Rhyas TCM4005 User manual

TILE CUTTER 600W
TCM4005
Original Instructions

2
45
3
2
1
Fig. 2
Fig. 1
7
5
4
39
11
13
12
10 1
2
8

EN
3
TILE CUTTER TCM4005
Thank you for buying this Rhyas product.
By doing so you now have an excellent product,
delivered by one of Europeís leading suppliers.
All products delivered to you by Rhyas are
manufactured according to the highest standards
of performance and safety. As part of our
philosophy we also provide an excellent customer
service, backed by our comprehensive Warranty.
We hope you will enjoy using this product for
many years to come.
The numbers in the text refer to the diagrams
on page 2
For your own safety and that of others,
we recommend that you read this
instruction manual carefully before using
this saw. Keep this instruction manual
and the documentation provided with the
saw for future reference.
Introduction
This tool is suitable for cutting various wall and
floor tiles with a maximum tile size of 500 x 500 x
35 mm. The diamond wheel can be replaced by
the customer. It is not permitted to use the tool for
any other materials.
Contents
1. Machine information
2. Safety instructions
3. Assembly
4. Operation
5. Service & maintenance
1. Machine information
Technical specifications
Voltage 230 V~
Frequency 50 Hz
Power consumption 600W/S2=10 min*
IP Class IP20
No load speed 2950/min
Max. depth of cut 90º 34 mm
Max. depth of cut 45º 18 mm
Cutting angle 0 - 45°
Ø Cutting blade Ø180 x Ø22.2 x 2.2 mm
Table dimensions 360 x 330 mm
Lpa (sound pressure level) 92+3 dB(A)
Lwa (sound power level) 105+3 dB(A)
Vibration <2.5 m/s2
*S2= Maximum period of operation with a capacity
of 600 W
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in
EN 61029; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned
• using the tool for different applications, or with
different or poorly maintainted accessories,
may significantly increase the exposure level
• the times when the tool is switched off or when
it is running but not actually doing the job, may
signifi cantly reduce the exposure level
Protect yourself against the effects of
vibration by maintaining the tool and its
accessories, keeping your hands warm, and
organizing your work patterns.
Contents of packing
1 Tile cutter
1 Water tray
1 Full-length adjustable fence
1 Set of instructions
1 Safety instructions
1 Guarantee card
Check the machine, loose parts and accessories
for transport damage.
2. Safety instructions
Explanation of the symbols
Denotes risk of personal injury, loss of
life or damage to the tool in case of non-
observance of the instructions in this
manual.
Indicates electrical shock hazard.
Immediately unplug the plug from the
mains electricity in the case that the cord
gets damaged and during maintenance.

EN
4
Wear ear and eye protection.
Faulty and/or discarded electrical or
electronic apparatus have to be collected
at the appropriate recycling locations.
Specific safety instructions
• Check your powertool for damage before
starting your work, particularly the diamond
blade. All parts must be fitted properly and
must meet all requirements in order to
guarantee the tool’s smooth operation. Any
safety guards or any lightly damaged parts
must be checked to see if they still function
properly before continuing the use of the tool.
Moving parts, and the diamond-blade guard in
particular, must be fitted properly and must not
jam. Do not use tools that cannot be switched
on or off with the switch.
• The diamond-blade guard must not be jammed
or removed.
• A jamming guard must be repaired
immediately.
• The riving knife must not be removed.
Electrical safety
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions.
Always check that the power supply
corresponds to the voltage on the rating
plate.
Connecting to the power supply
Check that the power supply and plug used in
accordance with tour tool. Have a look at the
rating plate on the tile cutter. Any changes should
always be carried out by a qualified electrician.
Warning! This machine must be
earthed.
If not properly earthed this machine can cause an
electrical shock. Be sure that the power supply
outlet is earthed. If there is any doubt, have it
checked by a qualified electrician.
Warning! Avoid contact with the
terminals on the plug when installing
(removing) the plug to (from) the power
supply outlet. Contact will cause a
severe electrical shock.
Replacing cables or plugs
Immediately throw away old cables or plugs
when they have been replaced by new ones. It is
dangerous to insert the plug of a loose cable in
the wall outlet.
Using extension cables
Only use an approved extension cable suitable
for the power input of the machine. The minimum
conductor size is 1.5 mm2. When using a cable
reel always unwind the reel completely.
3. Assembly
Assembly
Fig.1
• Mounting the riving knife.
• Unscrew the two (crosshead) screws (9) and
place the foot of the riving knife (10) under the
table.
• Place the small plate (2 holes with thread)
under the foot of the riving knife.
• Connect the riving knife with the two screws
and the plate.
• Mounting the saw blade.
• Unscrew two screws out of lower blade guard
and remove the guard.
• Dismount nut (counterclockwise) and outer
flange.
• Place blade on the inner flange.
• Mount outer flange and nut (clockwise) again.
• Place the lower blade guard back in position
and connect the two screws.
• Mounting the upper blade guard (11).
• Slide the guard in horizontal position across
the riving knife.
• Connect the guard to the riving knife with the
bolt (12) and the locknut.
• Be aware that the guard is connected under
the lock-pin (13). The lock-pin prevents the
guard falling backwards.
• Mounting the adjustable fence
• Connect the knob (7) with the fence (3) by
using the plate (1 hole with thread); do not
tighten the knob yet.

EN
5
• Slide the complete fence with (loosen) knobs
onto the table; the plates on the inner side of
the table.
• Set the required distance.
• Tighten the knobs by rotating them (clockwise).
• Place the water tank (4) under the table.
Installing the tile cutter
• The tile cutter may only be used as a fixed tool
and should be screwed down to a level and
horizontal surface. Please use the screw holes
in the base of the machine.
• The electrical supply must be connected to a
230 V earthed wall socket. The mains voltage
must comply with the information on the type
plate, and must be protected by a circuit
breaker.
• Do not use the power cable to pull the plug
from the socket. Protect the cable against
heat, oil and sharp objects.
Only use accessories and auxiliary
equipment mentioned in the instructions
for use or recommended or mentioned
by the manufacturer. Using other
accessories or auxiliary equipment may
carry a risk of injury for you and others.
4. Operation
Operation
Fig.1
• Before starting the job, please ensure there
is sufficient water in the water tray (4) i.e. the
diamond blade runs through the water. During
the job, the water tray must be topped up.
• Do not start working before the maximum
speed has been reached.
• The diamond blade must NEVER be exposed
to sideways pressure; they can break and the
flying pieces become projectiles!
• Do not attempt to cut extremely small pieces
from the tiles. Always make sure that the full
surface of the tile is on the work table. The
supplied mitre guide can be used to push the
tiles through the cutter. In the early stages
of cutting in particular, the tile must remain
absolutely level to avoid the tile moving up.
• Do not overload your tool. It is better and safer
to work within the indicated power range. Do
not cut materials other than tiles.
• Maintain your tools carefully. Keep the tools
sharp and clean in order to work properly and
safely.
• Follow the maintenance instructions and the
instructions for replacing the diamond blade.
• Stand safely and maintain your balance. Avoid
any unnatural body angles. Remain alert
and pay attention to your work. Use common
sense. Do not use the machine when you
cannot concentrate or when you are tired.
Full-length adjustable fence
Fig.1
The fence (3) enables you to cut parallel to the
cutting blade. Set up: Loosen the knobs (7) and
set the required distance. Tighten the knobs
on both sides of the work table. The markers
determine the measurements (8).
Mitre guide
Fig.1
The mitre guide has a variable setting between
0° and 45°. Loosen the knobs (5), set the mitre by
tilting the table (1) up until you have reached the
required tilt. Tighten the knobs (5) again on both
sides of the work table.
Checking and replacing the diamond blade
Fig.1 + 2
• Cracked or distorted diamond blades must be
replaced.
• Type of disk: a diamond blade with a diameter
of 180mm.
• Do not use diamond blades that do not meet
the specifications in these instructions.
• Ensure that the diamond blade is secured
properly and rotates in the correct direction.
• To replace a worn disk, please take the
following steps (Fig. 2).
Disconnect the plug from the socket.
• Remove the water tray (4, Fig. 1) from the
machine.
• Loosen the splash guard’s fixing bolts and
remove the splash guard.
• Loosen the blade fixing nut (4, Fig. 2).

EN
6
• Remove the counter flange (3, Fig. 2) and
blade (2, Fig. 2) and push the new blade on
the flange (1, Fig. 2). Consider the rotation
direction indicated on the blade. Attach the
counter flange (3, Fig. 2).
• Tighten the fixing nut (4, Fig. 2) and the splash
guard.
• Ensure you do not leave any tools lying on the
splash guard.
5. Service & maintenance
Make sure that the machine is not live
when carrying out maintenance work on
the motor.
The machines have been designed to operate
over a long period of time with a minimum of
maintenance. Continuous satisfactory operation
depends upon proper machine care and regular
cleaning.
Cleaning
Keep the ventilation slots of the machine clean to
prevent overheating of the engine.
Regularly clean the machine housing with a
soft cloth, preferably after each use. Keep the
ventilation slots free from dust and dirt.
If the dirt does not come off use a soft cloth
moistened with soapy water. Never use solvents
such as petrol, alcohol, ammonia water, etc.
These solvents may damage the plastic parts.
Please clean the tool immediately after use.
Disconnect the plug from the socket.
• Remove the water tray from the machine and
drain the dirty water.
• Unscrew the splash guard and clean it.
• Loosen the star-shaped knob, fold up the
table, and polish the entire machine.
The machine complies with all current safety
regulations. Repairs may only be carried out by an
approved company, because repair attempts by
unqualified people may cause injuries to the user
and bystanders. Regularly check the plug and
the cable and if they are damaged they should
be replaced by an approved company. Also
check any extension cables. Damaged safety
guards and switches must be replaced before the
machine is used again.
Lubrication
The machine requiers no additional lubrication.
Faults
Should a fault occur, e.g. after wear of a part,
please contact the service address on the
warranty card. In the back of this manual you find
an exploded view showing the parts that can be
ordered.
Environment
To prevent damage during transport, the
appliance is delivered in a solid packaging which
consists largely of reusable material. Therefore
please make use of options for recycling the
packaging.
Faulty and/or discarded electrical or
electronic apparatus have to be
collected at the appropriate recycling
locations.
Warranty
The guarantee conditions can be found on the
separately enclosed guarantee card.

EN
7

EN
8
Spare parts list
No. Description Position
702891 Nut 5
702892 Flange set 6 + 8
TCA1004 Diamond saw blade 7
702893 Guard 9 - 11
702894 Knob 12
407102 Guide 14 - 16
407559 On/off switch complete 17
407123 Mains plug 27
407107 Water tank 40
407111 Angle guide 41

EN
9

EN
10
GENERAL SAFETY INSTRUCTIONS
Warning!
Read all instructions. Failure to follow all instructions listed
below may result in electric shock, fire and/or serious injury.
The term “power tool” in all of the warnings listed below
refers to your mains operated (corded) power tool or battery
operated (cordless) power tool. Save these instructions.
1) Work area
a. Keep work area clean and well lit. Cluttered and dark
areas invite accidents.
b. Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gasses
or dust. Power tools create sparks which may ignite the
dust of fumes.
c. Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
2) Electrical safety
a. Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs which
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces
such as pipes, radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body is
earthed or grounded.
c. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d. Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock. Always
use tool in conjunction with a residual circuit breaker
device.
3) Personal safety
a. Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool while you are tired or under the influence of drugs,
alcohol or medication. A moment of inattention while
operating power tools may result in serious personal
injury.
b. Use safety equipment.Always wear eye protection.
Safety equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c. Avoid accidental starting. Ensure the switch is in the off
position before plugging in. Carrying power tools with
your finger on the switch or plugging in power tools that
have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.
e. Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
g. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of these devices can
reduce dust related hazards.
h. Use clamps or a vice to hold work. It’s safer than using
your hand and it frees both hands to operate tool.
4) Power tool use and care
a. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b. Do not use the power tool if the switch does not turn it
on and off. Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source before
making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power tools
are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding
of moving parts, breakage of parts and any other
condition that may affect the power tools operation.
If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power
tools.
f. Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
g. Use the power tool, accessories and tool bits etc., in
accordance with these instructions and in the manner
intended for the particular type of power tool, taking
into account the working conditions and the work to be
performed. Use of the power tool for operations different
from intended could result in hazardous situation.

(EN) We declare under our sole responsibility that this product is in conformity with directive 2011/65/EU
of the European parliament and of the council of 9 June on the restriction of the use of certain
hazardous substances in electrical and electronic equipment is in conformity and accordance with the
following standards and regulations:
EN
11
EN 55014-1, EN 55014-2-16, EN 51044-1, EN 50144-2,
EN 61000-3-2, EN 61000-3-3
2006/42/EC, 2006/95/EC, 2004/108/EC, 2002/96/EC, 2006/95/EC
Zwolle, 01-05-2014 W. Dekens
CEO Mactool Industrial BV
It is our policy to continuously improve our products and we therefore reserve the right to change the product specification
without prior notice.
Mactool Industrial BV • Lingenstraat 6 • 8028 PM • Zwolle The Netherlands
DECLARATION OF CONFORMITY
TCM4005
h. Damaged switches must be replaced at a customer
service repair centre. Do not use power tools that
cannot be switched on and off.
i. Do not leave power tools unattended while they are
switched on. Always switch off the tool and wait until it
has come to a full standstill before leaving.
j. If the mains cable has been damaged, it must be
replaced with a special mains cable. These can be
obtained from the manufacturer or the manufacturer’s
customer service department. The mains cable
may only be replaced by the manufacturer, the
manufacturer’s customer service department or equally
qualified persons.
5) Battery tool use and care
a. Ensure the switch is in the off position before inserting
battery pack. Inserting the battery pack into power tools
that have the switch on invites accidents.
b. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
c. Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
d. When battery pack is not in use, keep it away from other
metal objects like paper clips, coins, keys, nails, screws,
or other small metal objects that can make a connection
from one terminal to another. Shorting the battery
terminals together may cause burns of a fire.
e. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may
cause irritations or burns.
6) Service
a. Please use a qualified expert who uses original
replacement parts to repair your power tool. This will
ensure proper functioning of the power tool.
b. Caution! The use of any accessories or additional tools
other than those recommended in this manual may
lead to an increased risk of injury. Only use original
replacement parts.

1405-02
