Manual Runner Handbike (Electro)
Udinumber 870261760Run97000005321SF
Features Runner Handbike
• Both junior and senior.
• Including adapter (under the wheelchair).
• For folding wheelchair: adapter detachable.
• Stainless steel frame.
• Height and length adjustable.
• 20" aluminium rim.
• 7 Gears.
• 2nd brake/Parking brake.
• Coaster brake.
• Ergonomic handles. • Price corrector.
• Very easy to connect (roller system).
• Wedge angle and center of gravity of the wheelchair remain
adjustable.
• Bike stand after disconnection
• Lighting
• CE marking.
• Weight: ± 8.5 kg, titanium ± 7.5 kg.
• Warranty: parts 1 year / frame 5 years.
• Delivery time: 5 working days after receipt of the wheelchair at
Roam.
Installation directly by appointment is also possible.
ROAM Special Cycles B.V.
Buitenkamp 20
5321KB Hedel
Tel.nr. 073-5997042
Internet: www.roam.nl
1 January 2023
2
Introduction
Roam is a manufacturer of unique and special "bicycles” whereby independency of users is
priority number one.
The Roam Runner Handbike is available in both junior as well as a senior version and can
easily be connected to any wheelchair.
Roam was founded in 1987 by Theo de Rouw, who started doing business - on his own
initiative - in the evenings. His goal was: independency of disabled people as much as
possible.
As a result of this objective the business grew into a full-time job in less than 3 years.
With the same objective in mind, the company was converted into a V.O.F. in 1997 and
wife Johanna de Rouw became one of the partners. Later on Johan de Rouw joined the
company.
Over the years until now independency of disabled people has still remained the most
important keyword for Roam.
The management director is Johan de Rouw and the company has 12 staff members.
The company is NEN-EN-ISO 9001:2015 and NEN-EN-ISO 13485 certified and works
according to the National Care Standards. These certificates ensure that Roam delivers
quality - from development and design to delivery and aftercare- .
Roam is a custom friendly company. Her product range is subject to continuous
improvement in relation to regularly compliance and user’s wishes and needs.
In 2003, Roam was proclaimed: the most creative entrepreneur of the year by the
Chamber of Commerce (the certificate was awarded by the Chamber of Commerce). The
Roam approach now enjoys international prestige.
3
Welcome to the Roam-team
Thank you for purchasing our product, the Runner Handbike.
With great care, the Roam team has made your Runner Handbike roadworthy. The user
manual has already been received and describes how the Runner hand bike should be
handled. Please note that the complete manual should be read. Roam is not responsible
for incorrect use and ignoring the commandments / warnings. In case of incorrect or
improper use of the hand bike or manual Roam cannot be held responsible. In other words,
as a user you must follow the commandment described in the Manual.
The adventure of freedom and a step towards independence can begin with the Runner
Handbike and that means: first getting acquainted with this beautiful product; follow the
user manual. Take your time to experience!
The Runner Handbike is made to serve you as well as possible and we hope we enjoy your
bike. Do not hesitate to make your findings known to your dealer or the manufacturer.
We wish you a lot of fun with the Roam Runner Handbike.
ROAM Special Cycles B.V.
Buitenkamp 20
5321KB Hedel
Tel.nr. 073-5997042
Internet: www.roam.nl
4
Index
Introduction 2
Welcome to the Roam Team 3
Table of Contents 4
Control and Delivery 5
Commandments and warnings 6/7/8/9
Sharp adjustment of the wheelchair 9
Connecting and disconnecting the Handbike 9
Brakes 10
Gears 10
Maintenance and your professional 11
Maintenance 11
Tools intended for dealer/Roam Specialist 11
Checklist 12
Tightening moments for dealer/Roam Specialist 12
Warranty 13
EU Declaration of conformity 14
5
Delivery check
Check that the delivery of the hand bike matches the packing slip. If transport damage is
detected upon delivery, please inform your dealer. Roam trusts that the Runner Handbike
meets your expectations and wishes you a lot of success and above all a lot of cycling
pleasure.
Important
Upon delivery of your Runner Handbike, all parts described on the attached CD are tailor
made to your wishes. Certain parts need to be readjusted after some time. The best thing
to do is making an appointment with your dealer.
6
Commandments and warnings
Always observe the commandments and warnings below!
General
1. When purchasing the Runner Handbike, the dealer must provide the correct
information to ROAM Special Cycles BV about the use and application.
2. Before you start cycling, always check whether the adapter under the wheelchair is
properly secured. In the case of detachable adapters, the star buttons or quick-
release fasteners must be checked to see if they are properly secured.
3. Roam cannot be held liable for defects, damage, unsafe actions or situations,
accidents or incidents due to incorrect use, incorrect information or incorrect
maintenance or repair.
4. Right-angled and sharp turns should be taken at an appropriate speed to avoid the
risk of tipping over.
No changes
1. No changes may be made to the Runner. Roam is not responsible for damage
caused to the Runner by making changes.
2. The speed of our products may not be increased or changed in any way. When
changing our product, the manufacturer is in no way responsible or liable.
User
1. The user of the Runner Handbike should be in good mental health and not be
physically restricted in a sitting position.
2. The driver must be able to operate the Runner Handbike properly. The driver's
hearing and vision must be suitable for the use of the Runner Handbike. The user
should read and understand the manual carefully.
3. If the user is so limited that he/she has vision/hearing problems and/or cannot read
and understand the manual, parents/guardians/supervisors are responsible for the
application of the manual and the use of the Handbike by the end user.
4. The user is responsible and liable for proper use, as stated in this manual.
5. It is forbidden to use the Runner Handbike under the influence of alcohol / drugs or
mind-influencing medication.
6. When biking, make sure you are well equipped (mobile phone).
7. Include your dealer's number in your mobile phone. Provide good further equipment
such as: repair-set tires, small first aid kit, and water bottle with drinking water,
some ransom and identity card.
8. Provide good further equipment such as: repair kit tires, small first aid kit, and
water bottle with drinking water, some ransom and the identity card.
9. When using the Runner Handbike in the dark/dark/twilight or bad weather
conditions, lighting should be provided.
10. On longer journeys, protect yourself from bad weather conditions in winter or
excessive heat in the summer period.
11. The Runner Handbike is personal. It is forbidden for unauthorized persons to use
the Runner Handbike.
12. Only the owner/user is allowed to use the Runner Handbike.
7
Regulations
1. Adhere to the Bicycle Act which applies in the country.
2. Comply with the Bicycle Act that applies abroad (in the country you live) and adapt
to the circumstances.
3. For more information, please also visit websites concerned.
4. Comply with the laws and regulations of the central government.
Biking
1. A user/owner must be at least 16 years of age or older to be able to independently
drive the above-mentioned powered products because the speed of these products
is more than 10 km per hour.
2. Under the age of 16, the user must be under the supervision of a parent or
guardian when the Handbike Runner is used.
3. The user may use: the sidewalk, the footpath, the cycle path/ moped path and the
roadway. If all road components are present, the user/owner may decide for
himself which road is to be taken.
4. It is forbidden to use the motorway. Follow the traffic rules of the road being used.
On the sidewalk, for example, you can drive a maximum of 6 kilometers per hour.
Electronic devices, such as mobile phones, navigation systems, tablets or music
players, should not be held or used while driving.
5. The same rules apply as when texting, calling or listening to music on the bike. This
refers to the website of the Central Government.
6. Biking with the Runner. Adjust your speed to the conditions that occur. Think of
busy and bad roads, obstacles and roads along water features.
7. Keep your hands on the wheel and don't get distracted.
8. Before shifting gears while driving, the pedals must be kept still.
9. Take obstacles in the road surface (thresholds) at an appropriate speed.
10. The hands should always be held on the handles during biking (with the exception
of shifting gears).
11. Do not put the hands in rotating parts.
12. For good visibility in traffic, a flag is flown.
13. To protect the head, a helmet is worn.
14. For maintenance, settings, adjustments, replacement of parts and / or repairs,
reference is made to the dealer / Roam specialist.
15. The Roam specialist as well as the dealer is obliged to follow the manual and to
apply the recommended tools.
16. For roads where extra attention is required such as roads: with obstacles, along
waterways, equipped with elevations, railway crossings, tram rails or pedestrian
crossing and or driving along busy roads etc., must be driven at walking pace.
17. Driving should always be done at an appropriate speed, depending on the
circumstances.
8
Slopes and brakes
1. In a number of cases, if this manual is not followed correctly, a dangerous situation
may arise for the user and passengers of the Runner with regard to taking slopes.
2. For slopes of 5% or more, the brakes are not calculated. On slopes that are very
long or steep, the brakes can run hot and the engine can become overloaded so
that defects occur.
3. The preceding point regarding slopes also applies to descents. Note that when
descending a slope, the speed increases.
4. Note: On roads where oil, mud, sand or leaves are on the road surface, the braking
distance may be longer. This also applies to uneven road surfaces (potholes/holes)
and winter conditions.
Curves/Angles
Right-angled and sharp turns should be taken at an appropriate speed (depending on the
circumstances: road and physical capabilities) to avoid the risk of tipping over.
Battery
1. Store the battery at a temperature below 25°C The battery must be at least 30%
and a maximum of 80% charged.
2. The battery must be charged in the fireproof case, which is purchased from the
Runner.
3. The battery, when not in use, is stored and stored in the fireproof case.
4. Make sure that the battery is not discharged below 30% when in use.
5. Use only original chargers (no fast chargers).
6. Keep an eye on the battery while charging; never charge at night due to fire risk in
case of overheating. If a cell of the lithium battery catches fire, the other cells also
catch fire.
7. A lithium battery is extremely difficult to extinguish. In case of fire, call the alarm
number immediately.
8. A faulty battery can leak and release fumes. Sparks can also occur or the battery
can smell strong and become extremely hot. In one of these cases, disconnect the
battery.
9. If a device with a lithium ion battery leaks, gets excessively hot, smells strong,
produces smoke or produces sparks, it is wrong. If you notice any of the signals
mentioned, it is important that you disconnect the device from the charger and
move it outside.
10. Make sure you do not place the device near flammable materials and then call the
alarm number.
11. Replace damaged chargers.
12. Do not store batteries in direct sunlight.
13. When purchasing the Runner, the dealer must provide the correct information to
ROAM Special Cycles BV about the use and application.
Environment
A defective, leaking, fallen, or deformed battery battery should be replaced immediately.
The old battery must be returned to the dealer or to the environmental street of the
municipality.
9
Sharp adjustment of the wheelchair
Warning: Pay attention when adjusting the wheelchair sharply. If your
wheelchair is sharply adjusted, the Runner Handbike does not have as much
wheel pressure and the braking distance is many times longer. The user must
take this into account!
Handbike
Connecting
Connecting the Runner Handbike under your wheelchair is very easy. First of all, you put
the wheelchair on the brakes; then you close the lever of the connector on the Runner
Handbike (down) and now slide the Runner Handbike with the bearing holder as far as
possible into the adapter of your wheelchair. Now you need to open the lever of the
connector on the Runner Handbike (up), so that the bracket falls over the tab of the
adapter, then close the trade again. Now the Runner Handbike is docked. Put the
wheelchair off the brake and you can start driving. If there are any ambiguities for you,
we refer you to the videos on our website: www.:Roam.nl
Disconnecting
Disconnecting the Runner Handbike is also very easy. First put the wheelchair on the
brake, and then you have to stop the Runner Handbike, preferably grip the handlebars,
and then open the connector with your other hand and hold up the bracket of the clamp.
Now you can close the lever of the connector again so that the bracket is on the tab. Then
slowly slide the Runner Handbike out of the adapter and put it away. If there are any
ambiguities for you, we refer you to the videos on our website: www.:Roam.nl
10
Brakes
It is vital that you fully understand the operation of your Runner Hand bike's braking
system. If the braking system is not used correctly, this may result in you losing control of
the steering wheel or may lead to serious consequences (accident, serious injuries). The
Runner Hand bike is equipped with a disc brake. If, in the opinion of the user, the brake
does not function properly, the dealer should be contacted immediately. The dealer must
resolve any defects. It is forbidden to use the Runner Handbike when the braking system
does not work in any form.
Note: The disc brake can get hot; contact the dealer immediately if there is any doubt as
to whether the brake is not working correctly. Do not come into contact with the disc
brake, construction or housing. Before biking, always check your brake.
Coaster brakes
The drive is done by turning the pedals forward. The brake is activated by turning the
pedals in the opposite direction: so turn back! Pay attention to slopes: if these are more
than 5%, the brake can run hot and no longer brake! In this situation, you must keep the
speed limited (no more than 20 km per hour).
Gears
The bike comes with 7 Shimano gear. The gears can only be used while driving. For
shifting while driving, one should keep the pedals still Shift with one gear at a time and
reduce during the shifting force you apply to the pedals. If you force-turn the pedals
around, trying to force the shift lever to operate, there is a chance that you will slide off
the pedals, the bike will overturn and you will be seriously injured.
11
Maintenance and your professional
Vital parts such as cables, spokes and brakes get a chance to "set" themselves in the start-
up period. However, in order to be able to continue driving pleasantly and safely, a major
annual turn is necessary. Your professional not only has the tools and experience to set
and lubricate hidden rotating parts such as headset and hubs, but his hands, eyes and ears
are also able to detect small imperfections in time. Before winter sets in or before a holiday
trek, we advise you to have the bike checked. Proper maintenance is also extremely
important with regard to the warranty. Make an appointment with your dealer before the
service will be executed.
Maintenance Runner Handbike
1. Clean the Runner Handbike with a dry cloth.
2. In case of serious dirt, clean the Runner Hand bike with a soft damp sponge and dry
it.
3. Do not spray the Runner Handbike with a high pressure washer.
4. Do not apply chemical cleaning agents (chlorine/bleach/soda) when cleaning the
Runner Handbike.
5. Lubricate aluminium and chrome parts with an acid-free petroleum jelly or special
grease (ask your dealer).
6. Store the Runner Handbike dry.
Tools intended for dealer/Roam Specialist
For the modest work, a simple set of tools is sufficient. You are already well on your way
with a set of wrenches or socket wrenches (8 to 15), Allen wrenches, screwdriver,
combination pliers, a can of bicycle oil and of course a tire repair kit. When replacing, make
sure that original or equivalent parts are assembled for better operation and because in
some cases the warranty will otherwise expire. Ask your Roam dealer for advice!
12
Checklist
Check regularly:
1. Are the brakes working properly?
2. Are the brake pads not worn out?
3. Is stem not higher than the safety marking indicates?
4. Are all the nuts and bolts safe?
5. Is the tread of the tires not worn out and do they not have weak spots or bumps?
Are the tires on pressure (tire pressure is on the side of the tire)?
6. Is the stem and steering rod tightly attached?
7. Is the lighting working properly and are the batteries of the rear light not due for
replacement?
8. Is the side reflection of the tires clean and therefore clearly visible in the dark? Are
the handles still secure?
9. Are the reflectors of the pedals free of dirt and are the pedals still sufficiently stiff?
10. Is the quick release working properly? (there must be no play on it, nor must the
quick release be loose).
11. If in doubt, contact your dealer.
Tightening moments intended for dealer/Roam Specialist
Below you will find an overview of recommended tightening moments. We recommend that
you tighten the listed parts with a torque wrench based on the values mentioned.
Tightening the parts harder can lead to damage to your bike. It is best to ask your Roam
dealer for help and advice for this action.
Steering plug bolt 12-15 Nm
Expander bolt with angled bobbin 20-23 Nm
Hub axle nuts front wheels 20-27 Nm
13
Guarantee
Roam gives a 5-year warranty against defects in material and finish on the frame. All parts
and components manufactured and marketed by Roam have a 1-year warranty. This
warranty does not include: tire and parts wear. Roam will repair or replace parts where
necessary, provided that an official Roam dealer has agreed to return within the
established warranty period. Roam does not guarantee parts that are damaged as a result
of incorrect assembly and / or repair by the relevant owner, neglect, accident or incorrect
use.
Contact
ROAM Special Cycles B.V.
Buitenkamp 20
5321KB Hedel
Tel.nr. 073-5997042
Internet: www.roam.nl
14
Gebruiksaanwijzing
Microprocessor controlled
4-stages
Smart Battery Charger
Gebruikershandleiding
Model: EPL100-42
Leest u deze handleiding goed door en volg de instructies alvorens de oplader te gebruiken.
Land van herkomst: China
In het kort: De oplader is een slimme lader met microprocessor die in 4 stappen de accu laadt.
De oplader is voorzien van een 4 kleuren LED die de status van de lader aangeeft.
De oplader is voorzien van beveiliging die de accu beschermt tegen over-laden. Het is veilig om
de accu aan te lader te houden, deze zal,zodra vol, vanzelf stoppen met laden.
Het laden in 4 stappen:
Stap 1:
Wanneer de lader merkt dat de accu zeer leeg is zal de lader met een laag amperage laden. Dit zal de levensduur
van de accu beschermen.
LEDs:1 aan,2-4 uit )
Stap 2: Bulking met hoog amperage tot de accu voor 80% gevuld is.
(LEDs:1-4 knipperen achtereenvolgend)
15
Stap 3: Constante spanning. De uitgaande spanning is gelimiteerd tot 4.2V/cell, terwijl de
huidige spanning afbouwt tot de accu vol zit, dit voorkomt oververhitting. (LEDs:1-3 aan,4
knipperen)
Stap 4: Afronding. Op dit moment is de accu volledig geladen en zal de lader stoppen met
stroom leveren. Hierdoor kan de lader ook aan de accu blijven en hoeft deze niet verwijderd te
worden. (LEDs 1-4 Aan)
Belangrijke waarschuwing:
Zorg vóór het laden dat de lader en accu hetzelfde voltage hebben.
Specificaties:
Input: 100-240VAC@50/60Hz 0.5rms
Output: 2A
Maximaal voltage: 42V
Cut-Off current: 200mA
Oplaadmodus: Volledig automatisch in 4 standen
Geschikt accu type: 37V
Oplaadtijd in uren: 2 –10
Veiligheid : EN60950-1 EN60335
EMC: EN55022
Goedkeuring: UL GS CB CE FCC SAA C-TICK RoHS
16
Probleemoplossing:
Hoe te gebruiken:
1. Stop de lader in het stopcontact, alle lampjes zullen knipperen en daarna zal deze blijven
branden.
2. Verbind de oplader aan de accu via de daarvoor bestemde laadplug.
3. Als alle 4 ledjes groen branden, dan is de accu vol, en kan de lader verwijderd worden.
WAARSCHUWING:
1. Deze lader is geschikt voor het opladen van Lithium ion/LiFePO4 accu’s. Gebruik deze niet voor
een ander doeleinde.
2. Daar accu’s explosieve gassen bevatten is het belangrijk goed te ventileren en deze weg te
houden van elke bron van vlammen of vonken.
3. Ter voorkoming van risico of schade aan de plug en de kabel, svp bij het verwijderen dit doen
bij de plug, en niet aan de kabel.
4. Gebruik van een onjuist verlengsnoer kan leiden tot brand of een elektrische schok.
5. Gebruik svp de lader niet als je schade ziet aan de lader of de kabel.
Probleem
Foutindicatie
Mogelijke oorzaak
Oplossing
Oplader
werkt niet?
Er branden geen
LED’s op de
oplader
- Geen voeding
- Controleer netstroom en/of
stroompunt op spanning
De oplader
laadt de accu
niet op
De LED
indicatoren
knipperen
tegelijkertijd
- Kortsluiting
tussen accu en
oplader
- Plus/Min polen
op de accu
komen niet
overeen met de
oplader
- Controleer of er geen kortsluiting
ontstaat of is ontstaan.
- Controleer of de plus/min polen
overeenkomen met de plus/min van
de accu
Accu laadt
niet op.
4 ledjes lichten
niet op.
-Accu geen spanning
Accu is defect, vervang accu
17
6. Probeer niet zelf de lader uit elkaar te halen. Indien deze onderhoud nodig heeft breng dit naar
een gecertificeerd bedrijf. Het zelf loshalen kan elektrische schokken veroorzaken.
7. Om elektrische schokken te voorkomen, haal eerst de stekker uit het stopcontact voor u de
lader schoonmaakt of onderhoud pleegt op de lader.
18
Product-Specificatie
06/2018
Product TFT LCD Display
Type: APT TFT500C
Verkorte benaming: 500C
19
1.
Product Naam
TFT LCD display
Model : APT TFT500C
2.
Leveranciers
Fietsunie B.V.
Email : info@fietsunie.nl
3.
Elektrische Parameters
2.2inch IPS scherm
24V/36V/48V accu voeding
Nominaal vermogen : 40mA
Max stroomsterkte : 100mA
Gebruikstemperatuur : -20～70℃, Opslag temperatuur : -30～80℃
4.
Dimensies & Materiaal
Producthoes is ABS, het transparante venster is gemaakt van sterk Acryl.
Afmetingen: L 79mm*B40mm*H18mm
5.
Eigenschappen
Geschikt voor lage temperaturen，Max. -20℃.
Hoog-contrast 2.2inch IPS kleuren matrix scherm.
Ergonomisch makkelijk te gebruiken bedieningsknoppen
20
Snelheids display : Gem.Snelheid, Max-Snelheid, Snelheid(Real-time).
Kilometer / Mile : Hier kunt u kiezen tussen kilometers of mijlen.
Slimme accu indicatie : Biedt een betrouwbare accu indicatie.
9-level Assist : 3-level/5-level/9-level optional.
Rit-eigenschappen : Odometer/Rit afstand/Rijtijd
Maximale snelheidsindicator
Fout code indicatie
6.
TFT scherm overzicht
7.
Functionele beschrijving
Stand -
UP
POWER
MODUS
Table of contents
