RGBlink Mini User manual

● USB capture video complying with UVC for live streaming
● 4CH HDMI inputs
● 2’’TFT display on board to Live preview four input
● Auto cut and manual switch (T-Bar)
● 14 transition effects on T-Bar
● Support PIP
● Audio offers embeded or external source to select
● Support switch between 6-Picture PVW and PGM to HDMI
Out
● Licensed features including DSK, PTZ control etc.
● Control by PC or mobile phone (via APP)
● Compact design
mini
Quick Start

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
1 / 28
CONTENTS
Product Introduction...................................................................................................................................................2
Packing Configuration................................................................................................................................................. 3
Hardware Orientation................................................................................................................................................. 4
Front Panel.......................................................................................................................................................... 4
Interface Panel.....................................................................................................................................................5
Use Your Product......................................................................................................................................................... 6
MENU.................................................................................................................................................................. 6
Input............................................................................................................................................................ 6
HDMI........................................................................................................................................................... 7
USB3.0......................................................................................................................................................... 7
Audio........................................................................................................................................................... 7
IP Setting......................................................................................................................................................8
LANGUAGE.................................................................................................................................................. 8
Factory Reset...............................................................................................................................................8
INFO.............................................................................................................................................................9
Button S...............................................................................................................................................................9
PIP..............................................................................................................................................................10
FX............................................................................................................................................................... 10
Switch Input Source...........................................................................................................................................10
PIP (Picture-In-Picture or Picute by Picture) Operation................................................................................... 10
Software Operation........................................................................................................................................... 11
OBS Streaming..................................................................................................................................................19
OBS Setting...............................................................................................................................................19
Streaming Setting.............................................................................................................................................. 21
Upgrade............................................................................................................................................................. 22
Contact Information.................................................................................................................................................. 27

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
2 / 28
Product Introduction
mini is a “mini” singal switcher and mixer which is able stream 6-picture PVW or PGM from any
one out of the 4 HDMI inputs to any live broadcasting platform via third party live streaming
software such as OBS. It adopt compact design, equiped with a 2 inch TFT sreen to preview the 4
inputs in real time. 14 transition effects on board to collaborate with T-Bar to do transition
switching. Along with feature of seamless switch, there are other outstanding features such as
audio embeding, deblocking, and automatically indentifying color depeth of RGB4:4:4, YUV4:4:4,
YUV4:22,YUV4:2:0. Licensed features including DSK, logo, PTZ carmera control will be available
at additonal cost. It is also esay to operate either on board or on dedicated app on PC.
System Connection Diagram
mini System Connection Diagram

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
3 / 28
Packing Configuration
Note:
Power adapter supplied as standard according to destination market. There are CN,US,GB,EU,AU
standard availble to choose.
Power Adapter
USB3.0 Cable

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
4 / 28
Hardware Orientation
Front Panel
TFT display
To display 4 inputs and menu
PUSH
Knob, turn to select menu item, push to comfirm
Work as a quick button to switch HDMI Out between
6-Picture PVW and PGM when TFT is under the state
of previewing 4 inputs
M( menu)
Menu and Back Button
S
Function Select button, to select Transition effect,
Switch Mode (Fast or T-Bar), PIP and FX (reserved
licensed feature for future)
VOLUME
Turn to adjust volume of PGM
1,2,3,4
4 inputs, red is on air (PGM), static green is signal
standing by to switch, flash green is the ready to be
switched
T-Bar
Manual switch, push to left end or right end to switch
signal to PGM.

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
5 / 28
Interface Panel
HDMI OUT
1 HDMI Output port, connect to display to show Preview
(6 pictures) or PGM.
HDMI IN
4 HDMI Inputs, connect to input source from HD camera
or PC
DC 12V
1 DC Jack for power input, connect to 12V/4A power
adapter.
LAN
Communication port to link dedicated software for
control
USB
USB3.0 output, capture singal via third party streaming
software and push to live broadcasting websites
AUDIO IN/OUT
AUDIO In, anolog audio input port, connect to
microphone
AUDIO OUT, analog audio output port, connect to
loudspeaker.

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
6 / 28
Use Your Product
MENU
Main Menu
Input
When mini is power on, the native TFT
display show starting up page.
Push MENU and select the first menu item
<Input>
Push knob to enter <Input> menu

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
7 / 28
HDMI
USB3.0
Audio
Push MENU and select the second menu item
<HDMI>
Push knob to enter <HDMI> menu
HDMI means HDMI output, select Preview
output and PGM output for HDMI.
Output：Preview or PGM
Format：1920×1080@60
Push MENU and select the third menu
item<USB3.0>
USB3.0 means USB3.0 output，push knob to enter
<USB3.0>menu，select Preview output and PGM
output for HDMI.
Output：Choose PGM or Preview
Format：1920×1080@60
Choose <AUDIO>
SOURCE：EMBEDED or EXTREANAL
AUDIO BAR：ON/OFF

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
8 / 28
IP Setting
LANGUAGE
Factory Reset
LANGUGE, select Chinese or English
Factory Reset: Yes or No
Manually set IP address

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
9 / 28
INFO
Button S
Push button S, the TFT will show the transition effect menu <MIX>.The <MIX> led indicator beside
will light up. Push again, it will skip to next menu MODE, and again to PIP and again back to MIX
unless the device got license, it will skip to FX (Additonal features). The led indicators beside light
up meaning the corresponding feature menu is open. Use knob to select and confirm the desired
items after it enters the menu.
MIX
MODE
INFO:show the SN, IP,
MAC,MCU vesion and
VIDEO version.
Push button S once to open up the transition
effect menu, Use knob to select the desired
transition effect icon and push the knob to
confirm.
Push the button S twice to open up MODE menu.
MODE:FAST or T-Bar
TIME:0.5~5.0S
Choose FAST, the switching will be with transition
effect in set time.
Choose T-Bar, the switching will be with selected
transiton effect by pushing T-Bar

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
10 / 28
PIP
FX
FX is advanced features asking for license at additonal cost and reserved features of DSK, logo and
PTZ camera control.
Switch Input Source
After selecting transition effect and switch mode
1.Under Fast+Time mode, pushing green button will switch the input source in the selected time
with set transition effect. After switching , green turns to red.
2.Under T-Bar mode, pusing green button, it will flash and push T-bar to the end (left or right), the
source will be switched with selected transition effect. After switching , green turns to red.
Note: when T-Bar is not in the end position, no source can be selected.
PIP (Picture-In-Picture or Picute by Picture) Operation
1. Decide which source to be the main picture, select and switch it to PGM when PIP is OFF
2. Select the PIP layout mode in PIP menu
3. Select the input source and switch it to sub-picture on PGM
Push Button S three time to open PIP menu.
PIP menu offers 8layouts for main picture and sub
picture.

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
11 / 28
4. After swithcing, the selected green button turns to red.
after PIP mode is selected, the main pictute can not be changed unless go back to choose
PIP OFF and restart the above steps.
Software Operation
After software is installed, click the
icon and login the software.
After searching, all available mini
devices in the subnet can be found, up
to 128 devices can found if there are.
Click Search to search mini
device.

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
12 / 28
Select the desired device by SN and IP
and enter the management interface.
The software interface is a simulation
of opeation panel on real mini device.
For example, clicking Button M
can open up menu as on the device.
INPUT INFO
HDMI Output

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
13 / 28
USB3.0 Output

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
14 / 28
<MIX>
Choose switch time and transition
effect.

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
15 / 28
Streaming
Capture Device:choose RGBlink USB3.0
Capture
OBS:Slide On
AUDIO
<PIP>
Choose layout mode for
PIP

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
16 / 28
TEST PATTERN
HDMI Output Setting

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
17 / 28
IP Setting
Manaully set Gateway, MASK and IP for the device.
Password Protection
Set password for the device. After password is
set, password will be required when enter the
software operation interface.
\

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
18 / 28
VERSION
Factory Reset
T-Bar Calibration

© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: [phone] |[email protected] |www.rgblink.com
19 / 28
1.Click”+”icon
2.choose video capture device
3.Click video capture device to
open up setting page
4.Choose :RGBlink USB 3.0
Capture
5.Choose Video Format YUY2
If there is no video format
YUY 2 after setting above, check
the USB 3.0port connection. Make
sure it is linked to USB 3.0port on
PC by USB 3.0 cable. (USB 3.0
cable or port is standard in blue
while USB 2.0 is in black)
OBS Streaming
OBS Setting
mini is compatible with many third party steaming softwares, we recommend OBS, which is available to
download on https://obsproject.com/download.Download the software and update to the latest
version.
If the captured video is showing mosaic, change the video format to YUY2.
Audio Setting
When there is no audio playing first check the video source see if the it is set in default value and
then check the audio setting on OBS.
