RGBlink CP 3096H User manual

CP 3096H Quick Start
VIEWSIZE THE WORLD
Mixer
Preview and Program outputs separately
Three replacable optional input modules
T-BAR for seamless switching speed control
User define output resolution
DSK for subtitle overlay
Audio and video sync
EDID management

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
1
CONTENT
Product Introduction...............................................................................................................................2
Packing Configuration............................................................................................................................3
Hardware Orientation..............................................................................................................................4
Front Panel.........................................................................................................................................4
Back Panel .......................................................................................................................................10
Operating Instruction............................................................................................................................11
Content.............................................................................................................................................11
How to Change the Transition Effects ......................................................................................12
How to Do Customized Output Resolution...............................................................................12
How to Realize Single Image Switching...................................................................................13
How to Scale the Image............................................................................................................13
How to Crop the Image.............................................................................................................13
How to Set the Position of Image .............................................................................................14
How to Set up the PIP...............................................................................................................14
How to Use Black Out...............................................................................................................15
How to Realize the Screen Size and Full Size Switching.........................................................15
How to Realize the Text Overlay Setting ..................................................................................16
How to Save the Parameter......................................................................................................16
How to Load the Saved Parameter...........................................................................................16
Contact Information...............................................................................................................................17

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
2
Product Introduction
The CP 3096H is a mixer that supports analog and digital video graphics to be mixing together and
switch to the outputs. The operator can check the input separately by its Preview output, before taking
the dedicated input to the Program output. CP 3096H supports fully seamless switcher function based
on this application.
The CP 3096H standard version comes with inputs including CVBS (Composite), VGA, DVI, HDMI
and USB (for media files play out), and standard outputs come with 1 DVI for Preview, 2 DVI and 1
VGA (by DVI2 output connector) for Program. CP 3096H supports three replaceable optional input
modules and one optional SDI and CVBS output module. The three optional input modules are
available as SD/HD/3G SDI, HDMI, DVI, VGA, USB, CVBS based on requirement.
With its 10 bit gray scale processor built in, CP 3096H supports professional any in any out
conversion. It provides seamless switching between the demanding inputs with its flexiable control
panel and T-BAR switching. The operation can control the transition speed manually with the T-BAR.
CP 3096H supports the advance functions such as PIP, DSK, KEY and audio switching.
System Connection
RGBlink offers solutions to
demanding technical problems.
Any application questions, or
required further information,
please contact with our
customer Support Engineers.
CP 3096H System Connection Diagram

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
3
Packing Configuration
Note: SDI cable is only for SDI optional module.
Chinese Standard,American Standard or European Standard power cord is option.
Power Cord
USB Cable
SDI Cable
RCA to BNC
Cable
DVI 转HDMI 线
Quick Start
防静电袋
Certification
DVI to HDMI
Cable
DVI-D Cable

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
4
Hardware Orientation
Front Panel
Panel Instruction
1
Indicator area
6
Input sources area
2
OLED panel and menu area
7
Effects operation area
3
Audio sources area
8
Lock top panel area
4
Function area
9
Transition time control area
5
Volume control area
10
Effects switch control area

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
5
1. Indicator Area
2. OLED Panel and Menu Area
3. Audio Sources Area
Button Instruction
LINK
Multiple cascade indicator
DVI
DVI output indicator
CVBS
CVBS output indicator
SD
SD output format indicator
SDI
SDI output indicator
HD
HD output format indicator
VGA
VGA output indicator
RGB
RGB output format indicator
Button Instruction
OLED Panel
Show operation menu items
MENU
Menu button
Knob
Confirm and adjust OLED menu
ENTER
Confirm button

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
6
4. Function Area
Button Instruction
USB1
USB1 external, corresponds to AUDIO1,AUDIO2 orAUDIO3, system default
corresponds to AUDIO1.
HDMI2
System default HDMI2 as internal, if set HDMI as external, it corresponds to AUDIO1,
AUDIO2 or AUDIO3.
DVI3
DVI3 external, corresponds to AUDIO1,AUDIO2 or AUDIO3, system default
corresponds to AUDIO1.
VGA4
VGA4 external, corresponds to AUDIO1,AUDIO2 orAUDIO3, system default
corresponds to AUDIO1.
CVBS5
CVBS5 external, corresponds to AUDIO1,AUDIO2 or AUDIO3, system default
corresponds to AUDIO1.
MODULE6/
MODULE7/
MODULE8
SDI, HDMI and DVI optional module.
System default SDI as internal, if set SDI as external, it corresponds toAUDIO1,
AUDIO2 or AUDIO3.
System default HDMI as internal, if set HDMI as external, it corresponds to AUDIO1,
AUDIO2 or AUDIO3.
DVI external, corresponds to AUDIO1, AUDIO2 or AUDIO3, system default
corresponds to AUDIO1.
Button Instruction
LINK
Multiple cascade button
POSITION
Position adjustment button
LOAD
Load button
CROP
Crop button
SAVE
Save button
PAGE
Total 2 pages, use for save and load
FORMAT
Output formats button
BANK
Total 6 banks, use for save and load
BRIGHTNESS
Brightness adjustment button
1~6
Number button, use for save and load
SCALE
Scale button

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
7
5. Volume Control Area
6. Input Sources Area
Button Instruction
USB
USB signal source button
MODULE
SDI/HDMI/DVI optional module
HDMI
HDMI signal source button
BLACK
Black button
DVI
DVI signal source button
TP
Test Pattern button
VGA
VGA signal source button
1~9
Number button, use for scale, crop and
position adjustment
CVBS
CVBS signal source button

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
8
7. Effects Operation Area
8. Lock Top Panel Area
Button Instruction
PIP
Single and double image switch button
KEY
Alpha adjustment button
DSK
DSK effect button
1~5
PIP layouts shortcut button
Button Instruction
LOCK
Lock top panel

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
9
9. Transition Time Control Area
10. Effects Switch Control Area
Button Instruction
OLED Panel
Show transition time
Knob
Adjust transition time
Button Instruction
TAKE
Effects switch button
Effects mode
T-bar
Switch effects mode manually

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
10
Back Panel
Other Interface
1
Dial Switch
2
USB Interface
3. 4
RS-232 Interface
13
Switch
19
Power IEC-3
Input Interface
5~10
Audio input port
14
USB input USB-B port
15
HDMI input HDMI-A port
16
DVI input DVI-I port
17
VGA input DSUB15 port
18
CVBS input BNC port
19~21
S.H.D.U.V.C optional module
Output Interface
11. 12
Audio output port
22
DVI preview output DVI-I port
23
DVI output DVI-I port
24
DVI+VGA output DVI-I port
25. 26
3G-SDI output BNC port
27. 28
CVBS output BNC port

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
11
Operating Instruction
Content
How to Change the Transition Effects
How to Do Customized Output Resolution
How to Realize Single Image Switching
How to Scale the Image
How to Crop the Image
How to Set the Position of Image
How to Set up the PIP
How to Use Black Out
How to Realize Screen Size and Full Size Switching
How to Realize the Text Overlay Setting
How to Save the Parameter
How to Load the Saved Parameter

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
12
How to Change the Transition Effects
1. Push the Effect Modes button in Effects Switch Control Area, there are 6 kinds of effect modes:
POP CENTER:
PUSH CENTER:
PUSH LEFT:
POP LEFT:
POP L+T:
FADE:
2. Push the [TAKE] button, or use T-bar switcher to switch between the images with effects.
How to Do Customized Output Resolution
1. Push the [FORMAT] button in function area to enter the output formats menu.
2. Turn the knob and choose <CUSTOM>, push the knob for resolution setting.
3.Turn knob on each bit position, and change the value of the bit by the digital buttons on the front
panel.
4. After the digital, push the Knob will add ×, means before the ×is the horizontal size. Same operation
for vertical size.
5. After the digital, push the Knob will add @, means before the @ is the vertical size, and after the @ is
the refresh rate. Only 50 0r digital 60 supports for the refresh rate. Use the digital buttons to finish the
settings.
6. After input all the values, push knob to enable CP 3096H to output this resolution. CP 3096H will take
5 to 10 seconds to enable this output resolution.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
13
How to Realize Single Image Switching
CP 3096H can realize seamless effects switch between two channels, choose the signal in PREVIEW
area, then push the [TAKE] button, the signal will be switched to LED display.
For example, switch VGA to LED display, first push the [VGA] button in PREVIEW area, then push the
[TAKE] button or T-bar in effects switch control area, the LED display will show VGA signal.
System default the switch time is 1 seconds for [TAKE] button, if need to adjust the fade time, turn the
knob in transition time control area, and set according to actual need, push the [TAKE] button again, the
signal will be switched to the LED display with the adjusted time.
User can also switch the signal by pushing the signal button in PROGRAM area, but the signal in
monitor will not change.
How to Scale the Image
1. Push the [SCALE] button in function area and enter to the scale function menus.
2. Turn the knob, choose H SIZE or V SIZE and set according to actual need, user can adjust the items
by knob or number buttons, after setting, push the knob to confirm.
3. If image quality distorts by improper operation, it can be recover by reset.
How to Crop the Image
1. Push the [CROP] button in function area and enter to the crop function menus.
2. Turn the knob, choose H SIZE, V SIZE, H POS or V POS, and set according to actual need, user
can adjust the items by knob or number buttons, after setting, push the knob to confirm.
3. If image quality distorts by improper operation, it can be recover by reset.
Note: The setting is only for the selected input signal.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
14
How to Set the Position of Image
1. Push the [POSITION] button in function area and enter to the position adjustment function menus.
2. Turn the knob, choose H POS or V POS, and set according to actual need, user can adjust the
items by knob or number buttons, after setting, push the knob to confirm.
3. If image quality distorts by improper operation, it can be recover by reset.
How to Set up the PIP
Push the [PIP] button in Effects Operation Area, and enter to the PIP function menu. Choose the <PIP>
option, turn the knob, and choose ON to enable the PIP function.
LAYOUT: There are 7 kinds of PIP layouts, PIP L+T, PIP R+T, PIP L+B, PIP R+B, PIP CENT, PBP L+R
and PBP T+B. Take 3 results for example, shown as follows:
PIP L+T PBP L+R PBP T+B
SWAP IMAGE: It can set PIP to swap exchange, when choose ON, it can realize the main and
sub-picture exchange.
SELECT: Can choose to set the size or position of IMAGEA or IMAGE B individually.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
15
How to Use Black Out
Black out descriptions:
Black signal realizes one-key-touch to a black screen.
CP 3096H provides black effect processing for program output with fade in fade out effect.
Push the [BLACK/9] button, then output turns to black with fade in fade out effect.As shown below:
How to Realize the Screen Size and Full Size Switching
1. Push the [MENU] button, turn the knob, choose <OUTPUT>, and enter to the menu items, then
choose <SCREEN>.
2. Set the size and position of the screen according to actual need.
3. When screen setup is completed, choose <SCREEN SIZE> or <FULL SIZE> in <MODE> option,
and realize the screen size and full size switching.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
16
How to Realize the Text Overlay Setting
1. Push the [DSK] button in Effect Operation Area, rotate the knob, choose preset modes, there are 6
kinds of preset modes:
MODE 1: Black background, white/red/green font, the ALPHA of background is adjustable.
MODE 2: Black background, white/red/green font, the font of background is adjustable.
MODE 3: White background, black font, theALPHA of background is adjustable.
MODE 4: White background, black font, theALPHA of font is adjustable.
MODE 5: White background, red/green font, the ALPHA of background is adjustable.
MODE 6: White background, red/green font, theALPHA of font is adjustable.
2. Rotate the KEY LEVELknob to set ALPHA, the adjustment range is 0 to 16.
How to Save the Parameter
There are two pages and each page has 6 save modes, CP 3096H provides 12 save modes.
1. Push the [SAVE] button, the button light turns on, and PAGE, 1 and 2 button light flash.
2. Set [PAGE], choose 1 or 2.
3. Set [BANK], light of button BANK flashes, and button 1 to 6 are on or flash, the button on can be
saved and flash will be overwrite, push the button on to save.
How to Load the Saved Parameter
There are two pages and each page has 6 save modes, CP 3096H provides 12 save modes for load.
1. Push the [LOAD] button, the button light turns on, and PAGE, 1 and 2 button light flash.
2. Set [PAGE], choose 1 or 2.
3. Set [BANK], light of button BANK flashes, and button 1 to 6 are on or flash, the button on is ready for
recall and flash means just recall, push the button on to recall.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: [phone] Fax:[phone]
Email: [email protected] http://www.rgblink.cn
17
Contact Information
Warranty:
All video products are designed and tested to the highest quality standard and backed by
a full 3-year parts and labor warranty. Warranties are effective upon delivery date to
customer and are non-transferable. RGBlink warranties are only valid to the original
purchase/owner. Warranty related repairs include parts and labor, but do not include
faults resulting from user negligence, special modification, lighting strikes,
abuse(drop/crush), and/or other unusual damages.
The customer shall pay shipping charges when unit is returned for repair.
Headquarter: S603~604 Weiye Building Torch Hi-Tech Industrial Development Zone
Xiamen, Fujian Province, P.R.C
●Tel: [phone]
●Fax: [phone]
●Customer Hotline：[phone]
●Web:
~ http://www.rgblink.com
~ http://www.rgblink.cn
●E-mail: [e-mail]
