Rivulis S2000
Micro Sprinkler
Product Features
Anti-insect device
Standard or ow Regulated models
Applications
Orchards
Product Options
Flow rates
S2000: 8, 10, 14, 16, 20, 26, 33 gph
S2000 Flow Regulated: 6, 8, 11, 14, 19,
25, 33 gph
Optional: detachable built-in range limiter
on the gray spinner provides a restricted
wetting diameter of 1.64’-1.96
Operating Guidelines
Operating pressure range: 22-50 psi
Irrigation
Rivulis
The Rivulis S2000 Micro Sprinklers are the ideal choice for a wide range of applications including irrigation, cooling, and
frost protection for orchards and groves. Built to last, the Rivulis S2000 Micro Sprinkler line incorporates a strong bridge,
built-in anti-insect device, and a wear resistant design. The S2000 Micro Sprinkler delivers a consistent spray pattern at a
low angle, avoiding low hanging branches. The sprinklers can be congured with add-on features such as a spinner with a
range limiter, for a smaller wetting diameter around young trees or a trunk protector to keep the spray away from the tree
trunks. The sprinklers can be installed on the ground with a plastic stake or hung from a wire.
The Rivulis S2000 Flow Regulated Micro Sprinkler has the added feature of ow regulation, extending the use of the
sprinklers to applications with sloping elds and long lateral runs.

Rivulis S2000 Micro Sprinkler
Rivulis S2000 Micro Sprinkler Features
Hook
Bridge
Spinner
Nozzle
Flow regulation chamber
Membrane
Standard Components
Flow Regulated Components
Built-in Anti-Insect Device
The Rivulis S2000 Micro Sprinkler
design includes a built-in anti-
insect protection feature. Once the
ow stops, the spinner falls to
cover and protect the spinner and
nozzle outlets.
Range Limiter
The Rivulis S2000 Micro
Sprinkler can be ordered
with a Range Limiter Spinner. Once
the tree is mature enough, the
Range Limiter tab can be removed
and the spray pattern enlarges to its
standard diameter.
Trunk Protector
One or two Trunk
Protectors can be added
to any of the S2000 Micro
Sprinklers. The Trunk Protector
diverts the spray pattern away from
the trunk, keeping it dry.
Rivulis S2000 Micro Sprinkler Options
1
2
3
4
5
6
1
2
3
4
5
6

Rivulis S2000 Micro Sprinkler
Stake Installation
The standard stake installation
utilizes a Hammer stake, 4x7
tubing, and a 4x7 barbed connector
and is attached to a 3/8” threaded
Rivulis S2000 Sprinkler.
Hanging Installation
A hanging installation utilizes a
M44 adapter, 4x7 tubing, and a
4x7 barbed connector and is
attached to a 3/8” threaded Rivulis
S2000 Sprinkler.
Rivulis S2000 Micro Sprinkler Installation Options
Product Information
Product Information
Operating Guidelines
Operating Guidelines
Operating Data
Operating Data
Nominal
Flow Rate
Nozzle
Color
Nozzle
Size
Spinner
Color
(gph) (inch)
8Light Blue 0.03 Black
10 Black 0.033 Black
14 Blue 0.039 Black
16 Dark blue 0.043 Black
20 Green 0.047 Black
26 Red 0.055 Black
33 White 0.063 Black
Nominal
Flow Rate
Nozzle
Color
Nozzle
Size
Spinner
Color
(gph) (inch)
6Black 0.03 Gray
8Blue 0.039 Gray
11 Dark Blue 0.043 Gray
14 Green 0.047 Gray
19 Red 0.055 Gray
25 White 0.063 Gray
33 White 0.063 Black
Pressure
Range
Recommended Filtration
(psi) (microns) (mesh)
20-35 130 120
20-35 130 120
20-35 200 80
20-35 200 80
20-35 200 80
20-35 200 80
20-35 200 80
Pressure
Range
Recommended Filtration
(psi) (microns) (mesh)
20-50 130 120
20-50 130 120
20-50 130 120
20-50 200 80
20-50 200 80
25-50 200 80
20-35 200 80
Effective Wetting
Diameters* (@30 psi) Flow Rate vs. Pressure Data
w/Limiter 20 psi 25 psi 30 psi 35 psi
(ft.) (ft.) (gph) (gph) (gph) (gph)
20 38.3 9.2 10.1 10.9
21 511.1 12.5 13.7 14.8
23 513.3 14.9 16.3 17.6
26 516.4 18.4 20.2 21.8
30 521.1 23.6 25.9 28.1
33 72 7. 2 30.4 33.4 36.1
Effective Wetting
Diameters* (@30 psi) Flow Rate vs. Pressure Data
w/Limiter 20 psi 25 psi 30 psi 35 psi
(ft.) (ft.) (gph) (gph) (gph) (gph)
16 36.5 6.8 6.6 6.1
16 38.3 8.6 8.5 8.2
19 410.7 10.6 10.5 10.7
19 513.7 14.6 14.8 14.0
23 517.5 18.7 19.2 18.9
24 523.5 25.0 25.9 24.6
*At 30 psi and sprinkler height of 12” above the ground
Rivulis S2000 Micro Sprinkler
Rivulis S2000 Flow Regulated Micro Sprinkler

Rivulis S2000 Micro Sprinkler Rivulis S2000 Flow Regulated Micro Sprinkler
Maximum Number of Sprinklers* Maximum Number of Sprinklers**
Nominal
Flow Rate
Nozzle
Color
Sprinkler
Spacing
Internal Pipe Diameter (inch)
(gph) (ft) 0.6 0.62 0.72 0.83 1.05
8Lt. Blue
10 28 30 39 50 76
12.5 26 27 36 46 70
15 24 26 33 43 65
17.5 23 24 32 41 61
20 22 23 30 39 58
10 Black
10 24 25 33 43 64
12.5 22 23 30 39 59
15 20 22 28 37 55
17.5 19 20 27 35 52
20 18 19 25 33 50
14 Blue
10 19 20 27 34 52
12.5 18 19 25 32 48
15 16 17 23 30 45
17.5 15 16 22 28 42
20 15 16 21 27 40
16 Dk. Blue
10 17 18 24 31 46
12.5 16 17 22 28 43
15 15 16 20 26 40
17.5 14 15 19 25 38
20 13 14 18 24 36
20 Green
10 15 16 21 27 40
12.5 14 14 19 25 37
15 13 13 18 23 35
17.5 12 13 17 22 33
20 11 12 16 21 31
26 Red
10 12 13 17 23 34
12.5 11 12 16 21 32
15 11 11 15 19 29
17.5 10 11 14 18 28
20 910 13 17 26
33
White 10 10 11 15 19 29
12.5 10 10 13 18 27
15 9 9 13 16 25
Nominal
Flow Rate
Nozzle
Color
Sprinkler
Spacing
Internal Pipe Diameter (inch)
(gph) (ft) 0.6 0.62 0.72 0.83 1.05
6Black
10 35 37 48 62 93
12.5 32 34 44 57 85
15 30 32 41 53 80
17.5 28 30 39 50 76
20 27 28 37 48 72
8Blue
10 29 31 41 52 79
12.5 27 29 37 48 72
15 25 27 35 45 68
17.5 24 25 33 42 64
20 23 24 31 40 61
11 Dk. Blue
10 24 26 34 44 66
12.5 22 24 31 40 61
15 21 22 29 37 57
17.5 20 21 27 35 53
20 19 20 26 34 51
14 Green
10 21 22 29 37 56
12.5 19 20 26 34 51
15 18 19 25 32 48
17.5 17 18 23 30 45
20 16 17 22 28 43
19 Red
10 16 17 23 30 45
12.5 15 16 21 27 41
15 14 15 20 25 39
17.5 13 14 19 24 36
20 13 13 18 23 35
25 White
10 14 15 19 25 38
12.5 13 14 18 23 35
15 12 13 17 22 33
17.5 11 12 16 20 31
20 11 11 15 19 29
*0% slope, 10% ow rate variation, 30 psi
**0% slope, 30 psi
Flow Rate vs. Pressure Flow Rate vs. Pressure
20
Pressue (psi)
Flow Rate vs. Pressure - S2000 Micro Sprinkler
0
5
10
15
20
25
30
35
40
32.8
25.5
19.8
16.0
13.5
9.9
7.7
Flow Rate (gph)
25 30 35
33 gph
26 gph
20 gph
16 gph
14 gph
10 gph
8 gph
20
Pressue (psi)
Flow Rate vs. Pressure -
S2000 Flow Regulated Micro Sprinkler
0
5
10
15
20
25
30
35
40 25
19
14
11
8
6
Flow Rate (gph)
25 30 35
25 gph
19 gph
14 gph
8 gph
6 gph
11 gph
RIV_DS_S2000_R2_EN_W14_0274
