How-To: Remote Control the Robin
ROBIN
Tech Note

How-To: Remote Control the RobinRobin Tech Note
About this Tech Note
This Tech Note is meant for the following Robin products:
• Robin SIP
• Robin SV
• Robin CV
• Robin HV
Software release 3.5.0 and higher

How-To: Remote Control the RobinRobin Tech Note
Remote Control
The Robin SIP, SV, CV and HV can be controlled using HTTP commands. It’s also possible to
retrieve data from these Robin devices, such as: call status, streaming video and version info.
You can use:
1. Directly, with HTTP commands (eg. with cURL)
2. The ‘Events’ option in the web interface

How-To: Remote Control the RobinRobin Tech Note
Control the Robin with HTTP commands
The Robin SmartView is controllable with HTTP-commands and it is also possible to retrieve data.
A set of commonly used commands are shown below, in these examples with cURL-commands.
To use these commands, the provision of the login credentials of the ‘admin’ user are mandatory.
! Note: cURL is only one of many ways to send HTTP-commands. For more information about
cURL, see: http://en.wikipedia.org/wiki/CURL !
Access to the MJPEG-video stream - Only available on Robin products with built-in camera -
The Robin SV, CV and HV are equipped with a high resolution camera. It generates a Motion-JPEG
video stream that can be retrieved with the following command:
curl -u admin:<password> “http://<address>/pbhelper/stream.mjpeg”
• <password> = the password for the -admin- account
• <address> = the Robin SV address
! Note: Multiple simultaneous MJPEG video streams can affect the performance of the Robin
negatively. !
You can also set the preferred resolution and compression level, just add the following to the URL:
• ?width=320&height=240 = resolution for the requested video (320x240 pixels) - MAX
resolution = 720x576
• ?quality=80 = JPEG quality level (80) - MAX JPEG quality level = 100
! Note: Low resolution and low MJPEG quality will both result in low bandwidth usage. High reso-
lution and high MJPEG quality will both result in high bandwidth usage. !

How-To: Remote Control the RobinRobin Tech Note
Access to the latest video frame
- Only available on Robin products with built-in camera -
The Robin SV, CV and HV not only generate a Motion-JPEG video stream but also individual video
frames (JPEG). These frames can be retrieved by using the following command:
curl -u admin:<password> “http://<address>/camera/frame.jpeg”
• <password> = the password for the -admin- account
• <address> = the Robin SV address
You can also set the preferred resolution and compression level, just add the following to the URL:
• ?width=320&height=240 = resolution for the requested video (320x240 pixels) - MAX
resolution = 720x576
• ?quality=80 = JPEG quality level (80) - MAX JPEG quality level = 100
! Note: Low resolution and low JPEG quality will both result in low bandwidth usage. High resolu-
tion and high JPEG quality will both result in high bandwidth usage. !

How-To: Remote Control the RobinRobin Tech Note
Making calls using HTTP commands
You can control the Robin to make calls, disconnect calls and retrieve the current call status.
The Robin will answer to these commands in JSON.
Command: curl -u admin:<password> “http://<address>/api/v1/call_
setup?number=501”
Goal: Call extension 501
Answer: {
“ok” : true
}
Command: curl -u admin:<password> “http://<address>/api/v1/call_status”
Goal: Retrieve the call status of the Robin
Answer: {
“rv” : {
“status” : “outgoing call to 501”
},
“ok” : true
}
Command: curl -u admin:<password> “http://<address>/api/v1/call_hangup”
Goal: disconnect the call (call hangup)
Answer: {
“ok” : true
}
Command: curl -u admin:<password> “http://<address>/api/v1/api_ping”
Goal: ping the Robin (to check if it responds)
Answer: {
“rv” : {
“pong” : “pong”
},
“ok” : true
}
! Note: If the HTTP command to dial an extension contains an extension that is already known
in the phone book, the Robin dials that extension and will use the profile that is defined for that
extension. !

How-To: Remote Control the RobinRobin Tech Note
Control the audio mute function using HTTP commands
The audio settings of the Robin can be controled using http commands. The commands control the
mute function of the Robin. It mutes speakers of the Robin.
You can mute three types of audio:
• All incoming tones: Mute all tones from an incomming phone call
• All tones: Mute all tones from incomming and outgoing phone calls
• All audio: Mute the speakers of the Robin. It mutes all tones and voice. Use this option to listen-
in on the Robin.
The audio mute can also be disabled using one command.
The Robin will answer to these commands in JSON.
Command: curl -u admin:<password> “http://<address>/api/v1/mute_set?mute=tones_
incoming”
Goal: mute all tones from an incomming phone call
Answer: {
“rv” : {
“mute”:”tones_incoming”
},
“ok” : true
}
Command: curl -u admin:<password> “http://<address>/api/v1/mute_set?mute=tones_
all”
Goal: mute all tones from incomming and outgoing phone calls
Answer: {
“rv” : {
“mute”:”tones_all”
},
“ok” : true
}
Command: curl -u admin:<password> “http://<address>/api/v1/mute_set?mute=all_au
dio”
Goal: mute the speakers of the Robin. (mutes all tones and voice)
Answer: {
“rv” : {
“mute”:”all_audio”
},
“ok” : true
}

How-To: Remote Control the RobinRobin Tech Note
Command: curl -u admin:<password> “http://<address>/api/v1/mute_set?mute=off”
Goal: disable the audio mute (all sound will be on)
Answer: {
“rv” : {
“mute”:”off”
},
“ok” : true
}
Command: curl -u admin:<password> “http://<address>/api/v1/mute_get”
Goal: retrieve the audio mute status
Answer: {
“rv” : {
“mute”:”off” / :”all_audio” / :”tones_all” / :”tones_incoming”
},
“ok” : true
}

How-To: Remote Control the RobinRobin Tech Note
Control the door opener using HTTP commands
- Only available on the Robin SIP and Robin SV -
You can control the Robin to open and close the door and retrieve the status of the door opener.
The Robin will answer to these commands in JSON.
Command: curl -u admin:<password> “http://<address>/api/v1/dooropener_open”
Goal: Open the door and keep it open (close the relay)
Answer: {
“ok” : true
}
Command: curl -u admin:<password> “http://<address>/api/v1/dooropener_close”
Goal: Close the door (open the relay)
Answer: {
“ok” : true
}
Command: curl -u admin:<password> “http://<address>/api/v1/dooropener_pulse”
Goal: Open the door and keep it open for the time set in the GUI. After that, close the door
Answer: {
“ok” : true
}
Command: curl -u admin:<password> “http://<address>/api/v1/dooropener_status”
Goal: Retrieve the status of the door opener
Answer: {
“rv” : {
“status” : “Open”
},
“ok” : true
}

How-To: Remote Control the RobinRobin Tech Note
Control the relay switch(es) using HTTP commands
- Only available on the Robin CV and HV -
You can control the Robin to control the built-in relay switch(es).
- The Robin CV is equipped with one relay switch, the Robin HV is equipped with two relay switch-
es. -
The Robin will answer to these commands in JSON.
Command: curl -u admin:<password> “http://<address>/api/v1/switch_
set?state=on&switch=1”
Goal: Activate switch no. 1 (close the relay)
Answer: {
“rv” :
“ok” : true
}
Command: curl -u admin:<password> “http://<address>/api/v1/switch_
set?state=off&switch=1”
Goal: Deactivate switch no. 1 (open the relay)
Answer: {
“rv” :
“ok” : true
}
Command: curl -u admin:<password> “http://<address>/api/v1/switch_
set?state=pulse&duration=5&switch=1”
Goal: Activate switch no. 1 for the duration of 5 seconds (pulse the relay)
Answer: {
“rv” :
“ok” : true
}
‘Duration’ is a variable value (in seconds)
Command: curl -u admin:<password> “http://<address>/api/v1/switch_get?switch=1”
Goal: Retrieve the state of switch no. 1 (get status of switch)
Answer: {
“rv” : {
“state”:”off” / :”on”
},
“ok” : true
}
Use switch=1 for the relay switch on the Robin CV, use switch=1 or switch=2 for the Robin HV.

How-To: Remote Control the RobinRobin Tech Note
Configure the SIP-configuration using HTTP commands
The SIP configuration of the Robin can be programmed and read using HTTP commands.
The Robin will answer to these commands in JSON.
Command: curl -u admin:<password> “http://<address>/api/v1/get_button_count”
Goal: Retrieve the amount of available buttons on the Robin (1,2,4 or 6) -> Answer=1
Answer: {
“ok”:true,”rv”:1
}
Command: curl -u admin:<password> “http://<address>/api/v1/get_phonebook”
Goal: Retrieve the phone book data (in this example: no. 1001, 1002 and 1003)
Answer: {“ok”:true,”rv”:[
{“profile”:”---”,”index”:1,”description”:”Bria”,”extension”:”1003”,
”allow_register”:false},
{“profile”:”---”,”index”:2,”description”:”Yealink_1”,”extension”:”1001”,
”allow_register”:false},
{“profile”:”---”,”index”:3,”description”:”Yealink_2”,”extension”:”1002”,
”allow_register”:false}]}
Command: curl -u admin:<password> “http://<address>/api/v1/add_phonebook_entry?
description=Reception&number=101&allow_register=0”
Goal: Add a Phone book entry. In this example: Description=Reception,
number=101, Allow register (Peer to Peer) disabled (0)
Answer: {
“ok”:true,”rv”:[]
}
Command: curl -u admin:<password> “http://<address>/api/v1/delete_phonebook_
entry?index=1”
Goal: Remove entry no. 1 from the phone book.
Answer: {
“ok”:true,”rv”:[]
}
After removal of a phone book entry, the numbering of the remaining entries will change. Use the
‘get_phonebook’ command to retrieve the updated entries and numbers.

How-To: Remote Control the RobinRobin Tech Note
Command: curl -u admin:<password> “http://<address>/api/v1/get_callprio_
list?button=1”
Goal: Retrieve the call list (in this example: 1001, 1002 en 1003, for button 1)
Answer: {“ok”:true,”rv”:[
{“name”:”Yealink_1”,”number”:”1001”},
{“name”:”Yealink_2”,”number”:”1002”},
{“name”:”Bria”,”number”:”1003”}
]}
Command: curl -u admin:<password> “http://<address>/api/v1/set_callprio_list?first=
name1&second=name2&third=name3&button=2”
Goal: Configure the call list. In this example: First=name1, Second=name2,
Third=name3, this is the call list for button no. 2.
Answer: {
“ok”:true,”rv”:[]
}
Command: curl -u admin:<password> “http://<address>/api/v1/set_sip_config ?proto=
udp&host=192.168.200.202&port=5060&username=test&
password=secret&register=1”
Goal: Configure the SIP settings of the Robin. In this example: SIP protocol=UDP,
SIP proxy / Registar=192.168.200.202, SIP proxy port number=5060,
Username=test, Password=secret, Register enabled (1).
Answer: {
“ok”:true,”rv”:[]
}
Command: curl -u admin:<password> “http://<address>/api/v1/get_sip_config”
Goal: Retrieve the SIP configuration from the Robin
Answer: {“ok”:true,”rv”:
{“proto”:”udp”,”secondary_port”:5060,”secondary_host”:”ip or hostname”,
”host”:”192.168.200.202”,”port”:5060,”expires”:3600,”register”:true,
”password”:”secret”,”username”:”test”,”secondary”:false}}

How-To: Remote Control the RobinRobin Tech Note
Go-to-Robin using HTTP commands
Using HTTP commands, the Robin can connect, check the status and close the connection with the
G0-to-Robin remote server.
The Robin will answer to these commands in JSON.
Command: curl -u admin:<password> “http://<address>/api/v1/tunnel_connect”
Goal: Start the ‘Go-To-Robin’ connection (to enable remote support access to the Robin)
Answer: {
“ok”:true,”rv”:[]
}
Command: curl -u admin:<password> “http://<address>/api/v1/tunnel_disconnect”
Goal: Close the ‘Go-To-Robin’ connection
Answer: {
“ok”:true,”rv”:[]
}
Command: curl -u admin:<password> “http://<address>/api/v1/tunnel_status”
Goal: Retrieve the connection status of the ‘Go-To-Robin’ connection - In this example:
‘Connected’
Answer: {
“ok”:true,”rv”:{“status”:”connected”}
}

How-To: Remote Control the RobinRobin Tech Note
Upgrade software version using HTTP commands
The software of the Robin can be upgraded using HTTP commands. It takes eight steps to upgrade
the Robin.
The Robin will answer to these commands in JSON.
! Note: Use an interval time of 5 seconds between each command. !
1. Check for a new software version:
Command: curl -u admin:<password> “http://<address>/api/v1/do_update”
Goal: Start the check for a new software version.
Answer: {
“ok”:true,”rv”:[]
}
2. Check the status during the update command. Continue checking until the output is ‘empty’:
Command: curl -u admin:<password> “http://<address>/api/v1/get_upgrade_status”
Goal: Retrieve the actual status during the update check.
Answer: {
“ok”:true,”rv”:”Checking for new versions...” -> busy
or “ok”:true,”rv”:”” -> done
}
3. Retrieve the software versions. Is the “version_available” identical to the “version_installed”?
No update available. Is the “version_available” higher than the “version_installed”? New up-
date available, see step 4:
Command: curl -u admin:<password> “http://<address>/api/v1/get_versions”
Goal: Retrieve the software versions.
Answer: {
“ok”:true,”rv”:{
“version_available”:”dev+3870”,
”version_installed”:”dev+3869”,
”version_running”:”dev+3869”
}
}

How-To: Remote Control the RobinRobin Tech Note
4. Upgrade to the latest version:
Command: curl -u admin:<password> “http://<address>/api/v1/do_upgrade”
Goal: Start the software upgrade.
Answer: {
“ok”:true,”rv”:[]
}
5. Check the status during the upgrade command. Continue checking until the output is ‘Ok’ and
the upgrade is finished:
Command: curl -u admin:<password> “http://<address>/api/v1/get_upgrade_status”
Goal: Retrieve the actual status during the software upgrade.
Answer: {
“ok”:true,”rv”:”Upgrading...” -> busy
or “ok”:true,”rv”:”Ok” -> done
}
6. As soon as the upgrade is done, check the status of the upgrade using the ‘get_versions’ com-
mand. Is the “version_installed” higher than the “version running”? The upgrade was success-
ful and the Robin needs to reboot. See step 7:
Command: curl -u admin:<password> “http://<address>/api/v1/get_versions”
Goal: Retrieve the software versions.
Answer: {
“ok”:true,”rv”:{
“version_available”:”dev+3870”,
”version_installed”:”dev+3870”,
”version_running”:”dev+3869”
}
}
7. Reboot the Robin, the reboot procedure can take up to one minute:
Command: curl -u admin:<password> “http://<address>/api/v1/reboot”
Goal: Reboor the Robin
Answer: {
“ok”:true,”rv”:[]
}

How-To: Remote Control the RobinRobin Tech Note
8. After the reboot, use the ‘get_versions’ command to check if the upgrade. Is the “version_run-
ning” identical to the “version_installed” and is the “version_available” empty? The upgrade
went successfully:
Command: curl -u admin:<password> “http://<address>/api/v1/get_versions”
Goal: Retrieve the software versions.
Answer: {
“ok”:true,”rv”:{
“version_available”:””,
”version_installed”:”dev+3870”,
”version_running”:”dev+3870”
}
}

How-To: Remote Control the RobinRobin Tech Note
Miscellaneous settings using HTTP commands
Use HTTP commands to make miscellaneous settings.
Command: curl -u admin:<password> “http://<address>/api/v1/reset_defaults”
Goal: Restore the factory settings. The Robin will automatically reboot.
Answer: {
“ok”:true,”rv”:[]
}

How-To: Remote Control the RobinRobin Tech Note
Recording feature - HTTP commands
The recording feature of the Robin can be controlled using HTTP commands.
The Robin will answer to these commands in JSON.
video_list
The ‘video_list’ call retrieves a list with all recorded videos. Each entry contains the following fields:
• time: start time of the video (unix timestamp)
• duration: in seconds
• id: video id, a unique string for this video
• url: the url of the videostream
• event_data: the event data of the event that triggered the recording
Arguments:
• button: filters on button number (optional)
Command: curl -u admin:<password> “http://<address>/api/v1/video_list?button=3”
Goal: Retrieve the video list for a specific button - in this case button 3
Answer: {
“ok”: true,“rv”: {“video_list”: [
{“call_ids”: [
“c3aa4538”
],
“time”: 1394113333,
“id”: “2”,
“duration”: 300,
“url” : “/recording/video-2.m3u8”,
“event_data”: {
“button”: 3,
“type”: “button”},
{
“call_ids”: [
“970fdfe9”
],
“time”: 1394113375,
“id”: “5”,
“duration”: 300,
“url” : “/recording/video-5.m3u8”,
“event_data”: {
“button”: 3,
“type”: “button”}
]

How-To: Remote Control the RobinRobin Tech Note
}
}
Play HLS video
The video file can be accessed via the m3u8 url.
Command: curl -u admin:<password> “http://<address>/recording/video-5.m3u8”
Goal: Retrieve the video - In this case it contans four segments
Answer: #EXTM3U
#EXT-X-TARGETDURATION:10
#EXT-X-MEDIA-SEQUENCE:0
#EXTINF:10, no desc
/recording//2014/03/06/14/20140306144219_00000002_10.ts
#EXTINF:10, no desc
/recording//2014/03/06/14/20140306144229_00000003_10.ts
#EXTINF:8, no desc
/recording//2014/03/06/14/20140306144239_00000004_8.ts
#EXTINF:10, no desc
/recording//2014/03/06/14/20140306144247_00000005_10.ts
#EXT-X-ENDLIST
video_del
Remove a specific video.
Arguments:
• id: id of the video (see video_list)
Command: curl -u admin:<password> “http://<address>/api/v1/video_del?id=6”
Goal: Remove the video with -in this case- id: 6
Answer: {
“ok”:true,”rv”:[]
}

How-To: Remote Control the RobinRobin Tech Note
call_log
Retrieve the call log.
Arguments:
• id: id of a specific call
Command: curl -u admin:<password> “http://<address>/api/v1/call_log”
Goal: Retrieve the call log
Answer: {
“ok”: true,“rv”: {“call_log”: [
{
“number”: “[email protected]”,
“direction”: “incoming”,
“time”: 1386753209,
“id”: “55826c80”,
“duration”: 44
“result”:”hangup”
“answered”:true},
{
“number”: “[email protected]”,
“direction”: “incoming”,
“time”: 1386753970,
“id”: “19b46a5f”,
“duration”: 10
“result”:”busy”
“answered”:false},
{
“number”: “[email protected]”,
“direction”: “incoming”,
“time”: 1386754004,
“id”: “483ae77c”,
“duration”: 3
“result”:”error”
“answered”:false}
]
}
}
