Robe Robin BMFL Blade User manual

1
Version 1.2

2
Table of contents
1. Safety instructions ......................................................................................................... 3
2. Operating determination................................................................................................ 4
3. Fixture exterior view ...................................................................................................... 5
4. Installation....................................................................................................................... 6
4.1 Connection to the mains ............................................................................................ 6
4.2 Installing the lamp ...................................................................................................... 7
4.3 Lamp adjustment ....................................................................................................... 7
4.4 Replacing colour lters............................................................................................... 8
4.5 Replacing rotating gobos .......................................................................................... 9
4.6 Installing handle for the Follow Spot Mode ............................................................. 10
4.7 Replacing light frost ................................................................................................. 10
4.8 Rigging the xture .................................................................................................... 12
4.9 DMX-512 connection................................................................................................ 14
4.10 Ethernet connection ............................................................................................... 15
5. Remotely controllable functions................................................................................. 17
6. Control menu map........................................................................................................ 19
7. Control menu ............................................................................................................... 22
7.1 Tab " Address" ......................................................................................................... 23
7.2 Tab "Information"...................................................................................................... 24
7.3 Tab "Personality"...................................................................................................... 26
7.4 Tab "Manual Control" ............................................................................................... 28
7.5 Tab "Stand-alone" ................................................................................................... 28
7.6 Tab "Service"............................................................................................................ 29
7.7 Icon "Lamp menu".................................................................................................... 32
8. RDM ............................................................................................................................... 33
9. Wireless DMX operation .............................................................................................. 33
10. Error and information messages .............................................................................. 35
11. Technical Specications............................................................................................ 39
12. Maintenance and cleaning......................................................................................... 44
13. Change log.................................................................................................................. 44
Robin BMFL Blade

3
CAUTION!
Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOU INITIAL START - UP!
1. Safety instructions
Every person involved with installation and maintenance of this device have to:
- be qualied
- follow the instructions of this manual
CAUTION!
Be careful with your operations.
With a high voltage you can suffer
a dangerous electric shock when touching the wires!
This device has left our premises in absolutely perfect condition. In order to maintain this condition and to en-
sure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes
written in this manual.
Important:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this
manual or any unauthorized modication to the device.
Please consider that damages caused by manual modications to the device are not subject to warranty.
During the operation the housing becomes hot). Allow the xture to cool approximately 20 minutes prior to
manipulate with it.
Make sure that the available voltage is not higher than stated on the rear panel.
WARNING! This unit does not contain an ON/OFF switch. Always disconnect power input cable
to completely remove power from unit when not in use or before cleaning or servicing the xture.
Make sure that the power-cord is never crimped or damaged by sharp edges. Check the device and the power-
cord from time to time.
Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle the power-
cord by the plug. Never pull out the plug by tugging the power cord.
This device falls under protection class I. Therefore it is essential to connect the yellow/green conductor to
earth.
The electric connection, repairs and servicing must be carried out by a qualied employee.
Do not connect this device to a dimmer pack.
Do not switch the xture on and off in short intervals as this would reduce the lamp’s life.
During the initial start-up some smoke or smell may arise. This is a normal process and does not necessarily
mean that the device is defective.
Do not touch the device’s housing bare hands during its operation (housing becomes hot)!
For replacement use lamps and fuses of same type and rating only.
CAUTION ! EYE DAMAGES !
Avoid looking directly into the light source
(meant especially for epileptics) !

4
2. Operating determination
This device is a moving head for creating decorative effects and was designed for indoor use only.
This device is for professional use only. It is not for household use.
If the device has been exposed to drastic temperature uctuation (e.g. after transportation), do not switch it on
immediately. The arising condensation water might damage your device. Leave the device switched off until
it has reached room temperature.
Before switching the xture OFF, turn the lamp OFF and allow the xture to cool for a while.
Never run the device without lamp!
Do not shake the device. Avoid brute force when installing or operating the device.
Never lift the xture by holding it at the projector-head, as the mechanics may be damaged. Always hold the
xture at the transport handles.
When choosing the installation-spot, please make sure that the device is not exposed to extreme heat, moisture
or dust. There should not be any cables lying around. You endanger your own and the safety of others!
The minimum distance between light output and the illuminated surface must be more than 8 meters.
Make sure that the area below the installation place is blocked when rigging, derigging or servicing the x-
ture.
Always x the xture with an appropriate safety rope. Fix the safety rope at the correct holes only.
Only operate the xture after having checked that the housing is rmly closed and all screws are tightly fas-
tened.
The lamp must never be ignited if the objective-lens or any housing-cover is open, as discharge lamps may
explode and emit a high ultraviolet radiation, which may cause burns.
The maximum ambient temperature 45°C must never be exceeded.
CAUTION!
The lens has to be replaced when it is obviously damaged,
so that its function is impaired, e. g. due to cracks or deep scratches!
Operate the device only after having familiarized with its functions. Do not permit operation by persons not
qualied for operating the device. Most damages are the result of unprofessional operation!
CAUTION!
The lamp shall be changed if it has become damaged or thermally deformed
Please use the original packaging if the device is to be transported.
Please consider that unauthorized modications on the device are forbidden due to safety reasons!
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, burns due to ultraviolet radiation, lamp explosion, crash etc.
NOTE!
If the lamp is off (and xture is connected to mains), both colour wheels
cannot be controlled by the control panel or DMX command.
To control them, switch the lamp on.
CAUTION!
To avoid damage of the internal parts of the xture head, never let the sunlight or other
xture's lights directly to the front lens , even when the xture is not working !

5
3. Fixture exterior view
Front panel of the base:
1- Touch screen
2- ESCAPE button
3- NEXT button
4- PREVIOUS button
5 - ENTER/DISPLAY ON button
6 - Dust lters
The head should be locked for transportation - the tilt lock (7) and the pan lock (3) have to be in the locked
positions. To unlock the head, move these latches to unlock positions before operating the xture.
1- Front lens
2 - Air vents + lter
3 - Pan lock
4 - Air vents + lter
5- Handle
6- Yoke
7- Tilt lock
8- Head covers
The ENTER/DISPLAY ON button also serves for switching the display on when the xture is disconnected
from the mains.
Rear panel of the base:
1 - DMX output (5-pin XLR)
2 - DMX input (5-pin XLR)
3 - Ethernet input (RJ45)
4 - Fuse holder
5 - DMX output (3-pin XLR)
6 - DMX input (3-pin XLR)
7 - Power input (Neutrik
PowerCon)

6
4. Installation
Fixtures must be installed by a Qualied electrician in accordance with all
national and local electrical and construction codes and regulation.
4.1 Connection to the mains
For protection from electric shock, the xture must be earthed!
The Robin BMFL Blade is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz
AC power source from 200-240 Volts. The xture is protected by one 15 A blow primary fuse.
If you install a cord cap on the power cable to allow connection to power outlets, install a grounding-type (earthed)
plug, following the plug manufacturer’s instructions.
To apply power, rst check that the head pan and tilt locks are released.
The cores in the power cable are coloured according to the following table.
Core (EU) Core (US) Connection Plug Terminal Marking
Brown Black Live L
Light blue White Neutral N
Yellow/Green Green Earth
The earth has to be connected!
If you have any doubts about proper installation, consult a qualied electrician.
Do not connect the xture to a dimmer system!

7
4.2 Installing the lamp
DANGER ! Install the lamp with the device switched off only.
Unplug from mains before !
To insert the new lamp.
1. Disconnect the xture from power and allow it to cool at least 20 min-
utes.
2. Make sure that the xture´s head is in the position as
shown on the picture (notices on the lamp cover are in
a readable position) .Loosen the three quarter-turn
fasteners (1) on the lamp cover to
open this cover.
3. Holding the lamp by its ceramic base, carefully
turn the lamp to the left to loosen the lamp from
the lamp holder.
Gently pull the lamp out of the lamp holder
4. Holding the new lamp by its ceramics base and keeping its orientation as shown at the picture below,
gently insert the lamp to the lamp holder and turn its base to the right until two lamp electrodes snap
into slots in the lamp holder. Make sure that the lamp is installed tightly into the lamp socket.
Do not install a lamp with a higher wattage! A lamp like this generates temperatures the device is not de-
signed for. Damages caused by non-observance are not subject to warranty.
Please follow the lamp manufacturer‘s notes! Do not touch the glass bulb bare hand during the
installation!
5. Re-insert the lamp cover and tighten the three quarter-turn fasteners (1).
6. Switch on the xture.
7. Align the lamp (see instructions below)
8. Reset the "Lamp On Time” and "Lamp Strikes” counters in the menu "Information”.
Do not operate this xture with open lamp cover!
4.3 Lamp adjustment
The lamp holder is aligned at the factory. Due to differences between lamps,the ne adjustment may improve
light performance:
To adjust the lamp in the xture.
1. Switch on the xture and after its reset turn on the
lamp.
2. Go to the "Service" menu and select the item "Adjust
Lamp" to project the light beam on the wall.
3. Use items in this menu to focus the light beam
4 . Turn adjustment screws (2) one after another until you
c enter the hot spot (the brightest part of the beam) and
reach a max. light intensity at desired light distribution.

8
4.4 Replacing colour lters
Install colour lters with the device switched off only.
Unplug from mains before!
Colour lters
1. Disconnect the xture from mains and allow it to cool 10 minutes.
2. Remove the plastic cover of the head by loosening the 4 quarter-turn fasteners on the cover.
3. Turn the colour wheel 2 to the suitable position.
The dichroic lters are xed on the colour wheel by the magnets.
4. Release the dichroic lter (1) from the colour wheel 2 by inclining it from its position
to break the power of the magnet . Protect the glass lter with a piece of paper or clout.
5. Insert a new dichroic lter into the colour wheel 2.
6. Place the top cover back before applying power.

9
4.5 Replacing rotating gobos
Install gobos with the device switched off only.
Unplug from mains before!
To replace rotating gobos.
1. Disconnect the xture from mains and allow it to cool for 10 minutes .
2. Remove the plastic cover of the head by loosening the 4 quarter-turn fasteners on the cover.
3. Gently pull up the gobo holder (3) from the rotation gobo wheel .
4. Remove the spring lock (1) with an appro priate tool (e.g. small-bladed screwdriver) and remove it.
Do not touch the surface of the pattern of the glass gobo with bare ngers.
5. Remove the original gobo (2) and insert the new one (glazy side towards the lamp).
The Robe gobo has a small position point (8) at its edge which has to aimed at the position point (4) on
the gobo holder (4). Insert the spring lock to secure correct gobo position in the gobo holder.
6. Insert he gobo holder back under the distance slots (6, 7) into rotating gobo wheel in this way, that its
position point (4) has to aimed at a small toothlike projection (5) on the edge of the rotating gobo wheel.
Important! When inserting the gobo holder back to the rotating gobo wheel, one of the adjacent gobo holder
has to be oriented according to the same rule, it means that its position point (4) has to aimed at the toothlike
projection (5) on the edge of the rotating gobo wheel. You have keep both marks (4) and (5) side by side when
rotating the gobo wheel to the position allows inserting the gobo holder back.
5. Place the plastic cover back before applying power.
6. Use the menu Service to ne adjust replaced gobo (Service -> Calibration -> Calibrate effects -> R. Gobo
Index 1....6).
Note. The magnet (9) of the gobo holder has the same function as the position point (4) on the rest of gobo
holders.
Note: First three gobos have as a position point (8) little triangle, the second three gobos have a little line.

10
4.6 Installing handle for the Follow Spot Mode
Before installation of handle (handles) , switch the xture to the Follow Spot Mode (Personality--> Follow Spot
Mode). You can install one or two handles in different positions as needed. See picture below. Before switching
the Follow Spot Mode off, remove handle (handles) from the xture.
4.7 Replacing light frost
Install light frost module with the device switched off only.
Unplug from mains before!
To replace the light frost module.
1. Disconnect the xture from mains and allow it to cool for 10 minutes.
2. Move the head to the position that signs on the lamp cover (1) lead down (turned by 180°)
3. Remove plastic cover of the head by loosening the 4 quarter-turn fasteners on the cover.
4. Remove the fan assembly (2) by unscrewing two screws (3) on both sides of the fan assembly.

11
5 . Insert with caution a at-tip screwdriver between the metal sheet of the frost module (4) and the frost holder
(5) and gently turn the screwdriver to break a force of magnets (6) on the frost holder (5) and pull the light
frost module (4) out from the xture . The Frost module (4) is fastened to the frost holder (5) by means of
the four magnets (6).
6 . Insert new frost module in the frost holder (5). Check, that both slots (8) snapped correctly into
two protrusions (7) on the frost holder (5)
7. Screw the fan assembly (2) back to the xture and place the plastic cover back on the xture before
applying power.

12
4.8 Rigging the xture
A structure intended for installation of the xture(s) must safely hold weight of the xture(s) placed on it. The
structure has to be certicated to the purpose.
The xture (xtures) must be installed in accordance with national and local electrical and construction codes
and regulation.
For overhead installation, the xture must be always secured with a safety wire that
can bear at least 10 times the weight of the xture
When rigging, derigging or servicing the xture staying in the area below the installation place, on bridges,
under high working places and other endangered areas is forbidden.
The operator has to make sure that safety-relating and machine-technical installations are approved by an expert
before taking into operation for the rst time and after changes before taking into operation another time.
The operator has to make sure that safety-relating and machine-technical installations are approved by a skilled
person once a year.
Allow the xture to cool for ten minutes before handling.
The projector should be installed outside areas where persons may walk by or be seated.
IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including calculating working
load limits, installation material being used, and periodic safety inspection of all installation material and the
projector. If you lack these qualications, do not attempt the installation yourself, but use a help of professional
companies.
CAUTION: Fixtures may cause severe injuries when crashing down! If you have doubts concerning the safety
of a possible installation, do not install the xture!
The xture has to be installed out of the reach of public.
The xture must never be xed swinging freely in the room.
Danger of re !
When installing the device, make sure there is no highly inammable
material (decoration articles, etc.) in a distance of min. 1 m.
The minimum distance of 8 meters between light output from the moving head and the
lit objects must be kept!
CAUTION!
Use 2 appropriate clamps to rig the xture on the truss.
Follow the instructions mentioned at the bottom of the base.
Make sure that the device is xed properly! Ensure that the
structure (truss) to which you are attaching the xtures is secure.
The xture can be placed directly on the stage oor or rigged in any orientation on a truss without altering its
operation characteristics .
For securing a xture to the truss, install two safety wires which can hold at least 10 times the weight of the
xture. Use only the safety wires with screw-on carabines.
.
.
.

13
Omega holders positions:
Truss installation
1. Bolt each clamp (1) to the omega holder (2) with M12 bolt and lock nut through the hole in the holder.
2. Fasten the omega holders to the bottom of the base by inserting both quick-lock fasteners (3) into
the holes of the base and tighten fully clockwise.
3. Clamp the xture on a truss (6) and tighten the rigging clamps.
4. Pull one safety wire (4) around the truss (6) and through the handle (7) and another safety wire (4) pull
around the truss (6) and through the handle (7) and lock the screw-on carabine through attachment point (5)
as shown on the picture below.
When installing xtures side-by-side,
avoid illuminating one xture with another!
DANGER TO LIFE!
Before taking into operation for the rst time,the installation has to be approved by
an expert!
1-Clamp
2-Omega holder
3-Quick-lock fastener
4-Safety wire
5-Attachment point
6-Truss
7-Handle

14
4.9 DMX-512 connection
The xture is equipped with both 3-pin and 5-pin XLR sockets for DMX input and output.The sockets are wired
in parallel.
Only use a shielded twisted-pair cable designed for RS-485 and 3-pin or 5-pin XLR-plugs and connectors in
order to connect the controller with the xture or one xture with another.
DMX - output DMX-input
XLR mounting-sockets (rear view): XLR mounting-plugs (rear view):
If you are using the standard DMX controllers, you can connect the DMX output of the controller directly with
the DMX input of the rst xture in the DMX-chain. If you wish to connect DMX controllers with other XLR out-
puts, you need to use adapter cables.
Building a serial DMX-chain:
Connect the DMX-output of the rst xture in the DMX-chain with the DMX-input of the next xture. Always
connect one output with the input of the next xture until all xtures are connected. Up to 32 xtures can be
connected.
Caution: At the last xture, the DMX-cable has to be terminated with a terminator. Solder a 120 Ωresistor be-
tween Signal (–) and Signal (+) into a 3-pin (5-pin) XLR-plug and plug it in the DMX-output of the last xture.
1- Shield
2 - Signal (-)
3 - Signal (+)
4 - Not connected
5 - Not connected
1- Shield
2 - Signal (-)
3 - Signal (+)
4 - Not connected
5 - Not connected

15
4.10 Ethernet connection
The xtures on a data link are connected to the Ethernet with ArtNet communication protocol.The control soft-
ware running on your PC (or light console) has to support Art-Net protocol.
Art-Net communication protocol is a 10 Base T Ethernet protocol based on the TCP/IP.Its purpose is to allow
transfer of large amounts of DMX 512 data over a wide area using standard network technology.
IP address is the Internet protocol address.The IP uniquely identies any node (xture) on a network.
The Universe is a single DMX 512 frame of 512 channels.
The Robin MMX Blade is equipped with 8-pin RJ- 45 socket for Ethernet input.Use a network cable category 5
(with four “twisted” wire pairs) and standard RJ-45 plugs in order to connect the xture to the network.
RJ-45 socket (front view): RJ-45 plug (front view):
1- TD+ 5- Not connected
2- TD- 6- RX-
3- RX+ 7- Not connected
4- Not connected 8- Not connected
Patch cables that connect xtures to the hubs or LAN sockets are wired 1:1,that is,pins with the same numbers
are connected together:
1-1 2-2 3-3 4-4 5-5 6-6 7-7 8-8
If only the xture and the computer are to be interconnected,no hubs or other active components are needed.
A cross-cable has to be used:
1-3 2-6 3-1 4-8 5-7 6-2 7-5 8-4
If the xture is connected with active Ethernet socket (e.g. switch) the network icon will appear at the
bottom right corner of the screen:
Direct Ethernet operation
Connect the Ethernet inputs of all xtures with the Ethernet network.
Option “ Artnet" (gMaI or gMA2 or sACN) has to be selected from “Ethernet Mode” menu at each xture.
Set IP address (002.xxx.xxx.xxx / 010.xxx.xxx.xxx) and the Universe at each xture.
An advised PC setting: IP address: 002.xxx.xxx.xxx / 010.xxx.xxx.xxx (Different from xture IP addresses)
NET mask: 255.0.0.0
(DMX address=150) (DMX address=42) (DMX address=1)
IP addres=002.168.002.004 IP addres=002.168.002.003 IP addres=002.168.002.002
Universe=1 Universe=1 Universe=1

16
Ethernet / DMX operation
Option “ Artnet" (gMaI or gMA2 or sACN) has to be selected from “Ethernet Mode” menu at rst xture.
Option “Ethernet To DMX” has to be selected from the “Ethernet Mode” menu at the rst xture (connected to
the Ethernet) in the xture chain, next xtures have standard DMX setting.
Connect the Ethernet input of the rst xture in the data chain with the network. Connect the DMX output of this
xture with the input of the next xture until all xtures are connected to the DMX chain.
Caution: At the last xture, the DMX chain has to be terminated with a terminator. Solder a 120 Ωresistor
between Signal (–) and Signal (+) into a XLR-plug and connect it in the DMX-output of the last xture.
Example:
DMX address=1 DMX address=42 DMX address=150
IP addres=002.168.002.002
Universe=0
DMX address=1 DMX address=42 DMX address=150
IP addres=002.168.002.003
Universe=1

17
5. Remotely controllable functions
Lamp
The Osram Lok-it! HTI 1700/PS is a highly efcient, single-ended short-arc metal halide lamp with
6000 Kelvin colour temperature. The new Lok-it! plug’n’play system allows a quick one-touch lamp
replacement.
The xture allows three levels of the lamp power: 1700W, 1500W and Quiet (Quiet mode - the lamp power is
auto-controlled to ensure minimum noise of xture fans).
Note: It is also important to note, that the discharge lamp is a cold restrike type, that means, that the lamp has
to be cold before re-striking. For this reason, you have to wait a while after having switched the lamp off before
you can switch it on again.
Colour wheel 1
This wheel contains 6 dichroic lters + open.The colour wheel can be positioned between two adjacent colours
in any position. It is also possible to rotate the colour wheel continuously at different speeds ("Rainbow effect“
in both directions).
Colour wheel 2
This wheel contains 6 replaceable 'SLOT&LOCK' dichroic lters + open.The colour wheel can be positioned
between two adjacent colours in any position. It is also possible to rotate the colour wheel continuously at dif-
ferent speeds ("Rainbow effect“ in both directions).
CMY+CTO colour mixing system
The CMY color mixing system is based on graduated cyan, magenta, and yellow colour lters. A continuous
range of colors may be achieved by varying the amount of each lter from 0 to 100%.
Effect wheel
The effect wheel rotating in both directions with variable speed which creates wide spectrum of graphic ef-
fects.
Gobo wheels
The xture includes one static gobo wheel with 8 replaceable gobos and one rotating gobo wheel with 6 glass
gobos rotating in both directions, indexable, replaceable "SLOT&LOCK” system Gobo positioning and gobo
selection speed is available as well as a gobo-shake function.
Prism
Two rotating prisms (6-facet linear, 6-facet axial) with continuous rotation in both directions. 16 prism/gobo
macros available.
Frost
Frost module provides 3 types of variable frosts: light, medium and heavy.
Iris
Motorized adjustable iris, wide range of variable pulse effects.
Zoom
Motorized zoom unit enables zoom between 5 °- 55° (open hole); 5° – 48° (gobo).
Focus
Motorized focus allows to focus beam from approx. 5 metres to innity.
Shutter unit
This unit is used for strobe effects with variable speed.
Dimmer unit
Smooth 0 - 100 % dimming is provided by the mechanical dimmer unit.

18
Pan/Tilt
Fast pan/tilt movement due to built-in electronic motion stabilizer. The electronic motion stabilizer ensures precise
position of the xture´s head during its movement and reduces its swinging when the truss shakes.
Framing system
Framing system consists of four framing shutters which can be moved or swivelled to desired position sepa-
rately.

19
6. Control menu map
Default settings=Bold print
Tab Level 1 Level 2 Level 3 Level 4 Level 5 Level 6
Addressing DMX Address 001-255
DMX Presets Mode 1
Mode 2
View Selected Preset
Ethernet Settings Ethernet Mode Disable
ArtNet
gMAI
gMA2
sACN
Ethernet To DMX Off, On
IP Address/Net Mask Default IP Address
Custom IP Address
Net Mask
ArtNet Universe 0-255
MANet settings MANetI/II Universe 01-256
MANet Session ID 01-32
sACN Settings sACN Universe 00001-32000
sACN Priority 0-255
Information Fixture Times Power On Time Total Hours
Resetable Hours
Lamp On Time Total Hours
Remaining hours
Lamp Strikes Total Strikes
Resetable Strikes
Air Filters Elapsed Time
Alert Period 10-300
Fixture Temperatures Head Temperature Current
Maximum NonRes.
Maximum Res.
Ambient Temperature Current
Maximum NonRes.
Maximum Res.
Base Temperature Current
Maximum NonRes.
Maximum Res.
DMX Values Pan
:
Dimmer Fine
Wireless State Signal Quality
Unlink Wireless Adapter
Power Channel State
Software Versions Display System
Module M
Module G
Module P
Module O
Module C
Module D
Module S
Module F-A
Module F-B

20
Tab Level 1 Level 2 Level 3 Level 4 Level 5 Level 6
Wireless
Product IDs Mac Address
RDM UID
RDM Label
View Logs Fixture Errors
Fixture States Power On
Power Off
Lamp On
Lamp Off
Lamp On
Lamp Off
Fixture Position
Fixture Temperatures Head Temperature
Ambient Temperature
Base Temperature
Personality User Mode User A Settings
User B Settings
DMX Presets Mode 1
Mode 2
View Selected Preset
DMX Input Wired input
Wireless input
Wireless In/XLR Out
Pan/Tilt Settings Pan Reverse Off, On
Tilt Reverse Off, On
Pan/Tilt Feedback Off, On
Pan/Tilt mode Time
Speed
Pan/Tilt EMS On, Off
Follow Spot Mode Off
Soft
Medium
Hard
Microphone Sen-
sitivity
1-10-20
Blackout Settings Blackout During M.C. Off, On
Blackout while: Pan/Tilt moving Off, On
Colour Wheel Moving Off, On
TimeOut Blackout Off, On
Init Effect Positions Pan 0-255
:
Dimmer Fine 0-255
Screen Settings Display Intensity 1-10
Screen Saver Delay Off-10min.
Touchscreen Lock Off-10min.
Recalibrate Touchscreen
Display Orientation Normal
Inverted
Auto
Temperature Unit °C,°F
Fan Mode Auto
High
Dimmer Curve Linear
Square Law
Date & Time Settings
