RIP TUNES AS-4000BTK User manual

WIRELESS BLUETOOTH®
SPEAKER SYSTEM/SISTEMA INALÁMBRICO
BLUETOOTH® DE ALTAVOCES/BLUETOOTH® SANS
FIL SYSTÈME DE HAUT-PARLEURS
USER MANUAL • MANUAL DE USUARIO
MODE D’EMPLOI
Model Numbers:
AS-4000BTK (Black/Negro/Noir)
AS-4000BTS (Silver/Plateado/Argent)
AS-4000BTR (Red/Rojo/Rouge)
AS-4000BTW (White/Blanco/Blanc)

ENGLISH ESPAÑOL FRANÇAIS
ii
TABLE OF CONTENTS
Introduction 1
Important Safety Instructions 1
Package Contents 2
Product Features 3
Main Unit Controls 4
Operating Instructions 5
AUX Input Jack 5
Technical Specications 6
Troubleshooting 7
Contact Technical Support 7

ENGLISHESPAÑOLFRANÇAIS
3
INTRODUCTION
Congratulations on your purchase of the Riptunes Wireless
Bluetooth® Speaker System. Before using your Speaker Sys-
tem,pleasereadthroughthismanual.Thismanualwillhelpyou
use many of the exciting and useful features of your new unit.
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATING
AND RESERVE IT FOR FUTURE REFERENCE. IT WILL BE HELP-
FUL TO YOU IF YOU ENCOUNTER ANY OPERATING PROBLEM.
1. WARNING: To reduce the risk of electric shock or damage to the
unit’s main speakers, do not remove the front cover or disassemble
the back of the unit. There are no user-serviceable parts inside. Con-
tact technical support for further assistance.
2. WARNING: To prevent re or electric shock hazard, do not expose
the unit to rain or moisture.
3. Do not expose the Wireless Bluetooth® Speaker System or the
Adapter to any water (including drips or splashes). Objects lled with
liquids, such as vases and water bottles, should not be placed on or
near the unit.
4. No objects of any kind should be placed on top of the unit.
5. Keep the stereo system away from direct sunlight and heat sources
such as radiators or stoves.
6. Do not place the stereo system on an unstable table, stand, tripod,
bracket or cart. The unit may fall, resulting in possible damage or
injury.
7. Unplug the power from the outlet when the unit is not in use.
8. Dispose of this unit properly respecting your local laws for electron-
ics and battery disposal.
9. WARNING: The unit should not be exposed to excessive heat such as
sunlight, re or any other heat source.
10. WARNING: Only use attachments/accessories specied provided by
the manufacturer, except for a standard 3.5 mm auxiliary cable.

ENGLISH ESPAÑOL FRANÇAIS
4
PACKAGE CONTENTS
Your Riptunes package contents include the following:
AS-4000BT Wireless Bluetooth® Speaker
System
AC/DC Power Adapter
AC Power Cord
3.5mm (1.8”) High quality Male-to-Male Ste-
reo Cable - 3’
User Manual and Warranty Card

ENGLISHESPAÑOLFRANÇAIS
5
PRODUCT FEATURES
• A ve-unit three-way circuit design creates a higher
resolution, more natural sound.
• Large diameter woofer, special acoustic design and
rigorous tweaking of the speaker cabinet, provide a
high-delity low-frequency experience.
• Internal APT-X high-performance audio coding technol-
ogy creates CD-quality stereo sound.
• Innovative, forward-looking sophisticated design with
a beautiful cabinet nish.

ENGLISH ESPAÑOL FRANÇAIS
6
MAIN UNIT CONTROLS
The following picture illustrates the front facing panel:
The following picture illustrates the back facing panel:
USB Power Output
AUX Input
Power Switch
DC Input
Status Indicator Light
Pairing Button
Play / Pause
VOL -
VOL +

ENGLISHESPAÑOLFRANÇAIS
7
OPERATING INSTRUCTIONS
Getting Started and Bluetooth® Pairing
1. Use unit’s Power switch on the back panel to turn unit ON (I Position).
2. Once the unit is turned on, you will see a slowly blinking blue indicator light.
In this mode, the unit’s Bluetooth mode is turned on, but is not in pairing
mode. [If you have already paired and connected a device, the blue LED will
be steadily lit.]
3. Press the Bluetooth Pairing  button for 4 seconds to have the speaker
system enter pairing mode. The speaker will beep twice and the blue indica-
tor light will ash rapidly, putting the speaker in Bluetooth pairing mode for
approximately 10 minutes (before turning pairing o again).
4. Activate your other device’s Bluetooth function (you might refer to your de-
vice’s user’s guide). The speaker should connect to any Bluetooth certied
device within 30 feet..
5. When “Mavis” appears in the Bluetooth devices list, pair it to your device.
Once the device is paired & connected to the Speaker’s Bluetooth receiver,
the indicator light will turn to steady blue, and the speaker should emit a
single beep.
Playing Music Through Bluetooth (after Pairing)
1. You can control the speaker through your device or with the speaker’s Play/
Pause  and Volume ( and ) buttons, found on the top panel.
2. If a smartphone is connected and you receive a call during playback, an-
swering the call using the phone will put the speaker into standby mode &
it will mute. Once the call is disconnected, the speaker will resume playback
automatically (provided the phone is using a compatible Bluetooth version).
3. If the connected device moves too far away from the speaker (usually more
than 30 feet or less if blocked by walls, for example) the speaker discon-
nects from the device but will attempt to resume connection once the de-
vice is closer.
Playing Music Through Auxiliary input Jack
The unit also supports listening and playing media o other
non-Bluetooth devices as follows:
1. Plug in the high quality 3.5mm (1/8”) male-to-male connector auxiliary cable
(included) into the Aux-In jack on the rear of the unit and connect the other
end to the line-out or headphone jack of any standard audio device.
2. Once the AUX cable is attached to the back panel port labeled AUX, the
status indicator light will turn amber, indicating unit is using line in mode
instead of Bluetooth mode.
3. Both the top panel volume buttons and the connected device’s controls
can be used to adjust the volume. Play music from your attached device as

ENGLISH ESPAÑOL FRANÇAIS
8
usual. User your device’s controls for music/song control adjustment. It is
a good idea to keep your device’s volume level lower than the maximum to
ensure sound quality.
4. Once the AUX cable is disconnected from back panel of unit, the speaker
will continue Bluetooth operations & indicator light will turn BLUE.
Charging another device o the Speaker
The unit’s USB Output oers power of 5V/1A to charge anoth-
er device.
Note: It is recommended that you turn the unit o when not in
use to avoid unnecessary energy consumption.
TECHNICAL SPECIFICATIONS
GENERAL
Power Input: 100-240 V AC 50/60 Hz
16 V DC 2.8 A
Weight: 5lb.
Dimensions: 16.2” x 6.3” x 6.4”
USB output: DC 5V / 1A
AUDIO
Frequency response: 45 Hz-20 KHz
Audio output: R/L 7.5 W 4Ω x 2 (1 KHz, 10 HD)
R/L 5 W 6Ω x 2 (1 KHz, 10 HD)
C 15 W 4Ω x 1 (1 KHz, 10 HD)
BLUETOOTH®
Bluetooth version: Bluetooth 3.0 EDR
Bluetooth distance: 30 feet
Note: Design and specications are subject to change prior notice.

ENGLISHESPAÑOLFRANÇAIS
9
TROUBLESHOOTING
PROBLEM SOLUTION
The music coming out of the
speaker system sounds distorted
ad high volume.
While it’s ne to adjust the speak-
er to the maximum volume, it is
best if the source device is set to a
lower than maximum volume.
How come I can’t get the device to
turn on?
The device needs to be plugged in
to an AC outlet. If it is plugged into
an outlet, try another outlet. See
the “General operation” section
above.
Why can’t I seem to connect my
music source to Bluetooth? See the Bluetooth section above.
I paired my device and I see “Ma-
vis” in my devices list. However,
my Bluetooth icon is not lit and
the speaker’s is still blinking a slow
blue.
Your device is “paired” to the
speaker but not “connected.” Be
sure to select it from your device’s
Bluetooth menu and it should
connect.
TECHNICAL SUPPORT
For questions not answered in this manual, or for warranty
service, please contact Riptunes Technical Support:
By phone: [phone] (9:00 AM to 6:00 PM ET)
By e-mail: [e-mail]
Online: www.rip-tunes.com
© 2016 Riptunes by Impecca, a division of LT Inc., Wilkes
Barre, PA. Bluetooth is a registered trademark of Bluetooth
SIG, Inc.

FCC NOTE：
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS OR
CHANGE TO THIS EQUIPMENT. SUCH MODIFICATIONS OR CHANGE
COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF exposure guidelines, this equipment should be
installed and operated with a minimum distance of 20cm between the radiator and your
body.
