AUTOJET®1750+ SPRAY CONTROL PANEL
QUICK START GUIDE
Scan the QR code, or visit spray.com/autojetspraycontrol, to access manuals,
videos and additional resources on the AutoJet 1750+ Spray Control Panel.

1750+
SPRAY CONTROLLER
1.
POSITION OR MOUNT
THE PANEL
Mount the panel to a wall in a location that is close
to your nozzles.
Install wall anchors that are designed to support at
least 50 lbs. (90.7 kg) according to the anchor
manufacturer’s specifications.
The mounting holes are on 5-7/16" (138 mm) centers and
are made for 1/4" (6 mm) screws with 3/8" (10 mm) diameter
screw heads.
2.
CONNECT ELECTRICAL
SPRAY NOZZLES
Connect electrical spray nozzle cable to “Main”
connection. For multiple nozzles, connect nozzles to a
junction block and then connect the junction block cable
to “Main” connection. (Can connect up to 10 nozzles.)
1750+ Spray Control
5.44" (138 mm)
8.00" (203.2 mm)
0.27"
(6.8 mm)
10.72"
(272 mm)
11.34"
(288.1 mm)
0.83" (21 mm)
4 Places
Junction Block

1750+
SPRAY CONTROLLER
3. CONNECT TRIGGER OR SENSOR
Connect cable to “Trig” connection that will be used
to start spray sequence. Available triggers are:
•Trigger cable (for use with customer-supplied
trigger signal)
•Sensor, including: photo, prox, laser or thru-beam
(type should be selected based on customer’s
application)
•Handheld trigger
1750
+
SPRAY CONTROLLER
4.
DUALTRIGGER FAIL-SAFE
(IF APPLICABLE)
For fail-safe operation, or when dual trigger signals
will run the system, connect trigger interlock cable
to “T. int.” connection.

1750+
SPRAY CONTROLLER
1750+
SPRAY CONTROLLER
5.
REMOTE DUTY CYCLE
(IF APPLICABLE)
If using remote setpoint for Precision Spray Control (PSC),
connect input of a 4-20mA analog signal to “4-20mA”
connection to adjust the duty cycle remotely.
6.
POWER UP
THE PANEL
Plug into grounded (115-230 VAC, 1ph.) power source
and turn on power. HMI display will illuminate. To
set spray parameters and for HMI operation, please
refer to section 6 of the owner’s manual.
HMI Screen

PN: ML001750CONQS
North Avenue and Schmale Road, P.O. Box 7900, Wheaton, IL 60187-7901 USA
Tel: 1.800.95.SPRAY Intl. Tel: [phone]
Fax: 1.888.95.SPRAY Intl. Fax: [phone]
Email: [e-mail]
www.spray.com
7.
DOWNLOAD REMOTE DESKTOP APP ONYOUR MOBILE
DEVICE AND CONNECTTO CONTROLLER WI-FI
•Download VNC viewer to mobile device. Available from the Apple Store or Google Play
•Go to WiFi settings on mobile device. Connect to 1750: SSID: SSCOxxxxxx_xxx using password: SSCO1750
•Open VNC viewer, click +
•Enter IP address: 192.168.0.20:5900
•Name your system, hit create, then connect
© 2020 Spraying Systems Co. All rights reserved.
