ring 4000 User manual

Ring Smart Dash Cam 4000
Dashcam HD 1296p
English
Français
Español
Italiano
Dutch
Deutsch

WARNING
1
Individual special requirements and legislationof the countries must be observed, especiallyconcerning
the duration of the records/use andthe transfer of data. Please make yourself familiar with the datapro-
tection laws of your country and ensure thatyou comply with them. Please also familiarize yourself and
comply withthe relevant laws and regulations regarding theuse and ownership of dash cameras in
yourcountry.
DE/AT: Permanent and occasion-free recordings are not permitted, i.e. no recording of the entire route,
license plates or strangers (so-called loop function). When recording an event, e.g. an accident, all
parties involved must be informed about the recording and about its transfer to the police. No posting
of recordings in public media (Internet, social media) without the consent of all persons concerned or
only after disguising the persons and license plates. It must be impossible to draw conclusions about
persons, e.g. through pictures of the surroundings.
2 The dashcam must not be fitted in a position which obscures the driver’s view of the road ahead.
3Only use the supplied power adapter, otherwise damage may occur to the dashcam. Take care when
cleaning the dashcam lens and only use a suitable lens cleaner and a soft cloth. Do NOT expose this
product to rain, moisture or water under any circumstances; doing so may result in the risk of electric
shock or fire. Do NOT perform servicing other than that contained in the instruction manual, unless you
are qualified to do so. When installing in a vehicle, always place the device securely against the wind-
screen and where possible conceal the power cable under the vehicles interior trim. Make sure that the
power cable doesn’t interfere with the driver’s controls such as the steering wheel, pedals or gear lever.
Do NOT mount the dashcam in front of an airbag deployment area or in a position to obscure any interior
mirrors. Do NOT operate while driving and only adjust settings or review recordings while not driving.

If you haven’t already downloaded the app, do so now to
get the most from your dashcamera.
1 Download the app by searching for RINGconnect in
the App Store (iPhone) or Google Play (Android).
2 Open the app, follow the setup process shown and
enable all necessary settings when prompted.
BEFORE YOU BEGIN

1Dashcam
2Quick Start Guide
3Magnetic Mount
4USB Charging Cable
5Trim Removal Tool
6Window Sticker
PACKAGE CONTENTS
Ring Dash Cam 2000
Dashcam HD 1080p
1
6
4
5
3
2

ATTENTION! Choose the installation location in advance,
as the adhesive tape on the mount is of single use.
1Ensure glass is dirt, dust and grease free.
2Warm adhesive pad part of mount in hands to ensure strong adhesion to glass.
3Once mount has been positioned connect dashcamera to the magnetic mount.

To power the device and charge the battery, use only the power adapt-
er included. Connect the power cable to the mount, and then plug the
USB charger into the vehicles 12V power socket.
When the vehicle’s engine starts, the device turns on automatically.

1 Before installing a memory card, make
sure the device is turned off.
2 Insert the memory card until it clicks into
place.
3 Removing a card: press the card slightly
and then reamove it from the slot.
INSTALLING microSD CARD
WARNING! Do not apply excessive force when inserting a memory card to avoid
damage to the device. If necessary, use a thin pointed device to push the card
further. To remove the memory card, push the card until it clicks and remove the
card from the slot.

TURNING ON/OFF
•When the vehicle ignition is turned ON
the dashcam turns on automatically.
•To turn the device on manually, press
the power button.
•To turn the device off press and hold the
power button for approx. 3 seconds.

CONNECTING TO MOBILE
1Switch on dashcam.
2Your camera automatically
broadcasts a Wi-Fi network.
3Open your phone’s Settings.
4Tap on Wi-Fi
or Connections.
5Select the dashcam
hotspot and enter the
password “12345678”.
6You are now connected
to your device.

ADJUSTING VIEWING ANGLE
ATTENTION! Adjusting the viewing angle can only be done along the vertical
axis, so be sure to position the device correctly on the windshield along the hori-
zontal axis as close as possible to the windshield’s center.
While pulling or pushing the device in the holder, ensure that the camera cap-
tures the image in proportions of 30% sky/70% road.
Good Bad

To access the Menu settings, press the
“Settings” button on the main menu.
Video Quality: Select required option
(the highest option provides the
optimum viewing performance).
Image Resolution: 1-12 Megapixels
Loop Recording: 1, 3, or 5 minutes
Date Stamp: OFF / ON
Record Audio: OFF / ON
Parking Monitor: OFF / ON
G-sensor: OFF/LOW/MEDIUM/HIGH
MENU SETTINGS

1Emergency recording is to protect the
current video file from being overwritten
and deleted.
2Emergency recording is activated
automatically when the G-sensor trig-
gers (sudden acceleration/decelera-
tion), or at point of collision. Emergen-
cy recording is locked automatically to
avoid erasing during loop recording.
EMERGENCY RECORDING

1To access the playback
menu, press the album but-
ton on the main screen.
2Video & Image Menu.
•Select either Videos or
Images tiles to view.
RECORDING PLAYBACK

1Short-press each video file once
to get into the playback menu.
2Press and hold each video file
for 3 seconds to access the vid-
eo’s sub-menu. From there, lock,
download, share, or delete the
selected video.
VIDEO MENU

1Short-press each image file once
to get into the playback menu.
2Press and hold each image file
for 3 seconds to access the vid-
eo’s sub-menu. From there, lock,
download, share, or delete the
selected image.
IMAGE MENU

To access the FAQs Menu, press the
dropdown menu and select FAQs.
Swipe up or down to view all common
frequently asked questions.
FAQs MENU

1To access the Installation Guide
Menu, press the dropdown menu
and select Installation Guide.
2Another dropdown menu will ap-
pear. Select the dashcam being
used from the dropdown menu.
INSTALLATION GUIDE MENU

FAILURE TO PHOTOGRAPH/RECORD VIDEO
Check if there is enough free space on the micro SD card.
RECORDING HAS STOPPED
Too many video files stored. Only use at least class 10 U1 high-speed micro SD cards by proven
manufacturers.
When you try to view a photo/play a video file, the “wrong file” message appears.
File writing failure due to micro SD card file system error. Format the micro SD card.
BLURRED IMAGE
Ensure removal of lens sticker. Check for dirt on the lens. If there is any, wipe the lens with a soft
cloth before use (it is recommended to use special care products for the optics in order not to
damage the surface of the lens).

HANG UP (NO IMAGE, NO BUTTON RESPONSE)
Press the RESET button in the App to reboot the device.
MicroSD Card not recognized when used in Ring Smart
Dash Cam 4000 **
Please format card *
1Ensure MicroSD cards is inserted correctly into dashcam
2Connect dash cam to RINGconnect APP
3Once dashcam connected to APP select settings ‘COG ICON’
4Select FORMAT option
4Select YES to FORMAT MicroSD card
*Format MicroSD card will delete all information and recordings from the MicroSD card
** Dashcam will have a constant beep noise if card is not recognized and needs to be formatted.
Please note: If a micro SD card larger than 32GB is used, the latest firmware update is required.

FEATURES
*
Full HD at 30 FPS.
** Max record time dependent on screen resolution, memory card size, and rear camera
attachment.
Ring Smart Dash
Cam 4000 1440p 140 ° ≤128 GB* ≤20 HRS* Wi-Fi GPS
Ring Smart Dash
Cam 3000 1296p 130 ° ≤64 GB* ≤12 HRS* Wi-Fi GPS
Ring Smart Dash
Cam 2000 1080p 120 ° ≤32 GB* ≤6 HRS* Wi-Fi
Ring Dash Cam
1000 720p 110 ° ≤32 GB* ≤3 HRS*
