Rite-hite Level-rite hl-800 series User manual

LEVEL-RITETM

HL-800 SERIES

HYDRAULIC DOCK LEVELER

Owner’s Manual

PRINTED IN U.S.A. PUBLICATION NO. 1167rev.1

RITE-HITE PRINT SHOP 1-414-355-2600 NOVEMBER 2001

THIS MANUAL COVERS LEVELERS

AFTER SERIAL NUMBER M101516

By Rite-Hite

HL-800 HYDRAULIC DOCK LEVELER

Pub. No. 1167rev.1 - NOVEMBER 2001

SAFETY WARNINGS

LOCKOUT/TAGOUT PROCEDURES

The Occupational Safety and Health Administration (OSHA) requires that, in addition to posting safety warnings and

barricading the work area, the power supply has been locked in the OFF position or disconnected. It is mandatory

that an approved lockout device is utilized. An example of a lockout device is illustrated. The proper lockout

procedure requires that the person responsible for the repairs is the only person who has the ability to remove the

lockout device.

In addition to the lockout device, it is also a requirement to tag the power control in a manner that will clearly note

that repairs are under way and state who is responsible for the lockout condition. Tagout devices have to be

constructed and printed so that exposure to weather conditions or wet and damp locations will not cause the tag to

deteriorate or become unreadable.

RITE-HITE PRODUCTS CORPORATION does not recommend any particular lockout device, but recommends the

utilization of an OSHA approved device (refer to OSHA regulation 1910.147). RITE-HITE PRODUCTS

CORPORATION also recommends the review and implementation of an entire safety program for the Control of

Hazardous Energy (Lockout/Tagout). These regulations are available through OSHA publication 3120.

This is a statement of serious hazard. Failure to

follow the listed instructions could place the

individual at risk of serious injury or death.

WARNING

This is the highest level statement. Failure to

follow the listed instructions will most likely

result in severe injury or death.

DANGER

The statements used with this level of

warning deal with a safe operating

procedure. If the procedure is ignored, the

possibility of personal injury may exist.

CAUTION

IMPORTANT is used to draw attention

to a procedure that needs to be followed to

prevent machine or property damage.

IMPORTANT

When working with electrical or electronic

controls, make sure that the power source has

been locked out and tagged according to OSHA

regulations and approved local electrical codes.

WARNING

HL-800 HYDRAULIC DOCK LEVELER

Pub. No. 1167rev.1 - NOVEMBER 2001 i

TABLE OF CONTENTS

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .i

PIT DETAILS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

INSTALLATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

HYDRAULIC FLUID CHECK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

MAINTENANCE PROCEDURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

ADJUSTMENT PROCEDURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

ELECTRICAL SCHEMATICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

HYDRAULIC SCHEMATIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

FRAME REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

PLATFORM REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

CONTROL BOX REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

HYDRAULIC REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

OPTIONAL ARTD REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

WEATHERSEAL REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

INTRODUCTION

THE HL SERIES LEVELER BY RITE-HITE IS INTENDED TO PROVIDE A SAFER WORK PLACE FOR WORKERS

IN SHIPPING AND RECEIVING DOCK AREAS. THE HL SERIES LEVELER IS A HYDRAULICALLY OPERATED

DEVICE THAT, WHEN PROPERLY INSTALLED AND OPERATED, PROVIDES A SAFE AND SECURE ACCESS

BETWEEN DOCK AND TRUCK. THE HL SERIES LEVELER IS OPERATED FROM THE TOP OF THE DOCK.

NOTICE TO USER

YOUR LOCAL RITE-HITE REPRESENTATIVE PROVIDES A PLANNED MAINTENANCE PROGRAM (P.M.P.), WHICH

CAN BE FITTED TO YOUR SPECIFIC OPERATION. CALL YOUR LOCAL REPRESENTATIVE OR RITE-HITE

PRODUCTS CORPORATION AT (414) 355-2600.

IF ANY PROCEDURES FOR THE INSTALLATION, OPERATION, OR MAINTENANCE OF THE HL SERIES HAVE

BEEN LEFT OUT OF THIS MANUAL OR ARE NOT COMPLETE, CONTACT YOUR LOCAL RITE-HITE

REPRESENTATIVE.

HL-800 HYDRAULIC DOCK LEVELER

ii Pub. No. 1167rev.1 - NOVEMBER 2001

NOTES

HL-800 HYDRAULIC DOCK LEVELER

Pub. No. 1167rev.1 - NOVEMBER 2001 1

Pit Details for LEVEL-RITE™by Rite-Hite®Hydraulic and Mechanical Dock Levelers

6L X 6W 8L X 6W 8L X 7W

63 87 87

74 74 85

19-1/2 19-1/2 19-1/2

PIT DIMENSIONS FOR CAPACITIES: 30K, 35K, 40K

NOMINAL PIT SIZES

PIT LENGTH

PIT WIDTH DIM A

DIM B

DIM CPIT DEPTH

HL-800 HYDRAULIC DOCK LEVELER

2Pub. No. 1167rev.1 - NOVEMBER 2001

PIT DETAILS CONTINUED

Alternate

Junction Box

And Conduit

Location

4" x 4" x 2" NEMA 4 (By Others)

10"

ITEM 6: JUNCTION BOX LOCATION DIMENSIONS FOR HL SERIES

Preferred

Junction Box

And Conduit

Location

Minimum

1" Dia.

Conduit

Required

14"

27-1/2"

11-3/4"

23-1/2"

20"

7" Typ.

6" Typ.

1-1/4"

Typ.

1/4" Front Curb Angle

To Be Welded To

Mounting Plate

1/2" x 6"

Nelson Stud (16)

Mounting Plate

1/4" x 20" x 23-1/2"

H.R.S.

ITEM 5: RESTRAINT MOUNTING PLATE (OPTIONAL)

Typ.

RestraintMounting Plate Furnished By General Contractor Or

Available From RITE-HITE

At Additional Cost.

ITEM 1, 2, 3, 4:ANCHOR LAYOUT

FOR CURB ANGLES

12" 12"

IMPORTANT:

Curb Angles Nelson Studs

1/2" Dia. 6" Long Located As Shown

12" 12"

CONSTRUCTION NOTES

1. Concrete Behind Pit Steel Must Be Well Vibrated.

2. Rear Pit Wall Must Be Square With Dock Floor.

3. All Curb Angle Joints To Be Welded Securely.

4. 1/2" Pitch Toward Front Of Pit For Drainage.

5. Both Item 4 Bumper Mountings Must Be The

Same Design.

ITEM 1,2,3,4 - ANCHOR LAYOUT

FOR CURB ANGLES

ITEM QTY 6L X 6W 8L X 6W 8L X 7W

1 1 74 74 85

2 1 80 80 91

3 2 60 84 84

4 2 20 20 20

CONTRACTOR'S BILL OF MATERIALS FOR NOMINAL PIT SIZES

DESCRIPTION

FRONT CURB ANGLE

3 X 3 X 3/16

REAR CURB ANGLE

3 X 3 X 3/16

SIDE CURB ANGLE

3 X 3 X 3/16

SIDE VERTICAL ANGLES

3 X 3 X 3/16

ITEM 6 - JUNCTION BOX LOCATION

DIMENSIONS FOR HL SERIES

HL-800 HYDRAULIC DOCK LEVELER

Pub. No. 1167rev.1 - NOVEMBER 2001 3

INSTALLATION INSTRUCTIONS
