IQ plus®2100
Digital Bench Scale
Version 1.02
Installation Manual
To be the best by every measure

© 2003 Rice Lake Weighing Systems. All rights reserved. Printed in the United States of America.
Specifications subject to change without notice.
Version 1.0, June 2003
Contents
About This Manual................................................................................................................................... 1
1.0 Introduction.................................................................................................................................. 1
1.1 Operating Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.3 LED Annunciators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.4 Indicator Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.0 Installation................................................................................................................................... 3
2.1 Unpacking and Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2 Factory Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.0 Configuration................................................................................................................................ 4
3.1 Configuration Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1.1 Revolution Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1.2 EDP Command Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1.3 Front Panel Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.2 Menu Structures and Parameter Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2.1 Configuration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2.2 Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2.3 Calibration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2.4 Serial Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2.5 Digital Input Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2.6 Default Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2.7 Version Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.0 Calibration.................................................................................................................................. 14
4.1 Front Panel Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2 EDP Command Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.3 Revolution
™
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.0 EDP Commands.......................................................................................................................... 16
5.1 The EDP Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1.1 Key Press Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1.2 Reporting Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1.3 The RESETCONFIGURATION Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1.4 Parameter Setting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1.5 Normal Mode Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.2 Saving and Transferring Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.2.1 Saving Indicator Data to a Personal Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.2.2 Downloading Configuration Data from PC to Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6.0 Setup and Service Information.................................................................................................. 19
6.1 Enclosure Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.2 Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.2.1 Cable Grounding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.2.2 Load Cells. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.2.3 Setting the Load Cell Compensation Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.2.4 Serial Communications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.2.5 Digital Inputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.rlws.com or obtained by
calling 715-234-9171 and asking for the training department.

ii IQ plus 2100 Installation Manual
6.3 Enclosure Reassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.4 Board Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.5 IQ plus 210 Replacement Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.6 Bench Scale Maintenance................................................................................................................ 26
6.6.1 Load Cell Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.6.2 Bench Scale Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.6.3 Clamshell Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.7 RL2100 Replacement Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7.0 Appendix.................................................................................................................................... 32
7.1 Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.1.1 Displayed Error Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.1.2 Using the XE EDP Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.2 Status Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.2.1 Using the P EDP Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.2.2 Using the ZZ EDP Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.3 Continuous Output (Stream) Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.4 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.4.1 IQ plus 210 Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.4.2 RL2100 Bench Scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
IQ plus 2100 Limited Warranty.............................................................................................................. 35

Introduction 1
About This Manual
This manual is intended for use by service technicians
responsible for installing and servicing IQ plus
®
2100
digital bench scales.
Configuration and calibration of the indicator can be
accomplished using the indicator front panel k eys, the
EDP command set, or Version 2.3 or later of the
Revolution
™
configuration utility. See Section 3.1 on
page 10 for information about configuration methods
Some procedures described in this
manual require work inside the indicator
enclosure. These procedures are to be
performed by qualified service personnel
only
.
Authorized distributors and their emplo yees
can view or download this manual from the
Rice Lake Weighing Systems distributor site
at
www.rlws.com
.
1.0 Introduction
The IQ plus 2100 digital bench scale consists of an IQ
plus 210 digital weight indicator and an RL2100 bench
scale. The indicator can be mounted to the bench scale
using the 12-inch column or the attachment brack et, or
can be separately mounted on the tilt stand.
The IQ plus 210 is a single-channel digital weight
indicator housed in a NEMA 4X/IP66-rated stainless
steel enclosure. The indicator front panel consists of a
large (.8 in, 20 mm), six-digit, se ven-segment LED
display, seven LED annunciators, and tw o piezo
switches used to zero the scale and select the displayed
units. Features include:
• Drives up to four 350
Ω load cells
• Supports 4- and 6-wire load cell connections
•Two configurable digital input
•Single serial port supports full duple x, RS-232
communications at up to 9600 bps
•Available in 115 VAC and 230 VAC versions
The RL2100 bench scale is a vailable in the follo wing
configurations
•5, 10, and 25 lb (2.5, 5, and 10 Kg) capacities with a
10" x 10" (25cm x 25cm) platform
•50 and 100 lb (25 and 50 Kg) capacities with a 12" x
12" (30cm x 30cm) platform
The RL1042 anodized aluminum load cell is standard
in the RL2100 bench scale; the RL1380 stainless steel
load cell is a vailable as an option. A stainless steel
clamshell enclosure is also a vailable for load cell
protection.
1.1 Operating Modes
The IQ plus 210 has two modes of operation:
Normal (weighing) mode
Normal mode is the “production” mode of the
indicator. The indicator displays the gross weight,
and the LED annunciators described on page 2
indicate scale status and the type of weight v alue
displayed. Once configuration is complete and
legal seal is affi ed to the back of the indicator, this
is the only mode in which the IQ plus 210 can
operate.
Setup mode
Most of the procedures described in this manual
require the indicator to be in setup mode, including
configuration and calibration
To enter setup mode, remove the large fillister hea
screw from the enclosure backplate. Insert a
screwdriver or a similar tool into the access hole
and press the setup switch once. The indicator
display changes to show the word
CONFIG
.
Warning

2 IQ plus 2100 Installation Manual
1.2 Front Panel
Figure 1-1 shows the IQ plus 210 LED annunciators, buttons, and normal mode key functions.
Figure 1-1. IQ plus 210 Front Panel, Showing LED Annunciators and Normal Mode Key Functions
1.3 LED Annunciators
The IQ plus 210 display uses a set of se ven LED
annunciators to pro vide additional information about
the value being displayed:
•
Neg annunciator lights to sho w that the displayed
value is negative.
• Zero : Weight is within 0.25 graduations of zero.
This annunciator lights when the scale is zeroed.
• Motion : Scale in motion outside the specifie
motion band. Zeroing and print operations can only
be done when the motion LED is off.
•
lb, kg, oz, and g annunciators indicate the units
associated with the displayed v alue: lb=pounds,
kg=kilograms, oz=ounces, g=grams. lb and oz
annunciators are both lit when the displayed weight
is in pounds and ounces.
1.4 Indicator Operations
Basic IQ plus 210 operations are summarized below.
Zero Scale
1. Remove material from the scale and w ait for
the
Motion
LED to go out.
2. Press the
ZERO
button. The
Zero
annunciator
lights to indicate the scale is zeroed.
Change Display Units
Press the
UNITS
button to change the displayed units
between primary and alternate units. The LED
annunciators on the right side of the display sho w the
current displayed units. If more than one alternate unit
is configured, the display ycles through the alternate
units before returning to primary units; if no alternate
units are configured, the display does not change whe
the button is pressed.
DIGITAL WEIGHT INDICATOR
ZERO
Set scale weight to zero
UNITS
Change displayed units
kg
g
lb
oz
ZERO UNITS
Zero
Motion
Neg

Installation 3
2.0 Installation
The IQ plus 2100 digital bench scale is designed for easy
setup and installation. All models are preconfigured an
weight calibrated before shipment, with the load cell
connected to the indicator . For simple, standalone scale
applications, hardware installation consists of attaching
the indicator, mounting assembly, and bench scale, then
leveling the scale.
NOTE: The IQ plus 2100 is weight calibrated before
shipment from the factory, but recalibration at the
installation site is strongly recommended. Calibration by
a certified scale technician is required for Legal-for-Trade
applications.
2.1 Unpacking and Assembly
Immediately after unpacking, visually inspect the IQ
plus 2100 to ensure all components are included and
undamaged. The shipping carton should contain the
indicator, the bench scale, the indicator mount (tilt
stand, column, or attachment bracket), this manual, and
a parts kit. If an y parts were damaged in shipment,
notify Rice Lak e Weighing Systems and the shipper
immediately.
The parts kit contains the items listed below:
• Capacity label (PN 42350)
•One grounding clamp (PN 53075), e xternal
tooth lock washer, (PN 15133), and kep nut (PN
14626) for digital input or serial cable shield
grounding against the enclosure.
•Two wing knobs with n ylon washers for
attaching the indicator to the mounting
assembly, four rubber tilt stand feet (for tilt
stand option) or bench scale feet, jam nuts, lock
washers, and cap scre ws (for column and
attachment bracket options). See Section 6.7 on
page 28 for replacement part numbers.
To install, attach the mounting assembly to scale base,
then assemble the indicator to the mounting assembly .
Place the bench scale in the desired location then lift off
the scale platter and locate the b ubble level. Adjust the
corner feet until the scale is le vel and all feet are in
contact with the support surf ace. Tighten the jam nuts
against the scale to lock-in the level adjustment.
Plug power cord into power outlet to begin weighing.
The supply cord serves as the power
disconnect for the IQ plus 2100. The
power outlet supplying the indicator
must be installed near the unit and be
easily accessible.
2.2 Factory Setup
The IQ plus 2100 is preconfigured and weigh
calibrated at the factory before shipment. Table 2-1 lists
the default graduations and count-by configuration fo
each scale capacity.
If scale configuration must be changed, see Section 3.0
on page 4 for detailed configuration information. Se
Section 4.0 on page 14 for calibration instructions.
Caution
Scale
Capacity Count by
Configuration Parameters
DECPNT DSPDIV
5 lb 0.001 lb 888.888 1D
10 lb 0.002 lb 888.888 2D
25 lb 0.005 lb 888.888 5D
50 lb 0.01 lb 8888.88 1D
100 lb 0.02 lb 8888.88 2D
2.5 Kg 0.0005 Kg 88.8888 5D
5 Kg 0.001 Kg 888.888 1D
10 Kg 0.002 Kg 888.888 2D
25 Kg 0.005 Kg 888.888 5D
50 Kg 0.01 Kg 8888.88 1D
NOTE: All capacities are preconfigured for 5000 graduations
(GRADS parameter on CONFIG menu set to 5000).
Table 2-1. Default Scale Configurations

10 IQ plus 2100 Installation Manual
3.0 Configuration
To configure the IQ plus 210 indicator , the indicator
must be placed in setup mode. The setup switch is
accessed by removing the large fillister head scr w on
the enclosure backplate. Insert a scre wdriver into the
access hole and press the switch to enter setup mode.
When the indicator is placed in setup mode, the w ord
CONFIG
is shown on the display. The CONFIG menu is
the first of the main menus used to configure t
indicator. Detailed descriptions of these menus are
given in Section 3.2. When configuration is complete
press the setup switch ag ain to e xit setup mode, then
replace the setup switch access screw.
3.1 Configuration Methods
The IQ plus 210 indicator can be configured by usin
the front panel b uttons to navigate through a series of
configuration menus or by sending commands or
configuration data to the EDP port. Configuration usin
the menus is described in Section 3.1.3.
Configuration using the EDP port can be accomplished
using either the EDP command set described in
Section 5.0 or Version 2.3 or later of the Re volution
™
configuration utilit .
3.1.1 Revolution Configuration
The Revolution configuration utility pr vides the
preferred method for configuring the IQ plus 21
indicator. Revolution runs on a personal computer to set
configuration parameters for the indicator . When
Revolution configuration is complete, configurati
data is downloaded to the indicator.
Figure 3-1. Sample Revolution Display
Revolution supports both uploading and do wnloading
of indicator configuration data. This capability allo ws
configuration data to be retrie ved from one indicator ,
edited, then downloaded to another.
To use Revolution, do the following:
1. Install Revolution on an IBM-compatible per-
sonal computer running Windows
®
3.11 or
Windows 95. Minimum system requirements
are 8MB of e xtended memory and at least
5MB of available hard disk space.
2. With both indicator and PC po wered off,
connect the PC serial port to the RS-232 pins
on the indicator EDP port.
3. Power up the PC and the indicator . Use the
setup switch to place the indicator in setup
mode.
4. Start the Revolution program.
Figure 3-1 shows an example of one of the Re volution
configuration displays
Revolution provides online help for each of its
configuration displays. Parameter descriptions provided
in this manual for front panel configuration can also b
used when configuring the indicator using R volution:
the interface is different, but the parameters set are the
same.
3.1.2 EDP Command Configuration
The EDP command set can be used to configure the I
plus 210 indicator using a personal computer, terminal,
or remote k eyboard. Like Revolution, EDP command
configuration sends commands to the indicator serial
port; unlike Revolution, EDP commands can be sent
using any external device capable of sending ASCII
characters over a serial connection.
EDP commands duplicate the functions available using
the indicator front panel and pro vide some functions
not otherwise available. EDP commands can be used to
simulate pressing front panel b uttons, to configure th
indicator, or to dump lists of parameter settings. See
Section 5.0 on page 22 for more information about
using the EDP command set.

Configuration 11
3.1.3 Front Panel Configuration
The IQ plus 210 indicator can be configured using a series of menus accessed through the indicator front pane
when the indicator is in setup mode. Table 3-1 summarizes the functions of each of the main menus.
Figure 3-2. Front Panel Key Functions in Setup Mode
Menu Menu Function
CONFIG Configuration Configure grads, zero tracking, zero range, motion band, overload, and digital filtering
parameters.
FORMAT Format Set format of primary units, select alternate display units.
CALIBR Calibration Calibrate indicator. See Section 4.0 on page 20 for calibration procedures.
SERIAL Serial Configure serial port.
DIG IN Digital Input Assign digital input functions.
DEFLT Default Restore default configuration.
VERS Version Display installed software version number.
Table 3-1. IQ plus 210 Menu Summary
DIGITAL WEIGHT INDICATOR
ZERO/ENTER
Move down in menu or
enter parameter value and
return to menu level above
UNITS/RIGHT
Move right in menu /
next parameter value
kg
g
lb
oz
ZERO UNITS
Zero
Motion
Neg

12 IQ plus 2100 Installation Manual
Front Panel Menu Navigation
The front panel buttons are used to navigate through the
menus in setup mode (see Figure 3-2). The
UNITS
(
RIGHT
) button scrolls right (horizontally) on the same
menu level; the
ZERO
(
ENTER
) button moves down
(vertically) to dif ferent menu le vels and serv es as an
Enter key for selecting parameter v alues within the
menus.
Most of the configuration menus h ve three or four
levels. Figure 3-3 shows the general structure of the IQ
plus 210 configuration menus. Note the foll wing:
•On the first (main) menu l vel, press RIGHT to scroll
through the menus. Pressing RIGHT from the VERS
menu wraps around to the CONFIG menu. Press
ENTER from any of the main menus to mo ve down
to the first parameter for that menu
•On the middle (parameter) menu le vels, press
RIGHT
to scroll through the parameter prompts
for the menu. When the last parameter is
displayed, pressing
RIGHT
returns to the level
above . Press
ENTER
from any parameter prompt
to move down to the v alues prompts for that
parameter.
•On the bottom (parameter v alue) menu le vel,
press
RIGHT
to scroll through the values for the
parameter. Pressing
RIGHT
from the last v alue
wraps around to first alue. Press
ENTER
to
select the v alue and return to the parameter
prompt.
Figure 3-4 on page 13 sho ws an e xample of the
navigation used to select a parameter v alue under the
SERIAL menu.
To edit numerical v alues, use the RIGHT button to
select the digit; use the
ENTER
button to increment or
decrement the value of the flashing digit (see Figure 3-5
on page 13). Once all digits ha ve been edited, press
ENTER
to save the v alue and return to the parameter
prompt.
Figure 3-3. General Menu Structure
Parameter 1
Value 1
XXXXXXXXXXXXXX VERSDEFLTDIG IN
SERIALCALIBRCONFIG FORMAT
RIGHT
RIGHT RIGHT RIGHT
Menu Navigation
General Structure
RIGHT
RIGHT RIGHT RIGHT
ENTER
RIGHT RIGHT
RIGHT
Press ENTER at any parameter value to select the value and return to the parameter prompt
RIGHT
RIGHT RIGHT RIGHT
Parameter 2 Parameter 3 Parameter 4
Value 2 Value 3 Value 4
ENTER
Pressing RIGHT at the last parameter prompt returns to the menu prompt
(ENTER)
ZERO
(RIGHT)
UNITS

Configuration 13
Figure 3-4. Setup Mode Menu Navigation
Figure 3-5. Editing Procedure for Numeric Values
PRNFRQ
DEMAND
AUTO1
BITS TERMIN
BAUD
CR
9600
7ODD
7EVEN
8NONE CR/LF
48002400
1200
AUTO2
STREAM
XXXXXXXXXXXXXX VERSDEFLTDIG IN
SERIALCALIBRCONFIG FORMAT
RIGHT
RIGHT RIGHT RIGHT
ENTER
Menu Navigation
Serial Menu Example
RIGHT
RIGHT RIGHT RIGHT
ENTER
RIGHT RIGHT
RIGHT
With any of the BAUD parameter values displayed, press ENTER
to select the value and return to the BAUD parameter prompt
RIGHT
Navigation functions same
as BAUD parameter
When displaying last
parameter prompt, press
RIGHT to return to the
first-level menu prompt
(ENTER)
ZERO
(RIGHT)
UNITS
To edit numeric values, press the UNITS (RIGHT)
button to select the leftmost digit. Each digit flashes
when selected: Press
ZERO (ENTER) to
increment the value of the selected digit; press the
RIGHT button to move right to the next digit.
Once the last digit has been edited, press
RIGHT
again and the digit stops flashing. Press ENTER
to save the value entered and return to the menu level
above, or press
RIGHT to edit the value again,
starting with the leftmost digit.
00 0 0 0 0

14 IQ plus 2100 Installation Manual
3.2 Menu Structures and Parameter Descriptions
The following sections provide graphic representations of the IQ plus 210 menu structures. In the actual menu
structure, the values under each parameter are arranged horizontally. To save page space, menu choices are shown in
vertical columns. The factory default setting appears at the top of each column.
Most menu diagrams are accompanied by a table that describes all parameters and parameter values associated with
that menu. Default parameter values are shown in bold type.
3.2.1 Configuration Menu
Figure 3-6. Configuration Menu
CONFIG Menu
Parameter Choices Description
Level 2 submenus
GRADS 5000
number Graduations. Specifies the number of full scale graduations. The value entered must be in the range 1–10 000 and should be consistent with legal requirements and environmental
limits on system resolution.
To calculate GRADS, use the formula, GRADS = Capacity / Display Divisions.
Display divisions for primary and secondary units are specified on the FORMAT menu.
ZTRKBN OFF
0.5D
1D
3D
Zero track band. Automatically zeroes the scale when within the range specified, as long
as the input is within the configured zero range (ZRANGE parameter). Selections are ±
display divisions. Maximum legal value varies depending on local regulations.
ZRANGE 100%
1.9% Zero range. Selects the range within which the scale can be zeroed. The 1.9% selection is ± 1.9% around the calibrated zero point, for a total range of 3.8%. Indicator must be at
standstill to zero the scale. Use 1.9% for legal-for-trade applications.
MOTBAN 1D
2D
3D
5D
10D
20D
OFF
Motion band. Sets the level, in display divisions, at which scale motion is detected. If
motion is not detected for 1 second or more, the standstill symbol lights. Some
operations, including print, tare, and zero, require the scale to be at standstill. Maximum
legal value varies depending on local regulations.
If OFF is selected, ZTRKBN should also be set to OFF.
Table 3-2. Configuration Menu Parameters
XXXXXXXXXXXXXX
GRADS
5000 OFF
1D
0.5D
3D
ZTRKBN ZRANGE
100%
1.9%
OFF
2D
1D
3D
MOTBAN
10D
5D
20D
FS+2%
FS+9D
FS+1D
FS
OVRLOA
1
8
4
16
FILTER
8RT
4RT
16RT
number
VERSDEFLTDIG IN
SERIALCALIBRCONFIG FORMAT
2

Configuration 15
3.2.2 Format Menu
Figure 3-7. Format Menu
OVRLOA FS+2%
FS+1D
FS+9D
FS
Overload. Determines the point at which the display blanks and an out-of-range error
message is displayed. Maximum legal value varies depending on local regulations.
FILTER 4
8
16
4RT
8RT
16RT
1
2
Digital filtering. Selects the digital filtering rate used to reduce the effects of mechanical
vibration from the immediate area of the scale.
Choices indicate the number of A/D conversions that are averaged to obtain the
displayed reading. A higher number gives a more accurate display by minimizing the
effect of a few noisy readings, but slows down the settling rate of the indicator. Values
with the RT suffix provide a raised threshold for filtering larger noise spikes.
CONFIG Menu
Parameter Choices Description
Table 3-2. Configuration Menu Parameters (Continued)
KG GOZLB
PRIMAR ALTUNT
DSPDIVUNITS DECPNT
OZ
KG
88888.8
8888.88
1D
5D
2D
LB
88.8888
8.88888
888880
888888
OFF
ON
LB/OZ
G
LB/OZ
XXXXXXXXXXXXXX VERSDEFLTDIG IN
SERIALCALIBRCONFIG FORMAT
OFF
ON
OFF
ON
OFF
ON
OFF
ON
888 88
88 88.8
If UNITS=LB/OZ,
DECPNT selections are:
888.888

16 IQ plus 2100 Installation Manual
FORMAT Menu
Parameter Choices Description
Level 2 submenus
PRIMAR UNITS
DECPNT
DSPDIV
Specifies the decimal position, display divisions, and units used for the primary units. See
Level 3 submenu parameter descriptions.
ALTUNT LB
KG
OZ
G
LB/OZ
Specifies which alternate units can be displayed by pressing the UNITS. See Level 3
submenu parameter descriptions.
NOTE: The LB/OZ setting is not a Legal-for-Trade setting.
Level 3 submenus
Primary Units (PRIMAR Parameter)
DECPNT 888.888
8888.88
88888.8
888888
888880
8.88888
88.8888
or
88 88.8
888 88
Decimal point location. Specifies the location of the decimal point or dummy zeroes in the
primary unit display. Value should be consistent with local legal requirements.
If LB/OZ is selected as the primary unit, DECPNT selections are 88 88.8 and 888 88.
DSPDIV 1D
2D
5D
Display divisions. Selects the minimum division size for the primary units displayed weight.
UNITS LB
KG
OZ
G
LB/OZ
Specifies primary units for displayed and printed weight. Values are: LB=pound;
KG=kilogram; OZ=ounce; G=gram; LB/OZ=pounds and ounces.
Alternate Units (ALTUNT Parameter)
LB
KG
OZ
G
LB/OZ
ON
OFF Alternate units. Determines which units are displayed when the UNITS button is pressed. The value for the primary unit (selected on the PRIMAR parameter) is always ON.
NOTE: The LB/OZ setting is not a Legal-for-Trade setting.
Table 3-3. Format Menu Parameters

Configuration 17
3.2.3 Calibration Menu
See Section 4.0 on page 20 for calibration procedures.
Figure 3-8. Calibration Menu
CALIBR Menu
Parameter Choices Description
Level 2 submenus
WZERO — Display and edit the zero calibration A/D count value.
WVAL — Display and edit the test weight value.
WSPAN — Display and edit the span calibration A/D count value.
REZERO — Press ENTER to remove an offset value from the zero and span calibrations.
Use this parameter only after WZERO and WSPAN have been set. See Section 4.1 on
page 20 for more information about using this parameter.
Table 3-4. Calibration Menu Parameters
WZERO
*CAL*
Display and edit
zero calibration
A/D count value
Display and edit
test weight value
WVAL
*CAL*
Display and edit
span calibration
A/D count value
WSPAN
* CAL*
Press Enter to
remove offset from
zero and span
calibrations
REZERO
XXXXXXXXXXXXXX VERSDEFLTDIG IN
SERIALCALIBRCONFIG FORMAT

18 IQ plus 2100 Installation Manual
3.2.4 Serial Menu
Figure 3-9. Serial Menu
BITSBAUD
9600
7ODD
7EVEN
8NONE
4800
2400
1200
XXXXXXXXXXXXXX VERSDEFLTDIG IN
SERIALCALIBRCONFIG FORMAT
PRNFRQ
DEMAND
AUTO1
AUTO2
STREAM
TERMIN
CR
CR/LF
ECHO
ON
OFF
SERIAL Menu
Parameter Choices Description
BAUD 9600
1200
2400
4800
Baud rate. Selects the transmission speed for the serial port.
BITS 8NONE
7EVEN
7ODD
Selects number of data bits and parity of data transmitted from the serial port.
TERMIN CR/LF
CR Termination character. Selects termination character for data sent from the serial port.
ECHO OFF
ON This command enables or disables echoing of the serial commands sent to the indicator.
PRNFRQ DEMAND
AUTO1
AUTO2
STREAM
Print frequency. Specifies when the indicator sends data to the serial port:
DEMAND: When a PRINT digital input is activated or the KPRINT EDP command received.
AUTO1: Output enabled by scale in motion; transmitted when scale returns to standstill.
AUTO2: Output enabled by scale at center of zero; transmitted when a positive scale weight
is at standstill.
STREAM: Continuous output. See Section 6.3 on page 26 for output format.
Weight data is sent to the serial port in displayed units except when other units are specified
using one of the XGxEDP commands (see Section 5.1.5 on page 24).
If DEMAND, AUTO1, or AUTO2, is selected for this parameter, serial output is formatted as
follows:
wwwwwww uu GROSS
where wwwwww is a 7-digit weight field (leading zeroes suppressed, including decimal point and
minus sign, if required), uu is the units designator (lb, kg, oz, or G).
If pounds/ounces (LB/OZ) is specified as the primary units, the serial output is formatted as
shown below:
xxx lb yyyy oz GROSS
where xxx is the three-digit pounds weight (including minus sign, if required) followed by lb and
a space; and yyyy is the four-digit ounce weight (including decimal point) followed by oz.
Table 3-5. Serial Menu Parameters

Configuration 19
3.2.5 Digital Input Menu
Figure 3-10. Digital Input Menu
3.2.6 Default Menu
The DEFLT menu is used to reset indicator configuration to the de ault values. There are no parameters
associated with the DEFLT menu. From the DEFLT menu, press ENTER (ZERO) to move down to the RESET
parameter. Press ENTER again to reset the indicator to the def ault configuration alues or press RIGHT (UNITS)
to cancel the indicator reset and return to the menu le vel above. NOTE: All load cell calibration settings are lost
when the RESET function is performed.
Figure 3-11. Default Menu
3.2.7 Version Menu
The VERS menu is used to check the softw are version installed in the indicator . There are no parameters
associated with the VERS menu: when selected, the indicator displays the installed software version number.
Figure 3-12. Version Menu
DIG IN Menu
Parameter Choices Description
Level 2 submenus
DIGIN1
DIGIN2 OFF ZERO
UNITS
PRINT
Specifies the function activated by digital inputs 1 and 2.
Table 3-6. Digital Input Menu Parameters
XXXXXXXXXXXXXX VERSDEFLTDIG IN
SERIALCALIBRCONFIG FORMAT
DIGIN1
OFF
DIGIN2
ZERO
UNITS
PRINT
OFF
ZERO
UNITS
PRINT
XXXXXXXXXXXXXX VERSDEFLTDIG IN
SERIALCALIBRCONFIG FORMAT
RESET
XXXXXXXXXXXXXX VERSDEFLTDIG IN
SERIALCALIBRCONFIG FORMAT
Software
version

20 IQ plus 2100 Installation Manual
4.0 Calibration
The IQ plus 210 can be calibrated using the front panel, EDP commands, or the Re volution™ configuration utility.
Each method consists of the following steps:
• Zero calibration
• Entering the test weight value
• Span calibration
• Optional rezero calibration for test weights using hooks or chains.
The following sections describe the calibration procedure for each of the calibration methods.
Figure 4-1. Calibration (CALIBR) Menu
4.1 Front Panel Calibration
To calibrate the indicator using the front panel, do the
following:
1. Place the indicator in setup mode (display
reads CONFIG) and remo ve all weight from
the scale platform. If your test weights require
hooks or chains, place the hooks or chains on
the scale for zero calibration.
2. Press the RIGHT (UNITS) button until the
display reads CALIBR (see Figure 4-1). Press
ENTER (ZERO) to go to zero calibration
(WZERO).
3. With WZERO displayed, press ENTER to
calibrate zero. The indicator displays °CAL°
while calibration is in progress. When
complete, the A/D count for the zero
calibration is displayed. Press ENTER again to
save the zero calibration value and return to the
WZERO prompt or use the procedure sho wn in
Figure 4-2 to edit the v alue. When done, press
RIGHT to go to the WVAL prompt.
4. With WVAL displayed, press ENTER to show
the test weight value. If the value is equal to the
test weight you are using, press ENTER again
to save the v alue and return to the WVAL
prompt; if the v alue is incorrect, use the
procedure shown in Figure 4-2 to edit the
value. When done, press RIGHT to go to the
WSPAN prompt.
NOTE: When calibrating the indicator with
LB/OZ as the primary unit, enter the WVAL value
in ounces. For example, to calibrate a 5 lb scale
using LB/OZ, enter 80 (5 lb x 16 oz/lb) as the
WVAL value.
5. With WSPAN displayed, place test weights on
the scale then press ENTER to calibrate span.
The indicator displays °CAL° while calibration
is in progress. When complete, the A/D count
for the span calibration is displayed. Press
ENTER again to save the span calibration value
and return to the WSPAN prompt or use the
procedure shown in Figure 4-2 to edit the
value. When done, press RIGHT to go to the
REZERO prompt.
Figure 4-2. Editing Procedure for Numeric Values
WZERO
*CAL*
Display and edit
zero calibration
A/D count value
Display and edit
test weight value
WVAL
*CAL*
Display and edit
span calibration
A/D count value
WSPAN
*CAL*
Press Enter to
remove offset from
zero and span
calibrations
REZERO
XXXXXXXXXXXXXX VERSDEFLTDIG IN
SERIALCALIBRCONFIG FORMAT
To edit numeric values, press the UNITS (RIGHT)
button to select the leftmost digit. Each digit flashes
when selected: Press
ZERO (ENTER) to
increment the value of the selected digit; press the
RIGHT button to move right to the next digit.
Once the last digit has been edited, press
RIGHT
again and the digit stops flashing. Press ENTER
to save the value entered and return to the menu level
above, or press
RIGHT to edit the value again,
starting with the leftmost digit.
00 0 0 0 0

Calibration 21
6. The rezero function is used to remo ve a
calibration offset when hooks or chains are
used to hang the test weights.
•If no other apparatus was used to hang the
test weights during calibration, remove the
test weights and press RIGHT to return to
the CALIBR menu.
•If hooks or chains were used during
calibration, remove these and the test
weights from the scale. With all weight
removed, press ENTER to rezero the scale.
This function adjusts the zero and span
calibration values. The indicator displays
°CAL° while the zero and span calibrations
are adjusted. When complete, the adjusted
A/D count for the zero calibration is
displayed. Press ENTER again to save the
rezero value and return to the REZERO
prompt or use the procedure shown in
Figure 4-2 to edit the value. When done,
press RIGHT to return to the CALIBR
menu.
7. Press the setup switch to exit setup mode.
4.2 EDP Command Calibration
To calibrate the indicator using EDP commands, the
indicator EDP port must be connected to a terminal or
personal computer. (See Section 2.3.3 on page 5 for
EDP port pin assignments; see Section 5.0 on page 22
for more information about using EDP commands.)
Once the indicator is connected to the sending de vice,
do the following:
1. Place the indicator in setup mode (display
reads CONFIG) and remo ve all weight from
the scale platform. If your test weights require
hooks or chains, place the hooks or chains on
the scale for zero calibration.
2. Send the WZERO EDP command to calibrate
zero. The indicator displays °CAL° while
calibration is in progress.
3. Send the WVAL command to enter the test
weight value in the following format:
WVAL=nnnnnn<CR>
4. Place test weights on scale equal to the
specified WVAL.
5. Send the WSPAN EDP command to calibrate
span. The indicator displays °CAL° while
calibration is in progress.
6. To remove an of fset value, clear all weight
from the scale, including hooks or chains used
to hang test weights, then send the REZER O
EDP command. The indicator displays °CAL°
while the zero and span calibrations are
adjusted.
7. Send the KEXIT EDP command to e xit setup
mode.
4.3 Revolution™Calibration
To calibrate the indicator using Re volution, the
indicator must be in setup mode with the EDP port
connected to a PC running the Revolution configuratio
utility. Use the follo wing procedure to calibrate the
indicator:
1. Select Calibrate Indicator from the Revolution
main menu.
2. On the Weight Calibration display, select the
indicator model (IQ+210) and communications
port then click OK.
3. Revolution uploads calibration data from the
indicator then presents the information in a
display like that shown in Figure 4-3.
4. Enter the Value of Test Weight to be used for
span calibration then click OK.
5. The Zero Calibration dialog box prompts you
to remove all weight from the scale. Clear the
scale and click OK to begin zero calibration.
NOTE: If your test weights require hooks or
chains, place the hooks or chains on the scale
for zero calibration.
6. When zero calibration is complete, the Span
Calibration dialog box prompts you to place
test weights on the scale for span calibration.
Place tests weights on the scale then click OK.
7. The Rezero dialog box prompts you to remo ve
all weight, from the scale (including hooks or
chains). Remove the weights then click OK.
8. When calibration is complete, the New
Settings fields of the Weight Calibration
display are filled in. Click Exit to save the new
values and return to the Revolution main menu;
to restore the previous calibration values, click
Restore Settings.
Figure 4-3. Revolution Calibration Display

22 IQ plus 2100 Installation Manual
5.0 EDP Commands
The IQ plus 210 indicator can be controlled by a
personal computer or remote keyboard connected to the
indicator serial port. Control is pro vided by a set of
EDP commands that can simulate front panel key press
functions, display and change setup parameters, and
perform reporting functions. The EDP port provides the
capability to print configuration data or to s ve that data
to an attached personal computer . This section
describes the EDP command set and procedures for
saving and transferring data using the serial port.
5.1 The EDP Command Set
The EDP command set can be divided into fi e groups:
key press commands, reporting commands, the
RESETCONFIGURATION special function
command, parameter setting commands, and transmit
weight data commands.
When the indicator processes an EDP command, it
responds with the message OK. The OK response
verifies that the command w as received and has been
executed. If the command is unrecognized or cannot be
executed, the indicator responds with ??.
The following sections list the commands and
command syntax used for each of these groups.
5.1.1 Key Press Commands
Key press EDP commands (see T able 5-1) simulate
pressing the buttons on the front panel of the indicator.
5.1.2 Reporting Commands
Reporting commands (see T able 5-2) send specifi
information to the EDP port. These commands can be
used in both setup mode and normal mode.
5.1.3 The RESETCONFIGURATION Command
The RESETCONFIGURATION command can be used
to restore all configuration parameters to their de ault
values.
This command is equi valent to using the RESET
function on the DEFLT menu.
NOTE: All load cell calibration settings are lost when the
RESETCONFIGURATION command is run.
5.1.4 Parameter Setting Commands
Parameter setting commands allo w you to display or
change the current v alue for a particular configuratio
parameter (Tables 5-3 through 5-8).
Current configuration parameter settings can b
displayed in either setup mode or normal mode using
the following syntax:
command<ENTER>
Most parameter v alues only can be changed in setup
mode. Use the follo wing command syntax when
changing parameter values:
command=value<ENTER>
where value is a number or a parameter v alue. Use no
spaces before or after the equal (=) sign. If you type an
incorrect command or v alue, the display reads ??.
Changes to the parameters are saved as they are entered
but typically do not tak e effect until you e xit setup
mode.
For example, to set the motion band parameter to 5,
type the following:
MOTBAND=5D<ENTER>
Command Function
KZERO Press the ZERO button
KUNITS Press the UNITS button
KPRIM Display primary units
KPRINT Send demand data to serial port
KRIGHTARROW In setup mode, move right in the menu
(press the UNITS button)
KENTER In setup mode, press the ENTER
(ZERO) button
KEXIT In setup mode only, exit setup mode
Table 5-1. EDP Key Press Commands
Command Function
DUMPALL List all parameter values
VERSION Write IQ plus 210 software version
PWrite current displayed weight. See
Section 6.2 on page 26 for more
information.
ZZ Write current weight and annunciator
status. See Section 6.2 on page 26 for
more information.
RS Reset the indicator
SWrite one frame of stream format
Table 5-2. EDP Reporting Commands
