Operating Instructions

for the Control Units

of Vibratory Drives

ESK 2002

Rhein-Nadel Automation GmbH

Rhein-Nadel Automation GmbH 214.04.2014

VT-BA ESK2002-GB

Table of contents

Chapt........................................................................................................................ Page

1 Technical datas................................................................................................... 3

2 Safety notes................................................................................................... 4

3 Commissioning instructions ............................................................................... 4

4 Operation 7

5 Dimensional drawing..................................................................................... 15

6 Connection diagram Sensors....................................................................................... 16

Declaration of conformity

as defined by

Low voltage directive 2014/35/EU

and EMC directive 2014/30/EU

Herewith we declare that the product complies with the following provisions:

Low voltage directive 2014/35/EU

EMC directive 2014/30/EU

applied harmonized standards: DIN EN 60204 T1

EN 61439-1

remarks:

Rhein-Nadel-Automation

--------------------------------

Managing Director

Jack Grevenstein

Rhein-Nadel Automation GmbH 314.04.2014

VT-BA ESK2002-GB

1.1 Performance Characteristics

This compact control unit has been designed to operate a vibratory bowl feeder, a linear feeder and a hopper combina-

tion. It can connect a linear feeder or delivery belt to Channel 3 and a vibrating hopper or belt hopper to Channel 2. The

belt drives have to be equipped with an AC capacitor motor.

Control unit ESK 2002-10 manages a total output of 10 amps and control unit ESK 2002-16 a total output of 16 amps.

The unit has the following performance characteristics:

Three power outputs:

Channel 1: vibratory bowl feeder < 10 A (10A)

Channel 2: linear feeder or hopper < 4 A (6A)

Channel 3: linear feeder or hopper < 4A (6A)

Total load current max. 10 A (16A)

Channels 1 to 3 are phase controlled

Two sensor amplifiers with independently adjustable time levels (Incoming / Outgoing)

External 24VDC enabling inputs

Two relay outputs and four optocouplers for status messages and further links

A membrane keyboard for setting and changing the operating values (parameters) in the setting menus.

Plug connections for

ovibratory bowl feeder

olinear feeder

ohopper

osensors

ocommunication

Double-pole mains power switch

1.2 EC Conformity /CSA Conformity

The control device corresponds to the following regulations:

Low voltage directive 2014/35/EU

EMC directive 2014/30/EU

Applied harmonized standards:

DIN EN 60204 T1

EN 61439-1

1.3 Technical Data

Mains voltage:

230 Volt AC, 50/60 Hz, +20 / -15%

110 Volt AC, 50/60 Hz, +10 / -10%

Output voltage:

0 ... 208 Veff / 230 VAC ; 0 ... 98Veff / 110VAC

apparatuses type:

ESK 2002 - 10 / ESK 2002 - 16

Load current channel 1:

10 Aeff / 10 Aeff /

Load current channel 2:

4 Aeff / 4 Aeff /

Load current channel 3:

4 Aeff / 4 Aeff /

Total load current:

10 Aeff / 16 Aeff /

Minimum load current:

80 mA

Internal fuse:

F1 = 10A / F2 = 4A / F3 = 4A

Soft start time, soft stop time for three channels:

0 ... 5 sec., separate selectable

Sensor inputs:

3 Remote controls input:

24V DC (10-24VDC)

Sensor power supply:

24V DC, max. 60 mA (per sensor input)

Sensor delay ON:

0 ... 60 sec. can be selected separately

Sensor delay OFF:

0 ... 60 sec. can be selected separately

Outputs:

2 relays / 2 normalty open contacts voltage-controlled

2 potential-free change-over contact

Status output (optocoupler):

max. 30V DC 10mA

Relay contacts:

max. 6A 250V AC

Operating temperature:

0 ... 45° C

Type of protection:

IP 54

Rhein-Nadel Automation GmbH 414.04.2014

VT-BA ESK2002-GB

1.4 Accessoires

Label Denomination RNA-Mat-code

XS1,XS2,XS5 Connector, 5-poles 31002322 ( 50Hz Antriebe )

31002323 ( 100 Hz Antriebe)

XS3 Coupler connector, 5-poles, straight 35051144

XS3 Coupler connector, 5-poles, angular 35002546

XS4 Coupler connector, 12-poles, straight 35051641

XS4 Coupler connector, 12-poles, angular 35051642

2 Safety Instructions

It is always necessary to read and understand the safety instructions. This ensures that valuable material is not dam-

aged and injuries are avoided.

Steps must be taken to ensure that all persons working with this control unit are familiar with the safety regulations and

observe them.

The device described in this manual is a control unit for operating RNA bowl feeders and linear feeders. The limit val-

ues specified in the technical data must be observed.

Note!

This hand indicates tips on operation of the control unit.

Attention!

This warning triangle indicates safety instructions. Failure to heed this warning can lead to severe

injuries or death!

Work on electrical equipment of the machine/plant may be carried out only by a trained electrician or by

untrained persons under the leadership and supervision of a trained electrician in accordance with the

regulations for electrical engineering!

All safety and danger signs on the machine/plant must be observed!

The electrical equipment of a machine/plant must be inspected and checked regularly. Defects such as

loose connections or damaged cables must be remedied immediately!

Before commencing operation, make sure that the earthing line (power earth, PE) is intact and installed

at the connecting point. Only test instruments approved for this purpose may be used for checking the

safety grounding conductor.

3 Commissioning Instructions

Before connecting up to the mains and switching on the control unit, it is essential to check the following

points:

Is the control unit in proper working condition and closed with all screws?

Are the connector locks clicked in/screwed secure?

Are all cables and glands intact?

Is PROPER INTENDED USAGE ensured?

Does the mains voltage specification on the control unit agree with the local mains voltage?

Does the mains frequency specification on the vibratory drive agree with the local mains?

Is the correct operating mode set on the control unit? (See "Operating Mode" section)

Operation of the control unit may be commenced only when all questions asked above can be answered unambiguous-

ly with YES.

Before you start operation after repair work has been carried out or control units/vibrating drives have been

exchanged, set the output on the control unit to minimum before switching on. Check that the system is

working properly when you increase the output.

Rhein-Nadel Automation GmbH 514.04.2014

VT-BA ESK2002-GB

3.1 OPERATING MODE

Bowl feeder frequency coding in connector.

Operating mode 2

With bridge: 100 / 120Hz

With bridge: 6000 / 7200 oscillations/min

Operating mode 1

Without bridge: 50 / 60Hz

Without bridge: 3000 / 3600 oscillations/min

3.2 Sensor Inputs and Sensor Links

The control unit has two built-in sensor inputs. They can be used for checking the back pressure, the level, for cycle

control and other monitoring functions. The following basic rules apply:

Sensor input 1 acts on channel 1. In case nothing else has been programmed in menu C006, sensor input 1 acts on

chanel 1 and sensor input 2 acts on channal 2. If the operation level control is needed, therefore the sensor input 2 is

reserved. The sensor inputs can only be evaluated when they are activated. See the connecting diagram for the sensor

connections (XS3 plug connection).

3.3 Status Outputs and Relays

The status outputs are used for remote diagnostics of the control unit operating mode or for linking several control units

together. They are unassigned NPN-doped transistor routes and are potential-free.

The transistor route is always connected at the STANDBY status output when the control unit is connected to the

mains and switched on with the mains power switch.

The ON ACTION status output requires the same conditions as STANDBY. Additional Channel 1, channel 2 and chan-

nel 3 must be active. The transistor will block if it is set to BACK PRESSURE, OFF or STOP. The status outlets and

the remote control should be wired via the XS4 plug connection.

Rhein-Nadel Automation GmbH 614.04.2014

VT-BA ESK2002-GB

Rhein-Nadel Automation GmbH 714.04.2014

VT-BA ESK2002-GB

4. Operation

4.1 General

Control unit plug connections

Mains power

switch

The control unit is isolated from the mains with a double-pole switch.

XS 3

Plug connector for sensors

Channel 1

Plug connector for bowl feeder ( < 10A)

Channel 2

Plug connector for vibration feeder or 1-phase motor ( < 4A)

Channel 3

Plug connector for vibration feeder or 1-phase motor ( < 4A)

XS 4

Plug connector for optocoupler outputs and remote control input

The control unit display (membrane keyboard)

On/off

This key switches all connected devices off. "OFF" will appear in the display. The

control unit is still ready for operation.

Cursor up and cursor down

Use these keys to page through the control unit menu or to set parameters.

Enter

Use this key to confirm the parameters entered with the cursor.

Decimal point in display

If the decimal point is not flashing, you cannot make an entry.

If the decimal point is flashing, you can make an entry.

On/off

Cursor up

Cursor down

Enter

XS3

main switch

channel 1

channel 2

channel 3

Rhein-Nadel Automation GmbH 814.04.2014

VT-BA ESK2002-GB

4.2 Switching on the Control Unit

Switch on the control unit with the mains power switch. The main menu will appear in the display showing the last set-

point set in channel 1 (bowl feeder feed rate).

KANAL l

KANAL 2

CODE

The following displays may also appear depending on the circuit state of the unit.

KANAL l

KANAL 2

CODE

The remote control has been activated but is currently not available on the unit.

(middle priority)

KANAL l

KANAL 2

CODE

The unit has been switched off with the upper left-hand key on the membrane keyboard, all

functions are blocked.

(high priority)

KANAL l

KANAL 2

CODE

The back pressure control sensor has been assigned thus switching off channel 1 (bowl

feeder).(low priority)

4.3 Main Menu/Setting and Displaying Setpoints for Channel 1, Channel 2 and Channel 3

Display of setpoint or the channel 1

output (vibratory feeder)

Alternatively: STOP, OFF or BACK

PRESSURE

(see above)

KANAL l

KANAL 2

CODE

No entries possible

Enter code to change or make re-

quired settings.

KANAL l

KANAL 2

CODE

Enter code.

See section 4.4 for de-

scription of code.

Setpoint preset for channel 1

(bowl feeder)

KANAL l

KANAL 2

CODE

Entry in %; return to

display mode to store

Setpoint preset for channel 2

(vibrationunit or 1-phase motor)

KANAL l

KANAL 2

CODE

Entry in %; return to

display mode to store

Setpoint preset for channel 3

(vibrationunit or 1-phase motor)

KANAL l

CODE

KANAL 2

Entry in %; return to

display mode to store

From these four basic displays you can page through the main menu using the cursor keys (UP/DOWN). Press the

ENTER key in the main menu to activate a menu item for setting or adjustment. The decimal point will flash once you

have pressed the ENTER key. Changes can now be made using the cursor keys (UP/DOWN). Confirm the entries by

pressing the ENTER key again. The decimal point will no longer flash. You can scroll further through the menu using

the cursor keys. This procedure is also used in the code menus described below.

All displays shown in the following section represent the factory settings. If the actual display on the control unit differs,

the factory setting has been changed in the individual codes for a specific application.

Rhein-Nadel Automation GmbH 914.04.2014

VT-BA ESK2002-GB

4.4 Description of the Individual Codes for Programming the Control Unit

KANAL l

KANAL 2

CODE

Settings for channel 1

The following functions can be set or limited for channel 1 in this submenu:

- vibration amplitude - signal direction of the remote control

- remote control - soft start time and soft stop time

KANAL l

KANAL 2

CODE

Settings for channel 2

The following functions can be set or limited for channel 2 in this submenu:

- vibration amplitude - signal direction of the remote control

- remote control - soft start time and soft stop time

- selection Vibrationhopper or Belthopper with 1-phase motor

KANAL l

KANAL 2

CODE

Settings for channel 3

The following functions can be set or limited for channel 3 in this submenu:

- vibration amplitude - signal direction of the remote control

- remote control - soft start time and soft stop time

- selection Vibrationhopper or Belthopper with 1-phase motor

KANAL l

KANAL 2

CODE

Lock setpoint

This submenu allows the setpoints (vibration amplitude) to be blocked in the main menu. The

setpoints for channel 1, channel 2 and channel 3 can no longer be changed in the main menu.

This prevents the output values being accidentally changed. Changes can only be made using

code C001, code C002 and C012.

KANAL l

KANAL 2

CODE

Setting sensor input 1

Sensor input 1 is activated in this submenu. The following functions can also be set.

- invert input signal direction - time before switch-on

- time before switch-off

KANAL l

KANAL 2

CODE

Setting sensor input 2

Sensor input 2 is activated in this submenu. The following functions can also be set.

- invert input signal direction - time before switch-on

- time before switch-off

KANAL l

KANAL 2

CODE

Selecting the sensor links

The sensors activated with codes C004 and C005 can be linked to each other in this submenu.

KANAL l

KANAL 2

CODE

Setting the cycle control

Set the sensor input to be monitored and how the control will react when there is a fault.

KANAL l

KANAL 2

CODE

Display status

This submenu is used to check the set vibration frequency and the sensor inputs.

KANAL l

KANAL 2

CODE

To call software version

Determinat. 411. 59. 10. 23.11.99

date

version -no.

type

internal no.

type:

59 = ESK 2001

58 = ESG 2001

57 = ESK 2000

56 = ESG 2000

KANAL l

KANAL 2

CODE

Output preset with an external voltage

KANAL l

KANAL 2

CODE

Store parameters

If the values (user parameters) previously set in the different submenus are to be stored, call

this submenu.

KANAL l

KANAL 2

CODE

Block all setting functions

This code blocks all entry options on the control unit. The values can no longer be changed.

The menu can now only be enabled using this code.

KANAL l

KANAL 2

CODE

Reset parameters

This submenu allows the user to reset the control unit to the factory settings. If user parameters

have been stored, the control unit can also be set to these settings.

Rhein-Nadel Automation GmbH 10 14.04.2014

VT-BA ESK2002-GB

4.5 Application-specific Changes to the Factory Settings

4.5.1 Code C001 for Channel 1 (power output 1)

Aim: Setting and limiting the vibration amplitude, the remote control, the soft start time and the soft stop time.

Select code

KANAL l

KANAL 2

CODE

Set code

Code C001

KANAL l

KANAL 2

CODE

Set vibration amplitude

KANAL l

KANAL 2

CODE

0 - 100 %

Limit vibration amplitude(*)

KANAL l

KANAL 2

CODE

50 - 100 % (*)

Remote control

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Remote control signal direction

KANAL l

KANAL 2

CODE

I = start = 24V DC

0 = stop = 24V DC

Soft start time

KANAL l

KANAL 2

CODE

0 - 5 sec.

Soft stop time

KANAL l

KANAL 2

CODE

0 - 5 sec.

Return

KANAL l

KANAL 2

CODE

Store and return to

main menu

* RNA-Feeder with 200 V = 90 %

4.5.2 Code C002 for Channel 2 (power output 2 Vibration hopper or belt hopper)

Aim: Setting and limiting the vibration amplitude, the remote control, the soft start time and the soft stop time.

Select code

KANAL l

KANAL 2

CODE

Set code

Code C002

KANAL l

KANAL 2

CODE

Set vibration amplitude

Only in adjustable mode

KANAL l

KANAL 2

CODE

0 - 100 %

Limit vibration amplitude(*)

Only in adjustable mode

KANAL l

KANAL 2

CODE

50 - 100 % (*)

Remote control

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Delayed switching off

KANAL l

KANAL 2

CODE

InP = 1 und InT = 1

Remote control signal direction

KANAL l

KANAL 2

CODE

I = start = 24V DC

0 = stop = 24V DC

Soft start time

KANAL l

KANAL 2

CODE

0 - 5 sec.

Soft stop time

KANAL l

KANAL 2

CODE

0 - 5 sec.

Vibration hpper or 1-phase motor

KANAL l

KANAL 2

CODE

0 = Vibration drive

1 = 1 –phase motor

Return

KANAL l

KANAL 2

CODE

Store and return to

main menu

* RNA-Feeder with 200 V = 90 %

Rhein-Nadel Automation GmbH 11 14.04.2014

VT-BA ESK2002-GB

4.5.3 Code C012 for Channel 3 (power output 3, Vibration outlet or belt outlet)

Aim: Setting and limiting the vibration amplitude, the remote control, the soft start time and the soft stop time.

Select code

KANAL l

KANAL 2

CODE

Set code

Code C012

KANAL l

KANAL 2

CODE

Set vibration amplitude

Only in adjustable mode

KANAL l

KANAL 2

CODE

0 - 100 %

Limit vibration amplitude(*)

Only in adjustable mode

KANAL l

KANAL 2

CODE

50 - 100 % (*)

Remote control

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Delayed switching off

KANAL l

KANAL 2

CODE

InP = 1 und InT = 1

Remote control signal direction

KANAL l

KANAL 2

CODE

I = start = 24V DC

0 = stop = 24V DC

Soft start time

KANAL l

KANAL 2

CODE

0 - 5 sec.

Soft stop time

KANAL l

KANAL 2

CODE

0 - 5 sec.

Vibration hopper or 1-phase motor

KANAL l

KANAL 2

CODE

0 = Vibration drive

1 = 1 –phase motor

Return

KANAL l

KANAL 2

CODE

Store and return to

main menu

* RNA-Feeder with 200 V = 90 %

4.5.4 Code C003 Lock Setpoint

Aim: Blocking the setpoints in the main menu. The values can no longer be changed directly. Changes can only be

made using code C001, code C002 and code C012.

Select code

KANAL l

KANAL 2

CODE

Set code

Code C003

KANAL l

KANAL 2

CODE

Setpoint (oscillation amplitude)

KANAL l

KANAL 2

CODE

1 = can be set

0 = entry blocked

Return

KANAL l

KANAL 2

CODE

Store and return to

main menu

4.5.5 Code C004 Sensor Input 1 and Code C005 Sensor Input 2

Aim: Activating and setting the sensor inputs

Select code

KANAL l

KANAL 2

CODE

Set code

Code C004

KANAL l

KANAL 2

CODE

Sensor 1 input

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Invert input signal direction

KANAL l

KANAL 2

CODE

I = start = 24V DC

0 = stop = 24V DC

Sensor state delay

FREE, time before switch on.

KANAL l

KANAL 2

CODE

0 -60 sec.

Sensor state delay

ASSIGNED, time before switch-off.

KANAL l

KANAL 2

CODE

0 - 60 sec.

Return

KANAL l

KANAL 2

CODE

Store and return to

main menu

Code C005 is used for sensor input 2 in the same way.

Rhein-Nadel Automation GmbH 12 14.04.2014

VT-BA ESK2002-GB

4.5.6 Code C006 Sensor Links

Aim: Linking two previously activated sensor inputs.

Select code

KANAL l

KANAL 2

CODE

set code

Code C006

KANAL l

KANAL 2

CODE

Only one of the eight sensor links can be set active.

And (und) link with blow-off of the out-

let tracks

KANAL l

KANAL 2

CODE

I = active

0 = inactive

And (und) link without blow-off of the

outlet tracks

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Or link

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Min/Max link

KANAL l

KANAL 2

CODE

I = active

0 = inactive

And / S2 link

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Level control with external control

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Level control Signal lamp

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Single link

KANAL l

KANAL 2

CODE

I = active

0 = inactive

With the following two sensor links, it is possible to set the priority of both chanels

Channel 2 follows chanal 1

KANAL l

KANAL 2

CODE

I = activ

0 = inactiv (both channels

work independent)

or !

Channel 1 follows channel2

KANAL l

KANAL 2

CODE

I = activ

0 = inactiv (both channels

work independent)

Return

KANAL l

KANAL 2

CODE

Store and return to the

main menue

A brief description of the individual links

And (UND) link of the two sensor inputs with blow-off of the outlet tracks.

Example:

Application:

Two-track feeding system with back pressure control

Solution:

Track 1 (Sensor 1) full = blow-off track 1 (Relais K1)

Track 2 still free

Track 2 (Sensor 2) full = blow-off track 2 (Relais K2)

Track 1 still free

Track 1 + Track 2 full = bowl feeder (channel 1) stop blow-off air after approx. 4 sec

And (UND) link of the two sensor inputs without blow-off of the outlet track.

The bowl feeder (channel 1) switches off, if both sensors are assigned. The air for sorting may be

de-energizes later (4 sec) through relay K2.

And / S2 link

The bowl feeder (channel 1) switches off, when both sensors are assigned. When the sensor 2 is free,

the system is switched on. The air for sorting can be switched off later through relay K2.

Or/ link of both sensorinputs

The bowl feeder (channel 1) switches off, when one of the sensors is assigned. The air for sorting can

be switched off later (4sec) through relay K2.

Rhein-Nadel Automation GmbH 13 14.04.2014

VT-BA ESK2002-GB

Min/Max Connection of both sensor inputs

The bowl feeder switches of, when both sensor inputs are assigned. When both sensors are free, the

bowl feeder (channel 1) switches on. Relay K1 switches with switching off of the bowl feeder. Relay K2

switches 4 sec later (Blow-off switching)

Level control for the hopper with external control

Sensor 2 switches relay K1 according to the entered delay time (C005). When the sensor 1 is darkened,

relay K1 releases (looking of the hopper).

Application:

Sensor 1 = back pressure control

Sensor 2 = level control

Relay K1 = hopper control

Level control for signal lamp

Sensor 2 switches relay K1 according to the entered delay time (C005), without consideration of sensor

1 (Back pressure control).

Application:

Sensor 2 will be used as a level control (e.g. LC-N 24V DC). Relais K1 switches with a

signal lamp: Bowl feeder empty.

4.5.7 Code C008 Cycle control

Aim: Control sensors 1 (back pressure control) and/or 2.

The links "AND; SOL" must not be activated in code C006 when the cycle control system is activated.

Select code

KANAL l

KANAL 2

CODE

Set code

Code C008

KANAL l

KANAL 2

CODE

Sensor input 1 is monitored

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Sensor input 2 is monitored

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Monitoring dependent on

Channel 1

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Monitoring dependent on

channel 2

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Time until alarm signal

KANAL l

KANAL 2

CODE

3 -240 sec.

Switch-off of channel 1 and

Channel 2

KANAL l

KANAL 2

CODE

I = see below

0 = see below

Switch (Relay K1)

KANAL l

KANAL 2

CODE

I = warning at relay K1

0 = warning at relay K2

Return

KANAL l

KANAL 2

CODE

Store and return to

main menu

The cycle monitoring system monitors the FREE sensor state. The time (A 180) is used to set the

maximum time which a sensor may be free before an alarm signal is issued.

Relay K2 is picked up when an alarm signal is issued. The fault is cleared by covering the sensor.

If OUT = 1 and a fault occurs, the bowl feeder will also be switched off in addition to relay K2 (indicator

lamp: fault) and an ERROR message will appear in the display. The fault is cleared with the cursor key

at the bottom right.

If OUT = 0 and a fault occurs, only relay K2 is energized (indicator lamp: fault). The fault is cleared

automatically when sensor 1 is assigned.

If A.I. = 1 Relay K1 is checked on breakdown (switch changed over from relay K2 to K1)

4.5.8 Code C009 Display Status

Rhein-Nadel Automation GmbH 14 14.04.2014

VT-BA ESK2002-GB

Aim: Checking the set vibration frequency and the sensor inputs.

Select code

KANAL l

KANAL 2

CODE

Set code

Code C009

KANAL l

KANAL 2

CODE

Remote control signal

Channel 1

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Vibration frequency channel 1

KANAL l

KANAL 2

CODE

I = 50 Hz

0 = 100 Hz

Remote control signal

Channel 2

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Vibration frequency channel 2

KANAL l

KANAL 2

CODE

I = 50 Hz

0 = 100 Hz

Remote control signal

Channel 3

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Vibration frequency channel 3

KANAL l

KANAL 2

CODE

I = 50 Hz

0 = 100 Hz

Signal at sensor input 1

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Signal at sensor input 2

KANAL l

KANAL 2

CODE

I = active

0 = inactive

Return

KANAL l

KANAL 2

CODE

Store and return to

main menu

With the menu item HA = half-wave you can check whether the operating mode (100 –50Hz) has

been correctly selected.

4.5.9 Code C200 Blocking all Setting Functions

Aim: The user can no longer (accidentally) change the set values.

Select code

KANAL l

KANAL 2

CODE

Set code

Code C200

KANAL l

KANAL 2

CODE

Block the setting functions

KANAL l

KANAL 2

CODE

I = enabled

0 = block

End

KANAL l

KANAL 2

CODE

Store and return to

main menu

Now only code C200 will be accepted!!!

It is possible to change the setpoint for chanel 1 and 2 and 3 in the main menu (see 4.3)

4.5.10 Code C143 Store Parameters

Aim: Storing user parameters.

Select code

KANAL l

KANAL 2

CODE

Select code

Code C143

KANAL l

KANAL 2

CODE

Store

KANAL l

KANAL 2

CODE

KANAL l

KANAL 2

CODE

Return

KANAL l

KANAL 2

CODE

Store and return to

main menu

Once PUSH has been confirmed with ENTER, the selected parameters will be stored separately

by pressing a cursor key.

4.5.11 Code C210 Reset Parameters

Rhein-Nadel Automation GmbH 15 14.04.2014

VT-BA ESK2002-GB

Aim: Resetting to factory settings or restoring the stored user parameters.

Select code

KANAL l

KANAL 2

CODE

Set code

Code C210

KANAL l

KANAL 2

CODE

Factory setting

KANAL l

KANAL 2

CODE

KANAL l

KANAL 2

CODE

User parameters

KANAL l

KANAL 2

CODE

KANAL l

KANAL 2

CODE

End

KANAL l

KANAL 2

CODE

Store and return to

main menu

FAC Selection and confirmation of FAC. applies the factory settings.

US.PA. Selection and confirmation of US.PA restores the user parameters previously stored

under C143.

5 Scale Drawing

KANAL1

KANAL2

CODE

I/ 0 F

M10A

10A/250V

M 4A

4A/250V

KAPPE

204

213

166

153

156

139

180

255

14 14

295

Ø 9,0

Rhein-Nadel Automation GmbH 16 14.04.2014

VT-BA ESK2002-GB

Connecting Diagram

Rhein-Nadel Automation GmbH 17 14.04.2014

VT-BA ESK2002-GB

Rhein-Nadel Automation GmbH

Reichsweg 19/23 D - 52068 Aachen

Tel (+49) 0241/5109-159 Fax +(49) 0241/5109-219

Internet www.rna.de Email [email protected]

Rhein-Nadel Automation GmbH

Zweigbetrieb Lüdenscheid

Nottebohmstraße 57 D - 58511 Lüdenscheid

Tel (+49) 02351/41744 Fax (+49) 02351/45582

Email [email protected]

Rhein-Nadel Automation GmbH

Zweigbetrieb Ergolding

Ahornstraße 122 D - 84030 Ergolding

Tel (+49) 0871/72812 Fax (+49) 0871/77131

Email [email protected]

PSA Zuführtechnik GmbH

Dr. Jakob-Berlinger-Weg 1 D –74523 Schwäbisch Hall

Tel +49 (0)791/9460098-0 Fax +49 (0)791/9460098-29

Email [email protected]

HSH Handling Systems AG

Wangenstr. 96 CH - 3360 Herzogenbuchsee

Tel +(41) 062/95610-00 Fax (+41) 062/95610-10

Internet www.handling-systems.ch Email info@handling-systems.ch

RNA AUTOMATION LTD

Hayward Industrial Park

Tameside Drive, Castle Bromwich

GB - Birmingham, B 35 7 AG

Tel (+44) 0121/749-2566 Fax (+44) 0121/749-6217

Internet www.rna-uk.com Email rna@rna-uk.com

Vibrant S.A.

Pol. Ind. Famades C/Energia Parc 27

E - 08940 Cornella Llobregat (Barcelona)

Tel (+34) 093/377-7300 Fax (+34) 093/377-6752

Internet www.vibrant-rna.com Email [email protected]

Unit C Castle Bromwich Business Park, Tameside Drive

Birmingham B35 7AG, United Kingdom

Tel +44 (0)121 749 2566 Fax +44 (0)121 749 6217

Web: www.rnaautomation.com

Email: [email protected]

Other manuals for ESK 2002

This manual suits for next models

Table of contents

Other RNA Control Unit manuals

RNA

RNA ESR 2500 User manual

RNA

RNA ESM 906 User manual

RNA

RNA EBC 3000 User manual

RNA

RNA ESG 1000 User manual

RNA

RNA ESK 2002 Installation manual

RNA

RNA ESG 2000 User manual

Popular Control Unit manuals by other brands

Triax

Triax CCAV 300 Assembly instruction

Woodward

Woodward Flo-Tech 8400-511 Hardware manual

RTimes

RTimes RTSS-X502N user manual

Otto Bock

Otto Bock 6A42 Instructions for use

Siemens

Siemens SINUMERIK 808D Diagnostic manual

UAB Enilit

UAB Enilit Enilit RTU user manual

Emerson

Emerson Fisher OSE instruction manual

Lenze

Lenze E94AZHN0026 Mounting instructions

Rohde

Rohde ST 310 instruction manual

Grinnell

Grinnell F470 manual

schmersal

schmersal SRB303SQP-SS operating instructions

Genie

Genie 38647R.S Replacement instructions

Pentair

Pentair FLECK 3150 NXT Installer manual

ELCODIS

ELCODIS 710-0004-01 manual

ABB

ABB MicroFlex e150 user manual

Motorola

Motorola M68EM05D32 user manual

SIGMA TEK

SIGMA TEK HZS 7321 Technical manual

Behringer

Behringer CP35 Attenuators quick start guide

RNA ESK 2002 User manual

Popular Control Unit manuals by other brands
