Riffel RF198 User manual

RIFFEL MEAT GRINDER
RF198
INSTRUCTION MANUAL
Please read carefully and keep the instruction well
DESIGNED IN GERMANY
MADE IN CHINA

DESCRIPTION
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed including the following:
It is for household use, do not use outdoors.
Unplug from outlet while not in use, before putting on or taking off parts, and
before cleaning.
Unplug when assembling and disassembling the unit.
Close supervision is necessary when any appliance is used near children.
When carrying the unit be sure to hold the body with both hands. Do not
carry the unit by the food tray or grinding head.
Do not fix the blade and cutting plates when using kibbe attachment.
Never push products by hand. Use food pusher.
Do not grind hard food such as bones, nuts, etc.
Do not grind ginger and other materials with hard fiber.

Continuous running of meat grinder should be not more than 10 minutes
with the following 10minutes interval for motor cooling.
Operate the unit from “ON” to “R” or from “R” to “ON” after the previous
working condition stops more than 30 seconds, or it may cause some
unnormal case such as moving up and down and easily destroy the unit.
To avoid jamming, do not force to operate the unit with excessive
pressure.
When the circuit breaker activates, do not switch on.
Never try to replace the parts and repair the unit by yourself.
Do not immerse cord or the body of mixer into water as this would give
rise to electric shock.
This appliance is not intended for use by persons(including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety
Children should be supervised to ensure that they do not play with the
appliance.
Do not operate this appliance if the cord or plug is damaged. Return it to
the store of service or repair by professional serviceman.
FOR THE FIRST TIME
Check that voltage indicated on the rating
label corresponds the mains voltage in
your home.
Wash other parts except body(motor
housing) in warm soapy water.
Wash all parts (except body) in warm soapy
water.
Before plug in，Make sure the switch in the
OFF "0" position, that is the natural state of
all keys.
INSTRUCTION FOR USE
ASSENBLING
Hold the grinding head and insert it into
the head inlet(when inserting please pay
attention the grinding head must be
slanted as per arrow indicated on the
top,see fig.1),then move the locked knob
anticlockwise so that the grinding head
being fastened tightly . (fig.2)
Place the feeding screw into the grinding head, and turn to feed the

screw slightly until it is connect into the head inlet (fig.3).
Place the blade onto the shaft of feeding screw with the blade facing the
front as illustrated (fig.4).If it is not fitted properly, meat will not be
mincing.
Place the desired cutting plates next to the blade, fitting protrusions in
the slot (fig.5).
Support or press the centre of the cutting plates with one finger then
screw the fixing ring tight with another hand (fig.6). Do not over tighten.
Place the food tray on the grinding head and fix it into position.
Locate the unit on a flat place.
The air passage at the bottom and the side of the motor housing should
be kept free and not blocked.
MINCING MEAT
Cut all foods into pieces (Sinewless, boneless and fatless meat is
recommended, approximate size :20 mm x 20 mm x 60 mm) so that they
fit easily into the hopper opening.
Plug the unit on and press direction button ”ON” then ON/0/R switch
"ON" position.
Feed foods into the food tray. Use for it only the pusher (fig.7)
After using, Press OFF“0”position to let appliance to stop, then pull plug
out.
Reversal function
When the food is stuck,you can press the
“reverse” function, but you should press the key
“R” of the direction button first and then press
the key “R” of the ON/0/R switch, then the
machine can turn back the food and avoid
sticking.
After unblocking, release“R” ,and pull plug out,
then clean food out from head of appliance.
MAKING KIBBE
RECIPE
STUFFING
Mutton 100g
Olive oil 1 1/tablespoons
Onion (cut finely) 1 1/tablespoons
Spices to your taste
Salt to your taste
Flour 1 1/tablespoons
Mince mutton once or twice.

Fry onion until brown and add minces mutton, all spice, salt and flour.
OUTLET COUVER
Lean meat 450g
Flour 150-200g
Spices to your taste
Nutmeg (cut finely) 1
Powdered red pepper to your taste
Pepper to your taste
Mince meat three times and mix all ingredients together in a bowl. More
meat and less flour for outlet cover create better consistency and taste.
Grind the mixture three times.
Disassemble by reversing the steps from 5-3 to remove the cutting plate
and cutting blade.
Place kibbe attachments A and B onto the feed screw shaft together,
fitting protrusions in the slots
(fig.8).
Screw cap into place until tight. Do
not over tighten (fig.9).
Make the cylindrical outlet cover
(fig.10).(
Form kibbe ad illustrated below and deep fry.
MAKING SAUSAGE
Before starting please assemble sausage attachment as per following
(fig.11)
CLEANING AND MAINTENACE
DISADDEMBLING
Make sure that the motor has stopped
completely.
Disconnect the plug from the power outlet.

Disassemble by reversing the steps from 1-6 pictures.
To remove the cutting plate easily, place a screwdriver between the
cutting plate and the head as illustrated and lift it up (fig.12).
Press the fasten knob，move the head as per direction illustrated on fig
13,then you can take out the head.
CLEANING
Remove meat, etc. Wash each part in warm soapy water.
A bleaching solution containing chlorine will discolor aluminum surfaces.
Do not immerse the motor housing in water, but only wipe it with a damp
cloth.
Thinners and petrol will crack or change the color of the unit.
Wipe all the cutting parts by vegetable oil -wet cloth.
SPECIFICTION
Power supply
220-240V,50/60Hz
Max. Locked motor approx. wattage
1800W
Net/Gross weight
5.2Kg/6.7Kg
Overall dimension(L×D×H)
275mm X 188mmX 430mm
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local
regulations: hand in the non-working
electrical equipment to an appropriate
waste disposal center.

www.riffelappliances.de
