RGBlink MSP 227 User manual

MSP 227 Quick Start
VIEWSIZE THE WORLD
Convert any input of AV/YPbPr/VGA/DVI/HDMI
Picture mode selection
Color temperature selection
Auto adjust for screen
Buttons to setup and configure the MSP 227
Enter/Output button works as Output to select
output port
Dial Switch on the bottom to set output format
Input/Output resolution: Up to
1920x1080P@60Hz
HDCP compliant

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
1
CONTENT
Product Introduction ...................................................................................................................................2
Packing Configuration ..................................................................................................................................3
Hardware Orientation..................................................................................................................................4
Front Panel........................................................................................................................................................4
Back Panel.........................................................................................................................................................5
Bottom Panel and Dial Switch...........................................................................................................................6
Menu Operation ..........................................................................................................................................7
Using the MENU Button....................................................................................................................................7
Understanding the MENU Structure.................................................................................................................8
Using the MENU................................................................................................................................................9
System Connection .........................................................................................................................................11
Contact Information................................................................................................................................... 12

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
2
Product Introduction
MSP 227 converts any input of AV/YPbPr/VGA/DVI/HDMI to any output of AV/YPbPr/VGA/ DVI/HDMI.
Buttons on the front panel to setup and configure the MSP 227.
When no Menu on the screen, “Enter/Output” button works as Output to select output port, such as AV,
YPbPr, VGA, DVI or HDMI.
Dial Switch on the bottom to set output format (1080p, 720p, etc.).
Input/Output resolution: Up to 1920x1200/1920x1080/1600x1200.
HDCP compliant.
System Connection
RGBlink offers solutions to demanding
technical problems. Any application
questions, or required further
information, please contact with our
customer Support Engineers.
MSP 227 System Connection Diagram

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
3
Packing Configuration
AC Power Cord
Adapter
DVI-HDMI
Adapter
DVI-VGA
Adapter
DVI-YPbPr/AV
DVI 转HDMI 线
防静电袋

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
4
Hardware Orientation
Front Panel
Button Instruction
1
USB interface
5
Down button
2
AV/YPbPr/VGA/DVI/HDMI indicator
6
Left button
3
Menu button
7
Right button
4
Up button
8
Confirm button

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
5
Back Panel
Input Interface
1
DVI Input DVI-I port
Output Interface
2
DVI Output DVI-I port
Power Interface
3
Standard 12V/3A

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
6
Bottom Panel and Dial Switch
Dial Switch
Dial Switch
Used to set the output format. Please refer to the graph instruction on the bottom panel for
specific operation.
Bottom Panel

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
7
Menu Operation
Using the MENU Button
1. Connect one end of the DVI cable to the DVI output of MSP 227, and the other end to the DVI input of the
display, turn on the power for the display and MSP 227.
2. Push the “MENU”button and enter to the menu items.
3. Push the “UP”, “DOWN”, “LEFT”and “RIGHT”button to select the menus.
4. Push the “ENTER/OUTPUT”button to select the menu or settings.
5. Push the “MENU”button to return to the main menu.
6. All the menus and operations are shown on the display.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
8
Understanding the MENU Structure
The MENU structure is shown in the figure below:

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
9
Using the MENU
Push the [MENU] button in the default state, the display will show the main menus. There are 6 menu items in
the main menu. Push the [UP/DOWN] button to select the menu items, and push the [ENTER/OUTPUT] button
to confirm. The display will show the submenus as below:
Main Menu
Submenu
Picture Mode
Standard Mode
Default Contrast 50, Brightness 55, Color 50, Sharpness 0 and Tint 50 in standard
mode. No setup required.
Mild
Default Contrast 48, Brightness 48, Color 50, Sharpness 0 and Tint 50 in mild mode.
No setup required.
User
Default Color 50, Sharpness 0 and Tint 50 in user mode. User can set the Contrast
and Brightness.
Dynamic
Default Contrast 55, Brightness 48, Color 55, Sharpness 0 and Tint 50 in dynamic
mode. No setup required.
Color Temperature
Medium
Default Red 50, Green 50 and Blue 50 if select medium. No setup required.
Warm
Default Red 70, Green 38 and Blue 50 if select warm. No setup required.
User
User can set Red, Green and Blue if select user mode.
Cool
Default Red 50, Green 38 and Blue 70 if select Cool. No setup required.
Input
Auto (Default input), AV, YPbPr, VGA and HDMI can be selected.
Zoom Out
Level 1, default setting.
Level 2, Zoom out 2%.
Level 3, Zoom out 6%.
Level 4, Zoom out 10%.
*: Only available when AV output.
Note: MSP 227 V1.0 can not support this function.
Screen
Auto Adjust
Enable or disable the auto adjust function.
Auto Adjust
Auto adjust is available if select “On” for auto adjust option.
Horizontal Pos.
Push the [UP/DOWN] button to increase or decrease the horizontal position value.
