RHYNO
3 18V Windshield Cutter
-OPERATOR’S ANUAL - USA
NOTICE: This tool is specially designed to cut 0.500 inch (12.5 mm)
laminated glass only. Use of this product to cut materials other than
laminated glass may damage the tool and voids the warranty.
TO REDUCE THE RISK OF INJURY, USER MUST READ AND
UNDERSTAND OPERATOR’S
MANUAL.
Catalog No: RWC
-
3

[2]
WARNING! Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in
electric shock, fire and/or serious injury.
WARNING! To reduce the risk of
injury, read the instruction manual
If you have any questions or comments
about this or any RH NO tool, call us toll
free at:
844-25RH NO (844-257-4966)
United States and other patents apply.
RHYNO Windshield Cutter™ is a
Trademark of EnTheos Design Solutions,
LLC.
All rights reserved. Copyright 2019©
S MBOLOG
V ………………Volts
Hz ……………. Hertz
C ……………… Celcius
F ……………… Fahrenheit
AWG ……….. American Wire Gage
LED ………….. Light Emitting Diode
min …………. minutes
/min ……….. Per minute
bpm ………. Beats/min
ipm …………. Inches/min
RPM ………… rotations/min
sfpm ………. Surface feet/min
SPM ……….. Strokes/min
A ……………. Amperes
W …………… Watts
AC ………….. Alternating Current
DC ………….. Direct Current
……… Wear eye protection
……… Wear hearing protection
……… Wear respiratory protection
........ safety alert symbol
……… Read Manual
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal word. Please
read the manual and pay attention to these symbols.
DANGER: Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided,
may result in property damage.
NOTICE: Indicates a practice not related to personal injury which, if not avoided,
may result in property damage.

[3]
GENERAL POWER TOOL SAFET
WARNINGS
WARNING! To reduce the risk of
injury, read the instruction manual.
WARNING! Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in
electric shock, fire and /or serious injury.
SAVE ALL WARNINGS AND
INSTRUCTIONS FOR FUTURE
REFERENCE
The term “power tool” in the warnings
refers to your mains-operated (corded) or
battery-operated (cordless) power tool.
1) WORK AREA SAFET
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may
ignite the dust or fumes.
c) Keep children and bystanders away
while operating a power tool.
Distractions can cause you to lose
control.
2) ELECTRICAL SAFET
a) Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs with
earthed (grounded) power tools.
Unmodified plugs and matching outlets
will reduce risk of electric shock.
Variable Speed
Trigger Switch
Work Light
Battery Release
Button
Forward
-
Reverse
Button
Handle
Battery
Pack
Fuel Gage
Belt Clip
Cutter Blades

[4]
b) Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric
shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric
shock.
d) Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric
shock.
f) If operating the power tool in damp
locations is unavoidable, use a Ground
Fault Circuit Interrupter (GFCI)
protected supply. Use of a GFCI reduces
the risk of electric shock.
3) PERSONAL SAFET
a) Stay alert, watch what you are doing
and use common sense when
operating a power tool. Do not use a
power tool while you are tired or under
the influence of drugs, alcohol or
medication. A moment of inattention
while operating power tools may result
in serious personal injury.
b) Use personal protective equipment.
Always wear eye protection.
Protective equipment such as safety
glasses, dust mask, protective gloves or
hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your
finger on the switch or energizing the
power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a
rotating part of the power tool may
result in personal injury.
e) Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose
clothing or jewelry. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewelry or long
hair can be caught in moving parts.
g) If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use of
dust collection can reduce dust-related
hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job
better and safer at the rate for which it
was designed.
b) Do not use the power tool if the switch
does not turn on and off. Any power
tool that cannot be controlled with the
switch is dangerous and must be
repaired.
c) Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventive
safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.

[5]
Power tools are dangerous in the hands
of untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power
tool’s operation. If damaged, have the
power tool repaired before use. any
accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to
bind and are easier to control.
g) Use the power tool, accessories and
tool bits, etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those
intended could result in a hazardous
situation.
5) BATTER TOOL USE AND CARE
a) Recharge only with the charger
specified by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of fire
when used with another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep it
away from other metal objects like
paper clips, coins, keys, nails, screws,
or other small metal objects that can
make a connection from one terminal
to another. Shorting the battery
terminals together may cause burns or
a fire.
d) Under abusive conditions, liquid may
be ejected from the battery; avoid
contact. If contact accidentally occurs,
flush with water. If liquid contacts
eyes, additionally seek medical help.
Liquid ejected from the battery may
cause irritation or burns.
6) SERVICE
a) Have your power tool serviced by a
qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power tool
is maintained.
ADDITIONAL SAFET RULES FOR
SHEARS
WARNING: Tool use can generate and
disburse particles and dust which project
outward from the cutting blades that may
impact the face, eyes, hands or other body
parts. ALWA S use ANSI Z87.1 or
equivalent safety certified eye protection
during operation. Everyday eyeglasses are
NOT safety glasses.
WARNING: Tool use can generate and
disburse particles and dust which may cause
serious and permanent respiratory or other
injury. ALWA S use NIOSH/OSHA safety
certified respiratory protection during
operation.
WARNING: Exposed and cut glass along
with pieces and particles can cut your skin.
ALWA S wear cut-resistant gloves
constructed of leather, canvas or equivalent
during operation.
WARNING: Do not expose tool and
accessories to water or wet conditions.
Water entering a power tool will increase
the risk of electric shock.
WARNING: Depending on duration and
conditions of use, this tool may generate
noise which may contribute to hearing loss.
ALWA S use ANSI S12.6 or equivalent
safety certified hearing protection during
operation.
WARNING: Tool use may generate
particles, dust, or vapor which contains

[6]
chemicals known to cause cancer, birth
defects or other reproductive harm. Some
examples of these chemicals include:
•Copper and plastic from wiring
Your risk from these exposures varies,
depending on how often you do this type of
work. To reduce your exposure to these
chemicals, work in a well-ventilated area,
and work with approved safety equipment,
such as safety certified dust masks which
are specially designed to filter out
microscopic particles. Avoid prolonged
contact with dust by allowing particles or
dust to enter the mouth, eyes or lay on the
skin which can promote absorption of
harmful chemicals.
Hold power tool by insulated gripping
surfaces when performing an operation
where the cutter blades may contact
hidden wiring. Cutting blades contacting
“live” wires may make exposed metal parts
of the power tools “live” and could give the
operator an electric shock.
Air vents on tool cover moving parts and
should be avoided. Loose clothes, jewelry
or long hair can be caught in moving parts.
WARNING: Do not use this tool if you
are extremely tired, cannot maintain
adequate attention or are under the
influence of drugs, alcohol or medication.
A moment of inattention while operating
power tools may result in serious injury.
WARNING: Do not use this tool in
explosive atmospheres, such as in the
presence of flammable liquids, gases or
dust. Power tools create sparks which may
ignite the gas or fumes.
READ AND SAVE ALL INSTRUCTION FOR
FUTURE REFERENCE.
BATTER PACKS AND CHARGERS
The battery pack is not fully charged out of
the package. Before using the battery pack
and charger, read the safety instructions
below and then follow charging procedures
outlined. When ordering replacement
battery packs, be sure to include the catalog
number and voltage. Your tool uses a
RHYNO charger. Be sure to read all safety
instructions before using your charger.
Consult the chart at the end of this manual
for compatibility of chargers and battery
packs.
READ ALL INSTRUCTIONS
Important Safety Instructions for All
Battery Packs
WARNING! Read all safety warnings
and all instructions for the battery pack,
charger and power tool. Failure to follow
the warnings and instructions may result in
electric shock, fire and/or serious injury.
•Do not charge or use the battery pack in
explosive atmospheres, such as in the
presence of flammable liquids, gases or
dust. Inserting or removing the battery
pack from the charger may ignite the dust
or fumes.
•NEVER force the battery pack into the
charger. DO NOT modify the battery pack
in any way to fit into a non-compatible
charger as battery pack may rupture
causing serious personal injury. Consult
the chart at the top of page 3 for
compatibility of battery packs and
chargers.
•Charge the battery packs only in
designated RHYNO chargers.
•DO NOT splash or immerse in water or
other liquids.
•Do not store or use the tool and battery
pack in locations where temperatures
may reach or exceed 104°F (40°C) (such
as outside sheds or metal buildings in
summer. For best life, store battery pack
in a cool, dry location.
NOTE: Do not store the battery packs in a
tool with the trigger switch locked on.

[7]
Never tape the trigger switch in the ON
position.
•Do not incinerate the batter pack even if
it is severely damaged or is completely
worn out. The battery pack can explode
in a fire. Toxic fumes and materials are
created when lithium ion battery packs
are burned.
•If battery contents come into contact
with the skin, immediately wash area
with mild soap and water. If battery
liquid gets into the eye, rinse water over
the open eye for 15 minutes or until
irritation ceases. If medical attention is
needed the battery electrolyte is
composed of a mixture of liquid organic
carbonates and lithium salts.
•Contents of opened battery cells may
cause respiratory irritation. Provide
fresh air. If symptoms persist, seek
medical attention.
WARNING! Burn hazard. Battery liquid
may be flammable if exposed to spark or
flame.
WARNING! Fire hazard. Never attempt to
open the battery pack or any reason. If the
battery pack case is cracked or damaged, do
not insert into the charger. Do not crush,
drop or damage the battery pack. Do not
use a battery pack or charger that has
received a sharp blow, been dropped, run
over or damaged in any way (e.g., pierced
with nail, hit with a hammer, stepped on).
Damaged battery packs should be returned
to the service center for recycling.
Transportation
WARNING! Fire hazard. Do not store or
carry the battery pack so that metal objects
can contact exposed battery terminals. For
example, do not place the batter pack in
aprons, pockets, tool boxes, product kit
boxes, drawers, etc., with loose nails,
screws, keys, etc. Transporting battery
packs can possibly cause fires if the battery
terminals inadvertently come into contact
with conductive materials such as keys,
coins, hand tools, etc. The US Department
of Transportation Hazardous aterial
Regulations (H R) actually prohibit
transporting battery packs in commerce or
on airplanes in carry-on baggage UNLESS
they are properly protected from sort
circuits. So when transporting individual
battery packs, make sure that the battery
terminals are protected and well insulated
from materials that could contact them and
cause a short circuit.
Fuel Gage Battery Packs
RHYNO Battery Packs or tools include a fuel
gage which consists of three green LED
lights that indicate the level of charge
remaining in the battery pack.
The fuel gage is an indication of
approximate levels of charge remaining in
the battery pack according to the following
indicators:
To actuate the fuel gage, press and hold the
fuel gage button. A combination of three
green LED lights will illuminate designating
the level of charge left. When the level of
charge in the battery pack is below the
usable limit, the fuel gage will not illuminate
and the battery pack will need to be
recharged.

[8]
NOTE: The fuel gage is only an indication of
the charge left on the battery pack. It does
not indicate tool functionality and is subject
to variation based on product components,
temperature and end-user application.
Important Safety Instructions for
All Battery Chargers
WARNING! Read all safety warnings
and all instructions for the battery pack,
charger and power tool. Failure to follow
the warnings and instructions may result in
electric shock, fire and/or serious injury.
•DO NOT attempt to charge the battery
pack with any charges other than the
ones in this manual. The charger and
battery pack are specifically designed to
work together.
•These chargers are not intended for any
uses other than charging RH NO
rechargeable battery packs. Any other
uses may result in risk of fire, shock, or
electrocution.
•Do not expose the charger to rain or
snow.
•Pull by the plug rather than the cord
when disconnecting the charger. This
will reduce the risk of damage to the
electric plug and cord.
•ake sure that the cord is located so that
it will not be stepped on, tripped over or
otherwise subjected to damage or stress.
•Do not use an extension cord unless it is
absolutely necessary. Use of a cord
suitable for outdoor use reduces the risk
of electric shock.
•An extension cord must have adequate
wire size or AWG for safety. The smaller
the gage number of the wire, the greater
the capacity of the cable, that is, 16 gage
has more capacity than 18 gage. An
undersized cord will cause a drop in line
voltage resulting in loss of power and
overheating. When using more than one
extension to make up the total length, be
sure each individual extension contains at
least the minimum wire size. The
following table shows the correct size to
use depending on cord length and
nameplate ampere rating. If in doubt, use
the next heavier gage. The lower the
gage number, the heavier the cord.
•Do not place any object on top of the
charger or place the charger on a soft
surface that might block the ventilation
slots and result in excessive internal
heat. Place the charger in a position away
from any heat source. The charger is
ventilated through slots in the sides of the
housing.
•Do not operate the charger with a
damaged cord or plug.
•Do not operate the charger if it has
received a sharp blow, been dropped or
25 (7.6) 50 (15.2)
100 (30.5)
150 (45.7)
50 (15.2) 100 (30.5) 200 (61.0) 300 (91.4)
ore
Than
Not ore
Than
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not recommended
inimum Gage for Cord Sets
Volts
120V
220V
Total Length of Cord in Feet (meters)
American Wire Gage

[9]
otherwise damaged in any way. Take it
to an authorized service center.
•Do not disassemble the charger; take it
to an authorized service center when
service or repair is required. Incorrect
reassembly may result in a risk of electric
shock, electrocution or fire.
•Disconnect the charger from outlet
before attempting any cleaning. This
will reduce the risk of electric shock.
Removing the battery pack will not
reduce this risk.
•NEVER attempt to connect 2 chargers
together.
•The charger is designed to operate on
standard 120V/220V household
electrical power. Do not attempt to use
it on any other voltage.
WARNING! Shock hazard. Do not allow
any liquid to get inside the charger. Electric
shock may result.
WARNING! Burn hazard. Do not
submerge the batter pack in any liquid or
allow any liquid to enter the battery pack.
Never attempt to open the battery pack for
any reason. If the plastic housing of the
battery pack breaks or cracks, return to a
service center for recycling.
CAUTION: Burn hazard. To reduce the
risk of injury, charge only RHYNO
rechargeable battery packs. Other types of
battery packs may overheat and burst
resulting in personal injury and property
damage.
NOTICE: Under certain conditions, with the
charger plugged into the power supply, the
charger can be shorted by foreign material.
Foreign material of a conductive nature,
such as, but not limited to, grinding dust,
metal chips, steel wool, aluminum foil or
any buildup of metallic particles should be
kept away from the charger cavities.
Always unplug the charger from the power
supply when there is not battery pack in the
cavity. Unplug the charger before
attempting to clean.
Charging a Battery Pack
NOTICE: To ensure maximum performance
and life of lithium-ion battery packs, charge
the battery pack fully before first use.
1) WHEN TO CHARGE BATTER PACK
a. The fuel gage on the battery pack
indicates the current battery capacity.
If battery pack is less than 100% or 3
green bars, battery pack can be charged
to full capacity.
b. Remove the battery pack from the tool
for charging when needed. RHYNO
Lithium-ion battery packs do not
develop “memory” when charged after
only a partial discharge. It is not
necessary to run down the battery pack
before placing it on the charger.
c. You can “top off” each battery pack at
any time or at any level of battery
charge as needed.
d. The only time that it is necessary to
charge a battery pack is if it has reached
the end of its charge. To signal the end
of its charge, power to the tool will stop.
2) CHARGING A BATTER PACK
a. Align the battery pack with the bay and
slide the battery pack into the charger as
far as possible. The red LED will indicate
charging is ongoing.

[10]
b. After inserting the battery pack fully
into the charger slot, the LED will
indicate RED while charging.
c. When charging is complete, the LED will
indicate GREEN.
d. If the battery pack or charger is out of the
normal temperature range of 32°F-113°F
(0°-45°C) the LED will indicate RED &
GREEN.
e. A fully discharged battery pack with an
internal temperature in the normal
range will charge in about 15-20
minutes. Heavily cycled batteries may
take longer to completely charged.
NOTICE: Hot or cold batteries will take
longer to charge.
NOTICE: Inverters or generators rated to
100 watts or higher can be used to power
charger.
3) CLEANING
Clean out dust and debris from charger
vents and electrical contacts by blowing
with compressed air. Use only mild soap
and a damp cloth to clean the battery pack
and charger, keeping away from the
electrical contacts. Certain cleaning agents
and solvents are harmful to plastics and
other insulted parts. Some of these include
gasoline, turpentine, lacquer thinner, paint
thinner, chlorinated cleaning solvents,
ammonia and household detergents
containing ammonia. Never use
flammable or combustible solvents around
batteries, charger or tools.
4) REPAIRS
The charger has no serviceable parts.
Hot/Cold Battery Pack Delay
When the charger detects a battery pack
that is too hot or too cold, it automatically
starts a Hot/Cold Pack Delay, suspending
charging until the batty pack has reached an
appropriate temperature. The charger then
automatically switches to the pack charging
mode. This feature ensures maximum
battery pack life.
A cold battery pack will charge at a slower
rate than a warm battery pack. The battery
pack will charge at that slower rate
throughout the entire charging cycle and
will not return to maximum charge rate
even if the battery pack warms.
Lithium-Ion Battery Pack Only
Li-Ion tools are designed with an Electronic
Protection System that will protect the
battery pack against overloading,
overheating or deep discharge. The tool will
automatically turn off if the Electronic
Protection System engages. If this occurs,
place the Li-Ion battery pack on the charger
until it if fully charged.
ASSEMBL AND ADJUSTMENTS
WARNING! To reduce the risk of
serious personal injury, turn unit off and
remove the battery pack before making
any adjustments or removing /installing
attachments or accessories. An accidental
start-up can cause injury.
Installing and Removing the
Battery Pack
NOTE: For best results, make sure your
battery pack is fully charged.
