Rieber varithek acs 1100 d3 User manual

Issue: 07/12/2021
acs 1100 d3 –2x varithek®
with 3-sided splash guard acs 1100 d3 –attachment - 2x varithek® with attachment
acs 600 ec –1x varithek®
Example variants. acs varithek®
air-cleaning-system acs
Observe the operating instructions
Translation of the Original Operating Instructions
DOWNLOAD: USER MANUAL
QR code on type plate EN

Contents
2
Rieber GmbH & Co. KG
Contents
1Revision Index.................................................................................................................................................3
2Important Information.....................................................................................................................................3
2.1 The components of the technical documentation..............................................................................................3
2.2 Representation conventions in the text.............................................................................................................4
2.3 Structure of safety instructions..........................................................................................................................4
3Safety instructions and warnings..................................................................................................................5
3.1 Designated use.................................................................................................................................................5
3.2 Operator’s obligations.......................................................................................................................................7
3.3 Requirements for qualification of operating personnel ......................................................................................7
3.4 Avoid risks........................................................................................................................................................8
3.5 Instructions on behaviour in an emergency.......................................................................................................9
4Description of the equipment.......................................................................................................................10
4.1 Designations...................................................................................................................................................10
4.2 Air flow, ‘Basic’ filter stage..............................................................................................................................12
4.3 Technical data ................................................................................................................................................14
5Unloading from the pallet, first commissioning .........................................................................................16
6Use..................................................................................................................................................................17
6.1 Information on safe use ..................................................................................................................................17
6.2 Ensure undisturbed extraction of steam and vapour.......................................................................................18
6.3 Electronic fan control......................................................................................................................................19
7Ceaning, maintenance and care...................................................................................................................23
7.1 Safety information relating to cleaning, maintenance and care.......................................................................23
7.2 Cleaning agents for stainless steel .................................................................................................................23
7.3 Choose the correct cleaning method ..............................................................................................................23
7.4 List of activities to be performed and intervals ................................................................................................24
7.5 Clean cooking area, air ducts and splash guard .............................................................................................25
7.6 Clean side filter unit(s)....................................................................................................................................27
7.7 Maintain and clean the technical compartment...............................................................................................31
8Troubleshooting –What now?.....................................................................................................................34
8.1 Fault elimination..............................................................................................................................................34
8.2 Disposing of your product ...............................................................................................................................34
9Warranty and Liability...................................................................................................................................35
10 Manufacturer’s address................................................................................................................................35

Revision Index
Rieber GmbH & Co. KG
3
1 Revision Index
Revision
Change
07/12/2021
New edition
2 Important Information
2.1 The components of the technical documentation
•Operating instructions for acs… varithek®
Attached documents, available via the QR code on your device:
•Technical documentation for your special design variant, filter technology used including
maintenance instructions, customer drawing etc.
Page 6
•Online version of these operating instructions
•Cleaning agents for stainless steel
•Choose the correct cleaning method
•Declaration of conformity
•Spare parts and necessary instructions.
www.rieber.de
Select “→Customer Service”, at the top of the display bar.
In addition:
•Do you wish to have the operating instructions in another language?
www.rieber.de
Select “→Customer Service”, at the top of the display bar.
•Information on CHECK HACCP
www.rieber.de
Select “→Service”, at the top of the display bar.

Important Information
4
Rieber GmbH & Co. KG
2.2 Representation conventions in the text
•Lists are represented in this way.
➢Instructions on certain actions are represented in this way.
See ‘. . . ’ cross-references are represented in this way
CAUTION
indicates potential damage to property without any personal injury.
Failure to follow these instructions may cause damage to property.
User tip
►Useful information or tip
2.3 Structure of safety instructions
The signal words DANGER - WARNING - CAUTION classify the degree of risk of bodily injury in an actual
situation. You can avoid injury by complying with the behavioural rules provided.
The warning triangle symbol indicates a "General Danger".
DANGER
indicates imminent danger.
Failure to follow these warnings will result in serious bodily injury or even death.
WARNING
indicates a potentially hazardous situation .
Failure to follow these warnings may result in serious bodily injury or even death .
CAUTION
indicates a potentially hazardous situation .
Failure to follow these warnings may result in minor bodily injury .

Safety instructions and warnings
Rieber GmbH & Co. KG
5
3 Safety instructions and warnings
3.1 Designated use
This chapter provides information on the intended use of the product and warns against foreseeable misuse or
abuse, for your safety.
Generally intended use includes:
•For mobile meal services in catering, hotels and restaurants; also for managed care
facilities and schools.
•Only trained, instructed and authorised operating personnel are permitted.
Chapter ‘Operator’s obligations’ page 7 ff.
•Modification of the appliance, for example changing the filter combinations, by the operator
is not permitted.
•Use correctly sized cooking units, like the cooking modules in the Rieber varithek® range.
Baking, grilling, cooking, wok cooking and frying. The relevant operating instructions must
be observed.
•The intended use includes compliance with the technical data.
Prevent any predictable misuse and abuse:
•Modification of the appliance by the operator, for example the filter combinations, is not
permitted.
•Risks due to falling loose objects such as lids, cooking utensils, cutlery. Do not use the
appliance as a means of transport. Only set up the appliance on flat surfaces.
•The integrated air-cleaning-system acs ensures that the extracted air is passed back into
the room odour-free. This is not a replacement for an air-conditioning system.
•Front cooking is only admissible with the sneeze guard that can be closed on four sides.
•Do not lean against or sit on the appliance.
•Incorrect cleaning can substantially and irreparably damage the stainless steel surfaces.
•Not intended for private domestic use.

Safety instructions and warnings
6
Rieber GmbH & Co. KG
The appliances are equipped with special filter stages for the respective application.
➢Use the appliance as intended, in order to avoid strong odours and fumes.
Basic
Included in all filter combinations.
For frying and steaming primarily mild smelling food, a few hours a day.
•Grease, fleece, active carbon filter
Advanced
For frying and steaming strong smelling food, with little fat, light smoke production.
•Grease,
•Fleece,
•Plasma,
•Active carbon filter
Flexible HEPA
In addition to the Basic or Advanced combination, for occasional more intensive cooking and if fat is
used.
For frying and steaming strong smelling food, light smoke production.
•Grease,
•Fleece,
•(Plasma),
•HEPA,
•Active carbon filter
Advance+
For frying and steaming with more fat, stronger smoke production.
•Grease,
•Fleece,
•Electrostatic,
•Active carbon filter
Profi
For frying and grilling for intensive periods of time. Strong odours and fumes.
•Grease,
•Fleece,
•Electrostatic,
•Plasma,
•Active carbon filter
NOTE: Included in all filter combinations from Basic to Profi:
•High-performance grease separator
•Fleece filter mat
•Grease drip trays

Safety instructions and warnings
Rieber GmbH & Co. KG
7
3.2 Operator’s obligations
Operator
The operator is the person who operates the appliance for commercial or economic purposes either
himself/herself or lets others use it and bears the legal appliance responsibility for protection of the
user, staff or any third parties during operation.
Operator's obligations
The appliance is used in commercial applications. For this reason, the operator of the appliance must
meet all legal duties relating to work safety.
In addition to the safety instructions in this guide, the safety, accident prevention and environmental
protection regulations applying to the application of the appliance must be complied with.
In particular, the following shall apply:
•The operator must be familiar with the applicable work safety regulations and identify, by
carrying out a risk analysis, any additional hazards which are due to the place where the
appliance is used. These hazards must be addressed in the form of operating instructions
governing the operation of the appliance.
•During the whole service life of the appliance, the operator must verify if the operator's
operating instructions reflect the current versions of the applicable regulations. If necessary,
the operator must update the operating instructions accordingly.
•The operator must define and assign the responsibilities for installation, operation, repair,
maintenance and cleaning clearly.
•The operator must make sure that all personnel working with the appliance have read and
understood this guide. In addition, the operator must train the personnel and inform them of
the hazards involved at regular intervals.
•The operator must provide the personnel with the necessary protective equipment and
make sure that they wear it.
In addition, the operator must ensure that the appliance is always in a perfect technical condition. For
this reason, the following shall apply:
•The operator must ensure that the maintenance intervals defined in this guide are obeyed.
•The operator must have all safety equipment checked regularly for completeness and
proper function.
•The operator must ensure that the required media connections are available.
•The operator must ensure that all safety-relevant measures required on site are taken.
3.3 Requirements for qualification of operating personnel
Safe operation requires certain technical skills and personal qualification of each person.
•The responsibility for organization lies with the ‘Designated Representative’ (operator).
According to EN 50110-1, the Designated Representative is a 'person assigned the direct
responsibility for the performance of the work. If necessary, this responsibility can be
assigned partly to other persons. [...] The designated representative must instruct all
persons involved in the work on all hazards which may not be obvious for them’.
•The work may only be performed by ‘instructed persons’ . Train the operating personnel
for the respective work task; also in accordance with the operating instructions. Check
understanding by means of practical implementation. Repeat the instruction at least once a
year.

Safety instructions and warnings
8
Rieber GmbH & Co. KG
•Only ‘qualified personnel’ are allowed to carry out repair work.
IEC 60204-1 defines qualified personnel as "persons who, on account of their training and
relevant experience are in the position to recognise risks and avoid potentially dangerous
situations."
•Electrical work may only be carried out by a trained and experienced qualified electrician.
Electro-technically instructed persons may only work under the supervision of a qualified
electrician.
•Any repairs and/or overhaul during the warranty period may only be carried out by the
manufacturer´s service department.
Chapter ‘Warranty and Liability’, page 35
3.4 Avoid risks
This chapter describes general, appliance-specific safety instructions. In the following section, additional safety
information relating to a particular operation or situation is placed before the appropriate operation step or
description of the situation.
3.4.1 Risks due to transport of mobile appliance
Numerous hazards such as crushing can arise when transporting this heavy product.
➢acs…varithek®appliances may only be moved manually. Machine-aided transport, e.g. using fork
lift trucks or lift trucks, is not permissible. There is a risk of injury, and the appliance could be
damaged.
➢Remove accessories and transport them separately.
➢Disconnect the connection cable. Unplug the mains plug.
➢Only transport unit on a straight surface. Do no transport on a sloping surface.
➢Carry out transport with an adequate number of people.
➢Transport only permissible using the castors.
➢Secure the appliance against inadvertently rolling away with the ‘parking brake’.
➢Wear safety shoes to prevent injuries.
CAUTION
►Do not push or pull the appliance over sharp edges. Observe the permissible step
height of maximum 4 mm, otherwise the castors or ‘castors with parking brake’
could be damaged.
►We are not able to rule out the possibility of marks appearing on the floor due to
friction with castors or the formation of scratches due to split cracks in the castors,
for example.

Safety instructions and warnings
Rieber GmbH & Co. KG
9
3.4.2 Risks due to electricity
➢Before each use, inspect the product, the connecting plug and electric cable for any visible signs
of damage.
➢The cable must be routed so that it cannot be squeezed or overheated.
➢The socket outlet must be easily accessible so that the unit can be disconnected from the power
supply at any time.
➢Compare the connection data on the type plate with the data of the electrical network before
connecting (voltage and frequency, power rating).
3.4.3 Safety and monitoring devices
•High-performance grease separator
•The technical compartment is monitored by a safety switch, pressure switch.
•If the pressure deviates in the technical compartment, for example when the cover is open,
all components are electrically isolated or shut down. The appliance remains energised.
•Main switch, operating lamp, operating light, digital control
•Circuit-breaker(s)
3.5 Instructions on behaviour in an emergency
First aid for respiratory distress in case of →version with plasma technology /option
WARNING
Breathing difficulties, lacrimal irritation, mucosal irritations in throat, neck and lungs,
headache, strong tickle in the throat, cannot be excluded in the case of human error.
►All interference with the plasma generator is forbidden.
►Seek medical treatment if necessary. Ozone-containing air can trigger complaints.

Description of the equipment
10
Rieber GmbH & Co. KG
4 Description of the equipment
This chapter provides useful information on the structure and function of the equipment.
4.1 Designations
In linguistics and in terminology science a designation is the linguistic form used to refer to terms and concepts.
4.1.1 Appliance type ‘d3’
Example
‘d3’
Example
acs 1100 d3 – 2x varithek®
1 4 swivel castors, including 2 ‘swivel castors with parking brakes’ on the operator side
2 Electrical connection with cable and plug
3 Main switch and operating light. Electronic fan control
4 Power connections for cooking units. CEE 400 V and Schuko 230 V
5 Cover with 1x quick release
6 Extraction areas (→3-sided extraction of steam and vapour)
7 Sneeze guard attachment, including shelf for serving food.
Front sneeze guard glass, removable for cleaning.
With lighting.
8 Technical compartment. Cover with 2x quick release

Description of the equipment
Rieber GmbH & Co. KG
11
4.1.2 Appliance type ‘ec’
Example
‘ec’
Example
acs 600 ec –1x varithek®
6 Extraction areas
6.1 Air supply area → from radial fan
6.2 Extraction area → 1-sided extraction of steam and vapours
9 Splash guard, 3-sided from CNS 1.4301 →removable without the use of tools.
10 Cutting board, made of PE, →in place and locked. The cutting board can be removed for
cleaning.

Description of the equipment
12
Rieber GmbH & Co. KG
4.2 Air flow, ‘Basic’ filter stage
4.2.1 Appliance types acs… ‘d3’, Basic filter stage
Appliance type ‘d3’ means: 3-sided extraction of steam and vapours.
1 High-performance grease separator →Grease and steam are separated.
2 Grease drip trays → There is a uniform type of grease drip tray. Any residual grease particles
collect in the grease drip trays.
3 Fleece filter mat including holder →Particles and suspended matter are filtered out of the air.
The exhaust air exits downwards through the active carbon filter.
•Active carbon filter → for absorbing odours and pollutants Substances captured by
adsorption accumulate in the carbon. Substances to be filtered are physically absorbed by
means of the active carbon filter.

Description of the equipment
Rieber GmbH & Co. KG
13
4.2.2 Appliance types acs… ‘ec’, Basic filter stages
Appliance type ‘ec’ means ‘EasyClean’, 1-sided extraction of steam and vapour. The appliance types
in the ‘ec’ series have a fan motor. Extraction occurs on the left via the air blowing jet and on the right
with suction of the air, the ‘Push and Pull’ principle.
1 High-performance grease separator →Grease and steam are separated.
2 Grease drip trays → There is a uniform type of grease drip tray. Any residual grease particles
collect in the grease drip trays.
3 Fleece filter mat including holder →Particles and suspended matter are filtered out of the air.
The exhaust air exits downwards through the active carbon filter.

Description of the equipment
14
Rieber GmbH & Co. KG
4.3 Technical data
4.3.1 Generally applicable data
Rated voltage / mains
frequency
3N AC 400V 50/60Hz,
Approx. 2 m cable / CEE plug 400 V
Power consumption
Maximum 11 kW
Electrical fuse
Connect the appliance on site to a socket with a series-connected
residual current operated device (RCD) with a tripping current of 30
mA.
Protection class
IPX4 as per DIN EN 60529
→Unit offers protection against water splashes on all sides.
→Only use unit inside buildings. Protection against penetrating
moisture is required.
Equipotential bonding on the underside of the appliance. This
protective measure serves for additional safety. Standard-compliant
implementation with subsequent inspection of the system is carried
out by a qualified electrician.
IEC 60364-5-54:2011; for Germany
DIN VDE 0100:540:2012-06
Permissible ambient
temperature
from + +5 °C to + +40 °C
3-sided splash guard
3-sided splash guard made of CNS 1.4301. Can be removed without
the use of tools.
acs with ‘attachment’
Delivery / plate shelf made of 4 mm CNS.
CNS light strip with integrated LED lighting.
Guest-side sneeze guard safety glass made of VSG.
Front sneeze guard glass, removable for cleaning.
Air capacity in accordance
with DIN 61591
Circulating air 1150 m3per hour
Emitted sound pressure level
Lpa ≤70 dB(A)
Rustproof castors
in accordance with DIN 18867, part 8. Swivel castors made of
1.4301, wheel diameter 80 mm.
Including 2 ‘swivel castors with parking brakes’ on the operator side;
Ground clearance 120 mm
Ground clearance
120 mm
Material
Stainless steel CNS 1.4301
Technical compartment
Closed on 3 sides, with an inspection flap on the operating side,
removable with 2 quick-release fasteners.
Low-noise radial fan is arranged on a pull-out bracket, removable
without tools.
Scope of supply
Without system module, without varithek®appliance(s)

Description of the equipment
Rieber GmbH & Co. KG
15
4.3.2 Concerning appliance type ‘d3’
acs 1100 d3 – 2x varithek®
acs 1100 d3 – attachment –
2x varithek®
acs 1500 d3 – 3x varithek®
acs 1500 d3 – attachment –
3x varithek®
Permissible loading
maximum 100 kg
maximum 140 kg
External dimensions
(L x W x H)
Top edge of cover
approx.
1100 x 760 x 900 mm,
1103 mm splash guard,
1300 mm attachment
1500 x 760 x 900 mm,
1103 mm splash guard,
1300 mm attachment
Placement niche
(L x W x H) approx.
810 x 660 x 260 mm,
Usable depth 220 mm
1210 x 660 x 260 mm,
Usable depth 220 mm
Weight approx.
145 kg
165 kg
4.3.3 Concerning appliance type ‘ec’
acs 600 ec –1x varithek®
acs 1000 ec –2x varithek®
acs 1100 ec –attachment –
2x varithek®
Permissible loading
maximum 60 kg
maximum 100 kg
External dimensions
(L x W x H) approx.
600 x 760 x 900 mm,
1002 mm splash guard
1000 x 760 x 900 mm,
1002 mm splash guard,
1300 mm attachment
Placement niche
(L x W x H) approx.
410 x 737 x 260 mm,
Usable depth 220 mm
810 x 737 x 260 mm,
Usable depth 220 mm
Weight approx.
98 kg
125 kg

Unloading from the pallet, first commissioning
16
Rieber GmbH & Co. KG
5 Unloading from the pallet, first commissioning
# Unload appliance from the pallet
WARNING
Heavy appliance. See type plate.
►Wear protective gloves and safety shoes.
►Lift the appliance using at least 4 people. Another person quickly pulls the pallet
together with the 2 profiles away. Only appropriately trained personnel are
permitted.
➢ATTENTION
Do not unload from the pallet using a fork-lift truck, as this could cause substantial damage.
Lift / deposit a heavy load evenly with your knees bent and your upper body
straight and upright. Your feet should be at least hip-width apart and your
abdominal muscles braced. Breathe out. Do not twist your spine.
Example
➢Ensure that there are no protective foils on the inside or outside of the appliance.
# Clean the appliance
➢Clean the appliance thoroughly before using for the first time.
Clean with a damp cloth and rub dry with a clean cloth.
See ‘Ceaning, maintenance and care’, page 23 ff.

Use
Rieber GmbH & Co. KG
17
6 Use
This chapter provides information on the use and operation of the appliance.
6.1 Information on safe use
➢Before each use, check the appliance for any visible damage. The appliance is at room
temperature and is dry. Only use in dry rooms in the building.
➢The socket outlet must be easily accessible so that the unit can be disconnected from the power
supply at any
time.
➢Only operate the appliance with adequate lighting.
Equip the appliance with suitable accessories
➢Do not use gas cooking devices. Do not flambée.
➢For the deep-fryer, use an insertion mask that prevents slipping in the system module. Only
use one deep-fryer on the appliance, as otherwise the extraction and circulating air cleaning
system may be overloaded and odours may develop.
Example
Quickly exchangeable varithek®cooking
modules.
Highly efficient thanks to perfect heat transfer
with thermoplates®.
User tip
Only use correctly sized cooking units.
►Use cooking modules from the Rieber varithek ® range. Roasting, grilling, cooking,
wok cooking and frying. Use
varithek®functional components.
➢Contact Rieber customer service for assistance.
‘Manufacturer’s address’, page 35
➢Only operate appliances with the same voltage, i.e. 2x 400 V or 2x 230 V.

Use
18
Rieber GmbH & Co. KG
6.2 Ensure undisturbed extraction of steam and vapour
User tip
If the extraction is interrupted, unpleasant odours can develop.
►Make sure that the top edges of the cooking units do not exceed the maximum top
edge in the cooking area.
►With one-sided extraction, type ‘ec’: Place cooking units with higher odour
emissions during cooking and roasting on the right-hand side, as the extraction
effect is more intensive here.
►Ensure that the parts of the upper extraction area are completely assembled.
Ensure that the cutting board (option) is in position.
Type
‘d3’
↑ CORRECT
↑ INCORRECT
Type
‘ec’
↑ CORRECT
↑ INCORRECT
User tip
If the temperature is set too high, fumes and odours can develop.
►Set the temperature to maximum 250 °C.

Use
Rieber GmbH & Co. KG
19
# Freshly prepare food on the cutting board /option
Example
User tip
If the cutting board is not in place unpleasant odours can develop, as the extraction is
interrupted.
►Ensure that the cutting board is in position. Briefly removing the cutting board for
cleaning will not interrupt the extraction.
6.3 Electronic fan control
6.3.1 Operating panel
Button
1 ON/OFF
2 RESET
3 TURBO
4 Decrease ventilation intensity, levels 4 to 1
5 Increase ventilation intensity, levels 1 to 4
Display
6 LED display
7 LED fan fault, red = alarm
8 LED plasma fault, red = alarm
9 LED filter usage time exceeded, red = alarm
10 LED OK, green = fault-free

Use
20
Rieber GmbH & Co. KG
6.3.2 Switching on / Switching off
➢Switch the ON/OFF pushbutton with indicator light on the air-cleaning-
system acs to ON.
▌Control is in STANDBY.
➢Press ON/OFF button (1).
▌During normal operation the OK LED shows a green light.
▌The extraction system starts at the lowest fan speed, level 1.
Allow the ventilation to run on briefly if necessary, so that the vapours rising due to
residual heat cannot spread to the surrounding environment.
➢Press ON/OFF button to switch off.
▌The display goes out. The display is black.
User tip
►We recommend letting the extraction system run on for another 10
minutes at the end of the cooking process, so that the vapour caused by
the residual heat cannot disperse into the environment.
6.3.3 Adjust ventilation intensity
Adjust intensity, levels 1 to 4
➢Press the PLUS button (5), to increase the level.
Press the MINUS button (4), to decrease the level.
▌The selected level and the fan icon appear in the display.
TURBO is the highest ventilation intensity level.
Adjust TURBO
➢Press the TURBO button (3).
▌The fan icon and TURBO appear in the display.
▌After 5 minutes the fan switches back to the last selected
ventilation intensity.
