882IS Intrinsically Safe Indicator
Battery Tester Instructions
This document contains important 882IS battery tester safety, operation and set up instructions. Before using the battery tester,
please read all instructions and cautionary information on the battery tester and the 882IS. More information on the 882IS
indicator can be found at www.ricelake.com/882IS.
Manuals and additional resources are available from Rice Lake Weighing Systems at www.ricelake.com/manuals
Warranty information can be found on the website at www.ricelake.com/warranties
Follow all manufacturer safety precautions for the indicator, the battery charger and the battery.
Only use Rice Lake Weighing Systems approved charger for 882IS indicator batteries.
Batteries produce explosive gases and can explode.
Because hydrogen gas may be present, disconnect battery charger unit from AC power before connecting or
disconnecting output connectors from the battery.
Battery pack must be removed from the 882IS unit and taken to a non-hazardous location before testing.
Do not expose the tester to rain or moisture.
Do not disassemble.
Disconnect the tester from both the charger and the battery before maintenance or cleaning.
Connections to the battery must be made in the non-hazardous area before connecting the cable to the 882IS
indicator.
Battery must be fully charged for a healthy battery confirmation.
If modifications are made to the battery or it is changed in any way including field repair or modification, the FM
approval is void and all warranties, expressed or implied, are void. The customer becomes fully responsible and
liable for all such modifications.
Introduction
The 882IS Battery Tester is an instrument designed to test the six-volt, sealed, lead-acid batteries in the 882IS. While the
instrument is connected to the battery, it continuously measures the battery terminal voltage. When the Apply Load button is
pressed, the instrument measures voltage of the battery while it is under a full load. While the tester is connected to both the
battery and the IS6V2 battery charger, and the Apply Charge button is pressed, the instrument measures voltage going into
the battery from the battery charger.
Figure 1. 882IS Battery Tester
WARNING
CAUTION
IMPORTANT
Apply Charge
Button
Connector to
Battery
Connector to
IS6V2 Battery
Charger
Apply Load
Button
LED Display
PN 207786 Rev A
March 31, 2022

230 W. Coleman St. • Rice Lake, WI 54868 • USA
U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe [phone]
© Rice Lake Weighing Systems Specifications subject to change without notice.
www.ricelake.com
PN 207786 Rev A
March 31, 2022
Battery Test Connection Procedure.
1. Disconnect the 882IS battery cable from the 882IS indicator.
2. Remove the battery pack from the battery mount and take to a non-hazardous area.
3. Remove the lockout device and battery cable from the battery.
4. Plug the connector from the battery charger into the connector on the battery tester and
the the connector from the battery tester into the connector on the battery.
5. Connect the charger power cord to a properly grounded outlet supplying the correct input
voltage.
The 882IS battery tester is powered by the battery being tested. If the tester does not illuminate, the battery voltage is
too low to power the tester or the protection circuit in the battery pack is damaged.
Apply Load
When the Apply Load button is pressed, the instrument measures voltage of the battery while it is under a full load.
Press Apply Load on the battery tester for a few seconds to test the health of the battery.
Apply Charge
When the charger and tester are connected to power and the Apply Charge button is pressed, the instrument measures
voltage going into the battery from the battery charger.
Press Apply Charge on the battery tester for a few seconds to test the health of the battery barrier and connection to the charger.
To disconnect the battery tester from the battery, follow the connection steps in reverse order.
If battery is tested to be weak or unhealthy, do not attempt to repair the battery. Call Rice Lake Weighing Systems
technical support at 800-472-6703.
Healthy Battery Results Weak Battery Results
Displayed voltage:
• Immediately decreases slightly
• Displays a voltage of a value greater than or equal to 5.7 VDC
Displayed voltage:
• Fully charged battery displays a voltage of a value less than
5.7 VDC
Table 1. Apply Load Result Parameters
Healthy Battery Barrier and Charger Results Unhealthy Battery Barrier and Charger Test Results
Displayed voltage:
• Slowly increases as button is held down
If the voltage does not increase, it could mean:
• Battery charger is not connected, not powered up, or is defective
If the voltage is not displayed, it could mean:
• The battery pack is not connected
• The battery pack protection circuit is defective
• There is physical damage to the battery, connector or cable
Table 2. Apply Charge Result Parameters
Figure 2.
Remove Lockout Device
