RGBlink MSP 225 User manual

MSP 225 Quick Start
1U Frame
HDMI 1.3 Input
H.264 Output
Controlled by USB
Preview via Webpage

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
1
CONTENT
Product Introduction.................................................................................................................................................. 2
Packing Configuration.................................................................................................................................................3
Hardware Orientation................................................................................................................................................ 4
Interface.............................................................................................................................................................. 4
Button Panel........................................................................................................................................................ 4
Operating Instruction................................................................................................................................................. 5
System Connection..............................................................................................................................................5
How to Work....................................................................................................................................................... 5
Specification........................................................................................................................................................ 6
Using Software............................................................................................................................................................7
Installing Software...............................................................................................................................................7
Using Software.................................................................................................................................................. 12
Log in the Software................................................................................................................................... 12
Web Links.................................................................................................................................................. 13
Connect the Device................................................................................................................................... 13
I/O Set........................................................................................................................................................15
Network Set...............................................................................................................................................16
System Set................................................................................................................................................. 17
Factory Reset.............................................................................................................................................19
Logout........................................................................................................................................................19
Contact Information................................................................................................................................................. 20

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
2
Product Introduction
This compact convertor provides encoding of HDMI signals to H.264 internet streaming video over IP. Now any
video can be streamed to a connected website for viewing, expanding the reach possibilities. MSP 225 offers
two HDMI input channels and dual RJ45 connectors for IP output and connection to LAN/WAN.
Configuration of MSP 225 is made via a web browser interface, providing settings for encoding formats and
connection settings for web applications.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
3
Packing Configuration
AC Power Cord
QC Declaration

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
4
Hardware Orientation
Interface
Button Panel
No.
Interface
No.
Interface
1.2
H.264 Output RJ45
3
Standard 12V/3A
4
USB Control
5.6
HDMI Input HDMI-A Port

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
5
Operating Instruction
System Connection
Connect the computer with HDMI interface to the HDMI input port of MSP 225 with HDMI cable.
Connect the H.264 input port of MSP 226 to the H.264 output port of MSP 225 with network cable.
Connect power cable to device and plug into wall socket. In order to avoid the damage of device, please use the
standard power adapter.
How to Work

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
6
Specification
HDMI Input
Number of Inputs
2
Connector
HDMI-A
Supported Resolution
SMPTE: 480i60 | 576i50 | 720P50/59.94/60 | 1080i50/59.94/60 |
1080P25/29.97/30/50/59.94/60
VESA: 1024x768x60/75/85 | 1280x800x60 | 1280x1024x60/75/85 |
1360x768x60 | 1366x768x60 | 1400x1050x60 |1440x900x60 |
1600x1200x60 |1680x1050x60 | 1920x1080x60
Signal Level
TMDS pwl, single pixel input,165MHz bandwidth
Supported Standard
HDMI 1.3
H.264 Output
Number of Outputs
2
Connector
RJ45
Supported Resolution
176x144 | 240x180 | 320x180 | 320x240 | 320x256 | 352x228 | 352x480 |
400x224 | 400x320 | 480x270 | 480x272 | 480x320 | 480x360 | 480x384 |
480x480 | 544x480 | 608x448 | 640x360 | 640x480 | 704x576 | 720x404 |
720x480 | 720x540 | 720x576 | 850x480 |1024x576 | 1280x720 |
1680x1056 | 1920x1080
Refresh Rates
10~60FPS
Encoding Protocols
H.264 baseline/main/high profile L4.2，MJPEG/JPEG baseline
Supported Standard
H.264/MPEG-4 AVC
Extras
Communication
USB
Power Supply
12V DC (via universal Plug Pack)
Working Environment
0°C~45°C
Stored Environment
10%~85%
Net Weight
0.27kg
Device Dimension
98mm x 92.9mm x 44mm
Product Warranty
3 years parts and labor warranty

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
7
Using Software
Installing Software
Environment Requirements:
Processor: 1 GHz or above 32 bit or 64 bit processor
Memory: 2 GB or more
Graphics: Support DirectX 9 128M or above (open AERO effect)
Hard disk space: Above 16G (primary partitions, NTFS format)
Monitor: Resolution must be 1280 x720 pixel or above (it can not display normally if the resolution is lower than
1280 x720)
Operating system: Windows 7 or above (full version, not Ghost version or compact version)
Double click icon, it will pop-up the installer language box, select the language, for example, select
“English”, and click “OK” to confirm.
Click “Next” to install:

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
8
Select “Browse...” to select the MSP software install location:
Click “Install”:
During installation, it will pop up the window of InstallShield Wizard for Virtual Com port:

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
9
(1) If user install the MSP software for the first time, click “Next”:
Then click “Install", as shown in the figure below:

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
10
Click “Finish” and complete the installation, as shown in the figure below:
Then it will pop up the window of installation wizard for device driver, click “Next” to complete the
installation.
(2) If user have installed the MSP software before, click “Cancel”, and it will pop up the window as below:
Click “Yes” to cancel installation.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
11
Click “Finish” to exit installation.
Then it will pop up the window of installation wizard for device driver, click “Cancel” to exit the installation.
Click “Finish” and is ready to run the MSP management software:

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province,
P.R.C Tel: [phone] Fax: [phone]
Email: [email protected]
http://www.rgblink.cn
12
Using Software
Log in the Software
Double click the icon on the desktop. Log in interface will be enter after opening, the
user name is Admin, and there is no password, select “MSP 225”, and enter into the software by
clicking “Login”.
If user want to change the language to Chinese, click the drop down arrow after “Language” and
select “Chinese”, as shown in the figure below, then click “Login” to enter into the software.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
13
MSP management software interface is shown as follows.
MSP management software contains the functions including: web links, search, I/O set, network set, system set,
factory reset and logout. In the following parts, we will introduce these in detail.
Web Links
MSP management software sets up the web links. Click the web links icon on the top left corner,
and enter the company’s website, as shown in the figure below:
Connect the Device
First, set up the device IP, and ensure the IP of the computer and device is on the same network segment.
Connect the MSP management software to the computer with the network cable and power up the device.
Then, click the shortcut “Search” on the operation interface.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
14
Then it will search the device, and show the device name, device number and connect information after search,
as shown in the figure below:
Finally, click the device to connect, as shown in the figure below:

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
15
The software will enter to the I/O Set interface after connection, as shown in the figure below:
I/O Set
Click the “I/O Set”, and enter to the interface as follows:
User can view the input information and set output width/height and FTS, specific as follows:
Input

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
16
Display the input information, including input signal, width/height and Freq.
Output
Click the pull-down menus, and select the width/height and FTS. Click “Setting” to confirm.
Network Set
Click “Network Set”, and enter the interface as follows:

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
17
Click “Network Set”, user can view the URL play address, and set IP address, Mask, GateWay, DNS and MAC. As
shown in the figure below:
System Set
Click “System Set”, and enter the interface as follows:

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
18
SerialPort Set, System Info and role management are included in system set, specific as follows:
SerialPort Set
Click “SerialPort Set”, and pop-up window as follows:
Select the corresponding serial number. If select “Search by this configuration”, the software will search all the
devices with corresponding serial number.
System Info
Click “System Info”, and pop-up window as follows:
Display the device type, software version, serial number, software, hardware and board version.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
19
Role Management
Click “Role Management”, and pop-up window as follows:
Add: Select the user type as “Admin’ or “Users” in User’s List, and input the user name and password. Click
“Add” after setting.
Edit: Select the admin or users in user’s list, then edit the password or user type, click “Edit” after setting.
Del: Select the admin or users in user’s list, then click “Del”, the selected user will be deleted.
Factory Reset
Click “Factory Reset”, and pop-up window as follows:
Select “OK”, all the settings will be recover to factory setting.
Logout
Click the “Logout”, and enter the interface as follows:
Click “OK” will logout the software.
