Riello N35 Gateway Quickstart Guide
1. FIELD DEVICE CONNECTIONS
e gateway can connect with up to 8 boilers. Please see
job specic Riello burner drawings for linkageless LMV3,
LMV5 burners.
ARRAY 1.0 Integration
*** RS232 Converter with Array 1.0 is 20147499
(1 per boiler)
*** RS232-RS485 Device on Array V1.0 is pow-
ered through the RS232 bus.
*** AL Bus for cascade control is on a separate
daisy chain. Please see Array Control System
manual.
Array
Low Voltage
Terminal Strip
N35
- For the complete gateway manual, please follow
the link below:
https://www.riello.com/north-america/products/
burners-catalogue/protocol-gateway

*** AL Bus for cascade control is on a separate
daisy chain. Please see Condexa Installation and
Operation Manual
CONDEXA LOW VOLTAGE TERMINAL STRIP (TB1)
CONDEXA NA 75 P & CONDEXA NA 117 P Integration
CONTROLLER SET UP TABLE - FROM GATEWAY TO RIELLO DEVICE
CONTROLLER ADDRESSING BAUD RATE PARITY
ARRAY BOILER CONTROLLER NOT REQUIRED NOT REQUIRED NOT REQUIRED
CONDEXA BOILER CONTROLLER 1-8 9600 (xed) NOT REQUIRED
LMV3 W/ RWF55 CONTROLLER 1-6 (Par. 145) 19200 (Par. 146 = 1) None (Par. 147 = 0)
LMV5 CONTROLLER 1-6 19200 None
MULTI-FUNCTION DISPLAY (SOLO) 1-6 19200 None
MULTI-FUNCTION DISPLAY (PICCOLO) 1-2 19200 None
MASSIMO PANEL 1 (xed) 19200 (xed) NOT REQUIRED
2. RIELLO CONTROLLER MODBUS RTU SET-UP
*** AL Bus for cascade control is on a separate
daisy chain. Please see Array Control System
manual
Array
Low Voltage
Terminal Strip
ARRAY 2.0 Integration

3. DIP SWITCH SETTINGS
* Please note, for multi-function display
screen and Massimo:
- all BAS side congurations are done from the touch-
screen. Dip switches are ignored, except for S3 which
must be in the “o” position.
- Please consult automation manuals for more details.
B Dipswitches - SELECT PROFILE (ONLY N35 GATEWAY)
Prole B0 B1 B2 B3
1LMV3 OFF OFF OFF OFF
2LMV5 ON OFF OFF OFF
3ARRAY OFF ON OFF OFF
4CONDEXA ON ON OFF OFF
S Dipswitches - CONDEXA (ONLY N35 GATEWAY)
Prole S0 S1 S2 S3
LONWORKS (8 BOILERS) OFF OFF OFF ON
S Dipswitches - NUMBER OF BURNERS/BOILERS (NOT FOR CONDEXA)
Prole S0 S1 S2 S3
1 BURNER/BOILER OFF OFF OFF ON
2 BURNERS/BOILERS ON OFF OFF ON
3 BURNERS/BOILERS OFF ON OFF ON
4 BURNERS/BOILERS ON ON OFF ON
5 BURNERS/BOILERS OFF OFF ON ON
6 BURNERS/BOILERS ON OFF ON ON
7 BURNERS/BOILERS OFF ON ON ON
8 BURNERS/BOILERS ON ON ON ON

35 Pond Park Road
Hingham, Massachusetts
USA 02043
RIELLO BURNERS NORTH AMERICA
1(800)4-RIELLO
1(800)474-3556
www.riello.ca
2165 Meadowpine Blvd.
Mississauga, Ontario
Canada L5N 6H6
4. TROUBLE SHOOTING
TX and RX LED lights on the gateway should be ashing
1. If RX and TX LED lights are not blinking, re-verify section 1-4.
2. If “ERR” LED light is ashing red, ensure dipswitch A7 is in the o position. To reset
gateway move the S3 dipswitch to the “o” position, then back to the “on” position.
Default IP & subnet mask is: 192.168.1.24 & 255.255.255.0
For LONworks node id can be changed through the GUI, when logging into the browser.
