Rigol DP800A Series User manual

RIGOL
User’s Guide
DP800A Series Programmable
Linear DC Power Supply
Aug. 2014
RIGOL Technologies, Inc.

RIGOL
DP800A User’s Guide I
Guaranty and Declaration
Copyright
© 2012 RIGOL Technologies, Inc. All Rights Reserved.
Trademark Information
RIGOLis a registered trademark of RIGOL Technologies, Inc.
Publication Number
UGH03106-1110
Software Version
This manual is applicable to software 00.01.11.
Software upgrade might change or add product features. Please acquire the latest
version of the manual from RIGOL website or contact RIGOL to upgrade the
software.
Notices
RIGOL products are covered by P.R.C. and foreign patents, issued and pending.
RIGOL reserves the right to modify or change parts of or all the specifications
and pricing policies at company’s sole decision.
Information in this publication replaces all previously corresponding material.
Information in this publication is subject to change without notice.
RIGOL shall not be liable for either incidental or consequential losses in
connection with the furnishing, use or performance of this manual as well as any
information contained.
Any part of this document is forbidden to be copied, photocopied or rearranged
without prior written approval of RIGOL.
Product Certification
RIGOL guarantees this product conforms to the national and industrial standards in
China as well as the ISO9001:2008 standard and the ISO14001:2004 standard.
Other international standard conformance certification is in progress.
Contact Us
If you have any problem or requirement when using our products or this manual,
please contact RIGOL.
E-mail: [e-mail]
Website: www.rigol.com

RIGOL
II DP800A User’s Guide
Safety Requirement
General Safety Summary
Please review the following safety precautions carefully before putting the
instrument into operation so as to avoid any personal injury or damage to the
instrument and any product connected to it. To prevent potential hazards, please use
the instrument only specified by this manual.
Use Proper Power Cord.
Only the power cord designed for the instrument and authorized for use within the
local country could be used.
Ground the Instrument.
The instrument is grounded through the Protective Earth lead of the power cord. To
avoid electric shock, it is essential to connect the earth terminal of the power cord to
the Protective Earth terminal before connecting any inputs or outputs.
Connect the Probe Correctly.
If a probe is used, do not connect the ground lead to high voltage since it has
isobaric electric potential as the ground.
Observe All Terminal Ratings.
To avoid fire or shock hazard, observe all ratings and markers on the instrument and
check your manual for more information about ratings before connecting the
instrument.
Use Proper Overvoltage Protection.
Make sure that no overvoltage (such as that caused by a thunderstorm) can reach
the product, or else the operator might be exposed to the danger of electrical shock.
Do Not Operate Without Covers.
Do not operate the instrument with covers or panels removed.
Do Not Insert Anything Into the Holes of Fan.
Do not insert anything into the holes of the fan to avoid damaging the instrument.
Use Proper Fuse.
Please use the specified fuses.
Avoid Circuit or Wire Exposure.
Do not touch exposed junctions and components when the unit is powered.

RIGOL
DP800A User’s Guide III
Do Not Operate With Suspected Failures.
If you suspect damage occurs to the instrument, have it inspected by qualified
service personnel before further operations. Any maintenance, adjustment or
replacement especially to circuits or accessories must be performed by RIGOL
authorized personnel.
Keep Well Ventilation.
Inadequate ventilation may cause an increase of temperature or damage to the
device. So please keep the instrument well ventilated and inspect the intake and fan
regularly.
Do Not Operate in Wet Conditions.
In order to avoid short circuiting to the interior of the device or electric shock, please
do not operate the instrument in a humid environment.
Do Not Operate in an Explosive Atmosphere.
In order to avoid damage to the device or personal injuries, it is important to operate
the device away from an explosive atmosphere.
Keep Product Surfaces Clean and Dry.
To avoid the influence of dust and/or moisture in the air, please keep the surface of
the device clean and dry.
Electrostatic Prevention.
Operate the instrument in an electrostatic discharge protective environment to avoid
damage induced by static discharges. Always ground both the internal and external
conductors of cables to release static before making connections.
Proper Use of Battery.
If a battery is supplied, it must not be exposed to high temperature or in contact with
fire. Keep it out of the reach of children. Improper change of battery (note: lithium
battery) may cause explosion. Use RIGOL specified battery only.
Handling Safety.
Please handle with care during transportation to avoid damage to buttons, knob
interfaces and other parts on the panels.
Do Not Provide Power for the Active Load.
In order to avoid the anti-irrigation current which leads to the power control loop out
of control and damages the powered device, this power supply can only provide
power for the pure load without the current output function.

RIGOL
IV DP800A User’s Guide
Safety Terms and Symbols
Terms Used in this Manual. These terms may appear in this manual:
WARNING
Warning statements indicate conditions or practices that could result in
injury or loss of life.
CAUTION
Caution statements indicate conditions or practices that could result in
damage to this product or other property.
Terms Used on the Product. These terms may appear on the Product:
DANGER
indicates an injury or hazard may immediately happen.
WARNING
indicates an injury or hazard may occur.
CAUTION
indicates potential damage to the instrument or other property might
occur.
Symbols Used on the Product. These symbols may appear on the product:
Hazardous
Voltage
Safety
Warning
Protective
Earth
Terminal
Chassis
Ground
Test
Ground

RIGOL
DP800A User’s Guide V
Allgemeine Sicherheits Informationen
Überprüfen Sie diefolgenden Sicherheitshinweise
sorgfältigumPersonenschädenoderSchäden am Gerätundan damit verbundenen
weiteren Gerätenzu vermeiden.Zur Vermeidung vonGefahren, nutzen Sie bitte das
Gerät nur so, wiein diesem Handbuchangegeben.
Um Feuer oder Verletzungen zu vermeiden, verwenden Sie ein
ordnungsgemäßes Netzkabel.
Verwenden Sie für dieses Gerät nur das für ihr Land zugelassene und genehmigte
Netzkabel.
Erden des Gerätes.
Das Gerät ist durch den Schutzleiter im Netzkabel geerdet. Um Gefahren durch
elektrischen Schlag zu vermeiden, ist es unerlässlich, die Erdung durchzuführen. Erst
dann dürfen weitere Ein- oder Ausgänge verbunden werden.
Anschluss einesTastkopfes.
Die Erdungsklemmen der Sonden sindauf dem gleichen Spannungspegel des
Instruments geerdet. SchließenSie die Erdungsklemmen an keine hohe Spannung
an.
Beachten Sie alle Anschlüsse.
Zur Vermeidung von Feuer oder Stromschlag, beachten Sie alle Bemerkungen und
Markierungen auf dem Instrument. Befolgen Sie die Bedienungsanleitung für weitere
Informationen, bevor Sie weitere Anschlüsse an das Instrument legen.
Verwenden Sie einen geeigneten Überspannungsschutz
Stellen Sie sicher, daß keinerlei Überspannung (wie z.B. durch Gewitter verursacht)
das Gerät erreichen kann. Andernfallsbestehtfür den Anwender die
GefahreinesStromschlages.
Nicht ohne Abdeckung einschalten.
Betreiben Sie das Gerät nicht mit entfernten Gehäuse-Abdeckungen.
Betreiben Sie das Gerät nicht geöffnet
Der Betrieb mit offenen oder entfernten Gehäuseteilen ist nicht zulässig. Nichts in
entsprechende Öffnungen stecken (Lüfter z.B.)
Passende Sicherung verwenden
Setzen Sie nur die spezifikationsgemäßen Sicherungen ein.
Vermeiden Sie ungeschützte Verbindungen
Berühren Sie keine unisolierten Verbindungen oder Baugruppen, während das Gerät
in Betrieb ist.

RIGOL
VI DP800A User’s Guide
Betreiben Sie das Gerät nicht im Fehlerfall
Wenn Sie am Gerät einen Defekt vermuten, sorgen Sie dafür, bevor Sie das Gerät
wieder betreiben, dass eine Untersuchung durch qualifiziertes Kundendienstpersonal
durchgeführt wird.Jedwede Wartung, Einstellarbeiten oder Austausch von Teilen am
Gerät, sowie am Zubehör dürfen nur von RIGOL autorisiertem Personal
durchgeführt werden.
Belüftung sicherstellen
Unzureichende Belüftung kann zu Temperaturanstiegen und somit zu thermischen
Schäden am Gerät führen. Stellen Sie deswegen die Belüftung sicher und
kontrollieren regelmäßig Lüfter und Belüftungsöffnungen.
Nicht in feuchter Umgebung betreiben
Zur Vermeidung von Kurzschluß im Geräteinneren und Stromschlag betreiben Sie das
Gerät bitte niemals in feuchter Umgebung.
Nicht in explosiver Atmosphäre betreiben
Zur Vermeidung von Personen- und Sachschäden ist es unumgänglich, das Gerät
ausschließlich fernab jedweder explosiven Atmosphäre zu betreiben.
Geräteoberflächen sauber und trocken halten
Um den Einfluß von Staub und Feuchtigkeit aus der Luft auszuschließen, halten Sie
bitte die Geräteoberflächen sauber und trocken.
Schutz gegen elektrostatische Entladung (ESD)
Sorgen Sie für eine elektrostatisch geschützte Umgebung, um somit Schäden und
Funktionsstörungen durch ESD zu vermeiden. Erden Sie vor dem Anschluß immer
Innen- und Außenleiter der Verbindungsleitung, um statische Aufladung zu entladen.
Die richtige Verwendung desAkku.
Wenneine Batterieverwendet wird, vermeiden Sie hohe Temperaturen bzw. Feuer
ausgesetzt werden.Bewahren Sie es außerhalbder Reichweitevon Kindern
auf.UnsachgemäßeÄnderung derBatterie(Anmerkung:Lithium-Batterie)kann zu einer
Explosion führen. VerwendenSie nur von RIGOLangegebenenAkkus.
Sicherer Transport
Transportieren Sie das Gerät sorgfältig (Verpackung!), um Schäden an
Bedienelementen, Anschlüssen und anderen Teilen zu vermeiden.
Vermeiden Sie das einprägen von Strom und Spannung an den
Testklemmen.
Das DP800A Power Supply kann hierdurch zerstört werden, keine akive Last. Das
DP800A kann nur Strom und Spannungen leifern.

RIGOL
DP800A User’s Guide VII
Sicherheits Begriffe und Symbole
Begriffe in diesem Guide. Diese Begriffe können in diesem Handbuch
auftauchen:
WARNING
Die Kennzeichnung WARNING beschreibt Gefahrenquellen die leibliche
Schäden oder den Tod von Personen zur Folge haben können.
CAUTION
Die Kennzeichnung Caution (Vorsicht) beschreibt Gefahrenquellen die
Schäden am Gerät hervorrufen können.
Begriffe auf dem Produkt. Diese Bedingungen können auf dem Produkt
erscheinen:
DANGER (dt. GEFAHR)
weist auf eine Verletzung oder Gefährdung hin,
die sofort geschehen kann.
WARNING (dt. WARNUNG)
weist auf eine Verletzung oder Gefährdung hin,
die möglicherweise nicht sofort geschehen.
CAUTION (dt. VORSICHT)
bedeutet, dass eine mögliche Beschädigung des
Instruments oder anderer Gegenstände
auftreten kann.
Symbole auf dem Produkt. Diese Symbole können auf dem Produkt
erscheinen:
GefährlicheS
pannung Sicherheits- Hinweis Schutz-erde Gehäusemasse Erde

RIGOL
VIII DP800A User’s Guide
General Care and Cleaning
General Care:
Do not store or leave the instrument where it may be exposed to direct sunlight for
long periods of time.
Cleaning:
Clean the instrument regularly according to its operating conditions. To clean the
exterior surface, perform the following steps:
1. Disconnect the instrument from all power sources.
2. Clean the loose dust on the outside of the instrument with a lint-free cloth (with
a mild detergent or water). When cleaning the LCD, take care to avoid scarifying
it.
CAUTION
To avoid damage to the instrument, do not expose it to caustic liquids.
WARNING
To avoid injury resulting from short circuit, make sure the instrument is
completely dry before reconnecting to a power source.

RIGOL
DP800A User’s Guide IX
Environmental Considerations
The following symbol indicates that this product complies with the WEEE Directives
2002/96/EC.
Product End-of-Life Handling
The equipment may contain substances that could be harmful to the environment or
human health. In order to avoid the release of such substances into the environment
and harm to human health, we encourage you to recycle this product in an
appropriate system that will ensure that most of the materials are reused or recycled
appropriately. Please contact your local authorities for disposal or recycling
information.

RIGOL
X DP800A User’s Guide
DP800A Series Overview
DP800A series is high-performance programmable linear DC power supply. DP800A
series which provides clear user interface, superb performance specifications,
various analysis functions as well as various communication interfaces can fulfill
versatile test requirements.
Main Features:
User-friendly Design:
3.5 inches TFT display, can display multiple parameters and states at the same
time
Support Chinese/English interface and Chinese/English input method
Novel and exquisite industrial design and easy operation
Provide waveform display function to provide real-time and dynamic display of
the output voltage/current waveform, clearly showing the output state and
tendency of the instrument in together with the digital display of the voltage,
current and power values
Provide dial display function, indicating the current output state using the dial
pointer by simulating the traditional power display mode
Provide on-line help system for easy acquisition of help information
Multiple Safety Protection:
Provide overvoltage/overcurrent protection function; users can set the
overvoltage and overcurrent parameters to realize effective protection of the
load
Provide secondary over-temperature protection function to realize double
over-temperature protection of the software and hardware
Provide intelligent fan speed control function; judge and control the fan speed
automatically according to the working condition to effectively reduce the fan
noise
Provide fan failure check and alarm function
Provide keyboard lock function to avoid misoperation
Various Functions and Superb Performance:
Multi-channel output; up to 200W total output power; the output of each
channel can be controlled independently
Superb load regulation rate and linear regulation rate
Provide ultra-low output ripples and noise
Provide timing output function and support infinite and specified number of
cycles of output
Provide track function to track the channel voltage setting value and the output
on/off status
Provide Sense function to automatically compensate for the voltage drop caused
by the leads between the power supply and the load
Provide delay on/off output function and support infinite or specified number of

RIGOL
DP800A User’s Guide XI
cycles of channel on/off toggle
Provide built-in digital trigger to realize digital trigger input and trigger output
functions
Provide built-in on-line analyzer to perform on-line analysis of various statistic
parameters
Provide built-in monitor to monitor the output according to the user-defined
monitor condition
Provide built-in recorder to perform background recording of the output state
after power-on according to certain record period
Provide dedicated preset key to perform one-key reset and one-key recall of the
commonly used output voltage and current configurations
Support serial and parallel output functions
Support on-line self-test and manual calibration functions
Provide store and recall function
Support voltage and current linear programmable functions
Complete Interface Configurations and Flexible Control Method:
Standard configuration interfaces: USB HOST, USB DEVICE, LAN, RS232, Digital
I/O, Rear Output Interface (DP811A)
Support to extend a GPIB interface via the USB-GPIB interface converter
(option)
Support USB storage device storage
Support SCPI remote command control
Conform to LXI Core 2011 Device instrument standard
Provide standard 9 pin RS232 interface with flow control function
Provide 4-wire digital I/O interface which supports the trigger input/output
function

RIGOL
XII DP800A User’s Guide
Document Overview
Chapter 1 Quick Start
Introduce the appearance and dimensions, front panel, rear panel as well as user
interface of DP800A. In addition, it provides the detailed procedures of power
connection, power-on inspection and fuse replacement as well as the method of rack
mount installation of DP800A.
Chapter 2 Front Panel Operations
Introduce the function and operation method of each key at the front panel of
DP800A in detail.
Chapter 3 Remote Control
Introduce how to realize the remote control of the instrument.
Chapter 4 Troubleshooting
Introduce the possible failures and their solutions when using DP800A.
Chapter 5 Specifications
List the specifications of DP800A.
Chapter 6 Appendix
Provide the accessories and options as well as warranty information of DP800A.
Index
Provide keyword search to quickly locate the desired information.
Tip
For the newest version of this manual, download it from RIGOL official website
(www.rigol.com).

RIGOL
DP800A User’s Guide XIII
Format Conventions in this Manual
1. Button
The function key at the front panel is denoted by the format of “Button Name
(Bold) + Text Box” in the manual, for example, Utility denotes the “Utility” key.
2. Menu
The menu item is denoted in the following two modes in this manual.
(1) The menu item can be denoted by the format of “Menu Word (Bold) +
Character Shading”, for example, System denotes the “System” item under
Utility.
(2) The menu item can be denote by the screenshot of the menu key, for
example, .
3. Operation Step
The next step of the operation is denoted by an arrow “” in the manual. For
example, Utility System denotes pressing Utility at the front panel and
then pressing System.
Content Conventions in this Manual
DP800A series programmable linear DC power supply includes the following models.
In this manual, DP831A is taken as an example to illustrate the functions and
operating methods of DP800A series.
Model
Channel
Channel Output Voltage/Current
DP831A
3
8V/5A, 30V/2A, -30V/2A
DP832A
3
30V/3A, 30V/3A, 5V/3A
DP821A
2
60V/1A, 8V/10A
DP811A
1
Range 1: 20V/10A; Range 2: 40V/5A

RIGOL Contents
XIV DP800A User’s Guide
Contents
Guaranty and Declaration.........................................................................I
Safety Requirement.................................................................................II
General Safety Summary...........................................................................II
Safety Terms and Symbols ....................................................................... IV
Allgemeine Sicherheits Informationen ........................................................ V
Sicherheits Begriffe und Symbole.............................................................VII
General Care and Cleaning.....................................................................VIII
Environmental Considerations................................................................... IX
DP800A Series Overview ......................................................................... X
Document Overview............................................................................. XII
Chapter 1 Quick Start ........................................................................ 1-1
General Inspection.................................................................................1-2
Appearance and Dimensions ...................................................................1-3
Front Panel............................................................................................1-4
Rear Panel...........................................................................................1-13
To Connect to Power ............................................................................1-15
Power-on Inspection.............................................................................1-16
To Replace the Fuse.............................................................................1-16
User Interface......................................................................................1-18
To Use the Built-in Help System.............................................................1-20
To Rack Mount the Instrument ..............................................................1-21
To Install a Single Instrument.........................................................1-21
To Install Two Instruments .............................................................1-29
Chapter 2 Front Panel Operations...................................................... 2-1
Constant Voltage Output.........................................................................2-2
Constant Current Output.........................................................................2-6
Power Supply Series and Parallel Connections...........................................2-8
Power Supply Series Connection........................................................2-8
Power Supply Parallel Connection......................................................2-9
Track Function.....................................................................................2-10
To Enable the Track Function..........................................................2-10
To Track the On/Off Status of the Channel Output.............................2-13
Sense Working Mode............................................................................2-14
Timer and Delayer................................................................................2-16
To Set the Timer Parameters...........................................................2-17
To Enable the Timer.......................................................................2-26
To Set the Delay Parameters...........................................................2-27
To Enable the Delayer....................................................................2-31
Advanced Functions .............................................................................2-32
Recorder.......................................................................................2-33

Contents RIGOL
DP800A User’s Guide XV
Analyzer........................................................................................2-34
Monitor.........................................................................................2-37
Trigger..........................................................................................2-38
Display Setting.....................................................................................2-42
Brightness.....................................................................................2-42
Contrast........................................................................................2-42
RGB Luminance.............................................................................2-42
Display Mode.................................................................................2-43
User-defined Start-up Interface.......................................................2-44
Store and Recall...................................................................................2-46
Browser........................................................................................2-47
File Type.......................................................................................2-47
Save.............................................................................................2-48
Read.............................................................................................2-50
Delete...........................................................................................2-50
Copy and Paste..............................................................................2-51
Utility..................................................................................................2-52
I/O Configuration...........................................................................2-53
System Setting ..............................................................................2-59
System Information........................................................................2-60
System Language ..........................................................................2-61
Test/Calibration..............................................................................2-61
Print.............................................................................................2-62
Preset Setting................................................................................2-63
Option ..........................................................................................2-70
Chapter 3 Remote Control..................................................................3-1
Remote Control via USB......................................................................... 3-2
Remote Control via LAN......................................................................... 3-5
Remote Control via GPIB........................................................................ 3-8
Remote Control via RS232.....................................................................3-10
Chapter 4 Troubleshooting.................................................................4-1
Chapter 5 Specifications.....................................................................5-1
Chapter 6 Appendix............................................................................6-1
Appendix A: Accessories and Options ...................................................... 6-1
Appendix B: Warranty............................................................................ 6-2
Index .......................................................................................................1

Chapter 1 Quick Start RIGOL
DP800A User’s Guide 1-1
Chapter 1 Quick Start
The contents of this chapter are as follows:
General Inspection
Appearance and Dimensions
Front Panel
Rear Panel
To Connect to Power
Power-on Inspection
To Replace the Fuse
User Interface
To Use the Built-in Help System
To Rack Mount the Instrument

RIGOL Chapter 1 Quick Start
1-2 DP800A User’s Guide
General Inspection
1. Inspect the shipping container for damage
Keep the damaged shipping container or cushioning material until the contents
of the shipment have been checked for completeness and the instrument has
passed both electrical and mechanical tests.
The consigner or carrier shall be liable for the damage to instrument resulting
from shipment. RIGOL would not be responsible for free maintenance/rework
or replacement of the unit.
2. Inspect the instrument
In case of any damage, or defect, or failure, notify your RIGOL sales
representative.
3. Check the accessories
Please check the accessories according to the packing lists. If the accessories
are incomplete or damaged, please contact your RIGOL sales representative.
