Rich Context KWS0059-WM User manual

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
PARTS LIST KWS0059-WM
PART
NO. MATERIAL CODE PART Q’TY
1
2
3
4
5
6
8
7
9
10
11
12
13
24
2
1
1
2
26
32
1
1
1
1
1
1
PAGE 1 OF 3 COURTYARD CREATIONS INC.
STOP DON’T RETURN TO STORE!
Attention:
Make sure that each bolt needed for all steps matches the corresponding
figure to ensure proper assembly.
Step 1:
Place the left seat (#1) onto a non-abrasive surface, such as a carpet, with its
underside facing upwards. Fasten left leg A (#3) to the underside of the left
seat (#1) by using bolts (#9) and washers (#11). Keep the bolts loose.
See Figure 1.
KWS0059-CS03
18000337004
KWS0059-CS06
BOLT CAP
BOLT M6*28
BOLT M6*16
HEX.KEY WRENCH 4MM
17KAA0101----Y4
WASHER d6.5*D13*1.0RIGHT LEG A
LEFT LEG B
LEG
BACK ASSEMBLY
LEFT LEG A
RIGHT SEAT
LEFT SEAT
KWS0059-CS05
RIGHT LEG B
KWS0059-CS01
KWS0059-CS02
KWS0059-CS04 17FA05040301-Y4
17C24A0759131Y4
17C33A0706001Y4
FIGURE 1
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
required.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
Quote the following FQC NO. when contacting the service center.
!
!
!
!
SERVICE CENTER TOLL FREE NO.
TEL: [phone]
FAX: [phone]
Note:
The labels marked “L” and “R” on the seats (#1 and #2) and legs (#3, #4 ,#5,
and #6) should coincide with Figure 1 to Figure 4 to ensure proper assembly.
16
#9 BOLT M6*16
1
399
11 11
12 12
KWS0059-CS07
KWS0059-CS08
L
L

PAGE 2 OF 3
STOP DON’T RETURN TO STORE!
FIGURE 2 FIGURE 3
FIGURE 4 FIGURE 5
FIGURE 6 FIGURE 7
Step 2:
Fasten left leg B (#5) to the underside of the left seat (#1) by using bolts (#9)
and washers (#11). Fasten the brace on left leg A (#3) to left leg B (#5) by using
bolts (#9) and washers (#11). Tighten all of the bolts. See Figure 2.
Step 4:
Fasten right leg B (#6) to the underside of the right seat (#2) by using bolts
(#9) and washers (#11). Fasten the brace on right leg A (#4) to right leg B (#6)
by using bolts (#9) and washers (#11). Tighten all of the bolts. See Figure 4.
Step 6:
Fasten the legs (#7) to the seats (#1 and #2) by using bolts (#10) and washers
(#11). Make sure that all of the bolts have been tightened completely and
cover them with bolt caps (#12).
Step 7:
Close the seats (#1 and #2) as shown in Figure 7.
Step 5:
Fasten the legs (#7) to the back assembly (#8) by using bolts (#9) and washers
(#11). Keep the bolts loose. See Figure 5.
16
#9 BOLT M6*16
16
#9 BOLT M6*16
16
#9 BOLT M6*16
16
#9 BOLT M6*16
3
51
9
9
12
12
11
11
9
9
11
11
12
12
2
4
9
11
12 12
9
11
9
11
12
9
11
12
9
9
12
12
11
11 8
779
911
11
12
12
Step 3:
Place the right seat (#2) onto a non-abrasive surface, such as a carpet, with its
underside facing upwards. Fasten right leg A (#4) to the underside of the right
seat (#2) by using bolts (#9) and washers (#11). Keep the bolts loose.
See Figure 3.
R
R
R
L
6
42
77
21
10
12
11
Note:
The arrow marks on the legs (#7) should coincide with Figure 5 to ensure proper
assembly.
28
#10 BOLT M6*28
12
12
12

PAGE 3 OF 3
STOP DON’T RETURN TO STORE!
FIGURE 8 FIGURE 9
FIGURE 11
FIGURE 10
A B C D
Step 8:
Connect the two seats together by following step A, step B, step C, and step D.
See Figure 8.
Step 9:
When converting the back to a table, unlock the connector underneath the seats
and separate the two seats.
Step 11:
After the table top of the back assembly has been liftedup, press the safety locks
(2 sides) as shown in Figure 11.
Step 10:
Lift up the back assembly (#8) to create the table top. See Figure 10.
Cleaning and Maintenance
• Wash frame parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach, acid, or other solvents on the frame parts.
• We recommend the use of furniture covers when not in use.
• Inspect and tighten all bolts and fasteners on a regular basis to ensure the proper performance and safety of your bench.
• In order to prolong the life and beauty of your bench, we recommend that it be stored in a dry and protected area during off season periods.
READ THESE INSTRUCTIONS COMPLETELY BEFORE STARTING ASSEMBLY
SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU
HAVE ALL OF THEPARTSLISTED.
IF YOU DO NOTLOCATE ALL OF THE PARTS LISTED, INSPECT THE
PACKING MATERIAL FOR SMALL PARTSTHAT MAYHAVEBECOME
SEPARATED DURING SHIPMENT.
IF YOU EXPERIENCEANYDIFFICULTY DURING ASSEMBLYOR IF ANY
PARTS ARE MISSING OR DAMAGED,CALL THE HELP LINE AT 1-877-539-7436
BEFORERETURNING THIS ITEM TO THESTORE.
PROVIDE THEFOLLOWING INFORMATION WHEN CALLING:
1-MODEL NUMBER OF THEPRODUCT.
2-PARTNUMBER AND MATERIAL CODE OF THE PARTFROM THE PARTS LIST
MOST PROBLEMSCAN BERESOLVED WITHOUT RETURNING THIS PRODUCT
TO THERETAILER.
