65-2444-500
PPM Hexane Transmitter
Operator’s Manual
Part Number: 71-0550
Revision: 0
Released: 5/8/23

2• 65-2444-500 PPM Hexane Transmitter Operator’s Manual
WARNING
Read and understand this instruction manual before operating
instrument. Improper use of the gas monitor could result in bodily
harm or death.
Periodic calibration and maintenance of the gas monitor is essential
for proper operation and correct readings. Please calibrate and
maintain this instrument regularly! Frequency of calibration depends
upon the type of use you have and the sensor types. For most
applications, typical calibration frequencies are between 3 and 6
months but can be more often or less often based on your usage.

65-2444-500 PPM Hexane Transmitter Operator’s Manual • 3
Product Warranty
RKI Instruments, Inc. warrants gas alarm equipment sold by us to be free from defects in
materials, workmanship, and performance for a period of one year* from the date of shipment
from RKI Instruments, Inc. Any parts found defective within that period will be repaired or
replaced, at our option, free of charge. Parts must be returned to RKI Instruments, Inc. for repair
or replacement. This warranty does not apply to those items which by their nature are subject to
deterioration or consumption in normal service, and which must be cleaned, repaired or replaced
on a routine basis. Examples of such items are:
• Pump diaphragms and valves
•Fuses
•Batteries
• Filter elements
Warranty is voided by abuse including mechanical damage, alteration, rough handling, or repair
procedures not in accordance with instruction manual. This warranty indicates the full extend of
our liability, and we are not responsible for removal or replacement costs, local repair costs,
transportation costs, or contingent expenses incurred without our prior approval.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ANY AND ALL OTHER WARRANTIES AND
REPRESENTATIONS, EXPRESSED OR IMPLIED, AND ALL OTHER OBLIGATIONS OR
LIABILITIES ON THE PART OF RKI INSTRUMENTS, INC. INCLUDING BUT NOT LIMITED TO,
THE WARRANTY OF MERCHANTABILITY OR FITNESS FOR APARTICULAR PURPOSE. INNO
EVENT SHALL RKI INSTRUMENTS, INC. BE LIABLE FOR INDIRECT, INCIDENTAL, OR
CONSEQUENTIAL LOSS OR DAMAGE OF ANY KIND CONNECTED WITH THE USE OF ITS
PRODUCTS OR FAILURE OF ITS PRODUCTS TO FUNCTION OR OPERATE PROPERLY.
This warranty covers instruments and parts sold to users only by authorized distributors, dealers
and representatives as appointed by RKI Instruments, Inc.
We do not assume indemnification for any accident or damage caused by the operation of this gas
monitor and our warranty is limited to the replacement of parts or our complete goods. Warranty
covers parts and labor performed at RKI Instruments, Inc. only, and does not cover field labor or
shipment of parts back to RKI.

4• 65-2444-500 PPM Hexane Transmitter Operator’s Manual
Table of Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
PPM Hexane Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Amplifier. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Junction Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Mounting the PPM Hexane Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Wiring the PPM Hexane Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Startup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Introducing Incoming Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Transmitter Burn-In Period. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting the Zero Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Replacing Components of the PPM Hexane Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Calibration Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Calibration Kit Humidifier Tube. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Preparing for Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting the Zero Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting the Span Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting the Linearization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Returning to Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

65-2444-500 PPM Hexane Transmitter Overview • 5
Overview
This manual describes the 65-2444-500 ppm hexane transmitter. This manual also describes how
to install, start up, configure, maintain, and calibrate the transmitter when it is used with a gas
monitoring controller. A parts list at the end of this manual lists replacement parts and accessories
for the transmitter.
Specifications
Table 1 lists specifications for the ppm hexane transmitter.
WARNING: When using the 65-2444-500, you must follow the instructions and warnings in
this manual to assure proper and safe operation of the 65-2444-500 and to
minimize the risk of personal injury. Be sure to maintain and periodically
calibrate the 65-2444-500 as described in this manual.
Table 1: Specifications
Tar get Gas Hexane (C6H14)
Detection Range 0 - 500 ppm
Area Classification Explosion-proof for Class I, Groups B, C, and D
Sampling Method Diffusion
Input Power 10 - 30 VDC
Signal Output
4 to 20 mA with impedance maximums listed
below:
• 12 VDC input: 500 Ohms
• 24 VDC input: 1000 Ohms
Response Time 90% in 45 seconds

6• Description 65-2444-500 PPM Hexane Transmitter
Description
This section describes the ppm hexane transmitter’s components. It is a 4 to 20 mA type detector
head. It consists of the ppm hexane detector, amplifier, and junction box.
Figure 1: Component Location
Amplifier
J-Box
Hydrogen Detector
LINEAR
SPAN
Reducing Bushing,
3/4 NPT to1/2 NPT
DETECTOR PWR/ SIG
SWBR

65-2444-500 PPM Hexane Transmitter Description • 7
PPM Hexane Detector
The ppm hexane detector is a MOS type (metal oxide semiconductor) detector packaged in a 1/2
NPT nipple with a sintered metal flame arrestor on one end allowing ambient air to diffuse into
the detector. The flame arrestor also contains any sparks which may occur within the detector. The
1/2 NPT mounting threads at the top of the detector allow you to mount it into the bottom conduit
hub of the junction box. A rainshield screws onto the bottom of the detector (flame arrestor end).
The rainshield helps protect the detector from rain and debris in the monitoring environment.
Three color-coded leads extend from the top of the detector. The leads allow you to connect the
detector to the amplifier.
Amplifier
The amplifier converts the non-linear electrical output from the detector to a linear 4 to 20 mA
signal that corresponds to the detection range and transmits the signal to a gas monitoring
controller. The amplifier includes the terminal strips, span pot, linearizing pot, and test points.
Figure 2: Amplifier Component Location
Controller Terminal Strip
The controller terminal strip is a three position plug-in style terminal strip located near the top of
the amplifier. Use the controller terminal strip to wire the transmitter to a controller.
Detector Terminal Strip
The detector terminal strip is a three position plug-in style terminal strip located below the
controller terminal strip. Use the detector terminal strip to connect the detector to the amplifier.
NOTE: The detector is factory-wired to the detector terminal strip. See page 10 for all wiring
procedures related to the transmitter.
W
+ Test Point, Red
RB
DETECTOR
- Test Point, Black
Mounting Screw
w/ flat and lock washer
SPAN
PWR / SIG
S
JP2 Jumper
JP1 Jumper
LINEAR
Detector Terminal Strip
Span Pot
Controller Terminal Strip
Linearizing Pot

8• Description 65-2444-500 PPM Hexane Transmitter
Span Pot
The span pot is located to the left of the detector terminal strip (see Figure 2). Use a small flat
blade screwdriver to turn the span pot’s adjustment screw and adjust the amplifier’s full scale
response output during the calibration procedure.
Linearizing Pot
The linearizing pot (labeled LINEAR) is located in the bottom left corner of the amplifier (see
Figure 2). Use a small flat blade screwdriver to turn the linearizing pot’s adjustment screw while
applying mid-scale gas to linearize the transmitter’s output during the calibration procedure.
Test Points
The test points are on the right side of the amplifier (see Figure 2). The test points produce a 100
to 500 mV output that corresponds to the transmitter’s 4 to 20 mA output. Use the test points and
a voltmeter to measure the amplifier’s output during the start-up and calibration procedures. The
black test point on the bottom is the negative (-) test point and the red test point on the top is the
positive (+) test point.
JP1 and JP2 Jumpers
The JP1 and JP2 jumpers are both shipped from the factory. JP1 will only be installed on one pin
and JP2 will be installed on either one or both pins. When installing a new sensor, the jumper
configuration may need to be adjusted (see page 17).
Junction Box
Use the junction box to install the transmitter at a mounting site that is remote from the controller.
The junction box also protects the amplifier and wiring connections made to the amplifier. Use the
top 3/4 NPT conduit hub to connect wiring from the amplifier to the controller. Use the cover on
the front of the junction box to access the interior of the junction box. The detector and amplifier
are factory installed in the junction box.

65-2444-500 PPM Hexane Transmitter Installation • 9
Installation
This section describes procedures to mount the ppm hexane transmitter in the monitoring
environment and wire the transmitter to a controller.
Mounting the PPM Hexane Transmitter
Figure 3: Mounting the PPM Hexane Transmitter
1. Select a mounting site that is representative of the monitoring environment. Consider the
following when you select the mounting site.
• Select a site where the transmitter is not likely to be bumped or disturbed. Make sure there
is sufficient room to perform start-up, maintenance, and calibration procedures.
• Select a site where the target gas is likely to be found first. For hexane, which is heavier
than air, mount the transmitter near the floor or where hexane is most likely to accumulate.
2. At the monitoring site you select, hang or mount the junction box with the detector facing
down (see Figure 3).
.38
.75
2.70
JBox
Rubber
Spacers,
3X
3/4 NPT Female
3.65
Hydrogen
Detector
3/4 x 1/2 Reducing
Bushing
7.5 max

10 • Installation 65-2444-500 PPM Hexane Transmitter
Wiring the PPM Hexane Transmitter
WARNING: Always verify that the power to the controller is off before you make wiring
connections.
1. Turn off power to the controller.
2. Place the controller’s power switch in the OFF position.
3. Remove the junction box cover.
4. The detector leads are factory wired. Verify that the detector leads are wired to the amplifier’s
detector terminal strip as shown in Figure 4.
5. To gain access to a plug-in terminal strip for wiring, pull it out of its socket by grasping the
terminal strip and pulling. The detector strip is keyed so that the controller and detector
terminal strips cannot be reversed inadvertently.
6. Guide a three-conductor, shielded cable or three wires in conduit through the top conduit hub
of the junction box.
7. Pull out the controller terminal strip, and connect the three wires to the terminal strip as
follows (see Figure 4).
• Connect the positive wire to the PWR/SIG “+” terminal.
• Connect the signal wire to the PWR/SIG “S” terminal.
• Connect the negative wire to the PWR/SIG “-” terminal.
CAUTION: If shielded cable is used, leave the cable shield’s drain wire
disconnected and insulated at the transmitter. You will connect the
opposite end of the cable’s drain wire to the controller’s chassis (earth)
ground.
8. Reinstall the controller terminal strip into its socket.
9. Secure the junction box cover to the junction box.
10. Route the cable or wires leading from the ppm hexane transmitter through one of the conduit
hubs at the controller housing.
CAUTION: Do not route power and transmitter wiring through the same controller
conduit hub. The power cable may disrupt the transmission of the
transmitter signal to the controller.

65-2444-500 PPM Hexane Transmitter Installation • 11
11. Connect the wires to the applicable detector/transmitter terminal strip at the controller as
shown in Figure 4.
Figure 4: Wiring the PPM Hexane Transmitter to a Controller
12. If shielded cable is used, connect the cable’s drain wire to an available chassis (earth) ground
at the controller. RKI controllers typically have a ground stud that can be used to ground the
cable’s drain wire.
4-20mAIn(S)
+24VDC
-(DCGround)
Controller
Detector Wires
Black
Red
Cable Shield
P W R / SIG
S
SPAN
B R
LINEAR
DETECTOR
White
W

12 • Start Up 65-2444-500 PPM Hexane Transmitter
Start Up
This section describes procedures to start up the ppm hexane transmitter and place the transmitter
into normal operation.
Introducing Incoming Power
1. Complete the installation procedures described earlier in this manual.
2. Verify that the power wiring to the controller is correct and secure. Refer to the controller
operator’s manual.
NOTE: When a transmitter is first powered up after installation or being off power
for an extended period, its output may be high enough to cause an alarm or
low enough to indicate a failure for a brief period before stabilizing within a
few minutes. Be sure to make arrangements so that this does not cause
unwanted alarms.
3. Turn on power to the controller.
4. Turn on the controller.
5. Verify that the controller is on and operating properly. Refer to the controller operator’s
manual.
Transmitter Burn-In Period
Once power has been applied to the transmitter, it will take several days for the transmitter signal
to the controller to stabilize completely. This is the burn-in period. The zero reading should settle
down close to zero within 2-3 hours of applying power. The transmitter should be burned in for 5-
7 days for a stable zero and accurate response to gas. The transmitter is calibrated at the factory
before shipment and it is not necessary to calibrate the transmitter after startup. If calibration of
the transmitter after startup is desired, wait at least 5 days after startup before calibrating the
transmitter. A burn-in period of 7 days is recommended. See page 17 for calibration instructions.
Setting the Zero Signal
The detector’s zero setting is controlled by electronics and is not user-adjustable.

65-2444-500 PPM Hexane Transmitter Maintenance • 13
Maintenance
This section describes maintenance procedures. It includes preventive maintenance,
troubleshooting, and component replacement procedures.
Preventive Maintenance
This section describes a preventive maintenance schedule to ensure the optimum performance of
the ppm hexane transmitter. It includes daily and quarterly procedures.
Daily
Verify a display reading of 0 ppm at the controller. Investigate significant changes in the display
reading.
Biannual
Calibrate the ppm hexane transmitter as described on page 17.
Troubleshooting
The troubleshooting guide describes symptoms, probable causes, and recommended action for
problems you may encounter with the ppm hexane transmitter.
NOTE: This troubleshooting guide describes transmitter problems only. See the controller
operator’s manual for problems you may encounter with the controller.
Table 2: Troubleshooting the ppm Hexane Transmitter
Condition Symptom(s) Probable Causes Recommended Action
Fail Condi-
tion
• Controller indicates a
fail condition.
• The transmitter
wiring is
disconnected or
misconnected.
• The transmitter is
malfunctioning.
1. Verify that the transmitter wiring
is correct and secure.
2. Calibrate the transmitter.
3. If the fail condition continues,
replace the detector.
4. If the fail condition continues,
contact RKI for further
instruction.

14 • Maintenance 65-2444-500 PPM Hexane Transmitter
Replacing Components of the PPM Hexane Transmitter
This section includes procedures to replace the ppm hexane detector and amplifier.
Replacing the PPM Hexane Detector
1. Turn off power to the controller.
2. Place the controller’s on/off switch in the OFF position.
3. Remove the junction box cover.
4. Remove the detector terminal strip from its socket.
5. Disconnect the detector leads from the detector terminal strip. Note the position of the color-
coded leads as you remove them.
6. Unscrew the detector from the junction box.
7. Guide the detector leads of the replacement detector through the bottom conduit hub of the
junction box, then screw the mounting threads of the detector into the conduit hub.
8. Connect the detector leads to the detector terminal strip as shown in Table 3 below and
Figure 4 on page 11 of this manual.
Slow or No
Response/
Difficult or
Unable to
Calibrate
• Unable to accurately
set the span or
linearizing response
during calibration.
• Transmitter requires
frequent calibration.
NOTE: Under
“normal”
circumstances, the
transmitter requires
calibration once every
6 months.
Some applications may
require a more frequent
calibration schedule.
• The calibration
cylinder is low,
out-dated, or
defective.
• The calibration gas
flow rate is too
low.
• The transmitter is
malfunctioning.
1. Verify that the calibration
cylinder contains an adequate
supply of gas.
2. Verify that the regulator used for
calibration is a 0.5 LPM
regulator.
3. If the calibration/response
difficulties continue, replace the
detector.
4. If the calibration/response
difficulties continue, contact
RKI for further instruction.
Table 3: Reconnecting the PPM Detector to the Amplifier
Detector Lead Detector Terminal
Strip
Red R
White W
Table 2: Troubleshooting the ppm Hexane Transmitter (Continued)
Condition Symptom(s) Probable Causes Recommended Action

65-2444-500 PPM Hexane Transmitter Maintenance • 15
9. Re-install the detector terminal strip into its socket.
NOTE: When a transmitter is first powered up with a new detector, its output may be
high enough to cause an alarm or low enough to indicate a failure for a brief
period before stabilizing within a few minutes. Be sure to make
arrangements so that this does not cause unwanted alarms.
10. Turn on power to the controller.
11. Turn on the controller and place it into normal operation.
12. Allow the transmitter to run for 3 hours.
13. Perform a preliminary calibration as described on page 17. This will be a temporary
calibration since the new ppm detector must burn-in before it can be properly calibrated.
14. Allow the replacement detector to burn-in for at least 5 days before you continue with the next
step. A burn-in period of 7 days is recommended.
15. After the burn-in period, calibrate the transmitter as described on page 17.
NOTE: The JP1 and JP2 jumper configuration may need to be adjusted during
calibration.
Replacing the Amplifier
If you are replacing the amplifier, it is likely that the transmitter has been off power for an
extended period. Make sure to follow the preliminary calibration recommendation and the burn-in
period recommendation before making the final calibration.
1. Turn off power to the controller.
2. Place the controller’s on/off switch in the OFF position.
3. Remove the junction box cover.
4. Unplug the detector terminal strip and controller terminal strip from their sockets. You may
leave the wires connected to the terminal strips.
5. Unscrew and remove the screw with the flat and lock washers that secures the amplifier to the
junction box.
6. Remove the old amplifier.
Black B
Table 3: Reconnecting the PPM Detector to the Amplifier
Detector Lead Detector Terminal
Strip

16 • Maintenance 65-2444-500 PPM Hexane Transmitter
7. Install the detector and controller terminal strips into their sockets on the new amplifier as
shown in Figure 4 on page 11 of this manual. If controller leads or detector leads were
removed during this procedure, refer to Tables 4 and 5 below.
8. Install the amplifier into the junction box with the screw, lock washer, and flat washer you
removed in Step 5 above. A foam gasket that orients the amplifier and keeps it from rotating is
installed on the bottom of the amplifier. Make sure the amplifier is seated flat in the junction
box.
NOTE: When a transmitter is first powered up with a new amplifier, the initial
output may be either high or below zero. Be sure to make arrangements so
that this does not cause unwanted alarms.
9. Turn on power to the controller.
10. Turn on the controller and place it into normal operation.
11. Allow the transmitter to run for 3 hours.
12. Perform a preliminary calibration as described on page 17. This will be a temporary
calibration since the new ppm detector must burn-in before it can be properly calibrated.
13. Allow the replacement detector to burn-in for at least 5 days before you continue with the next
step. A burn-in period of 7 days is recommended.
14. After the burn-in period, calibrate the transmitter as described on page 17.
NOTE: The JP1 and JP2 jumper configuration may need to be adjusted during
calibration.
Table 4: Reconnecting the PPM Hexane Amplifier to the Controller
Amplifier’s
Controller Terminal
Strip
Controller’s
Transmitter Terminal
Strip (typical)
--(DC-)
S S (4 - 20 mA In)
++24V
Table 5: Reconnecting the PPM Hexane Detector to the Amplifier
Detector Lead
Amplifier’s
Detector Terminal
Strip
Red R
White W
Black B

65-2444-500 PPM Hexane Transmitter Calibration Frequency • 17
Calibration Frequency
Although there is no particular calibration frequency that is correct for all ppm hexane transmitter
applications, a calibration frequency of every 6 to 12 months is adequate for most applications.
Unless experience in a particular application dictates otherwise, RKI Instruments, Inc.
recommends a calibration frequency of every 6 months.
If an application is not very demanding, for example detection in a clean, temperature controlled
environment where hexane is not normally present, and calibration adjustments are minimal at
calibration, then a calibration frequency of every 12 months is adequate.
If an application is very demanding, for example if hexane is present often and in significant
concentrations or the environment is not well controlled, then more frequent calibration than
every 6 months may be necessary.
Calibration
This section describes how to calibrate the ppm hexane transmitter. It includes procedures to
prepare for calibration, set the span reading, set the linearization, and return to normal operation.
WARNING: The controller is not an active gas monitoring device during the calibration
procedure.
Calibration Kit Humidifier Tube
The ppm hexane detector requires normal atmospheric humidity levels to respond properly to
hexane. Normal atmospheric humidity variations do not affect the detector’s response to hexane
in ambient air, but the ultra low humidity level of gas from a calibration cylinder requires that the
calibration sample be humidified for the detector to respond properly. The calibration kit for the
ppm hexane transmitter includes a humidifier tube that is not normally included in other
calibration kits. This humidifier tube humidifies the calibration sample flowing through it by
absorbing humidity from the ambient air and adding it to the sample. The humidifier tube is
included in the “Parts List” on page 20.
WARNING: A humidifier tube must be used when calibrating the ppm hexane transmitter for
the detector to respond properly to the calibration gas. Failure to use a
humidifier tube will result in an inaccurate calibration.
Materials
• 0.5 LPM fixed flow regulator with an on/off knob
• calibration cup
• humidifier tube
• 250 ppm hexane calibration gas cylinder
• 500 ppm hexane calibration gas cylinder

18 • Calibration 65-2444-500 PPM Hexane Transmitter
Preparing for Calibration
1. Screw the calibration cup onto the bottom of the hexane detector.
2. Use the humidifier tube to connect the regulator to the calibration cup.
3. Set a voltmeter to measure in the millivolt (mV) range.
4. Remove the junction box cover, then plug the voltmeter leads into the test points on the
amplifier.
Plug the positive lead into the red + test point; plug the negative lead into the black - test
point.
5. Place the controller into its calibration mode or disable external alarms.
NOTE: Calibrating the ppm hexane transmitter may cause alarms. Be sure to put the
controller into its calibration program or disable external alarms before
continuing.
Setting the Zero Reading
The detector’s zero setting is controlled by electronics and is not user-adjustable.
Setting the Span Reading
The configuration of the JP1 and JP2 jumpers may need to be adjusted during calibration. Valid
configurations are:
• JP1 and JP2 both installed on one pin
OR
• JP1 installed on one pin and JP2 installed on both pins
1. Screw the regulator into the 500 ppm calibration cylinder.
2. Turn the regulator knob counterclockwise to open the regulator.
3. Allow the calibration gas to flow for 2 minutes.
4. Verify a reading of 500 mV (±2 mV) on the voltmeter. If necessary, use the span pot on the
amplifier to adjust the reading.
5. If you are calibrating a new sensor and the span pot cannot be adjusted high enough to obtain
a reading of 500 mV (±2 mV) on the voltmeter, remove the JP2 jumper (see page 7) and try to
adjust the span pot again.
Similarly, if you are calibrating a new sensor and the span pot cannot be adjusted low
enough to obtain a reading of 500 mV (±2 mV) on the voltmeter, install the JP2 jumper
(see page 7) and try to adjust the span pot again.
6. Turn the regulator knob clockwise to close the regulator.
7. Unscrew the regulator from the full-scale calibration cylinder.

65-2444-500 PPM Hexane Transmitter Calibration • 19
Setting the Linearization
1. Screw the regulator into the 250 ppm calibration cylinder.
2. Turn the regulator knob counterclockwise to open the regulator.
3. Allow the calibration gas to flow for 2 minutes.
4. Verify a reading of 300 mV (±2 mV) on the voltmeter. If necessary, use the linear pot on the
amplifier to adjust the reading.
5. Turn the regulator knob clockwise to close the regulator.
6. Unscrew the regulator from the half-scale calibration cylinder.
Returning to Normal Operation
1. Remove the voltmeter leads from the amplifier test points.
2. Unscrew the calibration cup from the detector.
NOTE: For convenience, leave the regulator and calibration cup connected by the
humidifer tube.
3. Secure the junction box cover to the junction box.
4. When the controller display reading falls below the alarm setpoints, return the controller to
normal operation.
5. Verify that the controller display reading decreases and stabilizes at 0 ppm.
6. Store the components of the calibration kit in a safe and convenient place.

20 • Parts List 65-2444-500 PPM Hexane Transmitter
Parts List
Table 6 lists replacement parts and accessories for the ppm hexane transmitter.
Table 6: Parts List
Part Number Description
18-0400RK Junction box with cover
33-2002RK-01 24” humidifier tube w/ 3/16” tubing on ends, for calibration kit
57-1070-01 Amplifier (specify target gas and detection range)
65-2444-500 0 - 500 ppm hexane transmitter (includes detector and amplifier)
71-0550 65-2444-500 PPM Hexane Transmitter Operator’s Manual (this document)
81-0083RK-11 Calibration cylinder, 250 ppm hexane in air, 34 liter steel
81-0083RK-13 Calibration cylinder, 250 ppm hexane in air, 103 liter
81-0083RK-21 Calibration cylinder, 500 ppm hexane in air, 34 liter steel
81-0083RK-23 Calibration cylinder, 500 ppm hexane in air, 103 liter
81-1050RK Regulator, 0.5 LPM, with pressure gauge and flow control knob, for 17 liter and 34 liter
steel calibration cylinders (cylinders with external threads)
81-1051RK Regulator, 0.5 LPM, with pressure gauge and flow control knob, for 34 liter aluminum, 58
liter, and 103 liter steel calibration cylinders (cylinders with internal threads)
81-1117RK Calibration cup
SG-8547-01 PPM hexane detector
