RHINO FM60/72 User manual

FM60/72
Side & Rear Discharge
60" & 72" Rotary Mowers
Published08/01 Effective S/N FM60-12900 to Currrent Part No. 00761717C
FM72-13900 to Current
OPERATOR'S MANUAL
This Operator's Manual is an integral part of the safe operation
of this machine and must be maintained with the unit at all
times. READ, UNDERSTAND, and FOLLOW the Safety and
Operation Instructions contained in this manual before
operating the equipment.
© 2004Alamo Group Inc.
RHINO®
1020S. SangamonAve.
GibsonCity,IL60936
800-446-5158
Email:[email protected] $0.00

All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded
operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has
designed this implement to be used with all its safety equipment properly attached to minimize the chance of
accidents.
BEFORE YOU START!! Read the safety messages on the implement and shown in your manual.
Observe the rules of safety and common sense!
TO THE OWNER/OPERATOR/DEALER
WARRANTY INFORMATION:
Read and understand the complete Warranty Statement found in this Manual. Fill out the Warranty Registration Form in full and return it
within 30 Days. Make certain the Serial Number of the Machine is recorded on the Warranty Card and on the Warranty Form that you retain.
The use of "will-fit" parts will void your warranty and can cause catastrophic failure with possible injury or death.

In order to reduce accidents and enhance the safe operation of mowers, Alamo Group Ag Division, in
cooperationwithotherindustrymanufacturershasdevelopedtheAEM/FEMAIndustrialandAgricultural
MowerSafety Practices videoand guide book.
Thevideowillfamiliarizeandinstructmower-tractoroperatorsinsafepracticeswhenusing industrialand
agriculturalmowingequipment. ItisimportantthatEveryMowerOperatorbeeducatedintheoperationof
theirmowing equipmentand be ableto recognizethe potential hazardsthat canoccur whileoperating a
mower. Thisvideo,along withthemoweroperator’smanual andthewarningmessagesonthemower,will
significantlyassistinthisimportanteducation.
YourAuthorizedAlamoAgDealermay have shown thisvideo and presented youa DVDVideowhenyou
purchasedyour mower. If youor any moweroperator have notseenthis video,WatchtheVideo,Read
thisOperator’sManual, andCompletetheVideoGuidebookbeforeoperatingyournewmower.Ifyou
do not understand any of the instructions included in the video or operator’s manual or if you have any
questionsconcerning safety ofoperation, contact yoursupervisor, dealerorAlamo GroupAg.
Ifyou wouldlikeaVHSvideotapeofthevideo,pleaseemailAEMV[email protected]orFaxAEM
VHSVideo at(830) 372-9529or mailin acompleted copyof theform on the back ofthis pagetoAEM
VHSVideo1502 EWalnutStreet,Seguin,TX78155.andrequest theVHS videoversion. Please include
yourname,mailingaddress,mowermodeland serial number.
Everyoperatorshouldbetrainedforeachpieceofequipment(TractorandMower),understandtheintended
use,andthepotential hazards beforeoperating theequipment.
Safety Training
MakestheDifference


BE SAFE!


BEALERT!
 
 
 BE ALIVE!


BE TRAINED
beforeoperating
theMower!

Alamo Group Ag. Division is willing to provide
one (1) AEM Mower Safety Practices Video
Please Send Me: VHS Format – AEM/FEMA Mower Operator Safety Video
DVD Format – AEM/FEMA Mower Operator Safety Video
Mower Operator’s Manual
AEM Mower Operator’s Safety Manual
RequesterName: Phone:
RequesterAddress:
City
State
Zip Code
MowerModel: SerialNumber:
Date Purchased: DealerSalesperson:
DealershipName: DealershipLocation:
Mailto: AEM Video Services
1502 E Walnut street
Seguin, TX 78155
Or Fax to: [phone]
OrEmail to: AEMV[email protected]

TABLE OF CONTENTS
SAFETYSECTION ......................................................................................................................................... 1-1
Safety Information ..........................................................................................................................................1-2
DecalLocation .............................................................................................................................................. 1-11
SafetyDecals ............................................................................................................................................... 1-12
Federal Laws & Regulations ................................................................................................................1-15
INTRODUCTIONSECTION ............................................................................................................................ 2-1
ASSEMBLY SECTION ..................................................................................................................................3-1
A-Frame Attachment ......................................................................................................................................3-2
Caster Wheel Attachments ............................................................................................................................3-3
Discharge Chute Installation ..........................................................................................................................3-4
Driveline Attachment ......................................................................................................................................3-4
OPERATION SECTION .................................................................................................................................4-1
Tractor Preparation ........................................................................................................................................4-2
Attaching Mower to Tractor ............................................................................................................................4-2
Driveline Attachment to Tractor......................................................................................................................4-3
Cutting Height Adjustment .............................................................................................................................4-3
Starting & Stopping Cutter..............................................................................................................................4-3
Cutting Speed.................................................................................................................................................4-4
Cutting Tips ....................................................................................................................................................4-4
DetachingandStoring..................................................................................................................................... 4-5
DrivelineLengthCheckProcedure .................................................................................................................. 4-5
FrontGaugeWheelInterferenceCheck .......................................................................................................... 4-6
Troubleshooting .............................................................................................................................................. 4-7
MAINTENANCE SECTION ............................................................................................................................5-1
Lubrication Information...................................................................................................................................5-2
Gearbox .........................................................................................................................................................5-3
Gauge Wheel Assemblies..............................................................................................................................5-3
DrivelineLubrication.......................................................................................................................................5-4
Blade Spindle Lubrication...............................................................................................................................5-4
Blade Servicing ..............................................................................................................................................5-5
BladeSharpening...........................................................................................................................................5-5
Blade Removal and Installation......................................................................................................................5-5
Belt Adjustment Procedure ............................................................................................................................5-6
BeltRemoval/Installation................................................................................................................................. 5-6
Storage ........................................................................................................................................................... 5-7
TorqueSettings .............................................................................................................................................. 5-7
BladeSpindleServiceInstructions.................................................................................................................. 5-8

SAFETY
SECTION
Safety Section 1-1

Safety Section 1-2
SAFETY
FM6072 08/01
© 2004 Alamo Group Inc.
Asafe andcarefuloperatoristhebestoperator. Safetyisofprimary importancetothemanufac-
turer and should be to the owner/operator. Most accidents can be avoided by being aware of
yourequipment,your surroundings, andobservingcertain precautions. The firstsectionof this
manual includes a list of Safety Messages that, if followed, will help protect the operator and
bystandersfrominjury or death. Readandunderstand these SafetyMessagesbefore assem-
bling,operating or servicingthis implement. This equipmentshould onlybe operated bythose
personswho have readthe Manual, whoare responsibleand trained, andwho know howto do
sosafelyand responsibly.
TheSafety Alert Symbol combined with a SignalWord, as seen below, isused throughout this
manual and on decals which are attached to the equipment. The Safety Alert Symbol means:
“ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!” The Symbol and Signal
Wordareintendedtowarntheowner/operatorofimpendinghazardsandthedegreeofpossible
injuryfacedwhenoperatingthisequipment..
CAUTION! ThelowestlevelofSafetyMessage;warnsofpossibleinjury. Decals
located on the Equipment with this Signal Word are Black and Yellow.
WARNING! Serious injury or possible death! Decals are Black and Orange.
DANGER! Imminentdeath/criticalinjury. DecalsareRedandWhite.(SG-1)
Practice all usual and customary safe working precautions and
above all---remember safety is up to YOU. Only YOU can prevent
serious injury or death from unsafe practices.
READ, UNDERSTAND, and FOLLOW the following Safety
Messages. Serious injury or death may occur unless care is
taken to follow the warnings and instructions stated in the Safety
Messages. Always use good common sense to avoid hazards.
(SG-2)

FM6072 08/01 Safety Section 1-3
SAFETY
© 2004 Alamo Group Inc.
Si no lee Ingles, pida ayuda a alguien que
si lo lea para que le traduzca las medidas
de seguridad. (SG-3)
PELIGRO! ¡LEAEL
INSTRUCTIVO!
DANGER! Never operate the Tractor or Implement until you have read and
completelyunderstandthisManual,theTractorOperator’s Manual,
andeachoftheSafetyMessagesfoundintheManualorontheTractor
andImplement. Learn how tostopthetractorenginesuddenly in an
emergency. Never allow inexperienced or untrained personnel too
operatetheTractorandImplementwithoutsupervision. Make sure
the operator has fully read and understood the manuals prior to
operation. (SG-4)
WARNING! Make certain that the “Slow Moving Vehicle” (SMV) sign is installed in
such a way as to be clearly visible and legible. When transporting the
EquipmentusetheTractorflashingwarninglightsandfollowalllocaltraffic
regulations.(SG-6)
WARNING! Operate this Equipment only with a Tractor equipped with an
approved roll-over-protective system (ROPS). Always wear seat
belts. Serious injury or even death could result from falling off the
tractor--particularly during a turnover when the operator could be
pinned under the ROPS. (SG-7)
WARNING! DonotmodifyoralterthisImplement. DonotpermitanyonetomodifyoralterthisImplement,
any of its components or any Implement function. (SG-8)
DANGER! BEFOREleavingthetractorseat,alwaysengagethebrakeand/orset
thetractor transmission in parkinggear,disengagethePTO,stopthe
engine,removethekey,andwaitforallmovingpartstostop. Placethe
tractorshiftleverintoalowrangeorparkinggeartopreventthetractor
fromrolling. NeverdismountaTractorthatismovingorwhiletheengine
is running. Operate the Tractor controls from the tractor seat only.
(SG-9)
WARNING! Alwaysmaintain the safetydecalsin good readablecondition. Ifthe decals are missing,damaged,
orunreadable,obtain andinstallreplacement decalsimmediately. (SG-5)

Safety Section 1-4
SAFETY
FM6072 08/01
© 2004 Alamo Group Inc.
DANGER! NeverallowchildrenorotherpersonstorideontheTractororImplement.
Falling off can result in serious injury or death. (SG-10)
DANGER! Neverallowchildrento operate or rideon theTractor or Implement.
(SGM-11)
WARNING! Do not mount the Tractor while the tractor is
moving. Mount the Tractor only when the
Tractor and all moving parts are completely
stopped.
(SG-12)
DANGER! Start tractor only when properly seated in the Tractor seat. Starting a
tractoringear can result ininjuryordeath. Read the Tractor operators
manual for proper starting instructions. (SG-13)
DANGER! NeverworkundertheImplement,theframework,or
any lifted component unless the Implement is
securelysupportedorblockeduptopreventsudden
or inadvertent falling which could cause serious
injury or even death. (SG-14)
WARNING! The operator and all support personnel should wear hard hats,
safety shoes, safety glasses, and proper hearing protection at all
timesforprotectionfrominjuryincludinginjuryfromitemsthrownby
the equipment. (SG-16)
DANGER! Do not operate this Equipment with hydraulic oil
leaking. Oilisexpensiveanditspresencecouldpresentahazard. Do
not check for leaks with your hand! Use a piece of heavy paper or
cardboard. High-pressure oil streams from breaks in the line could
penetratetheskinandcausetissuedamageincludinggangrene. Ifoil
does penetrate the skin, have the injury treated immediately by a
physician knowledgeable and skilled in this procedure. (SG-15)
CAUTION! PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE PER-
MANENT HEARING LOSS! Tractors with or without an Implement
attached can often be noisy enough to cause permanent hearing
loss. We recommend that you always wear hearing protection if the
noise in the Operator’s position exceeds 80db. Noise over 85db
over an extended period of time will cause severe hearing loss.
Noiseover90db adjacent to theOperatoroveran extended period of
time will cause permanent or total hearing loss. Note: Hearing loss
from loud noise [from tractors, chain saws, radios, and other such
sources close to the ear] is cumulative over a lifetime without hope
of natural recovery. (SG-I7)

FM6072 08/01 Safety Section 1-5
SAFETY
© 2004 Alamo Group Inc.
WARNING! Transportonlyat safe speeds. Serious accidents andinjuries canresult
fromoperatingthisequipmentatunsafespeeds. Understand the Tractor
and Implement and how it handles before transporting on streets and
highways. MakesuretheTractorsteeringand brakes are in good condi-
tionandoperateproperly.
Beforetransportingthe Tractor and Implement, determinethe safe
transportspeeds for you andtheequipment. Make sure you abide by
thefollowingrules:
Beaware of the operating conditions. DonotoperatetheTractorwithweakor faulty brakes. Whenoperatingdown
a hill or on wet or rain slick roads, the braking distance increases: use extreme care and reduce your speed.
When operating in traffic always use the Tractor’s flashing warning lights and reduce your speed. Be aware of
traffic around you andwatch out for the other guy. (SG-19)
Test the equipment at a slow speed in turns. Increase the speed
through the turn only after you determine that it is safe to operate
at a higher speed. Use extreme care and reduce your speed when
turning sharply to prevent the tractor and implement from turning
over. Determine the maximum safe turning speed for you and this
equipmentbefore operating on roads orunevenground.
Only transport the Tractor and Implement at the speeds that you
have determined are safe and which allow you to properly control the
equipment.
Test the tractor at a slow speed and increase the speed slowly.
Apply the Brakes smoothly to determine the stopping
characteristicsof the Tractor andImplement.
As you increase the speed of the Tractor the stopping distance
increases. Determine the maximum safe transport speed for
you and this Equipment.
2.
1.
3.
WARNING! Never attempt to lubricate, adjust, or remove material from the
Implementwhileitisinmotionorwhiletractorengineisrunning. Make
sure the tractor engine is off before working on the Implement.
(SG-20)
WARNING! Periodically inspect all moving parts for wear and replace when
necessary with authorized service parts. Look for loose fasteners,
worn or broken parts, and leaky or loose fittings. Make sure all pins
have cotter pins and washers. Serious injury may occur from not
maintaining this machine in good working order. (SG-21)
WARNING! Always read carefully and comply fully with the manufacturers instruc-
tions when handling oil, solvents, cleansers, and any other chemical
agent. (SG-22)
DANGER! Never run the tractor engine in a closed building or without adequate
ventilation. The exhaust fumes can be hazardous to your health.
(SG-23)

Safety Section 1-6
SAFETY
FM6072 08/01
© 2004 Alamo Group Inc.
DANGER! KEEPAWAYFROMROTATINGELEMENTStoprevententanglement
andpossible seriousinjury or death. (SG-24)
DANGER! Never allow children to play on or around Tractor or Implement. Children can slip or fall off the
Equipment and be injured or killed. Children can cause the Implement to shift or fall crushing
themselves or others. (SG-25)
WARNING! Do not exceed the rated PTO speed for the Implement. Excessive PTO speeds can cause
Implementdriveline or bladefailuresresulting in seriousinjury or death. (SG-26)
DANGER! NEVER use drugs or alcohol immediately before or while operating the
Tractor and Implement. Drugs and alcohol will affect an operator’s
alertness and coordination and therefore affect the operator’s ability to
operate the equipment safely. Before operating the Tractor or Imple-
ment,an operatoron prescription orover-the-counter medication must
consult a medical professional regarding any side effects of the medi-
cation that would hinder their ability to operate the Equipment safely.
NEVER knowingly allow anyone to operate this equipment when their
alertness or coordination is impaired. Serious injury or death to the
operator or others could result if the operator is under the influence of
drugs or alcohol. (SG-27)
WARNING! Mowonlyinconditionswhereyouhaveclearvisibilityindaylightorwithadequateartificiallighting.
Nevermowindarknessorfoggyconditionswhereyoucannotclearlyseeatleast100yardsinfront
andtothesidesofthetractorandmower. Makesurethatyoucanclearlyseeandidentifypassersby,
steepslopes,ditches,drop-offs,overheadobstructions,powerlines,debrisandforeignobjects. If
you are unable to clearly see this type of items discontinue mowing. (SGM-1)
DANGER! Thereareobviousandhiddenpotentialhazardsintheoperationofthis
Mower. REMEMBER! Thismachineisoftenoperatedinheavybrush
and in heavy weeds. The Blades of this Mower can throw objects if
shields are not properly installed and maintained. Serious injury or
evendeathmayoccurunlesscareistaken toinsurethe safetyofthe
operator, bystanders, or passersby in the area. Do not operate this
machinewithanyoneintheimmediate area. Stop mowing if anyone
is within 100 yards of mower. (SGM-2)
DANGER! OperatetheTractorand/orImplementcontrolsonlywhileproperlyseatedintheTractorseatwith
theseatbeltsecurelyfastenedaroundyou. InadvertentmovementoftheTractororImplementmay
cause serious injury or death. (SG-29)

FM6072 08/01 Safety Section 1-7
SAFETY
© 2004 Alamo Group Inc.
DANGER! AllSafetyShields,GuardsandSafetydevicesincluding
(butnotlimitedto)-theDeflectors,ChainGuards,Steel
Guards,GearboxShields,HydraulicTankShields,and
Retractable Door Shields should be used and main-
tained in good working condition. All safety devices
should be inspected carefully at least daily for missing
orbrokencomponents. Missing,broken,or wornitems
must be replaced at once to reduce the possibility of
injury or death from thrown objects, entanglement, or
blade contact. (SGM-3)
DANGER! Therotatingpartsofthismachinehavebeendesignedandtestedforruggeduse. However,
they could fail upon impact with heavy, solid objects such as steel guard rails and concrete
abutments. Such impact could cause the broken objects to be thrown outward at very high
velocities. Toreducethepossibilityofpropertydamage,seriousinjury,orevendeath,never
allow the cutting blades to contact such obstacles. (SGM-4)
WARNING! Manyvariedobjects,suchaswire,cable,rope,orchains,canbecomeentangledintheoperating
partsofthe mower head. These items could then swing outside thehousingatgreatervelocities
thantheblades. Suchasituationisextremelyhazardousandcouldresultinseriousinjuryoreven
death. Inspectthecuttingareaforsuchobjectsbeforemowing. Removeanylikeobjectfromthe
site. Never allow the cutting blades to contact such items. (SGM-6)
WARNING! Mow at the speed that you can safely operate and control the tractor and mower. Safe mowing
speeddependsonterrainconditionandgrasstype,density,andheightofcut. Normalgroundspeed
rangeisfrom0to5mph. Use slowmowingspeedswhenoperatingonornearsteepslopes,ditches,
drop-offs,overheadobstructions,powerlines,orwhendebrisandforeignobjectsaretobeavoided.
(SGM-7)
WARNING! Avoidmowinginreversedirectionwhenpossible. Checktomakesuretherearenopersonsare
behindthemoweranduseextremecarewhenmowinginreverse. Mowonlyataslowgroundspeed
whereyoucansafelyoperateandcontrolthetractorandmower. Nevermowanareainthereverse
directionthat you havenot inspected andremoveddebris or foreignmaterial. (SGM-8)
WARNING! Donot put handsorfeet under mowerdecks. BladeContact can result
serious injury or even death. (SGM-9)
WARNING! Extremecareshouldbetakenwhenoperatingnearlooseobjectssuch
as gravel, rocks, wire, and other debris. Inspect the area before
mowing. Foreignobjectsshouldberemovedfromthesitetoprevent
machinedamageand/orbodilyinjuryorevendeath. Anyobjectsthat
cannotberemovedmustbeclearlymarkedandcarefullyavoidedby
the operator. Stop mowing immediately if blades strike a foreign
object. Repair all damage and make certain rotor or blade carrier is
balancedbeforeresumingmowing. (SGM-5)

Safety Section 1-8
SAFETY
FM6072 08/01
© 2004 Alamo Group Inc.
DANGER! Replacebentorbrokenbladewithnewblades. NEVERATTEMPTTOSTRAIGHTENBLADES
SINCE THIS WILL LIKELY CRACK OR OTHERWISE DAMAGE THE BLADE WITH
SUBSEQUENT FAILURE AND POSSIBLE SERIOUS INJURY FROM THROWN BLADES.
(SGM-10)
DANGER! Always disconnect the main PTO Driveline from the Tractor before performing service on the
Mower. Never work on the Mower with the tractor PTO driveline connected and running. Blades or
Drivelines could turn without warning and cause immediate entanglement, injury or death. (SRM-3)
WARNING! Do not let the Blades turn when the Mower Deck is raised for any
reason, including clearance or for turning. Raising the Mower
deck exposes the Cutting Blades which creates a potentially
serious hazard and could cause serious injury or even death from
objects thrown from the Blades. (SRM-7)
WARNING! Never leave Tractor and Implemented unattended while the implement is in the lifted position.
Accidentaloperationofliftingleverorahydraulicfailure may cause sudden drop of unit with
injuryordeathbycrushing. Toproperly parktheimplementwhendisconnectingitfromthetractor,
lower the stand and put the retaining pin securely in place, or put a secure support under the A-
Frame. Lower the implement carefully to the ground. Do not put hands or feet under lifted
components. (S3PT-1)
WARNING! Be particularly careful when transporting the Implement with the Tractor. Turn curves or go up hills
only at a low speed and using a gradual steering angle. Rear mounted implements move the
center of gravity to the rear and remove weight from the front wheels. Make certain, by adding
front ballast, that at least 20% of the tractor’s weight is on the front wheels to prevent rearing up,
loss of steering control or Tractor tip-over. Slow down on rough or uneven surfaces to prevent
loss of steering control which could result in property damage or possible injury. Do not transport
unless 3-Point lift lever is fully raised and in the latched transport position. Dropping implement in
transport can cause serious damage to the tractor and/or Implement and possibly cause the
operator or others to be injured or killed. (S3PT-2)
DANGER! Make sure the PTO shield is installed when using PTO-driven equipment.
Always replace the PTO shield if it is damaged or missing. (S3PT-8)
WARNING! The rotating parts of this machine continue to rotate even after the PTO has been turned off. The
operator should remain in his seat for 60 seconds after the brake has been set, the PTO
disengaged, the tractor turned off, and all evidence of rotation has ceased. (S3PT-10)
“Wait a minute...Save a life!”
WARNING! DonotmowwithtwomachinesinthesameareaexceptwithCabtractorswiththewindowsclosed.
(SGM-11)
WARNING! Relieve hydraulic pressure prior to doing any maintenance or repair work
on the Implement. Place the Implement on the ground or securely
blocked up, disengage the PTO, and turn off the tractor engine. Push
and pull the Remote Cylinder lever in and out several times prior to
starting any maintenance or repair work. (S3PT-9)

FM6072 08/01 Safety Section 1-9
SAFETY
© 2004 Alamo Group Inc.
DANGER! Thereareobviousandhiddenpotentialhazardsintheoperationofthis
Mower. REMEMBER! Thismachineisoftenoperatedin weedsand
inheavygrass. TheBladesofthisMowercanthrowobjectsifshields
arenot properlyinstalledandmaintained. Seriousinjuryorevendeath
may occur unless care is taken to insure the safety of the operator,
bystanders, or passersby in the area. Do not operate this machine
with anyone in the immediate area. Stop mowing if anyone is within
100 yards of mower. (SFM-1)
DANGER! AllSafetyShields,GuardsandSafetydevicesincluding
(but not limited to) - the Discharge Deflectors, Steel
Guards,GearboxShields,BeltShileds,andPTOShields
should be used and maintained in good working condi-
tion. Allsafetydevicesshouldbeinspectedcarefullyat
leastdailyformissing or broken components. Missing,
broken, or worn items must be replaced at once to
reduce the possibility of injury or death from thrown
objects, entanglement, or blade contact. (SFM-2)
DANGER! RotaryMowersarecapable under adverse conditions
of throwing objects for great distances (100yardsor
more) and causing serious injury or death. Follow
safety messages carefully
-Mower Deck Shielding, and Discharge Deflector are installed
and in good, working condition;
-Mower section is running close to and parallel with the ground
without exposed Blades;
-Passersby are outside the existing thrown-object zone;
-All areas have been thoroughly inspected and all foreign material
such as rocks, cans, glass, andgeneral debris hasbeen removed.
NOTE: Where there are grass and weeds high enough to hide debris that could be struck
by the blades, the area should be: inspected and large debris removed, mowed at an
intermediate height, inspected closely with any remaining debris being removed, and
mowed again at desired final height. (This will also reduce power requiredto mow, reduce
wear and tear on the Mower drivetrain, spread cut material better, eliminate streaking, and
make the final cut more uniform.) (SFM-3)
STOP MOWINGIFPASSERSBYAREWITHIN100YARDS UNLESS:

Safety Section 1-10
SAFETY
FM6072 08/01
© 2004 Alamo Group Inc.
DANGER! Replacebentorbrokenbladewithnewblades. NEVERATTEMPTTOSTRAIGHTENORWELD
ON BLADES SINCE THIS WILL LIKELY CRACK OR OTHERWISE DAMAGE THE BLADE
WITHSUBSEQUENTFAILUREANDPOSSIBLESERIOUSINJURYFROMTHROWNBLADES.
(SGM-10)
PARTSINFORMATION
Servis-Rhinomowersusebalancedandmatchedsystemcomponentsforbladecarriers,blades,cuttershafts,
knives,knifehangers,rollers,drivetraincomponents,andbearings. ThesepartsaremadeandtestedtoServis-
Rhino specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of
“will fit” parts may reduce mower performance, void mower warranties, and present a safety hazard. Use
genuine Servis-Rhino mower parts for economy and safety. (SPRM-1)
SEEYOURSERVIS-RHINODEALER
In addition to the design and configuration of this Implement, including Safety Signs and Safety Equipment,
hazard control and accident prevention are dependent upon the awareness, concern, prudence, and proper
trainingofpersonnel involved in theoperation, transport,maintenance, andstorage ofthe machine. Referalso to
Safety Messages and operation instruction in each of the appropriate sections of the Tractor and Equipment
Manuals. Pay close attention to the Safety Signs affixed to the Tractor and Equipment. (SG-18)

FM6072 08/01 Safety Section 1-11
SAFETY
© 2004 Alamo Group Inc.
10
ITEM PARTNO. QTY LEVEL DESCRIPTION
1 00725746 1 PELIGRO TranslateSafetyMaterial
2 00749117 1 DANGER Multi-Hazard
3 00755742 1 DANGER CuttingBlades/ThrownObjects
4 00756004 ((1)) DANGER D/LShieldMissing-DoNotOperate
4A 00775933 2 WARNING GuardMissing
5 00756005 ((1)) DANGER RotatingDriveline/Entanglement
6 00756494 1 DANGER DrivelineHazards
6A 00769737 1 DANGER Blades/ThrownObjects
7 00758194 2 WARNING V-Belt Pinch Point
8 00760657 1 IMPORTANT GenuineRhinoParts
8A 00773723 1 PELIGRO RotatingDrivelineTranslation
9 D103 1 WARNING 540RPM
10 03200347 * REFLECTOR SMV
11 00755691 1 INSTRUC Lube, Blade Bolt
12 00763977 1 INSTRUC NoticetoOwner
13 99101 6 LOGONAME Rhino Name(2x7-3/8)
14 00769897 1 NAME FM60Name
00769899 1 NAME FM72Name
15 nfs 1 SERIALPLATE FM Serial Plate
16 2738332 2 REFLECT RedReflectors
17 00776481 1 INSTRUCT OperatorsManualInside(Decal)
18 00776031 1 --------------- Canister,OperatorsManual
19 00761717C 1 --------------- OperatorsManual
20 00021400 3 --------------- Bolt
21 00024100 6 --------------- Flatwasher
22 02959924 3 --------------- Locknut
*FurnishedbyTractorManufacturer
(())InstalledbyD/LManufacturer
3
2
13
6
7
1
12 13
14
3
13
4
13
8
4A
11
9
5
15
4A
8A
16
16
6A
20
21
17
18
22
21
NOTE: Rhinosupplies safetydecals onall productsmanufactured topromote safeoperation.
Damage to decals may occur while in shipping, use, or reconditioning, Rhino will replace the
safety decals on any product in the field, free of charge. Contact your Rhino dealer for more
information.

Safety Section 1-12
SAFETY
FM6072 08/01
© 2004 Alamo Group Inc.
1 - 00725746
3-00755742
4 - 00756004
5 - 00756005
6 - 00756494
7 - 00758194
9 - D103
2 - 00749117 - Not Shown
(See Inside Front Cover of Manual)
13 - 99101
8 - 00760657
R 04-09-99

FM6072 08/01 Safety Section 1-13
SAFETY
© 2004 Alamo Group Inc.
11 - 00755691
12 - 00763977
14 - 00769899
14 - 00769897

Safety Section 1-14
SAFETY
FM6072 08/01
© 2004 Alamo Group Inc.
8A - 00773723
6A-00773723
4A-00775933 17-00776481
