Rice Lake VS-11 User manual

VS-11
Dual-Range Veterinary Scale
Technical Manual
September 11, 2023 PN 220916 Rev A

Revision History
© Rice Lake Weighing Systems ● All Rights Reserved 3
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
Revision History
This section tracks and describes the current and previous manual revisions for awareness of major updates and when the
updates took place.
Revision Date Description
A September 11, 2023 Revision history established
Table i. Revision Letter History

VS-11 Dual-Range Veterinary Scale
4 Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.0 Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1 Display Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 Initial Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.3 Set Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.3.1 KG Units Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.3.2 LB/OZ Units Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.3.3 Unlock Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.4 Weigh With A Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.5 Weigh Without A Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.0 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.1 Firmware Version 2016 and After . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.1.1 Toggling Calibration between Pounds and Kilograms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.1.2 Calibrating with Pounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.1.3 Calibrating with Kilograms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.2 Firmware Version Prior to 2016 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5.0 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.1 Basic Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.2 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.3 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6.0 Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Contents

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 5
1.0 Introduction
The Rice Lake Dual-Range Veterinary Scale (VS-11) provides precise weighing of animals for accurate, reliable and
repeatable weighments. Movement compensation technology eliminates errors caused by spontaneous movement of the
animal and the weight can be displayed in pounds/ounces or in kilograms.
Manuals are available from Rice Lake Weighing Systems at www.ricelake.com/manuals
Warranty information is available at www.ricelake.com/warranties
Figure 1-1. VS-11 Dual-Range Veterinary Scale
1.1 Safety
Safety Definitions:
DANGER: Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes
hazards that are exposed when guards are removed.
WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes
hazards that are exposed when guards are removed.
CAUTION: Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.
IMPORTANT: Indicates information about procedures that, if not observed, could result in damage to equipment or
corruption to and loss of data.
General Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood.
Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake
Weighing Systems dealer for replacement manuals.
WARNING
Failure to heed could result in serious injury or death.
Ensure every individual operating or working with this unit has read and understands the following safety information.
Do not transport the scale with an animal on the weighing tray.
Clean the scale regularly to avoid cross contamination.
Do not allow minors (children) or inexperienced persons to operate this scale.
Do not use in the presence of flammable materials.
Do not use this product if any of the components are loose or cracked.
Do not drop the scale or subject it to violent shocks.
For accurate weighing, the scale must be placed on a level, stable surface.
Weight exceeding the maximum rated scale capacity may damage the scale.
Avoid contact with excessive moisture.
Do not make alterations or modifications to the scale; any alterations void the warranty.
For accurate weighing, verify proper setup is complete prior to first use. See Section 3.2 on page 8.
Operation at voltages and frequencies other than specified could damage the scale.
Utilizing adapters not supplied by Rice Lake Weighing Systems voids all warranties.
i

VS-11 Dual-Range Veterinary Scale
6 Visit our website www.RiceLake.com
2.0 Setup
The VS-11 comes fully assembled and includes the scale and a 120 V adapter. Immediately after unpacking, visually inspect
the VS-11 to ensure all components are included and undamaged. If parts were damaged in shipment, notify Rice Lake
Weighing Systems and the shipper immediately.
Use the following instructions for scale setup:
1. Place the scale on a sturdy, level surface.
2. Connect the 120 V adapter to the back of the scale.
3. Plug the AC adapter into a power source.
Figure 2-1. AC Power Connection Site
The VS-11 can also be powered by four AA alkaline batteries if an additional power source is not available. A battery powered
scale automatically turns off after two minutes of not being used to save battery life. Replace the batteries or connect to an AC
power source as soon as possible if the low battery indicator (Lo) displays.
Figure 2-2. Low Battery Indicator
AC Power Connection
120 V Adapter

Operation
© Rice Lake Weighing Systems ● All Rights Reserved 7
3.0 Operation
The VS-11 accurately weighs animals up to 44 lb (20 kg) and features a dual-range capacity for increased precision from
0-22 lb (0-10 kg). The weighing surface also includes a ruler for measuring the length of the animal. The built-in ruler can
measure animals up to 22.5 in (57 cm).
NOTE: If the scale is battery powered and has not been used for two minutes, it automatically turns off to save battery life.
3.1 Display Descriptions
The following section describes the VS-11 operating keys and their functions.
Figure 3-1. VS-11 Display
NOTE: The VS-11 comes pre-calibrated from the factory.
Item Description Function
1 Motion annunciator Displays when a weight reading is complete
2 Negative/Minus annunciator Indicates a negative weight reading
3 Zero annunciator Indicates the scale is stable and ready for use
4 Memory annunciator Indicates the last weight measurement is displayed after pressing RECALL
5 6-Digit LCD digital display Displays the weight in pounds/ounces or kilograms
6 On/Off Press to turn On
Press and hold to turn Off
Tare With weight on the scale, short press to tare off the weight, 0 displays
7 LB/KG Selects pounds/ounces or kilograms
8 RECALL Recalls the last weight measurement
Example: Weigh an animal on the scale and then remove the animal
Press RECALL and the animal’s weight displays again
9 LB/OZ annunciator Indicates the scale is weighing in pounds/ounces
KG annunciator Indicates the scale is weighing in kilograms
Table 3-1. Front Panel with Annunciators Displayed
ON/TARE
LB/KG
RECALL
zero mem lb oz
1
2
34
6
7
8
5
9

VS-11 Dual-Range Veterinary Scale
8 Visit our website www.RiceLake.com
3.2 Initial Setup
Use the following steps to set up and verify the VS-11 upon initial power up and periodically thereafter.
1. Plug AC adapter cable into the back of the scale (Figure 2-1 on page 6) and the AC adapter plug into a power source.
2. Turn on the scale. A self test runs and 0.00.0 lb or 0.00 kg displays when complete.
3. Place a weight, not exceeding 40 lb, on the scale. The weight measurement is complete when Ο displays.
4. Press to select unit of measure, lb/oz or kg.
5. Remove the weight from the scale. To display the weight again, press .
NOTE: If setup procedure fails, see Section 5.3 on page 12. If problem is not resolved, refer to a qualified service provider.
3.3 Set Units
The VS-11 can be set to display weights in lb/oz only, kg only, or to toggle between lb/oz and kg units on the scale.
3.3.1 KG Units Only
Lock the weight units to display in kg only.
1. Ensure the scale is turned on.
2. Press to change the displayed units to kg.
3. Press and hold for five seconds until kg flashes.
4. Release . The weight units are now locked in kg. Pressing does not switch units to lb/oz.
3.3.2 LB/OZ Units Only
Lock the weight units to display in lb/oz only.
1. Ensure the scale is turned on.
2. Press to change the displayed units to lb/oz.
3. Press and hold for five seconds until lb oz flashes.
4. Release . The weight units are locked in lb/oz. Pressing does not switch units to kg.
3.3.3 Unlock Units
Unlock the weight units to toggle between lb/oz and kg.
1. Ensure the scale is turned on.
2. Press and hold for five seconds until kg or lb oz flashes.
3. Release . Pressing toggles units between lb/oz and kg.
LB/KG
RECALL
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG

Operation
© Rice Lake Weighing Systems ● All Rights Reserved 9
3.4 Weigh With A Tare
The tare function removes the weight of additional items on the scale, such as a pad or collar, at the time the animal is weighed.
1. Turn on the scale. 0:0.0 lb oz or 0.00 kg displays.
2. Place a collar on the weighing tray. Ο displays when the weight reading is complete.
3. Press to remove the weight of the collar or any other accessory on the weighing tray.
4. Place an animal on the scale. Ο displays when the weight reading is complete.
5. Remove the animal from the scale.
6. Press to display the weight again, if necessary.
3.5 Weigh Without A Tare
Use this procedure when there are no additional items on the scale at the time the animal is weighed.
1. Turn on the scale. 0:0.0 lb oz or 0.00 kg displays.
2. Place an animal on the scale. Ο displays when the weight reading is complete.
3. Remove the animal from the scale.
4. Press to display the weight again, if necessary.
ON/TARE
RECALL
RECALL

VS-11 Dual-Range Veterinary Scale
10 Visit our website www.RiceLake.com
4.0 Calibration
This section contains procedures on how to calibrate the VS-11 based on the year of the firmware version.
4.1 Firmware Version 2016 and After
Use the following instructions to calibrate the VS-11 with a newer version of firmware.
NOTE: Ensure the scale is installed on a level surface.
The scale needs to be off at the start of the calibration procedure.
Calibration is performed using two 20 lb calibration weights or two 10 kg calibration weights.
4.1.1 Toggling Calibration between Pounds and Kilograms
IMPORTANT: The VS-11 must be configured to calibrate in pounds or kilograms. Ensure that the correct calibration units
have been selected before calibrating.
Perform the following steps to select and toggle calibration units from pounds to kilograms.
1. Press to turn the scale on.
2. Press and (at the same time). UNIT 1 displays.
3. Press . CAL displays and lb lights.
4. Press to switch to kg. CAL displays and kg lights.
5. Press and hold to turn the scale off.
4.1.2 Calibrating with Pounds
1. Ensure the scale is turned off.
2. Press and (at the same time). The raw A/D counts display.
3. Press again. CAL20 displays.
4. Load the scale with a 20 lb test weight. CAL40 displays.
5. Load the scale with a second 20 lb test weight to equal a total of 40 lb.
6. End briefly displays and scale returns to weigh mode. 40.00 displays.
7. Place a known weight onto the scale to confirm the correct calibration. If not correct, repeat the calibration procedure.
4.1.3 Calibrating with Kilograms
1. Ensure the scale is turned off.
2. Press and (at the same time). The raw A/D counts display.
3. Press again. CAL10 displays.
4. Load the scale with a 10 kg test weight. CAL20 displays.
5. Load the scale with the second a 10 kg test weight to equal a total of 20 kg.
6. End briefly displays and scale returns to weigh mode. 20.00 displays.
7. Place a known weight onto the scale to confirm the correct calibration. If not correct, repeat the calibration procedure.
ON/TARE
LB/KG
ON/TARE
ON/TARE
LB/KG
ON/TARE
LB/KG
ON/TARE
ON/TARE
LB/KG
ON/TARE
ON/TARE
