5. Once the Setup Wizard is finished, a “Configuring system
settings and rebooting” progress screen appears. Wait
until the process is complete.
6. Connect to the WLAN that you configured in the Setup
Wizard, and click OK to reconnect. You will be redirected
to the Unleashed login screen.
7. Enter your Admin Name and Password to login. FIGURE 5
The Login page
8. Upon successful login you will be presented with the
Unleashed Dashboard, which displays an overview of
your Unleashed network.
Mounting Instructions
Mounting on a Drop-Ceiling T-Bar
The factory-supplied T-bar mounting assembly kit allows
you to attach the AP to recessed and flush drop-ceiling T-
bars.
1. Position the studs on the bottom of the T-bar bracket (A
in the following Figure) in the keyholes on the AP
enclosure.
2. Slide the T-bar bracket away from the Ethernet ports on
the bottom of the AP until the AP retainer tab (B) snaps
into place, trapping the T-bar bracket studs in the
keyholes (C). FIGURE 6 Attaching the T-bar bracket to the
AP
3. Insert the locking tab (D) so it is in the first position on the
T-bar bracket (A).
4. Gently push the ceiling tiles, if present, up and out of the
way.
5. Position the T-bar bracket so its two clasps grip one edge
of the T-bar (A in the Figure below). Make sure that both
clasps are gripping the T-bar.
6. Hold the AP in place and gently push the locking tab
(B) until its clasp grips the other edge of the T-bar. Make
sure that all three clasps are gripping the T-bar.
FIGURE 7 Attaching the T-bar bracket to the T-bar
7. (Optional) Attach a customer-supplied padlock
through the bracket AP retainer tab (B) to lock the AP to
the T-bar bracket studs.
Mounting on a Flat Surface
The factory-supplied mounting screws and plastic wall
anchors allow you to attach the AP to a wall or other flat
surface.
1. Use the Mounting Template on the last page of this
Quick Setup Guide to mark the locations for two drill
holes on the mounting surface.
2. Use a 4.75mm (3/16”) drill bit to drill holes approximately
25mm (1”) deep into the mounting surface.
3. Insert the factory-supplied anchors (A in the Figure
below) and mounting screws (B) into the mounting
surface, leaving approximately 6 mm (1/4”) of the screw
heads protruding for the AP enclosure.
