Ricoh Aficio MP 6002 Owner's manual

Version: 1.0 Classification: Ricoh Family Group Internal Use Only
Created by: Technical Support Department Page 1 of 47 Last Printed: 15-Jun-12
Technician Version R
Date: 4th June 2012
Aficio MP 6002 (SP)
Aficio MP 7502 (SP)
Aficio MP 9002 (SP)
Technician Technical
Launch Information
www.ricohtechnical.co.uk
follow RUKTechSupport

15/06/2012 MP6002/7502/9002 Technical Launch Information
2
DOCUMENT REVISION LIST
REVISION DATE CHAPTER PAGE(S) DESCRIPTION

15/06/2012 MP6002/7502/9002 Technical Launch Information
3
Table of Contents
1.INTRODUCTION 6
1.1GENERAL 6
1.2INSTALLATION 6
1.3WARRANTY 6
1.4CAUTIONS 6
2.CONFIGURATION 7
2.1COPIER 7
2.2NRG BRAND PLAQUE 7
2.3EXTERNAL OPTIONS 8
2.4INTERNAL OPTIONS 9
2.5THIRD PARTY OPTIONS 9
2.6OPTION INTERCHANGEABILITY 10
2.7OPTION CORRELATION INTERCHANGEABILITY 12
2.8UPGRADE PATH 13
3.SPECIFICATION 14
3.1COPIER 14
3.2OPTIONS 15
3.2.1ARDF SPECIFICATIONS (STANDARD ) 15
3.2.2LCIT RT4010 (D613) 16
3.2.3A3TRAY (TYPE 9001 –D482) 17
3.2.4TAB SHEET UNIT (TYPE 9002 –B499) 17
3.2.5FILE FORMAT CONVERTER (TYPE E–D377) 17
3.2.6JOGGER UNIT (TYPE 9002A –B703) 17
3.2.73000 SHEET FINISHER (SR4080 –D610) 18
3.2.8PUNCH UNIT (TYPE 1075 –B531) 19
3.2.99-BIN MAILBOX (CS4000 –D616) 19
3.2.102000 SHEET FINISHER (SR4060 –D611) 20
3.2.11LG/B4 KIT (TYPE TYPE 9002 –B474) 21
3.2.12PUNCH UNIT FOR SR4060/4070 (TYPE 3260 –B702) 21
3.2.13JOGGER OPTION (TYPE 3260 –B703) 21
3.2.1COVER INTERPOSER TRAY (TYPE CI4000 –B614) 21
3.2.2MULTI-FOLDING UNIT (FD4000 –D615) 22
3.33000 SHEET FINISHER (SR4080 –D610) 23
3.4PRINTER SPECIFICATION 24
3.5SUPPORTED ENVIRONMENTS 24
3.6PRINTER DRIVER SPECIFICATIONS 25
3.7SCANNER SPECIFICATIONS 27
3.7.1GENERAL SPECIFICATIONS 27
3.7.2SCAN TO EMAIL 28
3.7.3SCAN TO FOLDER 29
3.7.4MAXIMUM ADDRESS NUMBERS PER SENDING 29
3.8FAX UNIT TYPE 9002 30
3.8.1GENERAL SPECIFICATIONS 30
3.9WIRELESS LAN 31
3.10DOCUMENT SERVER 31

15/06/2012 MP6002/7502/9002 Technical Launch Information
4
4.PRODUCT USER REMARKS 32
4.1METER READINGS 32
5.ENVIRONMENTAL, HEALTH AND SAFETY 33
5.1GENERAL 33
6.PRODUCT TRAINING 34
7.INSTALLATION 35
7.1GENERAL 35
7.2MINIMUM SPACE REQUIREMENTS 35
7.3INSTALLATION TIME 37
7.4METER CHARGING SETTINGS AT INSTALLATION 37
8.SERIAL NUMBER 38
8.1MAINFRAME 38
8.23000 SHEET FINISHER (100 SHEET STAPLER) 39
8.33000 SHEET FINISHER (50 SHEET STAPLER) 39
8.42000 SHEET FINISHER 39
8.5MULTI-FOLDING UNIT 39
8.6LCT 39
8.79BIN MAILBOX 39
8.8COVER INTERPOSER 39
8.9PUNCH UNIT SR4080 39
8.10PUNCH UNIT SR4070/4060 40
8.11JOGGER UNIT SR4080 40
8.12JOGGER UNIT SR4040/4030 40
8.13FAX UNIT 40
8.14MODEL OVERVIEW 40
9.TECHNICAL DOCUMENTATION 41
9.1RICOH TECHNICAL BULLETIN (R.T.B.) 41
9.2MODIFICATION BULLETIN (M.B.) 41
9.3PCIL 41
9.4SERVICE MANUALS /PARTS CATALOGUES 41
9.5RICOH UK TECHNICAL WEBSITE 41
10.TECHNICAL SUPPORT DEPARTMENT 42
10.1HELPDESK 42
10.2FAULT ESCALATION PROCEDURE 42
11.WARRANTY 43

15/06/2012 MP6002/7502/9002 Technical Launch Information
5
12.PERFORMANCE DATA 44
12.1PRODUCT DESIGN LIFE 44
12.2RELIABILITY TARGETS 44
12.3AVERAGE MONTHLY VOLUME 44
12.4MAXIMUM MONTHLY VOLUME 44
12.5PM PARTS (MAINFRAME) 45
12.6SUPPLIES 45
12.7STAPLES 46
13.QUICK REFERENCE GUIDE 47

15/06/2012 MP6002/7502/9002 Technical Launch Information
6
1. INTRODUCTION
1.1 GENERAL
The Aficio MP6002 (SP) / MP7502 (SP) / MP9002 (SP) replaces the very successful Aficio
MP6001/MP7001/MP8001/MP9001.
1.2 INSTALLATION
As the installation procedure for this machine is vital to its performance, it is recommended
that the Aficio MP6002/6002SP/7502/7502SP/9002/9002SP machines are installed by a
technician who has successfully completed the Aficio
MP6002/6002SP/7502/7502SP/9002/9002SP training course.
1.3 WARRANTY
Please refer to Section 11 for full details on Warranty cover on this product.
1.4 CAUTIONS
Ricoh carries out a continuous program of product development and improvement.
Therefore specifications, parts, code numbers and prices are subject to change and
should always be verified with current documentation.
Whilst every effort has been made to ensure the accuracy of information in this package
Ricoh cannot accept responsibility for any errors or omissions.

15/06/2012 MP6002/7502/9002 Technical Launch Information
7
2. CONFIGURATION
2.1 COPIER
UNIT TYPE PRODUCT NUMBER EDP CODE
Aficio MP6002 D131-27 416398
Aficio MP6002SP D132-67 416399
Aficio MP7502 D133-27 416400
Aficio MP7502SP D131-67 416401
Aficio MP9002 D132-27 416402
Aficio MP9002SP D133-67 416403
English Operating Instructions OI 975042
NOTE:Document Feeder is fitted as standard with these products.
SP Model includes Printer / Scanner option.
2.2 NRG BRAND PLAQUE
UNIT TYPE PRODUCT NUMBER EDP CODE
MP6002 Brand Plaque D131-27 416277
MP6002SP Brand Plaque D132-67 416377
MP7502 Brand Plaque D133-27 416282
MP7502SP Brand Plaque D131-67 416378
MP9002 Brand Plaque D132-27 416287
MP9002SP Brand Plaque D133-67 416379

15/06/2012 MP6002/7502/9002 Technical Launch Information
8
2.3 EXTERNAL OPTIONS
OPTION NAME EDP CODE
Finisher 3000 Sheets (100 sheet stapler) SR4080 415900
Output Jogger Unit For SR4080 Output Jogger Unit Type
9002B 416231
Finisher 3000 Sheets (50 Sheet Staple) SR4060 415901
Finisher 2000 Sheets Booklet Finisher SR4070 415902
Output Jogger Unit For SR4060/4070 Output Jogger Unit Type
9002A 415903
LCIT RT4010 Large Capacity Unit 415905
LG Size Paper Tray 81/2” X 14” Paper Size Tray
Type 9002 416232
Cover Interposer Cover Interposer Tray
Cl4000 415906
9 Bin Mail Box Mail Box CS4000 415907
Copy Tray Copy Tray Type 9002 416229
Multi-Folding Unit Multi-Folding Unit FD4000 415909
Tab Sheet Holder Tab Sheet Holder Type 9002 416230
Victoria Punch Unit NA 3/2 Punch Unit Type 1075 NA
3/2 415282
Victoria Punch Unit EU 2/4 Punch Unit Type 1075 EU
2/4 415283
Victoria Punch Unit S4 Punch Unit Type 850 S4 415284
Euphrates Punch Unit NA 3/2 Punch Unit Type 3260 NA
3/2 412209
Euphrates Punch Unit 2/4 EU Punch Unit Type 3260 2/4
EU 412210
Euphrates Punch Unit SC Punch Unit Type 3260 SC 412211
A3/DLT Tray A3/11”X17” Tray Type 9001 415017
Key Card Bracket Key Card Bracket 411203
Key Counter Bracket Key Counter Bracket 412537
Accessibility Handle ADF Handle Type c 416213

15/06/2012 MP6002/7502/9002 Technical Launch Information
9
2.4 INTERNAL OPTIONS
OPTION NAME EDP CODE
Optional Counter Interface Unit Optional Counter Interface Unit
Type A 413012
32MB Type BUK 32MB Type buk 924424
Data Over Write Security Unit Data Over Write Security Unit Type
H 416373
Copy Data Security Unit Copy Data Security Unit Type F 413985
File Format Converter File Format Converter Type E 414007
Gigabit Ethernet Gigabit Ethernet 414204
IEEE 1284 Interface Board IEEE 1284 Interface Board Type A 411699
IEEE 802.11a/g Interface Unit IEEE 802.11a/g Interface Unit
Type J 414009
IEEE 802.11g Interface Unit IEEE 802.11g Interface Unit 414186
Bluetooth Interface Bluetooth Interface Type D 415818
Copy Connector Copy Connector Type 3260 412415
VM Card VM Card Type U 416164
Fax Unit Fax Option Type 9002 415918
G3 Unit G3 Interface Unit Type 9002 415918
Printer/Scanner Unit Printer/Scanner Unit Type 9002 415920
Postscript3 Postscript3 Unit Type 9002 415924
IPDS IPDS Unit Type 9002 415927
Fax Connection Unit Fax Connection Unit Type E 415930
Netware SD Card For NetWare Printing
Type L 416236
Browser Unit Browser Unit Type J 416234
2.5 THIRD PARTY OPTIONS
OPTION NAME EDP CODE
Unicode Font Package ( 1 license ) Unicode Font Package For Sap 1
License 413009
Unicode Font Package ( 10 license ) Unicode Font Package For Sap 10
License 413010
Unicode Font Package ( 100 license ) Unicode Font Package For Sap
100 License 413011

15/06/2012 MP6002/7502/9002 Technical Launch Information
10
2.6 OPTION INTERCHANGEABILITY
ITEM PRODUCT NAME REMARKS
Paper
Drawers 11”X17” / A3 Tray Unit Type 9002 New Item
Tab Sheet Unit Tab Sheet Holder
Type 9002 New Item
LCT A4/LT LCT RT4010 New Item
LG Unit For LCT 81/2”X14” Paper Size
Tray Type 9002 New Item
Finishing
Option
Copy Tray Copy Tray
Type 9002 New Item
3,000sheet Finisher
50sheet Staple SR4060 New Item
2,000sheet Finisher
Saddle Stitch Staple SR4070 New Item
3,000sheet Finisher
100sheet Staple SR4080 New Item
Punch Unit NA3/2
For 50 Staple/Saddle
Stitch
Punch Unit
Type 3260 NA 3/2 Common To MT- C3.5
Punch Unit EU2/4
For 50 Staple/Saddle
Stitch
Punch Unit
Type 3260 EU 2/4 Common To MT- C3.5
Punch Unit Scandinavian 4
For 50 Staple/Saddle
Stitch
Punch Unit
Type 3260 SC Common To MT- C3.5
Punch Unit NA3/2
For 100 Staple Punch Unit Type 1075 NA Common To MT- C3.5
Punch Unit EU2/4
For 100 Staple Punch Unit Type 1075 EU Common To MT- C3.5
Punch Unit
Scandinavian 4
For 100 Staple
Punch Unit
Type 1075 SC Common To MT- C3.5
Jogger Unit
For 50 Staple/Saddle
Stitch
Output Jogger Unit
Type 9002A New Item
Jogger Unit
For 100 Staple/Saddle
Stitch
Output Jogger Unit
Type 9002B New Item
9-Bin Mailbox CS4000 New Item
Cover Interposer Cover Interposer Tray
Type CI4000 New Item
Multi-Folding Unit FD4000 New Item
Printer
Scanner
Printer Scanner Unit Printer/Scanner Unit Type 9002 New Item
Postscript 3 Postscript3 Unit Type 9002 New Item
Interface
Option IEEE1284 Centro IEEE 1284 Interface Board Type A Common To MT- C3.5

15/06/2012 MP6002/7502/9002 Technical Launch Information
11
Security
Option
Data Overwrite Unit DataOverwriteSecurity Unit Type
H
Unauthorized Copy Guard
Unit Copy Data Security Unit Type F Common to AP-C2
HDD Encryption HDD Encryption Unit
Connect
Copy Copy Connector Copy Connector
Type3260 (Common to Katana- C2)
Device SDK
Option VM Card VM Card Type U New Item
File Format
Convector File Format Converter File Format Converter Type H Common to MT-C4
Browser
Unit Browser Unit Browser Unit Type J New Item
FAX FAX Fax Option Type 9002 New Item
G3 Interface Unit G3 Interface Unit Type 9002 New Item
Others
Optional Counter I/F Optional Counter I/F Type A Common to MT-C4
Key Counter Bracket Key Counter Bracket
Type 1027 Common to MT-C4
Key Card Bracket Key Card Bracket
Type B Common to MT-C4
Copy Connector Copy Connector Type 3260 Common to V-C2
MTC-C4 = MP6001/7001/8001/9001
Katana C2 = Pro 907/1107/1357EX
AP–C2 = MPC4000/5000
VC2 = MPC6000/7500

15/06/2012 MP6002/7502/9002 Technical Launch Information
12
2.7 OPTION CORRELATION INTERCHANGEABILITY
1.DTL/A3 Tray- 2.Tab Sheet Holder 3.LCT 4.LCT LG Unit 5.Copy Tray 6.50sheet staple Fin SR4060 7.Saddle Stitch Fin SR4070 8.100sheet Staple Fin SR 4080
9
.
P
unc
h
U
n
it
s
f
or
Fi
n
SR4060/4070
10.Punch Unit for Fin SR4080 11.9-bin Mailbox 12.Cover Interposer
13
.
J
ogger
U
n
it
f
or
Fi
n
SR4060
/40
70
14.Jogger Unit for Fin SR 4080 15.Printer/Scanner Unit 16.PS3 17.EEE1284 Centro 18.Wireless LAN 19.Bluetooth 20.1000Base T Ethernet 21.USB Host I/F
2
2
.
U
nau
th
eror
i
ze
d
C
opy
Controlling
23.DOS Unit 24.VM Card Type U 25.Copy Connecto
r
26.File Form at Converter 27.Fax Option 28.G3 Interface Unit
29.USD2.0/SD Slot Type C 30.PDS Unit 31.Multi-Foldin
g
Unit FD4000
1.DTL/A3 Tray
2.Tab Sheet Holder
3.LCT
4.LCT LG Unit M
5.Copy Tray X X X X X X X X X
6.50sheet staple Fin
SR4060
X X X X X
7.50 sheets staples with
Saddle Stitch Fin SR4070
X X X X X
8.100sheet Staple Fin
SR4080
X X X X X X
9.Punch Units for
FinSR4060 & SR4070
X 1 1 X X X
10.Punch Unit for Fin
SR4080
X X X M X X X
11.9-bin Mailbox
X 1 1 X X X X
12.Cover Interposer
X 1 1 1 X
13.Jogger Unit for Fin
SR4060/SR4070
X 1 1 X X X
14.Jogger Unit for Fin
SR4080
X X X M X X X
15.Printer/Scanner Unit
16.PS3
M
17.IEEE1284 Centro
M
18.Wireless Lan
MXX
19. Bluetooth
MX X
20.1000B T Ethernet
MXX
21.USB Host
22. Unauthorised Copy
Control Unit
23.DOSUnit
24.VMCardTypeU
M
25.Copy Connector
26.FileFormatConverter
27.FAXOption M
28.G3 Interface Unit M
29.USD2.0/SD Slot Type
C
M
30.PDS Unit X 1 1
M
X
31.Multi-Folding Unit
FD4000
X
X: Cannot be installed together.
M: Must be installed together.
1: Must select one of these two options & install together.

15/06/2012 MP6002/7502/9002 Technical Launch Information
13
2.8 UPGRADE PATH
MP6002 MP7502 MP9002
Base models – no printing or scanning capabilities.
Can have Printer / Scanner and all other options added.
MP6002SP MP7502SP MP9002SP
As base models but with printing and scanning capability.
Can have all other options added.

15/06/2012 MP6002/7502/9002 Technical Launch Information
14
3. SPECIFICATION
3.1 COPIER
ITEMS SPECIFICATION
Configuration Console
Printing Process Four laser beams &
Electro-photographic printing
Scanning Element Simultaneous Double Sides Scanner
Flatbed with fixed CCD array image-sensing and Sheet through
with fixed CIS array image-sensing
Original Type Book/Sheet/Object
Original Size A3 – B6
11”x 17” – 5½” x 8½”(ADF)
Copy / print paper size Trays:
A3/DLT– A5/HLT
11”x 17” – 5½” x 8½”
Bypass (standard):
A3 – A6 SEF (A6 SEF: Bypass)
11”x 17” – 5½” x 8½”
Bypass (non-standard):
Vertical: 100-297mm /4”-12”
Horizontal: 140-432mm/5.5”-17”
Paper weight Tray(1-3):
52 - 216g/m2
(14-34lb bond)
Bypass(Standard):
52 - 216g/m2
(14-43lb bond)
Duplex:
64-169g/m2
(17-34lb bond)
A4/LCT
52 – 128g/m3
(14 – 34lb bond)
Reduction EU: 93,82,75,71,65,50,25%(7R)
Enlargement EU: 115,122,141,200,400%(5E)
Engine Speed MP6002: 60ppm
MP7502: 75ppm
MP9002: 90ppm
Resolution Marking: 1,200dpi
Scanning: 600dpi
Zoom 25-400%
Gradation Scanning: 256 scales
Marking: 2 levels (5 levels at max)
Warm-up time
MP6002 Less than 30 seconds MP7502 Less than 60 seconds
MP9002 Less than 300 seconds
1st Copy Speed MP6002: 3.9 seconds
MP7502: 3.2 seconds
MP9002: 2.9 seconds
Multiple copy Up to 999
Standard paper capacity 4,300 sheets
1st Tray: 1,550 x 2 (Tandem) sheets

15/06/2012 MP6002/7502/9002 Technical Launch Information
15
2ndTray: 550 sheets
3rdTray: 550 sheets
Bypass: 100 sheets
Maximum paper capacity 8,300 sheets
LCT: 4,000 sheets
Output capacity 500 sheets/A4,LT
250 sheets/A3, 11” x 17”
Memory Capacity RAM:512MB( Standard ) RAM:1GB (Upgrade)
1 GB (Base) 1.5 GB ( SP)
HDD: 250 GB
Rating power spec. MP6002/MP6002SP/MP7502/MP7502SP
EU/Asia: 220-240V, 50/60Hz, 8.5A
Power consumption MP6002/MP6001SP/MP7502/MP7502SP
Max 1.35kw
MP9002/MP9002SP
Max 1.84kw
Dimensions (W x D x H) Approx. 690 x 799 x 1,171 (mm)
Weight Less than 214 kg
3.2 OPTIONS
3.2.1 ARDF SPECIFICATIONS (STANDARD )
Dimensions (W x D x H) 680 x 560 x 180 mm
Weight Less than18Kg (39.6 lb)
Power consumption Less than 110W
Noise (power level) Less than 71db
Stack Capacity 150 Sheets (80g/m2)
250 Sheets (69g/m2)
Original size Simplex – B6-A3 (SEF)
Duplex – B5 – A3
Original Weight Simplex – 40 -128g/m2
Duplex – 52 – 128g/m2
Auto Original Size Detection A3 – 16K
Original set Position Left-Rear Corner / Face-up
Special Original Setting Batch, Mixed Size
Special original setting Batch and mixed sizes
Original feed speed FC: 55opm BK: 80opm

15/06/2012 MP6002/7502/9002 Technical Launch Information
16
3.2.2 LCIT RT4010 (D613)
(*1),(*2) (*3) with LG/B4 option, (*4) capacity calculated with 80 g/m2 / 20lb bond paper.
Paper capacity 4,000 sheets
2500 sheets (*3)
Paper Sizes
A4 LEF, B5 LEF, 8 Limitations
The following types of paper cannot be Multi-folded
Translucent paper
OHP transparencies
Labels
Tab stock
Thick paper
Paper of low stiffness
Multi-fold and punch cannot be used at the same time
Multi-folding unit and cover interposer can be installed
together but paper inserted from the cover interposer
cannot be folded.
Depending on the folding direction, rotated copy and z-
fold cannot be used together.
" x 11" LEF*1
Paper Weight 52 ~ 128 g/m2 (14 ~ 34 lb)
Pick-up and Feed FRR (Feed and Reverse Roller)
Power Consumption Less than 50 W (Max.)
Power Supply DC24 V, 5V (powered by the main unit)
Rated Voltage of Output
Connector Max. DC 24 V
Dimensions (W x D x H) 314 x 458 x 659 mm
462 x 458 x 659 mm ( with LG unit )
Weight 20.0 kg (44 lb )

15/06/2012 MP6002/7502/9002 Technical Launch Information
17
3.2.3 A3 TRAY (TYPE 9001 – D482)
A3 tray is fitted to the Tandem LCT in the first tray of the main frame and can feed A3
paper. The first tandem tray can normally feed A4 size paper only. Therefore it is useful for
users that require a lot of A3 usage.
Dimensions (W x D x H) 495 x 530 x 175 mm
Weight 10 kg
Paper size A3 SEF, B4 SEF,
Paper capacity 1000 sheets
3.2.4 TAB SHEET UNIT (TYPE 9002 – B499)
Dimensions (W x D x H) 66 x 280 x12 mm
Weight 50g
3.2.5 FILE FORMAT CONVERTER (TYPE E – D377)
When retrieving Document Server data that has been stored using copy or printer
applications, a File Format Converter is required. By attaching this option, the Ricoh
unique format is converted to a common file format (PDF / TIFF /JPEG).
3.2.6 JOGGER UNIT (TYPE 9002A – B703)
The Jogger Unit is installed above the shift tray of the 3000 Sheet Finisher D611/D612.
Paper Size A3-SEF,B4-SEF,11"x17"SEF
A4 LEF, B5 LEF, 8" x 11" LEF
Paper Weight 52 g/m2~ 216 g/m2 (14 ~ 58 lb)
Weight Less than 1.7 kg
Dimensions (W x D x H) 125 x 450 x 100 mm
Power Supply DC 24 V, DC 5V (From Finisher)
Power Consumption 24 W

15/06/2012 MP6002/7502/9002 Technical Launch Information
18
3.2.7 3000 SHEET FINISHER (SR4080 – D610)
UPPER TRAY
Paper Capacity (80 g/m2) 500 sheets (A4, 8½" x 11" and smaller)
250 sheets (B4, 8½" x 14" and larger)
Paper Size A3 to A6 SEF, 11" x 17" to 5½" x 8½", 12" x 18"
Paper Weight 52 to 216 g/m2
Upper Tray Full Detection Provided
SHIFT TRAY
Paper Capacity (80 g/m2) 3000 sheets (A4 LEF, B5 LEF, 8½" x 11" LEF)
1500 sheets (A3, A4 SEF, B4 and B5 SEF, 11" x 17",
8½" x 14", 8½" x 11" SEF, 12" x 18")
500 sheets (A5 LEF, 5½" x 8½" LEF)
100 sheets (A5 SEF, 5½" x 8½" SEF)
Paper Size A3 to A5, 11" x 17" to 5½" x 8½", 12" x 18" (including tab paper)
Paper Weight 52 to 216 g/m2
Shift Tray Full Detection Provided
STAPLER
Stapling Stack Size A4, B5, 8½" x 11" (Max. 100 Sheets)
A3, B4, 11" x 17", 8½" x 14" (Max. 50 sheets)
Stapling Paper Size A3 to B5
11" x 17" to 8½" x 11"
Stapling Paper Weight 64 to 80 g/m2
Staple Position 4 Modes
1 Staple: Front, Rear, Rear-Oblique
2 Stapes: 2 locations
Staple Capacity 5000 staples/cartridge
Staple Supply Cartridge or Staple Replacement
Stapled Stack Size Sheets Sets Sizes
10 ~ 100 200 ~ 30 A4 SEF, B5 SEF, 8½" x 11" SEF
A4 LEF, B5 LEF, 8½" x 11" LEF
2 ~ 9 150
10 ~ 50 150 ~ 30 A3, B4, 11" x 17", 8½" x 14"
2 ~ 9 150
Trim Waste Staple
Capacity 30,000 or more
Waste Staple Hopper Full
Detection Provided
Power Consumption Less than 100 W
Power Source DC 24 V (From Mainframe)
Size (W x D x H) 800 x 730 x 980 mm
Weight Less than 65 kg

15/06/2012 MP6002/7502/9002 Technical Launch Information
19
3.2.8 PUNCH UNIT (TYPE 1075 – B531)
Punch Specifications
Punching Allowed All modes
Allowed Paper Sizes Holes Feed Paper Size
2 holes SEF A3 ~ A5, 11" x 17" ~ 51/2" x 81/2"
LEF A4 ~ A5, 81/2" x 11", 51/2" x 81/2"
4 holes SEF A3, B4, 81/2" x 11"
LEF A4, B5, 81/2" x 11"
Allowed Paper Weight Holes Weight
2 holes 52 ~ 163 g/m2
(14 ~ 43 lb.)
4 holes
Rated Voltage of Output
Connector Max. DC 24 V
Dimensions (W x D x H) 700 x 620 x 960 mm
Weight Approx. 65 kg
Power Consumption 72 W (3 A/24 V)
Power Supply DC 24 V
Punch Hole Positions 2/4-hole
Punch Paper Size
4-Hole A3 SEF, 11" x 17" SEF
A4 LEF, 81/2" x 11" LEF
Paper Weight
4-Hole 52 g/m2~ 128 g/m2
Punch Waste Hopper Capacity
4-Hole 15K
Operation Modes All (Shift, Proof, Staple)
3.2.9 9-BIN MAILBOX (CS4000 – D616)
Bin Capacity 100 sheets per bin (80 g/m2)
Allowed Paper Sizes A3,A5
11" x 17" ~ 51/2" x 81/2"
Allowed Paper Thickness 52 ~ 128 g/m2
Power Consumption Less than 48W (average)
Power Supply DC 24 V, 5 V
Dimensions (W x D x H) 540 x 600 x 660 mm
Weight 15 kg
Note) CS4000 can not be fitted to the 100 sheet Staple Finisher SR4050 (It is only for 50
staple/Saddle stitch finisher)

15/06/2012 MP6002/7502/9002 Technical Launch Information
20
3.2.10 2000 SHEET FINISHER (SR4060 – D611)
Dimensions W x D x H 657 x 613 x 960 mm
Weight Less than 63kg
Less than 65kg with punch unit
Power consumption 96W or less
Noise 71dB or less
Configuration Console type attached base unit
Power source From base unit
Proof Tray
Stack
Capacity*
(1) not including Multi-folding paper
250 sheets A4, 8½ x 11 or smaller
50 sheets B4, 8½ x 14 or larger.
(2) Multi-folding paper only
30 sheets B4, 8½ x 14 0r larger
20 sheets A4, 8½ x 11 or smaller
Paper size
(1) Not including Multi-folding paper
A5 – A3 SEF, A6 SEF, A6 LEF
5½ x 8½ - 11 x 17 SEF, 12 x 18 SEF
(2) Multi-folding paper only
A3 SEF – A4 SEF, 5½x 8½ - 11 x 17 SEF, 12 x 18 SEF
Paper
Weight
(1) Not including Multi-folding paper
52 g/m2– 163 g/m2
(2) Multi-folding paper only
64 g/m2– 80 g/m2
Shift Tray
Stack
Capacity
(1) not including Multi-folding paper
2000 sheets A4, 8½ LEF x 11 LEF
1000 sheets A3SEF, A4 SEF, B4 SEF, B5
11 x 17 SEF, 8½ x 14 SEF
500 sheets A5 LEF
100 sheets A5 SEF, B6 SEF, A6 SEF,
5½ x 8½ SEF
(2) Multi-folding paper only
30 sheets B4, 8½ x 14 0r larger
20 sheets A4, 8½ x 11 or smaller
Paper size
(1) Not including Multi-folding paper
A5 – A3 SEF, A6 SEF, A6 LEF
5½ x 8½ - 11 x 17 SEF, 12 x 18 SEF
(2) Multi-folding paper only
A3 SEF – A4 SEF, 5½x 8½ - 11 x 17 SEF, 12 x 18 SEF
Paper
Weight
(1) Not including Multi-folding paper
52 g/m2– 256 g/m2
(2) Multi-folding paper only
64 g/m2– 80 g/m2
Remarks
* The capacity is calculated using 80g/m2/ 20lb bond paper.
It is not possible to select “Tab sheet” and “saddle stitch” at the same time.
