPION-1
If enabled, SCORPION automatically transmits a
background “watchdog” RF Signal approx. every
~45 secs.
RF Solutions Receivers with a Watchdog feature will
hold a Relay contact “ENERGISED” as long as
Watchdog is regularly received confirming the
transmitter is in range and the system is operating
correctly.
When using Watchdog it may be useful to
incorporate a Power Switch to avoid premature
battery discharge.
A power switch can be incorporated if this is
required please contact our Sales Dept.
To Set Watchdog Transmissions
Press SET Sw
3X
LED1 flashes
3x
LED 1 & 2
Flashes 1x
LED1 is either
ON or OFF
indicating current
Status
Press SET Sw To select
LED1 ON: Watchdog ON
LED1 OFF: Watchdog OFF
After selecting wait for timeout
Wait 3
Seconds
Wait 3
Seconds
