ring Smart Dash Cam 3000 User manual

C
M
Y
CM
MY
CY
CMY
K
13750 RING RRSDC30-pro_quick-start-guide Hi-res.pdf 1 13/04/2021 09:36

C
M
Y
CM
MY
CY
CMY
K
13750 RING RRSDC30-pro_quick-start-guide Hi-res.pdf 2 13/04/2021 09:36

English
Français
Español
Italiano
Dutch
Deutsch
Ring Smart Dash Cam 3000
Dashcam HD 1296p

WARNING
1
Individual special requirements and legislationof the countries must be observed, especiallyconcerning
the duration of the records/use andthe transfer of data. Please make yourself familiar with the datapro-
tection laws of your country and ensure thatyou comply with them. Please also familiarize yourself and
comply withthe relevant laws and regulations regarding theuse and ownership of dash cameras in
yourcountry.
DE/AT: Permanent and occasion-free recordings are not permitted, i.e. no recording of the entire route,
license plates or strangers (so-called loop function). When recording an event, e.g. an accident, all
parties involved must be informed about the recording and about its transfer to the police. No posting
of recordings in public media (Internet, social media) without the consent of all persons concerned or
only after disguising the persons and license plates. It must be impossible to draw conclusions about
persons, e.g. through pictures of the surroundings.
2 The dashcam must not be fitted in a position which obscures the driver’s view of the road ahead.
3Only use the supplied power adapter, otherwise damage may occur to the dashcam. Take care when
cleaning the dashcam lens and only use a suitable lens cleaner and a soft cloth. Do NOT expose this
product to rain, moisture or water under any circumstances; doing so may result in the risk of electric
shock or fire. Do NOT perform servicing other than that contained in the instruction manual, unless you are
qualified to do so. When installing in a vehicle, always place the device securely against the windscreen
and where possible conceal the power cable under the vehicles interior trim. Make sure that the power
cable doesn’t interfere with the driver’s controls such as the steering wheel, pedals or gear lever. Do
NOT mount the dashcam in front of an airbag deployment area or in a position to obscure any interior
mirrors. Do NOT operate while driving and only adjust settings or review recordings while not driving.

If you haven’t already downloaded the app, do so now to
get the most from your dashcamera.
1 Download the app by searching for RINGconnect in
the App Store (iPhone) or Google Play (Android).
2 Open the app, follow the setup process shown and
enable all necessary settings when prompted.
BEFORE YOU BEGIN

1Dashcam
2Quick Start Guide
3Magnetic Mount
4USB Charging Cable
5Trim Removal Tool
6Window Sticker
PACKAGE CONTENTS
1
6
4
5
3
2

ATTENTION! Choose the installation location in advance,
as the adhesive tape on the mount is of single use.
1Ensure glass is dirt, dust and grease free.
2Warm adhesive pad part of mount in hands to ensure strong adhesion to glass.
3Once mount has been positioned connect dash camera to the magnetic mount.

To power the device and charge the battery, use only the power adapter
included. Connect the power cable to the mount, and then plug the
USB charger into the vehicles 12V power socket.
When the vehicle’s engine starts, the device turns on automatically.

ADJUSTING VIEWING ANGLE
ATTENTION! Adjusting the viewing angle can only be done along the vertical axis,
so be sure to position the device correctly on the windshield along the horizontal
axis as close as possible to the windshield’s center.
While pulling or pushing the device in the holder, ensure that the camera captures
the image in proportions of 30% sky/70% road.
Good Bad

CONNECTING TO MOBILE
1Hold down power button
to switch on dashcamera.
2Press UP arrow for 3
seconds to open Wi-Fi
hotspot details screen.
3Open your phone’s
Settings.
4Tap on Wi-Fi
or Connections.
5Select the dashcamera
hotspot and enter the
password that is displayed
on the dashcamera.
6You are now connected to
your device.

CONFIGURATION
Power Button: Press to turn the device on. Press and hold to turn the device off.
Menu Button: Use this button to switch between the video, photo and playback.
Press this button during recording to take picture.
Up Button: Press to move up the menu. In the VIDEO and PHOTO mode, press and
hold to zoom in; in Playback mode, use to select a file.
Down Button: Press to move down the menu. In the VIDEO and PHOTO mode,
press and hold to delete the image (if you used zoom + before); in the Playback mode,
press to select a file.
Rec Button: Press to start/stop recording. When in the menu, use to confirm the
selected menu item.
Reset Button (on bottom of camera): Press to reboot, if no other button responds.

PHOTO MODE
Stop recording and then press and hold Menu button for 2 seconds to
enter Photo Mode. Press Rec to capture image.
PLAYBACK MODE
When in Photo Mode press and hold the Menu button for 2 seconds to
enter Playback Mode. Press the Up and Down button to choose video
playback or image viewer. Press Rec button to play selected video. Press
and hold the Menu button for 2 seconds to exit Playback Mode.
MENU OPTIONS
Stop recording then press Menu key once to enter Menu options and
using Up and Down button to set the options, press Rec to confirm.

INSTALLING microSD CARD
1 Before installing a memory card, make
sure the device is turned off.
2 Insert the memory card until it clicks into
place.
3 Removing a card: press the card slightly
and then remove it from the slot.
WARNING! Do not apply excessive force when inserting a memory card to avoid
damage to the device. If necessary, use a thin pointed device to push the card
further. To remove the memory card, push the card until it clicks and remove the
card from the slot.

TURNING ON/OFF
•When the vehicle ignition is turned ON
the dashcam turns on automatically.
•To turn the device on manually, press
the power button.
•To turn the device off press and hold the
power button for approx. 3 seconds.

LOOP RECORDING
1
Insert the microSD card into the memory
card slot; the Loop Recording mode is
set to 3 minutes as default.
2 When the memory card storage is full,
the device will automatically replace the
oldest video file with the newest one;
exception is the files protected from
deletion.

EMERGENCY RECORDING
1Emergency recording is to protect the
current video file from being overwritten
and deleted.
2Emergency recording is activated
automatically when the G-sensor trig-
gers (sudden acceleration/decelera-
tion), or at point of collision. Emergen-
cy recording is locked automatically to
avoid erasing during loop recording.

1Playback (ensure dashcam recording
has stopped).
•In the standby mode, press and
hold the MENU button to switch
between Video & Photo.
2Video & Photo Mode.
•Select the file to view using the Up/
Down and Rec buttons.
•Using the Up/Down buttons,
select the file you need to view and
click the Rec button to start play-
back.
VIEWING VIDEOS & PHOTOS

DELETE FILES
1Press the Menu button to enter the sub-
menu (ensure dashcam recording has
stopped).
2Use the Up / Down buttons to select
Delete and press the Rec button.
3Select the option to delete all files/one
file, then confirm your choice by
following the instructions on the display.
ATTENTION! Locked files can only be
deleted when unlocked; to unlock them,
use the Lock item of the submenu in the
Playback mode. Another way to delete
locked files is to format the memory card
all data from memory card will be deleted!
WARNING! Deleted files cannot be
restored. Backup necessary files before
proceeding with deletion.

GENERAL SETTINGS
To access General Settings, press the Menu
Button once from the Home screen.
Video Resolution: Select required option
(the highest option provides the optimum
viewing performance).
Loop Recording: 3 or 5 minutes
G-Sensor: OFF/LOW/MEDIUM/HIGH
Night Vision: OFF/ON/AUTO
Recording Audio: OFF/ON
Date Stamp: OFF/ON

ADVANCED SETTINGS
To access Advanced Settings, press the
Menu Button twice from the Home screen.
WiFi: OFF/ON
Date/ Time: Adjust for correct Date and
Time.
Language: Select the preferred menu lan-
guage from the list.
Plate Number: OFF/ON
Screen Saver: OFF/ON
Button Sound: OFF/ON
Parking Monitor: OFF/ON
Card Formatting: Before using camera,
format SD card for optimal performance.
