RIESE & MULLER Packster 40 CARRY SYSTEM User manual

Riese & Müller GmbH | Am alten Graben 2 | D-64367 Mühltal | Tel.: [phone] | Fax: [phone] | E-Mail: [e-mail] | Internet: www.r-m.de
Page 4of 6
State: 12.04.2019 15:43:00Datei: VBK0188-P40-carry-171106.docx
ENGLISH: Owners Manual
Packster 40 CARRY SYSTEM (VBK0188)
Packster 40 CARRY SYSTEM (VBK0188)
The optional Carry System makes luggage transport convenient.
Scope of delivery
1x front plate 180170 incl. Velcro and Grip tape
1x bottom plate 180271, incl. grip tape
1x upper rail
1x lower rail incl. plugs
2x long stay incl. plastic studs
2x short stay
1x shroud Carry System
4x countersunk screw (Torx M5 x 16 DIN 965 A2)
9x countersunk screw (Torx M5 x 25 DIN 965 A2)
4x countersunk screw (Torx M5 x 30 DIN 965 A2)
1x countersunk screw (Torx M5 x 40 DIN 965 A2)
6x rounded head bolt (allen M 5 x 20 mm ISO 7380 A2)
4x rounded head bolt (allen M 5 x 25 mm ISO 7380 A2)
2x rounded head bolt (Torx M 5 x 12 mm ISO 14583 A2)
6x plastic spacer 6x15x5
6x spacer flat-round
3x washer (d = 5,3 mm DIN 134 A2)
14x selflock nut M5 with flange
Assembly
1. Put 4 plastic spacer 6x15x5 in place (fig. 1).
2. Put bottom plate in place and fix it with 5 bolts M5x25 and 5 nuts (fig. 2).
fig. 1: Grip tape and spacer fig. 2: bottom plate

Riese & Müller GmbH | Am alten Graben 2 | D-64367 Mühltal | Tel.: [phone] | Fax: [phone] | E-Mail: [e-mail] | Internet: www.r-m.de
Page 5of 6
State: 12.04.2019 15:43:00Datei: VBK0188-P40-carry-171106.docx
ENGLISH: Owners Manual
Packster 40 CARRY SYSTEM (VBK0188)
3. Mount bolt M5x40 , plastic spacer 5x20x3 , washer and nut (fig.3).
4. Put 2 plastic spacers 6x15x5 in place. Mount front plate with 4 bolts M5x25 and 4 nuts
(fig. 4).
5. Connect lower rail , 2 long stays (plastic stud up forward) and 2 short stays by 4 countersunk
screws M5x30 (fig. 5). Do not tighten bolts yet.
6. Connect upper rail and stays by 4 rounded head bolts M5x25 (fig. 5). Tighten all bolts.
Tightening torque 3-4 Nm.
7. Connect lower rail to bottom plate by 6 countersunk screws M5x20 and spacers flat-round (fig. 6).
Attention: insert bolts straight and carefully. Tightening torque 3-4 Nm.
8. Connect upper rail by 2 rounded head bolts M5x12 and washer . Connect upper rail to front plate by
4 countersunk screws M5x16 and nuts (fig. 6). Tightening torque 4-5 Nm.
9. Apply shroud and fix it by its velcro belts (fig. 7).
fig. 3: bolt M5x40 fig. 4: front plate
fig. 5: rail assembly fig. 6: mount rail
fig. 7: apply shroud

Riese & Müller GmbH | Am alten Graben 2 | D-64367 Mühltal | Tel.: [phone] | Fax: [phone] | E-Mail: [email protected] | Internet: www.r-m.de
Page 6of 6
State: 12.04.2019 15:43:00Datei: VBK0188-P40-carry-171106.docx
ENGLISH: Owners Manual
Packster 40 CARRY SYSTEM (VBK0188)
Carry System use
Before each ride the following items must be checked:
The luggage must be fixed securely and nothing should get caught by the wheels.
The maximum loading capacity of the Carry System is 60kg. The maximum load of the E-Bike shall not
exceeded.
Any kind of modification at the Carry System is prohibited.
WARNING
Luggage can loosen if not fixed securely and may cause heavy accidents!
When riding with a full load, the handling is affected and it takes longer to stop.
Be sure to make some handling and braking test prior to heading into traffic.
Informations for use
Wood is a working material. So check the tight bolt connections on a regular base.
If the Packster is exposed to humid conditions, we recommend to apply wood protective oil at all
blank edges.
