ROBINHOOD ic 300 User manual

Page 1 of 6
Description: IRONING CENTRE
Model Number: IC300/ 200/ 100
SPECIFICA ION DIAGRAM
MODEL
IC 300
IC 200
IC 100
Model pictured: IC300
Issue:
H

Page 2 of 6
Exploded View

Page 3 of 6
Part number
Item Description IC100 IC200 IC300
1 CABINE BODYWRAPPER
2 OP COVER
3 BO OM COVER
4 SHELF 107604WH 107604WH 107604WH
5 CONSOLE
6 IMER N/A 107655 107655
7 IMER KNOB N/A 107499WH 107499WH
8 WIRE COVER
9 SNAP ON INSULA ION CAP N/A 107646 107646
10 LAMP HOLDER N/A 103715 103715
11 DIFFUSER N/A 103125 103125
12 POWER CORD N/A 107778 107778
13 POWER POIN N/A 107810 107810
14 IC GLOBE N/A 102722 102722
15 HEIGH ADJUS BRK R/H
16 HEIGH ADJUS BRK L/H
17 ELEC RIC COVER N/A 107851WH 107851WH
18 SWIVEL ASSEMBLY SPARE PAR N/A N/A 107673
19 PIVO ROD 107874WH 107874WH 107855WH
20 RO A IONAL BEARING N/A N/A 107617
21 IRONING BOARD SPARE PAR 107671 107671 107672
22 BUSH N/A N/A 107845
23 IRONING BOARD PLAS ICS FAMILY 107753WH 107753WH 107753WH
24 PIVO S OP 107872WH 107872WH 107872WH
25 RE AINER BRACKE PLAS IC 107771WH 107771WH 107771WH
26 BOARD RE AINER 107876WH 107876WH 107876WH
27 DOOR 107628 107628 107628

Page 4 of 6
* Parts not available outside production
** Available as separate accessory (Part not shown on diagram)
Part number
Item Description IC100 IC200 IC300
28 I/C INS ALLA ION KI (DOOR) 107668 107668 107668
29 BOARD COVER IBC01 IBC01 IBC01
30 SPACER IRONING BOARD (Prior to Dec 05) 107622WH 107622WH N/A
31 GROMME HEIGH ADJUS MEN 107877 107877 107846
32 U BAR 107875WH 107875WH 107875WH
33 HEYCO BUSH N/A 104044 104044
34 COLLAR ACCESSORY ICMC ICMC ICMC

Page 5 of 6
Ironing Board Removal
On IC100 and IC200 models
Undo the screws on both spacers.
Lift the board retainer and hold the Ironing board with a slight angle to its vertical
position.
Slide the pivot rod to one side.
ilt one end of the pivot rod away from the cabinet until there is enough clearance to
slide the pivot rod out.
Slide the pivot rod out of the cabinet, remove board assembly, and replace the
board.
Reassemble the board, pivot rod and spacers in reverse order.
Lift the board to slight angle from its vertical position.
ilt one end of the board and insert one end of the pivot rod into the cabinet until
there is enough clearance to slide the other end of pivot rod into the other side of
cabinet
Adjust the pivot rod to obtain full engagement on both sides.
Ensure spacer locking tabs are correctly located under the board, tighten screws.
Care should be takes not to over tighten the screws.
ON IC300
Undo the M8 nut under the Ironing board.
Replace the Ironing board.
Replace flat washer and locknut; tighten to achieve correct locking when rotated.

Page 6 of 6
Electrical Circuit Diagram from the IC-SERIES
New Zealand
Robinhood Ltd
elephone: 0800 760 667
Facsimile: 0800 276 246
Email: [e-mail]
www.robinhood.co.nz
Australia
Robinhood P Y Ltd
elephone: 0800 760 667
Facsimile: 0800 276 246
Email: [e-mail]
www.robinhood.com.au
ECN: 08 144
