Rigol RSA5000 Series User manual

RIGOL
User’s Guide
RSA5000 Series Real-time
Spectrum Analyzer
Dec. 22, 2017
RIGOL TECHNOLOGI ES, I NC.
www.valuetronics.com

www.valuetronics.com

RIGOL
RSA5000 User's GuideI
Guaranty and Declaration
Copyright
© 2017 RIGOL TECHNOLOGI ES, I NC. All Rights Reserved.
Trademark I nformation
RIGOL is a registered trademark of RIGOL TECHNOLOGIES, I NC.
Publication Number
UGD20101-1110
Softw are Version
00.01.00
Software upgrade might change or add product features. Please acquire the latest
version of the manual from RIGOL website or contact RIGOL to upgrade the
software.
Notices
RIGOL products are covered by P.R.C. and foreign patents, issued and pending.
RIGOL reserves the right to modify or change parts of or all the specif ications
and pricing policies at the company’s sole decision.
I nformation in this publication replaces all previously released materials.
I nformation in this publication is subject to change without not ice.
RIGOL shall not be liable for either incidental or consequential losses in
connection with the furnishing, use, or performance of this manual, as well as
any information contained.
Any part of this document is forbidden to be copied, photocopied, or rearranged
without prior written approval of RIGOL.
Product Certification
RIGOL guarantees that this product conforms to the national and industrial
standards in China as well as the I SO9001:2008 standard and the ISO14001:2004
standard. Ot her international standard conformance certif ications are in progress.
Contact Us
If you have any problem or requirement when using our products or this manual,
please contact RIGOL.
E-mail: [e-mail]
Website: www.rigol.com
www.valuetronics.com

RIGOL
II RSA5000 User’s Guide
Safety Requirement
General Safety Summary
Please review the following safety precautions carefully before putting the
instrument into operation so as to avoid any personal injury or damage to the
instrument and any product connected to it. To prevent potential hazards, please
follow the instructions specif ied in this manual to use the instrument properly.
Use Proper Pow er Cord.
Only the exclusive power cord designed for the instrument and authorized for use
within the local country could be used.
Ground the I nstrument.
The instrument is grounded through the Protective Earth lead of the power cord. To
avoid electric shock, connect the earth terminal of the power cord to the Protective
Earth terminal before connecting any input or output terminals.
Connect the Probe Correctly.
I f a probe is used, the probe ground lead must be connected to earth ground. Do not
connect the ground lead to high voltage. Improper way of connection could result in
dangerous voltages being present on the connectors, controls or other surfaces of
the oscilloscope and probes, which will cause potential hazards for operators.
Observe All Terminal Ratings.
To avoid f ire or shock hazard, observe all ratings and markers on the instrument and
check your manual for more information about ratings before connecting the
instrument.
Use Proper Overvoltage Protection.
Ensure that no overvoltage (such as that caused by a bolt of lightning) can reach the
product. Otherwise, the operator might be exposed to the danger of an electric
shock.
Do Not Operate Without Covers.
Do not operate the instrument with covers or panels removed.
Do Not I nsert Objects I nto the Air Outlet.
Do not insert objects into the air outlet, as doing so may cause damage to the
instrument.
Use Proper Fuse.
Please use the specif ied fuses.
www.valuetronics.com

RIGOL
RSA5000 User's Guide III
Avoid Circuit or Wire Exposure.
Do not touch exposed junctions and components when the unit is powered on.
Do Not Operate With Suspected Failures.
I f you suspect that any damage may occur to the instrument, have it inspected by
RIGOL authorized personnel before further operations. Any maintenance,
adjustment or replacement especially to circuits or accessories must be performed
by RIGOL authorized personnel.
Provide Adequate Ventilation.
I nadequate ventilation may cause an increase of temperature in the instrument,
which would cause damage to the instrument. So please keep the instrument well
ventilated and inspect the air outlet and the fan regularly.
Do Not Operate in Wet Conditions.
To avoid short circuit inside the instrument or electric shock, never operate the
instrument in a humid environment.
Do Not Operate in an Explosive Atmosphere.
To avoid personal injuries or damage to the instrument, never operate the
instrument in an explosive atmosphere.
Keep Product Surfaces Clean and Dry.
To avoid dust or moisture from affecting the performance of the instrument, keep the
surfaces of the instrument clean and d r y.
Prevent Electrostatic I mpact.
Operate the instrument in an electrostatic discharge protective environment to avoid
damage induced by static discharges. Always ground both the internal and external
conductors of cables to release static before making connections.
Use the Battery Properly.
Do not expose the battery (if available) to high temperature or f ire. Keep it out of the
reach of children. Improper change of a battery (lithium battery) may cause an
explosion. Use the RIGOL specif ied battery only.
Handle with Caution.
Please handle with care during transportation to avoid damage to keys, knobs,
interfaces, and other parts on the panels.
www.valuetronics.com

RIGOL
IV RSA5000 User’s Guide
Safety Notices and Symbols
Safety Notices in this Manual:
WARNI NG
I ndicates a potentially hazardous situation or practice which, if not
avoided, will result in serious injury or death.
CAUTI ON
I ndicates a potentially hazardous situation or practice which, if not
avoided, could result in damage to the product or loss of important data.
Safety Terms on the Product:
DANGER
I t calls attention to an operation, if not correctly performed, could
result in injury or hazard immediately.
WARNI NG
It calls attention to an operation, if not correctly performed, could
result in potential injury or hazard.
CAUTI ON
I t calls attention to an operation, if not correctly performed, could
result in damage to the product or other devices connected to the
product.
Safety Symbols on the Product:
Hazardous
Volt age
Safety Warning
Protective Earth
Terminal
Chassis Ground
Test Ground
www.valuetronics.com

RIGOL
RSA5000 User's Guide V
Care and Cleaning
Care
Do not store or leave the instrument where it may be exposed to direct sunlight for
long periods of time.
Cleaning
Clean the instrument regularly according to its operating conditions.
1. Disconnect the instrument from all power sources.
2. Clean the external surfaces of the instrument with a soft cloth dampened with
mild detergent or water. When cleaning the LCD, take care to avoid scarifying it.
CAUTI ON
To avoid damage to the instrument, do not expose it to caustic liquids.
WARNI NG
To avoid short-circuit resulting from moisture or personal injuries, ensure
that the instrument is completely dry before connecting it to the power
supply.
Environmental Considerations
The following symbol indicates that this product complies with the WEEE Directive
2002/ 96/ EC.
Product End-of-Life Handling
The equipment may contain substances that could be harmful to the environment or
human health. To avoid the release of such substances into the environment and
avoid harm to human health, we recommend you to recycle this product
appropriately to ensure that most materials are reused or recycled properly. Please
contact your local authorities for disposal or recycling information.
www.valuetronics.com

RIGOL
VI RSA5000 User’s Guide
RSA5000 Series Overview
RSA5000 series is a new generation of cost-eff icient real-time spectrum analyzer
with high performance. With superb performance specif ications and the clear user
interface, the RSA5000 series allows you to operate it through various ways, such as
pressing keys on the front panel, using the touch screen, connecting the mouse and
the keyboard. Remote communication interfaces are also available. The instrument
can be widely used in education science, corporate R&D, industrial production, and
other f ields.
Main Features:
Ultra-Real technology
Frequency: up to 6.5 GHz
Displayed average noise level (DANL): < -165 dBm (typical)
Phase noise: < -108 dBc/ Hz (typical)
Level measurement uncertainty: < 0.8 dB
6.5 GHz tracking generator
Min. RBW 1 Hz
EMC f ilter and quasi-peak detector
Various measurement functions
Multiple measurement modes
Up to 40 MHz real-time analysis bandwidth
Multiple trigger modes and trigger masks
Density, Spectrogram, and other display modes
PC software options
10.1'' capacitive multi-touch screen, supporting touch gestures
USB, LAN, HDMI and other communication and display interfaces
www.valuetronics.com

RIGOL
RSA5000 User's Guide VII
Document Overview
Topics in this manual:
Chapter 1 Quick Start
This chapter introduces the front/ rear panel and user interface as well as
announcements during f irst use of the analyzer.
Chapter 2 Functions of the Front Panel of GPSA
This chapter gives detailed function descriptions of the GPSA's front panel keys and
the associated menu keys.
Chapter 3 Functions of the Front Panel of RTSA
This chapter gives detailed function descriptions of the RTSA's front panel keys.
Chapter 4 I nput/ Output
This chapter introduces the parameter settings for the input/ output interface.
Chapter 5 Shortcut Key
This chapter introduces the functions of the shortcut keys on the front panel.
Chapter 6 System Function
This chapter introduces the system function settings.
Chapter 7 Remote Control
This chapter shows how to control the analyzer in remote mode.
Chapter 8 Troubleshooting
This chapter lists the troubleshooting information and messages that may appear
during the use of the analyzer.
Chapter 9 Appendix
This chapter lists the options and accessories that can be ordered along with your
analyzer as well as the service and support information.
www.valuetronics.com

RIGOL
VII I RSA5000 User’s Guide
Format Conventions in this Manual:
1. Keys:
The keys on the front panel are usually denoted by the format of "Key Name
(Bold) + Text Box". For example, FREQ denotes the FREQ key.
2. Menu Keys:
The menu softkeys are usually denoted by the format of "Menu Word (Bold) +
Character Shading". For example, Center Freq denotes the center frequency
menu item under the FREQ function key.
3. Connectors:
The connectors on the front or rear panel are usually denoted by the format of
"Connector Name (Bold) + Square Brackets (Bold)". For example, [ Gen Output
50Ω].
4. Operation Procedures:
"" represents the next step of operation. For example, FREQ Center Freq
indicates pressing FREQ on the front panel and then pressing the menu softkey
Center Freq.
Content Conventions in this Manual:
The RSA5000 series spectrum analyzer includes the following models. This manual
takes RSA5065-TG as an example.
Model
Frequency Range
Tracking Generator
RSA5065
9 kHz to 6.5 GHz
None
RSA5032
9 kHz to 3.2 GHz
None
RSA5065-TG
9 kHz to 6.5 GHz
6.5 GHz
RSA5032-TG
9 kHz to 3.2 GHz
3.2 GHz
User Manuals of this Product:
Quick Guide, User’s Guide, Programming Guide, Data sheet, etc. For the desired
manual, please download it from www.rigol.com.
www.valuetronics.com

Contents RIGOL
RSA5000 User's Guide IX
Contents
Guaranty and Declaration .........................................................................I
Safety Requirement ................................................................................ I I
General Safety Summary ...........................................................................I I
Safety Notices and Symbols...................................................................... I V
Care and Cleaning .................................................................................... V
Environmental Considerations.................................................................... V
RSA5000 Series Overview ...................................................................... VI
Document Overview .............................................................................. VI I
Chapter 1 Quick Start .........................................................................1-1
General I nspection ................................................................................ 1-2
Appearance and Dimensions................................................................... 1-3
To Prepare for Use................................................................................. 1-4
To Adjust the Supporting Legs.......................................................... 1-4
To Connect to AC Power .................................................................. 1-5
Tu r n -on Checkout ........................................................................... 1-5
Self-calibration................................................................................ 1-5
To Set the System Language............................................................ 1-6
Front Panel ........................................................................................... 1-7
Function Keys on the Front Panel ..................................................... 1-8
Utility Function Keys on the Front Panel ...........................................1-10
Front Panel Key Backlight ...............................................................1-11
Front Panel Connector ....................................................................1-12
To Use the Numeric Keypad ............................................................1-14
Rear Panel ...........................................................................................1-16
User I nterface......................................................................................1-18
Mouse/ Keyboard/ Touch Screen Operation Rule........................................1-20
Mouse Operation Rule ....................................................................1-20
Keyboard Operation Rule ................................................................1-21
Touch Screen Operation Rule ..........................................................1-22
Menu Operation ...................................................................................1-23
Parameter Setting.................................................................................1-25
To Use the Built-in Help System .............................................................1-27
Fuse Replacement ................................................................................1-28
Mode Setting .......................................................................................1-29
Mode ............................................................................................1-29
Mode Setup...................................................................................1-30
Chapter 2 Functions of the Front Panel of GPSA................................. 2-1
Basic Settings ....................................................................................... 2-2
FREQ............................................................................................. 2-2
SPAN ............................................................................................. 2-8
www.valuetronics.com

RIGOL Contents
XRSA5000 User’s Guide
AMPT .............................................................................................2-9
Sweep and Function Settings................................................................. 2-14
BW...............................................................................................2-14
Sweep .......................................................................................... 2-18
Tr i g g e r ......................................................................................... 2-22
Tr ace ............................................................................................2-26
Tracking Generator (Option) ...........................................................2-32
Measurement Settings ..........................................................................2-35
Meas ............................................................................................2-35
Meas Setup ...................................................................................2-38
Marker Measurement ............................................................................ 2-66
Marker.......................................................................................... 2-66
Marker To .....................................................................................2-73
Marker Function ............................................................................ 2-75
Peak.............................................................................................2-79
Chapter 3 Functions of the Front Panel of RTSA................................. 3-1
Basic Settings ........................................................................................3-2
FREQ..............................................................................................3-2
SPAN..............................................................................................3-2
AMPT .............................................................................................3-5
Sweep and Function Settings...................................................................3-6
BW.................................................................................................3-6
Sweep ............................................................................................3-8
Tr i g g e r ......................................................................................... 3-10
Tr ace ............................................................................................3-15
Measurement Settings ..........................................................................3-17
Meas ............................................................................................3-17
Meas Setup ...................................................................................3-25
Marker Setup ....................................................................................... 3-32
Marker.......................................................................................... 3-32
Marker To ..................................................................................... 3-32
Marker Function ............................................................................ 3-32
Peak.............................................................................................3-32
Chapter 4 I nput/ Output..................................................................... 4-1
Chapter 5 Shortcut Key ...................................................................... 5-1
Auto Tune .......................................................................................5-1
Preset.............................................................................................5-3
User ...............................................................................................5-9
Quick Save......................................................................................5-9
Cont ...............................................................................................5-9
Single.............................................................................................5-9
Chapter 6 System Function ................................................................ 6-1
System ...........................................................................................6-1
File.................................................................................................6-9
www.valuetronics.com

Contents RIGOL
RSA5000 User's Guide XI
Recall ...........................................................................................6-13
Save .............................................................................................6-15
Chapter 7 Remote Control ..................................................................7-1
Remote Control Overview ....................................................................... 7-2
Remote Control via USB ......................................................................... 7-3
Remote Control via LAN ......................................................................... 7-4
Chapter 8 Troubleshooting .................................................................8-1
Chapter 9 Appendix ............................................................................9-1
Appendix A: RSA5000 Accessories and Option List .................................... 9-1
Appendix B: Warranty ............................................................................ 9-2
I ndex ....................................................................................................... 1
www.valuetronics.com

www.valuetronics.com

Chapter 1 Quick Start RIGOL
RSA5000 User's Guide 1-1
Chapter 1 Quick Start
This chapter gives you a quick review about the appearance and dimensions of the
RSA5000 series, its front and rear panel, user interface, as well as announcements
during f irst use of the analyzer.
Contents in this chapter:
General I nspection
Appearance and Dimensions
To Prepare for Use
Front Panel
Rear Panel
User I nterface
Mouse/ Keyboard/ Touch Screen Operation Rule
Menu Operation
Parameter Setting
To Use the Built-in Help System
Fuse Replacement
Mode Setting
www.valuetronics.com

RIGOL Chapter 1 Quick Start
1-2 RSA5000 User’s Guide
General I nspection
1．I nspect the packaging
I f the packaging has been damaged, do not dispose the damaged packaging or
cushioning materials until the shipment has been checked for completeness and
has passed both electrical and mechanical tests.
The consigner or carrier shall be liable for the damage to the instrument
resulting from shipment. RIGOL would not be responsible for free
maintenance/ rework or replacement of the instrument.
2．I nspect the instrument
I n case of any mechanical damage, missing parts, or failure in passing the
electrical and mechanical tests, contact your RIGOL sales representative.
3．Check the accessories
Please check the accessories according to the packing lists. I f the accessories
are damaged or incomplete, please contact your RIGOL sales representative.
www.valuetronics.com

Chapter 1 Quick Start RIGOL
RSA5000 User's Guide 1-3
Appearance and Dimensions
Figure 1-1 Front View Unit: mm
Figure 1-2 Ver tical View Unit: mm
www.valuetronics.com

RIGOL Chapter 1 Quick Start
1-4 RSA5000 User’s Guide
To Prepare for Use
To Adjust the Supporting Legs
You can unfold the supporting legs to use them as stands to tilt the instrument
upwards for easier operation and observation. You can also fold the supporting legs
for easier storage or shipment when the instrument is not in use.
Figure 1-3 To Adjust the Supporting Legs
To unfold the
supporting legs
To fold the
supporting legs
www.valuetronics.com

Chapter 1 Quick Start RIGOL
RSA5000 User's Guide 1-5
To Connect to AC Pow er
Please use the power cord provided in the accessories to connect the spectrum
analyzer to the AC power source. The AC power supply specif ication of this spectrum
analyzer is 100-240 V, 45-440 Hz. The power consumption of the instrument cannot
exceed 95 W. When the spectrum analyzer is connected to the AC power source via
the power cord, the instrument automatically adapts to the voltage range, and you
do not need to select the voltage range manually.
CAUTI ON
To avoid electric shock, ensure that the instrument is correctly grounded.
Turn-on Checkout
After connecting the instrument to the power source properly, press the Power key
on the front panel to start the spectrum analyzer. Then, you will see an initial
splash screen. Following the start-up screen which shows the start-up initialization
process information, the sweep curve is displayed.
Self-calibration
After the instrument starts, execute self-calibration.
Press System Alignment Align Now, and then the instrument will perform
self-calibration with the internal calibration source.
www.valuetronics.com

RIGOL Chapter 1 Quick Start
1-6 RSA5000 User’s Guide
To Set the System Language
RSA5000 series spectrum analyzer supports multiple system languages. You can
press System Language to switch the system language.
www.valuetronics.com
