65-2330RK
Hydrogen Sulfide Transmitter
Operator’s Manual
Part Number: 71-0197RK
Revision: A
Released: 6/11/20

2 • 65-2330RK H2S Transmitter
WARNING
Read and understand this instruction manual before operating
transmitter. Improper use of the transmitter could result in bodily
harm or death.
Periodic calibration and maintenance of the transmitter is
essential for proper operation and correct readings. Please
calibrate and maintain this transmitter regularly! Frequency of
calibration depends upon the type of use you have and the sensor
types. Typical calibration frequencies for most applications are
between 3 and 6 months, but can be required more often or less
often based on your usage.

65-2330RK H2S Transmitter • 3
Product Warranty
RKI Instruments, Inc. warrants gas alarm equipment sold by us to be free from defects in
materials, workmanship, and performance for a period of one year from date of shipment from
RKI Instruments, Inc. Any parts found defective within that period will be repaired or
replaced, at our option, free of charge. This warranty does not apply to those items which by
their nature are subject to deterioration or consumption in normal service, and which must be
cleaned, repaired, or replaced on a routine basis. Examples of such items are:
Warranty is voided by abuse including mechanical damage, alteration, rough handling, or
repair procedures not in accordance with the operator’s manual. This warranty indicates the
full extent of our liability, and we are not responsible for removal or replacement costs, local
repair costs, transportation costs, or contingent expenses incurred without our prior approval.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ANY AND ALL OTHER WARRANTIES
AND REPRESENTATIONS, EXPRESSED OR IMPLIED, AND ALL OTHER
OBLIGATIONS OR LIABILITIES ON THE PART OF RKI INSTRUMENTS, INC.
INCLUDING BUT NOT LIMITED TO, THE WARRANTY OF MERCHANTABILITY OR
FITNESS FOR APARTICULAR PURPOSE. IN NO EVENT SHALL RKI INSTRUMENTS,
INC. BE LIABLE FOR INDIRECT, INCIDENTAL, OR CONSEQUENTIAL LOSS OR
DAMAGE OF ANY KIND CONNECTED WITH THE USE OF ITS PRODUCTS OR
FAILURE OF ITS PRODUCTS TO FUNCTION OR OPERATE PROPERLY.
This warranty covers instruments and parts sold to users by authorized distributors, dealers,
and representatives as appointed by RKI Instruments, Inc.
We do not assume indemnification for any accident or damage caused by the operation of this
gas monitor, and our warranty is limited to the replacement of parts or our complete goods.
a) Absorbent cartridges d) Batteries
b) Pump diaphragms and valves e) Filter elements
c) Fuses

4 • 65-2330RK H2S Transmitter
Table of Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
H2S Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Junction Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Mounting the H2S Transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Wiring the H2S Transmitter to a Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Introducing Incoming Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Setting the Zero Signal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Replacing Components of the H2S Transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Calibration Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Preparing for Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting the Zero Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting the Response Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Returning to Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

65-2330RK H2S Transmitter • 5
Overview
This manual describes the 65-2330RK hydrogen sulfide (H2S) transmitter. This manual also
describes how to install, start up, maintain, and calibrate the transmitter when using it with a
gas monitoring controller. A parts list at the end of this manual lists replacement parts and
accessories for the H2S transmitter. See the controller operator’s manual for information
specific to the controller.
Specifications
WARNING: Do not use this product in a manner not specified in this instruction manual.
Table 1 lists specifications for the H2S transmitter.
WARNING: When using the 65-2330RK, you must follow the instructions and warnings in
this manual to assure proper and safe operation of the 65-2330RK and to
minimize the risk of personal injury. Be sure to maintain and periodically
calibrate the 65-2330RK as described in this manual.
Table 1: Specifications
Target Gas Hydrogen sulfide (H2S)
Sampling Method Diffusion
Signal Output 4 to 20 mA
Detection Range 0 to 100 ppm (parts per million)
Accuracy ± 5% of reading or ± 2 ppm H2S (whichever is greater)
Response Time 90% in 30 seconds
Operating Temperature -40°F to 104°F (-40°C to 40°C)

6 • 65-2330RK H2S Transmitter
Description
This section describes the components of the H2S transmitter. The H2S transmitter is a 4-20
mA type detector head. It consists of the H2S detector, amplifier, and junction box.
Figure 1: H2S Transmitter Component Location
Controller Terminal Strip
Amplifier
Detector Terminal Strip
J-Box
H2S Detector
S
SIG/PWR SPAN ZERO
100 mV- 500 mV
Range -TestPoint(Black)
+ Test Point (Red)
Factory Adjust Pot
Span Pot
Zero Pot
TOXIC OXY

65-2330RK H2S Transmitter • 7
H2S Detector
The H2S detector consists of the detector housing body, detector housing cap, cap gasket, and
the plug-in sensor.
Figure 2: H2S Detector Component Location
Detector Housing Body
The detector housing body protects the electronic components within the housing. Use the
mounting threads at the top of the housing to screw the H2S detector into the 3/4 NPT hub on
the bottom of the junction box. Two wires extend from the top of the detector housing body.
Use these wires to connect the H2S detector to the amplifier. One of the wires is red and one of
the wires is black.
The housing includes a four-socket pattern. This socket pattern accepts the sensor’s four pins
to secure the sensor within the detector housing. A pre-amplifier, located between the sockets
and two interconnect wires, conditions the sensor’s signal before the signal reaches the
controller.
Housing Cap & Cap Gasket
The housing cap screws onto the detector housing. It retains the plug-in sensor and protects it
from damage. A foam gasket inside the housing cap seals against the face of the sensor when
the cap is screwed onto the housing body. A hydrophobic membrane on the outside of the cap
face keeps water and particulates away from the sensor face behind the cap. Unscrew the
detector cap to access the plug-in sensor for maintenance or replacement. A cap gasket seals
the interface between the housing and cap.
Plug-In H2S Sensor
The sensor is secured within the detector assembly by the housing cap. Through a series of
chemical and electrical reactions, the sensor produces an electrical output that corresponds to
the detection range of the transmitter.
Detector Housing Cap
Hydrophobic Membrane
Plug-In H2S Sensor
Detector Housing Body
Cap Gasket

8 • 65-2330RK H2S Transmitter
Amplifier
The amplifier converts the electrical output from the sensor to a 4 to 20 mA signal that
corresponds to the detection range and transmits the signal to a gas monitoring controller. A
foam gasket that orients the amplifier and keeps it from rotating is installed on the bottom of
the amplifier. The amplifier includes the controller terminal strip, detector terminal strip, zero
pot, span pot, and test points (Figure 1).
Controller Terminal Strip
The interconnect terminal strip is a two position plug-in style terminal strip located at the top
edge of the amplifier. Use the controller terminal strip to connect the amplifier to a controller.
Detector Terminal Strip
The detector terminal strip is a four-point plug-in style terminal strip near the bottom of the
amplifier. Use the detector terminal strip to connect the H2S detector to the amplifier.
NOTE: The H2S detector is factory-wired to the detector terminal strip. See the Installation
section of this manual for all wiring procedures related to the transmitter.
Zero Pot
The zero pot is located in the upper left corner of the amplifier (see Figure 1). Use a small flat
blade screwdriver to turn the zero pot’s adjustment screw and adjust the amplifier’s zero (H2S
free) output during the start-up and calibration procedures. Turn the adjustment screw
clockwise to increase the zero output and counterclockwise to decrease the zero output.
Span Pot
The span pot is located to the right of the zero pot (see Figure 1). Use a small flat blade
screwdriver to turn the span pot’s adjustment screw and adjust the amplifier’s response output
during the calibration procedure. Turn the adjustment screw clockwise to increase the output
and counterclockwise to decrease the output.
CAUTION:The third potentiometer is factory-set. Do not adjust it.
Test Points
The test points (red and black) are on the left side of the amplifier (see Figure 1). The test
points produce a 100 mV to 500 mV output that corresponds to the transmitter’s 4 to 20 mA
output. Use the test points and a voltmeter to measure the transmitter’s output during the start-
up and calibration procedures. The black test point in the lower left corner is the negative (-)
test point and the red test point below the zero pot is the positive (+) test point.
Junction Box
Use the junction box to install the H2S transmitter at a mounting site that is remote from the
controller. The junction box protects the amplifier and wiring connections made to the
amplifier. Use the top 3/4 NPT conduit hub to connect wiring from the amplifier to the
controller. Use the cover on the front of the junction box to access the interior of the junction

65-2330RK H2S Transmitter • 9
box. Three spacers installed on the back of the junction box control the distance of the
junction box from a mounting surface and ensure that there is enough room to install a
calibration cup on the detector during calibration.
Installation
This section describes procedures to mount the H2S transmitter in the monitoring environment
and wire the transmitter to a controller.
Mounting the H2S Transmitter
1. Select a mounting site that is representative of the monitoring environment. Consider the
following when you select the mounting site.
• Select a site where the transmitter is not likely to be bumped or disturbed. Make sure
there is sufficient room to perform start-up, maintenance, and calibration procedures.
• Select a site that is at normal breathing level.
Figure 3: Mounting the H2S Transmitter
3.10
.75 .38
Rubber
Spacers
3X
3/4 NPT
Female
3.65
1 1/2-20 Thread for
Calibration Cup
J-Box
H2S Detector
6.8 Max

10 • 65-2330RK H2S Transmitter
2. At the monitoring site you select, hang or mount the junction box with the detector facing
down (see Figure 3).
Wiring the H2S Transmitter to a Controller
WARNING: Always verify that power to the controller is OFF before you make wiring
connections.
1. Turn off the controller.
2. Turn off power to the controller.
3. Remove the junction box cover.
4. The detector leads are factory wired. Verify that the detector leads are wired to the
amplifier’s detector terminal strip as shown in Figure 4.
5. To gain access to a plug-in terminal strip for wiring, pull it out of its socket by grasping the
terminal strip and pulling. The detector terminal strip is keyed so that the controller and
detector terminal strips cannot be reversed inadvertently.
6. Guide a two-conductor, shielded cable, or two wires in conduit through the top conduit
hub of the junction box.
7. Pull out the controller terminal strip and connect the two wires to the terminal strip as
follows (see Figure 4).
• Connect the positive wire to the terminal labeled SIG/PWR “+” terminal.
• Connect the signal wire to the terminal labeled SIG/PWR “S” terminal.
CAUTION:If shielded cable is used, leave the cable shield’s drain wire insulated and
disconnected at the transmitter. You will connect the opposite end of the cable’s
drain wire to the controller’s chassis (earth) ground.
8. Reinstall the controller terminal strip into its socket.
9. Secure the junction box cover to the junction box.
10. Route the cable or wires leading from the H2S transmitter through one of the conduit hubs
at the controller housing.
CAUTION:Do not route power and transmitter wiring through the same controller conduit
hub. The power cable may disrupt the transmission of the transmitter signal to the
controller.

65-2330RK H2S Transmitter • 11
11. Connect the wires to the applicable detector/transmitter terminal strip at the controller as
shown in Figure 4.
Figure 4: Wiring the H2S Transmitter to a Controller
12. If shielded cable is used, connect the cable’s drain wire to an available chassis (earth)
ground at the controller. RKI controllers typically have a ground stud that can be used to
ground the cable’s drain wire.
Start Up
This section describes procedures to start up the H2S transmitter and place the transmitter into
normal operation.
Introducing Incoming Power
1. Complete the installation procedures described earlier in this manual.
2. Verify that the power wiring to the controller is correct and secure. Refer to the controller
operator’s manual.
SPAN
SIG/PWR
S
ZERO
Cable Shield
+ 24 VDC
4 - 20 mA In (S)
Controller
Red
Black
TOXIC OXY
H2S Detector
J-Box

12 • 65-2330RK H2S Transmitter
3. Turn on power to the controller.
4. Turn on the controller.
5. Verify that the controller is on and operating properly. Refer to the controller operator’s
manual.
CAUTION:Allow the transmitter to warm up for 5 minutes before you continue with the next
section, “Setting the Zero Signal”.
Setting the Zero Signal
NOTE: If you can verify that the detector is in a fresh air environment (environment known to
be of normal oxygen content and free of toxic and combustible gases), it is not
necessary to apply zero air when verifying or setting the fresh air reading.
The procedure below describes applying zero emission air, usually called zero air, using a
calibration kit that includes a calibration cup, calibration gas, sample tubing, and a fixed flow
regulator with an on/off knob. RKI Instruments, Inc. recommends using a 0.5 LPM (liters per
minute) fixed flow regulator.
1. Unscrew and remove the junction box cover from the junction box.
2. Set a voltmeter to measure in the millivolt (mV) range.
3. Plug the voltmeter leads into the test points on the amplifier. Plug the positive lead into the
red (+) test point; plug the negative lead into the black (-) test point.
4. Screw the calibration cup onto the bottom of the H2S detector.
5. Screw the regulator into the zero air calibration cylinder.
6. Use the sample tubing to connect the regulator to the calibration cup.
7. Turn the regulator’s on/off knob counterclockwise to open it. Gas will begin to flow.
8. Allow the gas to flow for two minutes.
9. Verify a voltmeter reading of 100 mV (±2 mV).
10. If necessary, use a small flat-blade screwdriver to adjust the zero pot until the voltmeter
reading is 100 mV (±2 mV).
11. Turn the regulator’s on/off knob clockwise to close it.
12. Unscrew the calibration cup from the detector.
13. Unscrew the regulator from the zero air calibration cylinder. For convenience, leave the
sample tubing connected to the regulator and the calibration cup.
14. Store the components of the calibration kit in a safe and convenient place.
15. Remove the voltmeter leads from the test points.
16. Secure the junction box cover to the junction box.

65-2330RK H2S Transmitter • 13
Maintenance
This section describes maintenance procedures. It includes preventive maintenance,
troubleshooting, and component replacement procedures.
Preventive Maintenance
This section describes a preventive maintenance schedule to ensure the optimum performance
of the H2S transmitter. It includes daily and quarterly procedures.
Daily
Verify a display reading of 0 ppm H2S at the controller. Investigate significant changes in the
display reading.
Quarterly
Calibrate the H2S transmitter as described in “Calibration” on page 18. See the calibration
frequency discussion in “Calibration Frequency” on page 17 to determine if a quarterly
calibration schedule fits your needs.
Troubleshooting
The troubleshooting guide describes symptoms, probable causes, and recommended action for
problems you may encounter with the H2S transmitter.
NOTE: This troubleshooting guide describes transmitter problems only. See the controller
operator’s manual for problems you may encounter with the controller.
Table 2: Troubleshooting H2S Transmitter
Condition Symptom(s) Probable Causes Recommended Action
Fail
Condition
• Controller indicates
a fail condition.
• The transmitter
wiring to the
controller is
disconnected or
misconnected.
• The plug-in sensor is
not properly plugged
into the sockets in
the detector housing
body.
• The wiring from the
detector to the
amplifier is
disconnected or
misconnected.
• The transmitter’s
zero reading is low
enough to cause a
fail condition.
• The transmitter is
malfunctioning.
1. Verify that the transmitter wiring
to the controller is correct and
secure.
2. Confirm that the plug-in sensor is
installed properly.
3. Verify that the wiring from the
detector to the amplifier is correct
and secure.
4. Perform a fresh air adjustment. A
full calibration is recommended.
5. If the fail condition continues,
replace the plug-in sensor as
described later in this section.
6. If the fail condition continues,
contact RKI for further instruction.

14 • 65-2330RK H2S Transmitter
Replacing Components of the H2S Transmitter
This section includes a procedure to replace the H2S plug-in sensor, the entire detector
assembly, the hydrophobic membrane, and the amplifier. In most cases, it is not necessary to
replace the entire detector assembly.
Replacing the Plug-In H2S Sensor
CAUTION:The sensor contains electrolyte which is a dilute acid. Do not disassemble the
sensor when replacing it with a new one. If sensor electrolyte comes in contact
with your skin, wash affected area thoroughly with soap and water.
1. Turn off the controller.
2. Turn off or unplug power to the controller.
3. Unscrew the detector housing cap from the detector housing body. Make sure not to lose
the cap gasket.
4. Unplug and remove the H2S sensor.
5. Remove the replacement sensor from its packaging and remove the wire jumper. This wire
jumper is installed on the sensor pins for shipment or storage but must be removed for the
sensor to operate properly when installed in a detector.
Slow or No
Response/
Difficult or
Unable to
Calibrate
• Unable to accurately
set the zero or
response reading
during calibration.
• Transmitter requires
frequent calibration.
Note: Under
“normal”
circumstances, the
transmitter requires
calibration once every
3 months.
Some applications
may require a more
frequent calibration
schedule.
• The calibration
cylinder is low, out-
dated, or defective.
• The hydrophobic
membrane in the
detector housing cap
is wet or clogged
with dirt or other
particulates.
• The calibration gas
is not an appropriate
concentration.
• The transmitter is
malfunctioning.
1. Verify that the calibration cylinder
contains an adequate supply of a
fresh test sample.
2. Check the face of the detector
housing cap and remove any
particulate contamination from the
hydrophobic membrane if
necessary. If the membrane
appears saturated with
contamination or damaged,
replace the membrane as described
in the next section.
3. Verify that the calibration gas
concentration is appropriate for
the transmitter. Zero emission air
(20.9% oxygen) is normally used
for a zero adjustment if the
environment is suspect and 25
PPM H2S in nitrogen is normally
used for a response test.
4. If the calibration/response
difficulties continue, replace the
plug-in sensor as described later in
this section.
5. If the calibration/response
difficulties continue, contact RKI
for further instruction.
Condition Symptom(s) Probable Causes Recommended Action

65-2330RK H2S Transmitter • 15
WARNING: The H2S sensor will not operate properly if the wire jumper is not removed.
6. Carefully plug the replacement sensor into the four-socket pattern that is located in the
detector housing.
7. Make sure the cap gasket is in place and screw the detector housing cap back onto the
detector housing body.
8. Turn on or plug in power to the controller.
9. Turn on the controller and place into normal operation.
CAUTION:Allow the replacement sensor to warm up for 5 minutes before you continue with
the next step.
10. Calibrate the transmitter as described in “Calibration” on page 18.
Replacing the H2S Detector
NOTE: In most cases, it is only necessary to replace the plug-in H2S sensor.
1. Turn off the controller.
2. Turn off or unplug power to the controller.
3. Remove the junction box cover.
4. Remove the detector terminal strip from its socket.
5. Disconnect the detector leads from the detector terminal strip. Note the position of the
color-coded leads as you remove them.
6. Unscrew the detector from the junction box conduit hub.
7. Guide the detector leads of the replacement detector through the bottom conduit hub of the
junction box, then screw the mounting threads of the detector into the conduit hub. If
necessary for environmental conditions, apply thread sealant or Teflon tape to the hub and/
or detector threads to seal them.
8. Connect the detector leads to the appropriate detector terminal strip terminals. Connect the
red wire to the terminal labeled TOXIC + and the black wire to the terminal labeled
TOXIC -. See Figure 4 for the detector wiring connections to the amplifier.
Figure 5: Plug-In Sensor Jumper Removal
Remove jumper

16 • 65-2330RK H2S Transmitter
9. Reinstall the detector terminal strip into its socket.
10. Turn on or plug in power to the controller.
11. Turn on the controller and place it into normal operation.
CAUTION: Allow the replacement detector to warm up for 5 minutes before you continue
with the next step.
12. Calibrate the replacement detector as described in “Calibration” on page 18.
13. Secure the junction box cover to the junction box.
Replacing the Hydrophobic Membrane
1. Turn off the controller.
2. Turn off or unplug incoming power to the controller.
3. Unscrew the detector housing cap from the detector housing body.
4. Gently pry up the edge of the white hydrophobic membrane with a small flat blade
screwdriver or a similar tool.
5. Peel off the hydrophobic membrane. It may be necessary to clean off the detector housing
cap face to remove any residue left from the adhesive backed membrane.
6. Install the new membrane in the recess on the face of the detector housing cap.
7. Make sure the cap gasket is in place and screw the detector housing cap back onto the
detector housing body.
8. Turn on power to the controller.
9. Turn on the controller.
Replacing the Amplifier
1. Turn off the controller.
2. Turn off or unplug power to the controller.
3. Remove the junction box cover.
4. Unplug the detector terminal strip and controller terminal strip from their sockets. You
may leave the wires connected to the terminal strips.
5. Unscrew and remove the screw with the flat and lock washers that secures the amplifier to
the junction box. The screw is at the bottom right of the amplifier.
6. Remove the old amplifier.
7. Place the new amplifier in the same position as the old amplifier. A foam gasket that
orients the amplifier and keeps it from rotating is installed on the bottom of the amplifier.
Make sure the amplifier is seated flat in the junction box.
8. Install the new amplifier into the junction box with the screw, lock washer, and flat washer
you removed in Step 5.

65-2330RK H2S Transmitter • 17
9. Install the detector and controller terminals strips into their sockets on the new amplifier
as shown in Figure 4. If controller leads or detector leads were removed during this
procedure, refer to Figure 4 for the detector and amplifier connections.
NOTE: When a transmitter is first powered up with a new amplifier, the initial output may be
either high or below zero depending on the setting of the zero pot. Be sure to make
arrangements so that this does not cause unwanted alarms.
10. Turn on or plug in power to the controller.
11. Turn on the controller and place it into normal operation.
12. Allow the transmitter to warm up for 5 minutes.
13. Calibrate the H2S transmitter as described in “Calibration” on page 18.
Calibration Frequency
Although there is no particular calibration frequency that is correct for all applications, a
calibration frequency of every 3 months is adequate for most H2S transmitter applications.
Unless experience in a particular application dictates otherwise, RKI Instruments, Inc.
recommends a calibration frequency of every 3 months for the H2S transmitter.
If an application is not very demanding, for example detection in a clean, temperature
controlled environment, and calibration adjustments are minimal at calibration, then a
calibration frequency of every 6 months is adequate.
If the application is very demanding, for example if the environment is not well controlled,
then more frequent calibration than every 3 months may be necessary.

18 • 65-2330RK H2S Transmitter
Calibration
This section describes how to calibrate the H2S transmitter. It includes procedures to prepare
for calibration, set the zero reading, set the response reading, and return to normal operation.
It describes the test using a calibration kit that includes a calibration cup, calibration gas,
sample tubing, and a fixed flow regulator with an on/off knob. RKI Instruments, Inc.
recommends using a 0.5 LPM (liters per minute) fixed flow regulator.
Preparing for Calibration
NOTE: Calibrating the H2S transmitter may cause alarms. Be sure to put the controller into its
calibration program or disable external alarms before calibration.
WARNING: Do not remove the detector housing cap or junction box cover while the
circuits are energized unless the area is determined to be non-hazardous.
Keep the detector housing cap and junction box cover tightly closed during
operation.
1. Unscrew and remove the junction box cover.
2. Set a voltmeter to measure in the millivolt (mV) range.
3. Plug the voltmeter leads into the test points on the amplifier. Plug the positive lead into the
red (+) test point; plug the negative lead into the black (-) test point.
4. Use the following formula to determine the correct test points output for the calibrating
sample.
Output (mV) = (calibrating sample/fullscale) X 400 + 100
For example, with a calibrating sample of 25 ppm H2S and a fullscale setting of 100 ppm,
the correct output is 200 mV.
200 (mV) = (25/100) X 400 +100
5. Screw the calibration cup onto the detector housing.
Setting the Zero Reading
NOTE: If you can verify that the H2S transmitter is in a fresh air environment, you do not
need to apply zero air to the detector before adjusting the zero reading.
1. Screw the regulator into the zero air calibration cylinder.
2. Use the sample tubing to connect the regulator to the calibration cup.
3. Turn the regulator knob counterclockwise to open the regulator.
4. Allow the gas to flow for two minutes, then verify a reading of 100 mV (± 2mV). If
necessary, use the zero pot on the amplifier to adjust the reading to 100 mV (± 2mV).

65-2330RK H2S Transmitter • 19
5. Turn the regulator knob clockwise to close the regulator.
6. Unscrew the regulator from the zero air calibration cylinder.
7. Leave the sample tubing connected to the regulator and the calibration cup.
Setting the Response Reading
1. Verify that the calibration gas is representative of the transmitter’s target gas.
2. For toxic gas cylinders (like H2S), it is important to vent the regulator while installing it
onto the cylinder. Venting the regulator during installation helps prevent air from getting
into the cylinder and degrading the gas. Open the regulator by turning the knob
counterclockwise and then install it onto the cylinder.
3. Allow the gas to flow for two minutes, then verify that the reading matches the response
reading (± 2mV) you determined earlier. If necessary, use the span pot on the amplifier to
adjust the reading to match the correct response reading.
4. Turn the regulator knob clockwise to close the regulator.
5. Unscrew the regulator from the calibration cylinder.
Returning to Normal Operation
1. Remove the voltmeter leads from the amplifier test points.
2. Unscrew the calibration cup from the detector.
NOTE: For convenience, leave the components of the calibration kit connected by the sample
tubing.
3. Secure the junction box cover to the junction box.
4. When the display reading falls below the alarm setpoints, return the controller to normal
operation.
5. Verify that the controller display reading decreases and stabilizes at 0 ppm.
6. Store the components of the calibration kit in a safe and convenient place.

20 • 65-2330RK H2S Transmitter
Parts List
Table 5 lists replacement parts and accessories for the H2S transmitter.
Table 3: Parts List
Part Number Description
06-1248RK Sample tubing (order by the foot)
07-0033RK Detector housing cap gasket
18-0400RK-01 Junction box with rubber spacers
57-1064RK-03 Amplifier (specify target gas when ordering)
65-2330RK H2S transmitter (includes detector and amplifier)
65-2495RK H2S replacement detector assembly (includes sensor)
71-0176RK 65-2330RK H2S Transmitter Operator’s Manual (this document)
81-0151RK-04 Calibration cylinder, 25 ppm H2S in nitrogen, 34 liter aluminum
81-0076RK-01 Zero air calibration cylinder, 34 liter steel
81-1050RK Regulator with gauge and knob, 0.5 LPM, for 17 liter and 34 liter steel cal-
ibration cylinders (cylinders with external threads)
81-1051RK Regulator with gauge and knob, 0.5 LPM, for 34 liter aluminum, 58 liter,
and 103 liter calibration cylinders (cylinders with internal threads)
81-1117RK Calibration cup
ES-1537-H2S H2S replacement sensor
