Installation Instructions for
Cattle Fountain Series,
Combination Fountain
Series, & AC Series
Congratulations, you have just purchased the finest watering fountain
on the market. This unit is built to give you excellent service when
properly installed and maintained. Please follow instructions
carefully. Read and understand all instructions before installing.
Part # 17837
17 October, 2012

Cattle Fountain, Combination Fountains, AC Series
Installation Instructions
A. Location - Putting the fountain in a location that offers protection from the wind will enhance the
performance of the fountain. Livestock will tend to gather in this protected area, enticing them to drink more.
Access panel should be opposite of prevailing winter wind to give additional protection to the supply line.
B. Water Supply Line - Horizontal underground water line (1) should be sized to account for pressure drop,
relating to distance, and placed well below frost line. A one-inch vertical supply pipe (2) is recommended. A shut-
off valve (3) should be installed under fountain to allow for easier servicing. For optimum serviceability, a stop
and waste valve can be installed below frost level to drain water back when unit is not in use. Vertical supply line
must be centered in riser tube (4) to provide an air space between the line and frozen ground outside of tube.
Flush water supply line thoroughly before connection to fountain. Water supplies with foreign material such as
sand, rust, etc. may require a filter to keep fountain valve working properly.
C. Electric Supply – It is usually most cost effective to run your electrical line the same time you are trenching
your water supply. Any electrical service must be installed and maintained by a qualified electrician.
D. Riser Tube - Install a riser tube and extend it at least one foot below frost line
or down to horizontal underground water line. For optimum water line protection,
use the 12” diameter insulated Ritchie Thermal Tube, part numbers and sizes are
shown to the left. Tube opening must be kept clear. NOTE: The supply line
touching the riser tube is the most common cause of the supply line freezing.
Do not surround the supply line with insulation, wood, or other foreign
material. Any foreign material in the tube may cause frost to migrate to the
supply line causing it to freeze.
Ritchie Thermal Tube
Part # Description
18158 1’ Top Section
16417 2’ Top Section
16612 4’ Top Section
16416 2’ Extension
Use in combination to reach
desired depth
Cattle, Combination, and AC Series
Fountains Installation Instructions
1
17 October, 2012

E. Mounting Platform - A concrete platform must be provided for all fountains. Use a minimum of 4” thick,
(6” recommended), large enough to accommodate fountain, and additional 4” step (on top of the platform)
extending 18” out from each side of the unit. This will protect the unit from manure handling equipment, as well
as discouraging animals from defecating in the fountain. Extending the platform provides animals a place to stand
while drinking, consider the size of your animals when determining the dimensions of your platform. The
concrete step and platform should slope away from the fountain for drainage. A rough broom finish to concrete
surface provides better footing for livestock.
F. Hose Connection - Connect hose fitting to shut-off valve at top of concrete. Slip on barb fitting with
furnished clamps. Hose should not touch insulation or outside surface of fountain. Place the hose under the
fountain as you move the unit in place over the riser tube.
G. Anchoring Fountain - Steel fountains are provided with four hold-downs to anchor your unit securely to the
concrete. Screw the hold down angles on to the unit then anchor down the unit. Use of 3/8” x 3-1/2” stainless steel
expansion anchor bolts (not included) is recommended for concrete installations. Anchor bolts are available from
Ritchie in a two pack, part # 14261. Use an all-weather sealant under the outside edge when anchoring to concrete
to keep air from leaking under fountain.
H. Final Water Connection– Connect the top of the supplied hose to the valve, cut hose to proper length and
slip onto the barb fitting of the valve assembly. Clamps and fittings are furnished to secure the connection.
I. Cable Heater – Uncoil cable heater and loop around the valve.
Attach the remaining part of the cable heater to the water supply, as
far down the riser tube as possible, with the cable twist ties provided.
(See drawing on previous page.) This heater is water tight, but should
not be immersed in water.
CAUTION: Installation must not cause any strain on heater
wiring connections. Do not cross the cable over itself along the
water line. Avoid heater damage caused by hot spots due to its
leads lying close to each other. Do not wrap additional
insulation around heater.
J. Electrical Connection - The electrical installation should be made and maintained by a qualified electrician
conforming to national and local codes. A means for disconnection must be incorporated in the fixed wiring in
accordance with the wiring rules. A suitable fuse or circuit breaker with properly sized wire must protect the 3-wire power to
the fountain. For wiring connections, see wiring diagram. Do not by-pass the terminal block to power unit. Make
connections according to the wiring diagram below.
WARNING: DISCONNECT POWER IF THE WATER SUPPLY IS TO BE SHUT OFF FOR AN
EXTENDED AMOUNT OF TIME. FAILURE TO TURN OFF POWER CAN RESULT IN DAMAGE TO
THE WATERING FOUNTAIN.
Cattle, Combination, and AC Series
Fountains Installation Instructions
2
17 October, 2012

NOTE: National/Local electrical codes may require livestock waterers installed in feedlots in open feeding area to
be grounded by a separate stranded copper grounding conductor or at least no.6 AWG terminating at a point
where the branch circuit receives its supply. Check with local authorities.
WARNING This installation must be made and maintained in strict conformity with National/Local plumbing codes
and National/Local electrical codes (CSA in Canada). The applicable provisions of these codes take precedent.
Failure to make and maintain all installations properly may result in loss of livestock, personal Injury, or death.
HEATER 120V
FENWAL THERMOSTAT
CABLE HEATER
TERMINAL BLOCK
GROUND LUG
HEATER 120V
(BLACK)
POWER SUPPLY
SINGLE PHASE 120V
DISC THERMOSTAT
OR
Cattle, Combination, and AC Series
Fountains Installation Instructions
3
17 October, 2012

K. Terminal Block – The terminal block is provided for easy and quick
connection to the power source. The push buttons provide quick connection with
a screwdriver or by hand. If you are using solid wire then you will be able to just
push the wire into the slot. Stranded wire will require you to press the button
down.
HEATER 240V
FENWAL THERMOSTAT
CABLE HEATER
TERMINAL BLOCK
HEATER 240V
(WHITE)
POWER SUPPLY
GROUND LUG
SINGLE PHASE 240V
DISC THERMOSTAT
OR
Cattle, Combination, and AC Series
Fountains Installation Instructions
4
17 October, 2012

L. Fenwal Thermostat (Cattle Fountains and Combination) - The adjustable range
is from 0o. F (-18oC) to 100oF (38oC). Thermostat is not preset at factory. Fill the
trough to proper water level. Check the water temperature with a thermometer. The next
morning, check the water temperature again. If the water is warmer than desired, turn
the thermostat down. If there is ice forming on the surface of the water, turn the
thermostat up. Only slight adjustments should be made to the thermostat at any time. A
1/16 turn on the thermostat will change the water temp. 7oF (4oC). 44oF (7o C) in the
trough represents the most economical operation. Counter clockwise raises the
thermostat setting.
M. Disc Thermostat (AC Series) – The disc thermostat is mounted in a
bracket under the trough, which allows it to be moved relative to the heater. To
ease movement of thermostat turn ¼ turn. To lock in position after adjustment
turn ¼ turn back. As the thermostat is moved toward the heater, the water
temperature in the trough is lowered. The best location is determined by
checking the trough temperature several times during the heating season.
N. Drain Plug – Insert the drain plug firmly into the drain hole in the center of
the trough.
O. Float Adjustment – Open water-supply shut-off valve, check for and fix
any leaks. Adjust float for a water depth of 2 inches below top of trough or
overflow pipe by adjusting the thumbscrew or wing nut.
P. Install Side Access Panel and Cover – Once all water line connections have been checked for leaks and
electrical hook-up is complete, the side access door may be installed. With the valve functioning properly and the
water level set at the proper level, you may install the valve cover.
Q. Children should be supervised to ensure that they do not play with the appliance – This appliance is not
intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instructions concerning use of the
appliance by a person responsible for their safety.
R. Cleaning Your Fountain – To clean your watering fountain you will need a good stiff bristled brush.
Remove the cover then brush the valve area to remove any build-up then brush the tank. Remove the plug that is
located in the valve chamber area under the float to drain out the water and debris. You can shut off the water
with the shut-off valve located under the unit or by holding the float in the up position. After the water and debris
has drained reinstall the plug and let the tank refill. Now is a good time to readjust the float if needed. Reinstall
cover and you are done.
Cattle, Combination, and AC Series
Fountains Installation Instructions
5
17 October, 2012

Ritchie Valves
Ritchie valves come in two sizes and four pressure ratings – blue for very high pressure, green for high supply
line pressure, red for moderate supply pressure, and white for low-pressure applications. Differences in the size of
trough also impacts valve choice. Although different pressure rated valves may be used in a fountain, each
fountain will only accommodate one size and configuration of valve. If water pressure is over 60 psi, and if the
valve does not shut off, a pressure-reducing valve may be needed. Your individual situations may require a
change from the standard valve supplied with your fountain, see your Ritchie Dealer if this is needed.
NOTE: Four orifice sizes are available for multi-purpose fountains and two sizes are available for cattle fountain
valves. They are color-coded.
Ritchie Limited Warranty Effective September 2012
Ritchie Industries, Inc. warrants its
products to be free of defective materials and
workmanship. Defective part(s) will be repaired
or replaced at the option of Ritchie Industries.
This warranty specifically excludes all labor
and shipping charges.
This warranty does not apply to any
appearance items, to any product whose exterior
has been damaged or defaced, to any product
that has been improperly installed, to any
product subjected to misuse, abnormal service
or handling, and to any products altered or
repaired with other than original equipment or
manufacturer’s parts.
This warranty gives you specific legal
rights, and you may also have other rights
which vary from state to state.
All warranty claims must be processed
through an Authorized Ritchie Dealer/
Distributor. Proof of purchase is required.
This warranty is not transferable. The period
of warranty begins at original date of purchase
as follows:
Poly Units
Base, top and ball closures
10 year limited against manufacturing defect. 100% first five
years, then declining 20% per year for the remaining five years.
Stainless Steel Units
Stainless trough and stainless valve chamber frame:
Ten years against manufacturing defect or corrosion. 100% all
ten years.
Casing and cover:
10 year limited against manufacturing defect. 100% first year,
then declining 10% per year for the remaining nine years.
Component Parts
All component parts, such as floats, valves, heating elements:
One year from the date of purchase against manufacturing defect,
100%.
Hydrants
All component parts:
One year from the date of purchase against manufacturing defect,
100%.
1/2” Part # GPM Pressure Range
White 12574 4.8 Low, 5-40 psi.
Red 12575 3.4 Moderate, 40-60 psi.
Green 13597 1.45 High, 60-80 psi.
3/4” Part # GPM Pressure Range
White 16697 33 Low, 5-40 psi.
Red 11101 20 Moderate, 40-60 psi.
Green 15377 16.5 High, 60-80 psi.
Blue 18197 5 Very High, 80-100 psi.
Cattle, Combination, and AC Series
Fountains Installation Instructions
6
17 October, 2012

Trouble Shooting
Problem Solution
Water in Trough Too
Warm Adjust thermostat to lower temperature
Check to see if thermostat has failed by contacts burning closed
Ice in Trough
Check fuses or circuit breakers
Check all heating elements to make sure they are working and hot
Adjust thermostat to higher temperature
Check for voltage from thermostat output
Check voltage to fountain with and without electrical load
Check that heaters are wired properly
Valve Freezing
Check that cable heater is installed properly and fastened to water supply line and is
working when heaters are hot
Check for missing or damaged insulation
Check for air gaps for wind penetrations
Supply line Freezing
Check that the cable heater is uncoiled and fastened around valve, to supply line
and is working when heaters are hot
Check that supply piping is centered in riser tube
Check that riser tube is free of water and mud that may freeze
Check that flexible hose does not touch side of casing or frame
Check casing for air leaks
Check for air gaps between casing and concrete floor
Valve won’t stop dripping
Check float adjustment. Check for waterlogged float, or float rubbing on side of
valve compartment
Disassemble valve
and check for sand or
scale in valve rubber.
Also check valve
orifice outlet for wear
and damage. A screen
or filter my be required
with sandy or scaly
water
Turn valve rubber over
and re-assemble
Check for excessive water system pressure
Low water flow
Check that valve inlet is not plugged or supply hose is not kinked
Check system pressure from supply hose by installing a tee and a pressure gauge
directly in front of the valve to check pressure drop when valve is open. A severe
pressure drop indicates a restriction or undersized supply system.
Check that shutoff valves are fully open
Pin must be pushed out of valve
to dissemble
1/2”
Valve
3/4”
Valve
Valve Rubber
Valve Rubber
Cattle, Combination, and AC Series
Fountains Installation Instructions
7
17 October, 2012

#5E Cattle Fountain
Part # 16745
Item Part # Description Qty Item Part # Description Qty
1 13374 5E Cover 1 15 11514 Valve Bracket 3/4" pkg 1 pkg
2 16590 5E Frame 1 16 15377 Green Male Valve 3/4" pkg 1 pkg
3 13823 5E Casing Pkg 1 pkg 17 18314 Float with Hardware pkg 1 pkg
4 16746 5E Trough pkg 1 pkg 18313 Hardware for Float pkg 1 pkg
511154 Access Pnl 17"x20" Assembled 1 18 16993 Green Valve & Float pkg 1 pkg
6 15299 Bolt 3/8"x1/2" SS (4/pkg) 1 pkg 19 13775 Hold Down Angle SS (4/pkg) 1 pkg
7 16534 Fenwal Thermostat SS pkg 1 pkg 20 16975 Flipper/Hinge (2/pkg) - Optional 1 PKG
18320 O-Ring Fenwal (6/pkg) 1 pkg NS 12583 Valve Supply Line pkg 1 pkg
18074 Nut Brass Fenwal (6/pkg) 1 pkg NS 13830 Cable Htr 120V 48W (1/pkg) 1 pkg
8 15154 Screw 1/4"x5/8" TC SS (10/pkg) 1 pkg NS 15632 5E Casing Insulation pkg 1 pkg
9 18114 Trough Bolt & Nut (5/pkg) 1 pkg NS 13790 5E Frame Inulation pkg 1 pkg
10 18628 Drain Plug (2/pkg) 1 pkg NS 11107 5E Accessory pkg 1 pkg
11 11419 Heater 120V 250W (1/pkg) 2 pkg
12 18075 Drain Washer (6/pkg) 1 pkg 16824 5E 240V
13 11473 Drain Pipe with Elbow 1 NS 11403 Heater 240V 300W (1/pkg) 2 pkg
14 16629 Standpipe pkg 1 pkg NS 16424 Cable Htr 240V 48W (1/pkg) 1 pkg
14
18
17
16
15
20
19
9
7
8
6
1
410
11
13
12
5
3
2
Cattle, Combination, and AC Series
Fountains Installation Instructions
8
17 October, 2012

#3E Cattle Fountain
Part # 16743
Item Part # Description Qty Item Part # Description Qty
1 13373 3E Cover 1 15 11514 Valve Bracket 3/4" pkg 1 pkg
2 16589 3E Frame 1 16 15377 Green Male Valve 3/4" pkg 1 pkg
3 12657 3E Casing Pkg 1 pkg 17 18314 Float with Hardware pkg 1 pkg
4 16744 3E Trough pkg 1 pkg 18313 Hardware for Float pkg 1 pkg
511154 Access Pnl 17"x20" Assembled 1 18 16993 Green Valve & Float pkg 1 pkg
6 15299 Bolt 3/8"x1/2" SS (4/pkg) 1 pkg 19 13775 Hold Down Angle SS (4/pkg) 1 pkg
7 16534 Fenwal Thermostat SS pkg 1 pkg 20 16974 Flipper/Hinge (2/pkg) - Optional 1 pkg
18320 O-Ring Fenwal (6/pkg) 1 pkg NS 12583 Valve Supply Line pkg 1 pkg
18074 Nut Brass Fenwal (6/pkg) 1 pkg NS 13830 Cable Htr 120V 48W (1/pkg) 1 pkg
8 15154 Screw 1/4"x5/8" TC SS (10/pkg) 1 pkg NS 15634 3E Casing Insulation pkg 1 pkg
9 18114 Trough Bolt & Nut (5/pkg) 1 pkg NS 13789 3E Frame Inulation pkg 1 pkg
10 18628 Drain Plug (2/pkg) 1 pkg NS 11107 3E Accessory pkg 1 pkg
11 11419 Heater 120V 250W (1/pkg) 2 pkg
12 18075 Drain Washer (6/pkg) 1 pkg 16826 3E 240V
13 11472 Drain Pipe with Elbow 1 NS 11403 Heater 240V 300W (1/pkg) 2 pkg
14 16629 Standpipe pkg 1 pkg NS 16424 Cable Htr 240V 48W (1/pkg) 1 pkg
14
18
17
16
15
20
19
7
9
10
6
3
5
11
13
12
4
8
2
1
Cattle, Combination, and AC Series
Fountains Installation Instructions
9
17 October, 2012

#3 Combination Fountain
Part # 16769
Item Part # Description Qty Item Part # Description Qty
1 13373 3C Cover 1 18 16993 Green Valve & Float pkg 1 pkg
2 16589 3C Frame 1 19 13775 Hold Down Angle SS (4/pkg) 1 pkg
3 12656 3C Casing Pkg 1 pkg 20 16974 Flipper/Hinge (2/pkg) - Optional 1 pkg
4 16744 3C Trough pkg 1 pkg 21 16767 3C Lower Trough SS 1
511154 Access Pnl 17"x20" Assembled 1 22 11472 Drain Pipe with Elbow 1
6 15299 Bolt 3/8"x1/2" SS (4/pkg) 1 pkg 23 12404 Grate - Clean out 2
7 16534 Fenwal Thermostat SS pkg 1 pkg 24 12801 Swing Door w/Rod 2
18320 O-Ring Fenwal (6/pkg) 1 pkg 25 13166 Rod with Nut for Swing Door 2
18074 Nut Brass Fenwal (6/pkg) 1 pkg 26 11118 3C Innerhood 2
8 15154 Screw 1/4"x5/8" TC SS (10/pkg) 1 pkg 27 11515 Valve Bracket 1/2" w/ screws 1 pkg
9 18114 Trough Bolt & Nut (5/pkg) 1 pkg 28 12575 Red Valve 1/2" 1 pkg
10 18628 Drain Plug (2/pkg) 1 pkg 29 13613 Float with Short Arm 1 pkg
11 11419 Heater 120V 250W (1/pkg) 3 pkg NS 12583 Valve Supply Line pkg 1 pkg
12 18075 Drain Washer (6/pkg) 1 pkg NS 13830 Cable Htr 120V 48W (1/pkg) 1 pkg
13 18603 Drain Fitting Flared 1 NS 15633 3C Casing Insulation pkg 1 pkg
14 16629 Standpipe pkg 1 pkg NS 13789 3E Frame Inulation pkg 1 pkg
15 11514 Valve Bracket 3/4" pkg 1 pkg NS 18326 3C Accessory pkg 1 pkg
16 15377 Green Male Valve 3/4" pkg 1 pkg 16816 3C 240V
17 18314 Float with Hardware pkg 1 pkg NS 11403 Heater 240V 300W (1/pkg) 2 pkg
18313 Hardware for Float pkg 1 pkg NS 16424 Cable Htr 240V 48W (1/pkg) 1 pkg
14
18
17
16
15
1
8
2
9
4
12
13
3
5
10
20
11
7
11 10
19 6
21
22
12 23
24
25
26
27
28
29
Cattle, Combination, and AC Series
Fountains Installation Instructions
10
17 October, 2012

2AC
Part # 18033
Item Part # Description Qty Item Part # Description Qty
1 13379 2AC Cover 1 15 11515 Valve Bracket 1/2" w/ Scrws pkg 1 pkg
2 13449 2AC Frame pkg 1 pkg 16 15154 Screws Valve Bracket (6/ pkg) 1 pkg
3 18035 2AC Casing 1 pkg 17 12575 Red Valve 1/2" pkg 1 pkg
4 18036 2AC Trough 1 pkg 18 13613 Float with Short Arm pkg 1 pkg
5 12140 Access Panel 8" Assembly 1 19 13775 Hold Down Angle SS (4/pkg) 1 pkg
6 15299 Bolt 3/8"x1/2" SS (4/pkg) 1 pkg 20 16973 Flipper/Hinge (2/pkg) - Optional 1 pkg
7 11885 Disc Thermostat pkg 1 pkg NS 13830 Cable Htr 120V 48W (1/pkg) 1 pkg
8 15158 J-Bolt & Nut ZP (10/pkg) 1 pkg NS 18323 2AC Accessory pkg 1 pkg
9 17500 Drain Pipe Guard 1 NS 15652 2AC Casing Insulation pkg 1 plg
10 18628 Drain Plug (2/pkg) 1 pkg NS 13850 2AC Frame Insulation pkg 1 pkg
11 14150 Heater 120V 125W (1/pkg) 2 pkg
12 18075 Drain Washer (6/pkg) 1 pkg 16839 2AC 240V
13 11471 Drain Pipe with Elbow 1 NS 16664 Heater 240V 200W (1/pkg) 2 pkg
14 16866 Standpipe pkg 1 pkg NS 16424 Cable Htr 240V 48W (1/pkg) 1 pkg
18
17
15
16
14
1
2
8
9
13 12
4
7
20
10
11
6
19
5
3
Cattle, Combination, and AC Series
Fountains Installation Instructions
11
17 October, 2012

2AC Special Assembly
Part # 18043
Item Part # Description Qty Item Part # Description Qty
1 13379 2AC Cover 1 15 11515 Valve Bracket 1/2" w/ Scrws pkg 1 pkg
2 13449 2AC Frame pkg 1 pkg 16 15154 Screws Valve Bracket (6/ pkg) 1 pkg
3 18058 2AC SP Casing 1 pkg 17 12575 Red Valve 1/2" pkg 1 pkg
4 18036 2AC Trough 1 pkg 18 13613 Float with Short Arm pkg 1 pkg
5 12140 Access Panel 8" Assembly 1 19 13775 Hold Down Angle SS (4/pkg) 1 pkg
6 15299 Bolt 3/8"x1/2" SS (4/pkg) 1 pkg 20 16973 Flipper/Hinge (2/pkg) - Optional 1 pkg
7 11885 Disc Thermostat pkg 1 pkg NS 13830 Cable Htr 120V 48W (1/pkg) 1 pkg
8 15158 J-Bolt & Nut ZP (10/pkg) 1 pkg NS 18323 2AC Accessory pkg 1 pkg
9 17500 Drain Pipe Guard 1 NS 18059 2AC SP Casing Insulation pkg 1 plg
10 18628 Drain Plug (2/pkg) 1 pkg NS 13850 2AC Frame Insulation pkg 1 pkg
11 14150 Heater 120V 125W (1/pkg) 2 pkg
12 18075 Drain Washer (6/pkg) 1 pkg 18420 2AC Special 240V
13 11471 Drain Pipe with Elbow 1 NS 16664 Heater 240V 200W (1/pkg) 2 pkg
14 16866 Standpipe pkg 1 pkg NS 16424 Cable Htr 240V 48W (1/pkg) 1 pkg
18
17
15
16
14
1
2
820
4
10
7
11
6
19
5
3
9
13 12
Cattle, Combination, and AC Series
Fountains Installation Instructions
12
17 October, 2012

1AC
Part # 18034
Item Part # Description Qty Item Part # Description Qty
1 13379 1AC Cover 1 16 15154 Screws Valve Bracket (6/ pkg) 1 pkg
2 18039 1AC Frame pkg 1 pkg 17 12575 Red Valve 1/2" pkg 1 pkg
3 18037 1AC Casing 1 pkg 18 13613 Float with Short Arm pkg 1 pkg
4 18038 1AC Trough 1 pkg 19 13775 Hold Down Angle SS (4/pkg) 1 pkg
5 12140 Access Panel 8" Assembly 1 20 16973 Flipper/Hinge (2/pkg) - Optional 1 pkg
6 15299 Bolt 3/8"x1/2" SS (4/pkg) 1 pkg NS 13830 Cable Htr 120V 48W (1/pkg) 1 pkg
7 11885 Disc Thermostat pkg 1 pkg NS 18323 1AC Accessory pkg 1 pkg
8 15158 J-Bolt & Nut ZP (10/pkg) 1 pkg NS 15651 1AC Casing Insulation pkg 1 plg
10 18628 Drain Plug (2/pkg) 1 pkg NS 13850 1AC Frame Insulation pkg 1 pkg
11 11419 Heater 120V 250W (1/pkg) 1 pkg
12 18075 Drain Washer (6/pkg) 1 pkg 16841 1AC 240V
13 11471 Drain Pipe with Elbow 1 NS 11403 Heater 240V 300W (1/pkg) 1 pkg
14 16866 Standpipe pkg 1 pkg NS 16424 Cable Htr 240V 48W (1/pkg) 1 pkg
15 11515 Valve Bracket 1/2" w/ Scrws pkg 1 pkg
18
17
15
16
14
20
1
2
8
12
13 11
4
7
5
3
6
19
10
Cattle, Combination, and AC Series
Fountains Installation Instructions
13
17 October, 2012

Hold Down Anchor Bolt Locations
Note: Do not drill holes for anchors before location can be verified with unit.
Anchor Bolt Locations
Fountain Model Part # Hole to Hole Location
3 Cattle Fountain 16743 15-1/2” x 30”
5 Cattle Fountain 16745 18-1/8” x 38-1/2”
3 Combination Fountain 16769 15-1/2” x 30”
1 AC 18034 8-1/2” x 18”
2 AC 18033 8-7/16” x 26-3/8”
2 AC Special 18043 8-7/16” x 26-3/8”
Cattle, Combination, and AC Series
Fountains Installation Instructions
14
17 October, 2012
