Rigol DP700 Series User manual

RIGOL
User’s Guide
DP700 Series Programmable
Linear DC Power Supply
Apr. 2016
RIGOL TECHNOLOGIES, INC.

RIGOL
DP700 User’s Guide I
Guaranty and Declaration
Copyright
© 2016 RIGOL TECHNOLOGIES, INC. All Rights Reserved.
Trademark Information
RIGOL is a registered trademark of RIGOL TECHNOLOGIES, INC.
Publication Number
UGH05101-1110
Software Version
00.01.02
Software upgrade might change or add product features. Please acquire the latest
version of the manual from RIGOL website or contact RIGOL to upgrade the
software.
Notices
RIGOL products are covered by P.R.C. and foreign patents, issued and pending.
RIGOL reserves the right to modify or change parts of or all the specifications
and pricing policies at the company’s sole decision.
Information in this publication replaces all previously released materials.
Information in this publication is subject to change without notice.
RIGOL shall not be liable for either incidental or consequential losses in
connection with the furnishing, use, or performance of this manual, as well as
any information contained.
Any part of this document is forbidden to be copied, photocopied, or rearranged
without prior written approval of RIGOL.
Product Certification
RIGOL guarantees that this product conforms to the national and industrial
standards in China as well as the ISO9001:2008 standard and the ISO14001:2004
standard. Other international standard conformance certifications are in progress.
Contact Us
If you have any problem or requirement when using our products or this manual,
please contact RIGOL.
E-mail: [e-mail]
Website: www.rigol.com

RIGOL
II DP700 User’s Guide
Safety Requirement
General Safety Summary
Please review the following safety precautions carefully before putting the
instrument into operation so as to avoid any personal injury or damage to the
instrument and any product connected to it. To prevent potential hazards, please
follow the instructions specified in this manual to use the instrument properly.
Use Proper Power Cord.
Only the exclusive power cord designed for the instrument and authorized for use
within the local country could be used.
Ground the Instrument.
The instrument is grounded through the Protective Earth lead of the power cord. To
avoid electric shock, connect the earth terminal of the power cord to the Protective
Earth terminal before connecting any input or output terminals.
Connect the Probe Correctly.
If a probe is used, the probe ground lead must be connected to earth ground. Do not
connect the ground lead to high voltage. Improper way of connection could result in
dangerous voltages being present on the connectors, controls or other surfaces of
the oscilloscope and probes, which will cause potential hazards for operators.
Observe All Terminal Ratings.
To avoid fire or shock hazard, observe all ratings and markers on the instrument and
check your manual for more information about ratings before connecting the
instrument.
Use Proper Overvoltage Protection.
Ensure that no overvoltage (such as that caused by a bolt of lightning) can reach the
product. Otherwise, the operator might be exposed to the danger of an electric
shock.
Do Not Operate Without Covers.
Do not operate the instrument with covers or panels removed.
Do Not Insert Objects Into the Air Outlet.
Do not insert objects into the air outlet, as doing so may cause damage to the
instrument.
Use Proper Fuse.
Please use the specified fuses.

RIGOL
DP700 User’s Guide III
Avoid Circuit or Wire Exposure.
Do not touch exposed junctions and components when the unit is powered on.
Do Not Operate With Suspected Failures.
If you suspect that any damage may occur to the instrument, have it inspected by
RIGOL authorized personnel before further operations. Any maintenance,
adjustment or replacement especially to circuits or accessories must be performed
by RIGOL authorized personnel.
Provide Adequate Ventilation.
Inadequate ventilation may cause an increase of temperature in the instrument,
which would cause damage to the instrument. So please keep the instrument well
ventilated and inspect the air outlet and the fan regularly.
Do Not Operate in Wet Conditions.
To avoid short circuit inside the instrument or electric shock, never operate the
instrument in a humid environment.
Do Not Operate in an Explosive Atmosphere.
To avoid personal injuries or damage to the instrument, never operate the
instrument in an explosive atmosphere.
Keep Product Surfaces Clean and Dry.
To avoid dust or moisture from affecting the performance of the instrument, keep the
surfaces of the instrument clean and dry.
Prevent Electrostatic Impact.
Operate the instrument in an electrostatic discharge protective environment to avoid
damage induced by static discharges. Always ground both the internal and external
conductors of cables to release static before making connections.
Use the Battery Properly.
Do not expose the battery (if available) to high temperature or fire. Keep it out of the
reach of children. Improper change of a battery (lithium battery) may cause an
explosion. Use the RIGOL specified battery only.
Handle with Caution.
Please handle with care during transportation to avoid damage to keys, knobs,
interfaces, and other parts on the panels.
Do Not Use this Instrument to Provide Power for the Active Load.
The backflow current may cause the power control loop to be out of control, which
could further damage the devices that receives the power supply from this
instrument. Therefore, this instrument is only allowed to provide power for the pure
load that does not have the current output function.

RIGOL
IV DP700 User’s Guide
Safety Notices and Symbols
Safety Notices in this Manual:
WARNING
Indicates a potentially hazardous situation or practice which, if not
avoided, will result in serious injury or death.
CAUTION
Indicates a potentially hazardous situation or practice which, if not
avoided, could result in damage to the product or loss of important data.
Safety Terms on the Product:
DANGER
It calls attention to an operation, if not correctly performed, could
result in injury or hazard immediately.
WARNING
It calls attention to an operation, if not correctly performed, could
result in potential injury or hazard.
CAUTION
It calls attention to an operation, if not correctly performed, could
result in damage to the product or other devices connected to the
product.
Safety Symbols on the Product:
Hazardous
Voltage
Safety Warning
Protective Earth
Terminal
Chassis Ground
Test Ground

RIGOL
DP700 User’s Guide V
Allgemeine Sicherheits Informationen
Überprüfen Sie diefolgenden Sicherheitshinweise
sorgfältigumPersonenschädenoderSchäden am Gerätundan damit verbundenen
weiteren Gerätenzu vermeiden. Zur Vermeidung vonGefahren, nutzen Sie bitte das
Gerät nur so, wiein diesem Handbuchangegeben.
Um Feuer oder Verletzungen zu vermeiden, verwenden Sie ein
ordnungsgemäßes Netzkabel.
Verwenden Sie für dieses Gerät nur das für ihr Land zugelassene und genehmigte
Netzkabel.
Erden des Gerätes.
Das Gerät ist durch den Schutzleiter im Netzkabel geerdet. Um Gefahren durch
elektrischen Schlag zu vermeiden, ist es unerlässlich, die Erdung durchzuführen. Erst
dann dürfen weitere Ein- oder Ausgänge verbunden werden.
Anschluss einesTastkopfes.
Die Erdungsklemmen der Sonden sindauf dem gleichen Spannungspegel des
Instruments geerdet. SchließenSie die Erdungsklemmen an keine hohe Spannung
an.
Beachten Sie alle Anschlüsse.
Zur Vermeidung von Feuer oder Stromschlag, beachten Sie alle Bemerkungen und
Markierungen auf dem Instrument. Befolgen Sie die Bedienungsanleitung für weitere
Informationen, bevor Sie weitere Anschlüsse an das Instrument legen.
Verwenden Sie einen geeigneten Überspannungsschutz.
Stellen Sie sicher, daß keinerlei Überspannung (wie z.B. durch Gewitter verursacht)
das Gerät erreichen kann. Andernfallsbestehtfür den Anwender die
GefahreinesStromschlages.
Nicht ohne Abdeckung einschalten.
Betreiben Sie das Gerät nicht mit entfernten Gehäuse-Abdeckungen.
Betreiben Sie das Gerät nicht geöffnet.
Der Betrieb mit offenen oder entfernten Gehäuseteilen ist nicht zulässig. Nichts in
entsprechende Öffnungen stecken (Lüfter z.B.)
Passende Sicherung verwenden.
Setzen Sie nur die spezifikationsgemäßen Sicherungen ein.
Vermeiden Sie ungeschützte Verbindungen.
Berühren Sie keine unisolierten Verbindungen oder Baugruppen, während das Gerät
in Betrieb ist.

RIGOL
VI DP700 User’s Guide
Betreiben Sie das Gerät nicht im Fehlerfall.
Wenn Sie am Gerät einen Defekt vermuten, sorgen Sie dafür, bevor Sie das Gerät
wieder betreiben, dass eine Untersuchung durch RIGOL autorisiertem Personal
durchgeführt wird. Jedwede Wartung, Einstellarbeiten oder Austausch von Teilen am
Gerät, sowie am Zubehör dürfen nur von RIGOL autorisiertem Personal
durchgeführt werden.
Belüftung sicherstellen.
Unzureichende Belüftung kann zu Temperaturanstiegen und somit zu thermischen
Schäden am Gerät führen. Stellen Sie deswegen die Belüftung sicher und
kontrollieren regelmäßig Lüfter und Belüftungsöffnungen.
Nicht in feuchter Umgebung betreiben.
Zur Vermeidung von Kurzschluß im Geräteinneren und Stromschlag betreiben Sie das
Gerät bitte niemals in feuchter Umgebung.
Nicht in explosiver Atmosphäre betreiben.
Zur Vermeidung von Personen- und Sachschäden ist es unumgänglich, das Gerät
ausschließlich fernab jedweder explosiven Atmosphäre zu betreiben.
Geräteoberflächen sauber und trocken halten.
Um den Einfluß von Staub und Feuchtigkeit aus der Luft auszuschließen, halten Sie
bitte die Geräteoberflächen sauber und trocken.
Schutz gegen elektrostatische Entladung (ESD).
Sorgen Sie für eine elektrostatisch geschützte Umgebung, um somit Schäden und
Funktionsstörungen durch ESD zu vermeiden. Erden Sie vor dem Anschluß immer
Innen- und Außenleiter der Verbindungsleitung, um statische Aufladung zu entladen.
Die richtige Verwendung desAkku.
Wenneine Batterieverwendet wird, vermeiden Sie hohe Temperaturen bzw. Feuer
ausgesetzt werden. Bewahren Sie es außerhalbder Reichweitevon Kindern auf.
UnsachgemäßeÄnderung derBatterie (Anmerkung: Lithium-Batterie) kann zu einer
Explosion führen. VerwendenSie nur von RIGOLangegebenenAkkus.
Sicherer Transport.
Transportieren Sie das Gerät sorgfältig (Verpackung!), um Schäden an
Bedienelementen, Anschlüssen und anderen Teilen zu vermeiden.
Vermeiden Sie das einprägen von Strom und Spannung an den
Testklemmen.
Das DP700 Power Supply kann hierdurch zerstört werden, keine akive Last. Das
DP800A kann nur Strom und Spannungen leifern.

RIGOL
DP700 User’s Guide VII
Sicherheits Begriffe und Symbole
Begriffe in diesem Guide:
WARNING
Die Kennzeichnung WARNING beschreibt Gefahrenquellen die leibliche
Schäden oder den Tod von Personen zur Folge haben können.
CAUTION
Die Kennzeichnung Caution (Vorsicht) beschreibt Gefahrenquellen die
Schäden am Gerät hervorrufen können.
Begriffe auf dem Produkt:
DANGER
weist auf eine Verletzung oder Gefährdung hin, die sofort
geschehen kann.
WARNING
weist auf eine Verletzung oder Gefährdung hin, die möglicherweise
nicht sofort geschehen.
CAUTION
weist auf eine Verletzung oder Gefährdung hin und bedeutet, dass
eine mögliche Beschädigung des Instruments oder anderer
Gegenstände auftreten kann.
Symbole auf dem Produkt:
Gefährliche
Spannung Sicherheits- Hinweis Schutz-erde Gehäusemasse Erde

RIGOL
VIII DP700 User’s Guide
Care and Cleaning
Care
Do not store or leave the instrument where it may be exposed to direct sunlight for
long periods of time.
Cleaning
Clean the instrument regularly according to its operating conditions.
1. Disconnect the instrument from all power sources.
2. Clean the external surfaces of the instrument with a soft cloth dampened with
mild detergent or water. When cleaning the LCD, take care to avoid scarifying it.
CAUTION
To avoid damage to the instrument, do not expose it to caustic liquids.
WARNING
To avoid short-circuit resulting from moisture or personal injuries, ensure
that the instrument is completely dry before connecting it to the power
supply.
Environmental Considerations
The following symbol indicates that this product complies with the WEEE Directive
2002/96/EC.
Product End-of-Life Handling
The equipment may contain substances that could be harmful to the environment or
human health. To avoid the release of such substances into the environment and
avoid harm to human health, we recommend you to recycle this product
appropriately to ensure that most materials are reused or recycled properly. Please
contact your local authorities for disposal or recycling information.

RIGOL
DP700 User’s Guide IX

RIGOL
XDP700 User’s Guide
DP700 Series Overview
DP700 series power supply is a type of affordable programmable linear DC power
supply with high performance. With superb performance specifications, pure and
reliable output, and clear user interface, the DP700 series supports timing output and
trigger function, and provides a remote communication interface, enabling you to
meet your diversified test requirements.
Main Features:
DP711: single output, 30 V/5 A, total power up to 150 W
DP712: single output, 50 V/3 A, total power up to 150 W
Low ripple and noise:
DP711: <500 uVrms/3 mVpp, <2 mArms
DP712: <500 uVrms/4 mVpp, <2 mArms
Excellent load and line regulation rate: <0.01% + 2 mV; <0.01% + 2 mA
Transient response time: <50 μs
1 mV/1 mA resolution (optional)
Sound overvoltage/overcurrent/overtemperature protection, with the response
time for the overvoltage protection less than 10 ms
External trigger function supported, enabling synchronous output for multiple
devices
Timing output supported (10 ms to 99999 s) for up to 2,048 groups
3.5-inch TFT-LCD; compact and elegant; easy to use
Front panel locking and any specified key locking supported
RS232 interface communication supported

RIGOL
DP700 User’s Guide XI
Document Overview
Chapter 1 Quick Start
This chapter introduces some basic information that you should know when you use
the DP700 series power supply for the first time. It contains the following contents:
out-of-box inspection method, the appearance and dimensions of the instrument,
descriptions of the front/rear panel, how to connect the instrument to the AC power,
how to carry out the power-on inspection, how to replace the fuse, a brief
introduction about the user interface, and how to set the parameters.
Chapter 2 Front Panel Operations
This chapter introduces what functions can be realized through the front panel
operations and the operation methods.
Chapter 3 Remote Control
This chapter introduces how to remotely control the instrument.
Chapter 4 Troubleshooting
This chapter introduces the possible failures and solutions in using the DP700 series
power supply.
Chapter 5 Specifications
This chapter lists the specifications of the DP700 series power supply.
Chapter 6 Appendix
This chapter provides order information and warranty information of the DP700
series power supply.
Index
This chapter provides keyword search information, enabling you to quickly locate the
desired information.
Tip
For the latest version of this manual, download it from the official website of
RIGOL
(www.rigol.com).
Format Conventions in this Manual
Key
(1) The key on the front panel is denoted by the format of “Key Name (Bold) + Text
Box” in the manual. For example, On/Off denotes the "On/Off" key.
(2) Use the screen shot to indicate the key. For example, denotes the Power
key.

RIGOL
XII DP700 User’s Guide
Content Conventions in this Manual
DP700 series programmable linear DC power supply includes the following models.
Unless otherwise specified, this manual takes DP711 as an example to illustrate the
functions and operation methods of the DP700 series.
Model No. of Channels Output Voltage/Current
DP711 1 30 V/5 A
DP712
1
50 V/3 A

Contents RIGOL
DP700 User’s Guide XIII
Contents
Guaranty and Declaration.........................................................................I
Safety Requirement................................................................................II
General Safety Summary...........................................................................II
Safety Notices and Symbols......................................................................IV
Allgemeine Sicherheits Informationen.........................................................V
Sicherheits Begriffe und Symbole.............................................................VII
Care and Cleaning.................................................................................VIII
Environmental Considerations.................................................................VIII
DP700 Series Overview............................................................................X
Document Overview............................................................................... XI
Chapter 1 Quick Start.........................................................................1-1
General Inspection ................................................................................ 1-2
Appearance and Dimensions................................................................... 1-3
Front Panel........................................................................................... 1-4
Rear Panel...........................................................................................1-10
User Interface......................................................................................1-12
Power-on Inspection.............................................................................1-14
Fuse Replacement................................................................................1-17
Built-in Help Information.......................................................................1-17
Parameter Setting Method.....................................................................1-18
Chapter 2 Front Panel Operations ......................................................2-1
Constant Voltage Output........................................................................ 2-2
Constant Current Output........................................................................ 2-5
Power Supply in Series and Parallel Connection ........................................ 2-8
Power Supply in Series Connection ................................................... 2-8
Power Supply in Parallel Connection.................................................. 2-9
Timer..................................................................................................2-10
Set Timer Parameters.....................................................................2-11
Enable the Timing Output...............................................................2-14
Trigger ................................................................................................2-16
Trigger Input.................................................................................2-16
Trigger Output...............................................................................2-17
Synchronous Output.......................................................................2-17
Store and Recall...................................................................................2-20
Manage Files.................................................................................2-21
Restore Default Settings.................................................................2-24
Clear All Saved Files.......................................................................2-25
System Utility Function .........................................................................2-26
System Setting ..............................................................................2-27
RS232 Interface Setting..................................................................2-30

RIGOL Contents
XIV DP700 User’s Guide
System Information .......................................................................2-32
Test and Calibration.......................................................................2-33
Option Configuration......................................................................2-35
Remote Locking...................................................................................2-37
Front Panel Locking .......................................................................2-37
Key Locking ..................................................................................2-38
Chapter 3 Remote Control ................................................................. 3-1
Chapter 4 Troubleshooting ................................................................ 4-1
Chapter 5 Specifications .................................................................... 5-1
Chapter 6 Appendix ........................................................................... 6-1
Appendix A: Order Information................................................................6-1
Appendix B: Warranty.............................................................................6-2
Index........................................................................................................1

Chapter 1 Quick Start RIGOL
DP700 User’s Guide 1-1
Chapter 1 Quick Start
Contents in this chapter:
General Inspection
Appearance and Dimensions
Front Panel
Rear Panel
User Interface
Power-on Inspection
Fuse Replacement
Built-in Help Information
Parameter Setting Method

RIGOL Chapter 1 Quick Start
1-2 DP700 User’s Guide
General Inspection
1．Inspect the packaging
If the packaging has been damaged, do not dispose the damaged packaging or
cushioning materials until the shipment has been checked for completeness and
has passed both electrical and mechanical tests.
The consigner or carrier shall be liable for the damage to the instrument
resulting from shipment. RIGOL would not be responsible for free
maintenance/rework or replacement of the instrument.
2．Inspect the instrument
In case of any mechanical damage, missing parts, or failure in passing the
electrical and mechanical tests, contact your RIGOL sales representative.
3．Check the accessories
Please check the accessories according to the packing lists. If the accessories
are damaged or incomplete, please contact your RIGOL sales representative.

Chapter 1 Quick Start RIGOL
DP700 User’s Guide 1-3
Appearance and Dimensions
Figure 1-1 Front View Unit: mm
Figure 1-2 Side View Unit: mm
202
324
331.7
140

RIGOL Chapter 1 Quick Start
1-4 DP700 User’s Guide
Front Panel
V
mV
mA A
+
POWER
ON OFF
30V/5A
Number
1 2 3
4 5 6
7 8 9
Memory
System
OK
0
Figure 1-3 Front Panel
1. LCD
3.5-inch TFT-LCD. It is used to display the parameter setting, output status, help
information, prompt message, etc.
2. Function Keys
2.1 System utility function key
System
(1) System setting
Set the system language, power-on setting, and
brightness; turn on or off the beeper and screen saver;
enable the trigger input and trigger output.
(2) RS232 interface setting
Set baud rate and parity; view stop bit and data bit.
(3) System information
View the device model, serial number, and software
version.
(4) Test and calibration
View the test information: fan state.
View the auto calibration information: the auto
calibration status and the last auto calibration time.
 Perform manual calibration for voltage DAC calibration,
1. LCD
2. Function Keys
3. Output On/Off Key
4. Power Key
5. Output
Terminals
6. Arrow Keys and
Confirmation Key
7. Knob
8. Num Keys and
Return Key
