RideSafer Delighter JD16100 Series User manual

SAFE TRAFFIC SYSTEM DELIGHTER
BOOSTER
Type: Belt-positioning booster
Last date made: 2021
First made: 2016
Weight limits: 40 to 100 lbs. with vehicle lap and
shoulder belt; child must be at least four years old.
Backrest: N/A.
Belt path: Use vehicle lap-shoulder belt to restrain child. There is no
shoulder belt guide. Route both sides of the lap belt and lower end of
shoulder belt under armrest guides (diagram 1). Restraint may be
installed using inflatable safety belt.
Tether and LATCH: N/A.
Other: May be used with the Ride Safer Travel Vest.
Restraint expires 7 years from date of manufacture.
Important: This information sheet is not a substitute for complete manufacturer’s directions and current recall list.
SafetyBeltSafe U.S.A., P.O. Box 553, Altadena CA 91003 [phone] (800)745-SAFE ©SafetyBeltSafe U.S.A. #450 07/21
P. 1 of 1
1

™®
™®
S
A
F
E
T
R
A
F
F
I
C
S
Y
S
T
E
M
,
I
N
C
.
•
WARNING
Owner’s Manual
RideSafer Delighter
Booster Seat
Model Number: JD16100XXX
For Children:
40 to 100 lbs. (18 to 45 kg)
For use ONLY with vehicle lap and
shoulder belt.
NOT for use with vehicle lap belt only.
Carefully read and understand all instructions and warnings in
this manual. Failure to properly use this Booster Seat
increases the risk of serious injury or death in a sudden stop

2
Table of Contents
1.0 General Warnings and Information..............................................4
Features..........................................................................................
2.0 WARNINGS................................................................................6
3.0
3.1 Booster Seat (Front) 9
3.2 Booster Seat (Back)............................... 9
3.3 Booster Seat (Bottom) 10
4.0 Preparing Booster Seat for Use
4.1 Select a Vehicle Seating Location to
Install the Booster Seat..............................................................11
5.0 Proper Use Check List.................................................................
........................................................
..............................................................
.............................................................
11
9
6.0 Weight and Height Limits............................................................12
7.0 Selecting a Vehicle Seating Location.........................................13
7.1 Overall Considerations for Selecting
a Seating Location.....................................................................14
7.2 Seating Locations to Avoid.........................................................15
16
8.0 Booster Seat Installation and Use..............................................
8.1 Securing Child in Booster Seat
with Vehicle Lap and Shoulder Belt...........................................18
9.0 Vehicle Seat Belts
9.1 Check that the Vehicle Seat Belt is Safe to Use..........................21

3
Table of Contents
10.0 Additional Information
10.1 Certifications................................................................................25
10.2 Use with a RideSafer Travel Vest............................................. 25
10.3 Discontinue the Use of Booster Seat........................................ 25
26
26
27
11.0 Cleaning and Maintenance........................................................
12.0 Replacement Parts.....................................................................
13.0 Booster Seat Registration.........................................................

4
1.0 General Warnings and Information
WARNING
READ AND UNDERSTAND ALL INSTRUCTIONS IN THIS MANUAL AND IN
YOUR VEHICLE OWNER’S MANUAL BEFORE INSTALLING OR USING
THIS BOOSTER SEAT. THE CHILD’S SAFETY DEFENDS ON YOUR
CORREC INSTALLATION AND USE OF THIS BOOSTER SEAT. Failure to
properly install or use this booster seat increases the risk of serious injury or
death to the child and others in a sharp stop or crash.
The ultimate safety of a child depends on the proper use and
installation of this booster seat in a vehicle. Proper installation requires
that you read and understand this entire manual and the vehicle’s
owner’s manual before placing child in the booster seat.
DO NOT allow others to install or use this booster seat unless they
completely understand its proper use and installation.
- When using this booster seat with a vehicle lap and shoulder belt
to secure a child, the vehicle seat belt must be properly routed and
positioned on the child and snugly adjusted around child.
- This booster seat is for use in passenger cars, multi-purpose
vehicles (vans and SUVs), trucks, and school buses that are
equipped with a vehicle lap and shoulder belt.
- This child restraint is NOT certified for use on aircraft.

5
1.0 General Warnings and Information
Child’s safety depends on:
1. Choosing the correct child restraint for the child’s age, weight and
height.
2. Choosing the best location within the vehicle for installing the child
restraint. If possible, the child should be correctly restrained in the
back seat until age 13.
3. Proper use and installation requires proper routing and adjustment
of the vehicle’s lap and shoulder belt.
NOTE: Not all vehicle seat belts or vehicle seating positions can be
used with this booster seat. NEVER use with a lap-only seat belt.
4. Proper belt adjustment is required. Position the vehicle lap and
shoulder belt on the child as instructed in this manual.
NEED HELP?
Contact Safe Traffic System, Inc. at 1-847-233-0365 or visit one of the
following online resources:
• www.nhtsa.gov
• www.parentcentral.gov/parents/index.htm
• www.seatcheck.org

6
2.0 WARNINGS
Do not use with Lap Belt ONLY
Failure to properly use this booster seat or follow these warnings can
result in serious injury or death of the child. Please read and follow all
booster seat and vehicle instructions carefully.
• Only use this booster seat with children who weigh between
40–100 pounds (18–45 kilograms) and whose height is between
40–57 inches (101–145 centimeters) who is capable of sitting
upright unassisted. Using this booster seat with a child who does
not meet these requirements will increase the risk of serious
injury or death to the child.
• The child must be at least 4 years old and at least 40 lbs. (18 kg)
to use this booster seat.
• The child’s safety depends on you correct installation and use of
this booster seat. Failure to properly install or use this booster
seat increases the risk of serious injury or death to the child and
others in a sharp turn, sudden stop or crash.
• Only use this booster seat in a forward facing vehicle seat. The
booster seat and the child must be facing the front of the car.
• The vehicle seat belt must be correctly routed and snugly
adjusted around the child’s body.
• Properly position the lap belt across the
upper thighs and position the shoulder
belt across the center of the shoulder.
• The vehicle’s lap and shoulder belt must
be used to restrain the child.
• Never use only the lap belt.
• Never leave your child unattended in the
car.

7
2.0 WARNINGS
• Refer to the vehicle owner’s manual for appropriate seating
locations when a booster seat is used.
• Properly position the lap belt across the upper thighs and position
the shoulder belt across the center of the shoulder.
• Children under 13 years old should always ride in the back seat
of the vehicle.
• If the vehicle seating location has a frontal airbag you must follow
the vehicle manufacturer’s instructions for correct use or
deactivation.
• The safest location for children under 13 years old is the back
seat of the vehicle.
• When not in use, secure the booster seat with a seat belt to avoid
injuries to other occupants during a crash.
• This booster seat is designed and tested to accommodate a child
of a specific weight and height. Using the booster seat for a child
whose weight and height are outside of these limits will increase
the risk of death or serious injury in the event of a crash. (see
“weight and heigh limits”)
• Not all vehicle seating locations can be used for booster seats.
Read the vehicle owner’s manual for specific information.
• Do not use this booster seat in the home, on boats, low speed
vehicles, farm equipment, all-terrain vehicles (atvs), golf carts,
motorcycles or any other vehicles that do not meet certification
requirements as passenger vehicles.
• Do not use accessories or parts other than those specifically
provided for this booster seat and approved for use by Safe
Traffic System, Inc. Use of unapproved accessories could alter
the performance and safety of the booster seat in a crash.

2.0 WARNINGS
8
• Never use this booster seat without the seat cover.
• Do not store in locations where the plastic may become
deformed. (contact Safe Traffic System, Inc. for specific informa-
tion.)
• Discontinue the use of this booster seat after 7 years from the
date of manufacture.
• Do not use this booster seat if it has been involved in a crash. A
crash can cause damage that cannot be detected by visual
inspection. Using the booster seat following a crash could result
in serious injury or death.
• Do not use this booster seat if it is missing any parts or if it is
damaged.
• No booster seat can guarantee protection from injury in every
situation but proper use according to instructions helps to reduce
the risk of serious injury or death.

9
3.0 Features
3.1 Booster Seat (Front)
3.2 Booster Seat (Back)
Seat Pad
Armrest Armrest
Pocket (Both Sides)
Seat Pad
Armrest Armrest

10
3.3 Booster Seat (Bottom)
3.0 Featuress
RideSafer™Delighter®
Booster Car Seat
RideSafer™Delighter®
Booster Car Seat
S
A
F
E
T
R
A
F
F
I
C
S
Y
S
T
E
M
,
I
N
C
.
• Carefully read and understand all instructions and warnings
in this manual. Failure to properly use this Car Seat increases
the risk of serious injury or death in a sudden stop or crash.
WARNING
For Children:
30 to 100 lbs. ( 13.6 to 45 kg).
For use ONLY with vehicle lap and
shoulder belt.
NOT for use with vehicle lap belt only.
Owner’s Manual
Owner’s
Manual
Flap
Pocket
(Storage for Owner’s Manual) Bottom of Seat

11
The steps to prepare the Booster Seat for use with a child are
outlined below and described in detail in this owner’s manual.
4.1 Select a Vehicle Seating Location
to Install the Booster Seat
•Select a vehicle seating location
with a Vehicle Lap and Shoulder Belt.
•Never use a vehicle seating location
with ONLY a Lap Belt.
√Lap and Shoulder Belts are snugly adjusted around child.
Lap Belt is placed on hips low and flat and contacting thighs. √
√Shoulder Belt is centered on shoulder.
√Child is sitting up, not slouching down under Vehicle Lap Belt.
√Shoulder Belt is not under arm or behind back of child.
√Top of child’s ears are below top of vehicle seat back or
vehicle headrest.
Do not use with
Lap ONLY Seat Belt
4.0
Preparing Booster Seat for Use
5.0 Proper Use Check List

12
•FAILURE TO USE CHILD RESTRAINT APPROPRIATE FOR
YOUR CHILD’S SIZE MAY INCREASE THE
RISK OF SERIOUS INJURY OR DEATH.
•AVOID INJURIES FROM WHIPLASH.
TOP OF CHILD’S EARS MUST BE
BELOW TOP EDGE OF VEHICLE
SEAT BACK OR VEHICLE HEADREST.
WARNING
DEATH or SERIOUS INJURY can occur
6.0 Weight and Height Limits
Shoulder Belt Zone
(Center on the Shoulder)
• Child must be at least 4 years of age and
• Child’s weight is between 40 and 100 lbs.
(18 and 45 kg) and
• Child’s height is between 40 and 57 in.
(101 and 145 cm) and
• Top of child’s ears must be below top of
vehicle seat back or vehicle headrest and
• The shoulder belt lays across child’s
shoulder in the zone shown and the lap
belt is positioned low on the hips contact-
ing the thighs.
This child restraint is designed for use only by a child who meets ALL of
the following requirements:
The American Academy of Pediatrics recommends using a Booster
Seat until child reaches a standing height of 57 in. (145 cm) before
securing child with a vehicle seat belt, without a Booster Seat.

13
7.0
Selecting a Vehicle Seating Location
WARNING
There are many different types of vehicles, vehicle seat belt
systems, or other occupant restraint systems in use today.
Accordingly, this manual can only give guidelines for proper
installation in your vehicle. In addition to this manual, you must
also read and understand the vehicle owner’s manual, which
should address use of child restraints. If your vehicle owner’s
manual does not address the installation of child restraints,
please contact your local vehicle dealer, or the vehicle’s
manufacturer to obtain this information before using this
Booster Seat.
Not every seating location within a vehicle may be safe for the
installation of this Booster Seat. In fact, some vehicles have no
seating location that is safe for the installation of a Booster Seat.
Improper placement of this Booster Seat within a vehicle will increase
the risk of death or serious injury in a sudden stop or crash.
See “Vehicle Seat Belts” section for more information on vehicle seat
belts.
Please follow the instructions in this manual and in the vehicle owner’s
manual carefully to ensure proper location and installation of this
Booster Seat. If you are uncertain about the proper location of the
Booster Seat within the vehicle, contact your vehicle manufacturer
directly or through their dealer before using this Booster Seat. You are
also invited to call Safe Traffic System, Inc. at 1-847-233-0365 for
additional information or assistance.

14
7.0 Selecting a Vehicle Seating Location
7.1 Overall Considerations for Selecting a Seating Location:
• Please review the vehicle’s owner’s manual to determine the
best location for Booster Seat use, any specific instructions for
Booster Seat installation, or to determine if any locations are
unsafe for Booster Seat use. If you do not have the vehicle’s
owner’s manual or the owner’s manual does not address child
Booster Seat use, please contact the vehicle manufacturer to
obtain this information before using the Booster Seat.
• Use a rear seat location whenever possible. Rear seating
locations have been shown to be statistically safer for children
than a front seating location.
• Only use a vehicle from seating location if specifically allowed
in the vehicle’s owner’s manual and follow all instructions in the
vehicle’s owner’s manual.
• Safe Traffic System recommends
using a rear seat location
whenever possible as this is the
safest location for the Booster
Seat.

15
7.0 Selecting a Vehicle Seating Location
7.2 Seating Locations to Avoid
DO NOT use this Booster Seat in the following seating
locations.
• Never use this Booster Seat in a vehicle seating location that
has an Active Air Bag unless allowed in the vehicle’s owner’s
manual. If the vehicle is equipped with a front passenger Air
Bag, please refer to the vehicle’s owner’s manual for additional
information about Air Bags and child safety seat installation.
• DO NOT use this Booster Seat in a vehicle seating location
that has a vehicle seat back that does not lock into position. A
vehicle seat back that folds forward must lock to prevent it from
moving forward in a sudden stop or crash.
• DO NOT use this Booster
Seat in any vehicle seat
that faces to the rear of
the vehicle.
• DO NOT use this Booster Seat in
any vehicle seat that faces to the
side of the vehicle.

16
8.0 Booster Seat Installation and Use
WARNING
DEATH or SERIOUS INJURY can occur
• Child must be at least 4 years old and
weigh at least 40 lbs. (18 kg) to use this
Booster Seat.
• Use only the Vehicle’s Lap and Shoulder
Belt system when restraining the child in
this Booster Seat.
• Never use the Booster Seat with a Vehicle
Lap ONLY Belt across front of child. Using
a Booster Seat with a Vehicle Lap Belt
ONLY could result in serious injury or
death.
• Snugly adjust the Lap and Shoulder Belt
around child according to the instructions in
the vehicle owner’s manual.
- The Shoulder Belt must be properly
positioned over shoulder (NOT touching
child’s neck and NOT off shoulder).
- Vehicle Lap Belt must be positioned low
on the hips, contacting the thighs.
- Never use Shoulder Belt loose,
positioned under child’s arm, or behind
child.

17
8.0 Booster Car Seat Installation and Use
WARNING
DEATH or SERIOUS INJURY can occur
• Vehicle Lap and Shoulder Belt must be
properly positioned on child. Use Vehicle
Shoulder Belt Positioner to center Vehicle
Shoulder Belt on child’s shoulders.
• If child will not keep Vehicle Shoulder Belt
properly positioned on shoulder, DO NOT
use this Booster Seat. Use a different child
restraint system.
• Discontinue use of the Booster Seat when
the top of the child’s ears are above top of
the vehicle seat back or vehicle headrest.
• Securely belt this Booster Seat in vehicle,
even when not occupied. An unsecured
Booster Seat can injure other occupants in
a crash.

8.0
Booster Seat Installation and Use
18
8.1 Securing Child in Booster Seat with Vehicle
Lap and Shoulder Belt
2. If the vehicle seat back is adjustable, adjust
vehicle seat back into the upright position or
the position specified in the vechcle’s owner's
manual for use with a Booster Seat.
3.
Place child in Booster Seat with child’s
back and rump contacting seating surfaces.
•Do not place the Booster Seat in a
seating position that has a Vehicle
Lap Belt ONLY.
WARNING
1. Place the Booster Seat on the vehicle seat in a seating location
equipped with a Vehicle Lap and Shoulder Belt and centered
between the Lap and Shoulder Belt Anchorages (see “Select a
Vehicle Seating Location to Install Booster Seat” section).

8.0 Booster Seat Installation and Use
19
4. Pull the Vehicle Lap and Shoulder Belt across
front of child and under both Armrests. Buckle
the vehicle seat belt.
5. Shoulder Belt on child should pass over the
shoulder midway between the neck and the
end of the shoulder on child.
- Vehicle Shoulder Belt on buckle
side must be under the Armrest.
- Position vehicle lap belt under
Armrests and low on the hips,
contacting the top of thighs.
- Position Vehicle Shoulder Belt
across the chest and center of
the shoulder.
- Check to be sure that the
Vehicle Shoulder Belt is properly
positioned in the zone over the
center child’s shoulder.
