ROBINHOOD RWE3CH6SS User manual

1
Description: ROBINHOOD WALL CANOPY
Model Numbers: RWE3CH6SS, RWE3CH9SS
Model pictured: RWE3CH9SS
RW
E
Issue:
B
All dimensions in mm
Model may vary slightly from images pictured

2
Overview
Pre-inst ll tion
Thank you for purchasing a quality Robinhood rangehood. Robinhood has a high standard of quality control
and e ery rangehood is tested and appro ed before it lea es the factory.
Import nt:
oPlease read the entire instructions before installing the rangehood.
oAlways switch power off prior to installation.
oStainless steel is ery easily damaged during installation if abraded or knocked by tools. Protect the
rangehood with the cardboard box or plastic bag during installation.
oAll electrical work must be done in accordance with local and national electrical codes as applicable.
oFor safety, this product must be earthed.
oA power outlet should be within 1500mm of the power cord exit from the rangehood.
oThe power socket must be accessible and enable the end user to isolate the rangehood from the power for
the purpose of internal cleaning or maintenance.
o150mm round ducting adapter is supplied. All other ducting accessories are not supplied. All ducting must
comply with local requirements and building codes.
oIf re-circulating, ensure that the side outlet grilles are not obstructed. E en a partial obstruction will
restrict the efficiency of the rangehood.
oSee Ducting options next page.
Contents of p ck ging:
1 x rangehood
1 x 150mm ducting adaptor
1 x packet of fasteners and wall plugs
2 x chimney pieces (upper and lower)
2 x chimney bracket
1 x mounting bracket
Typic l equipment required:
oelectric drill
oscrewdri er
otape measure
ospirit le el
oduct tape (if ducting)
ojig saw (if ducting)
oladder (if ducting)

3
Pre-Inst ll tion - continued
Ducting Options
The method of ducting should be carefully considered before installing the rangehood. The guide below
recommends the ducting components to use for all common ducting configurations - through the top of the home
(for the roof and soffit) and through the rear of the home. 150mm round ducting should be used in conjunction
with this model rangehood. Alternati ely this rangehood can be operated in recirculation mode (see Recirculation
mode pg 6).
The highlighted re in the t ble below gives the recommended Uniduct item numbers for different
mounting nd outlet options.
Duct mounting option
Re r
Top (roof) Top (soffit/e ve)
Uniduct item numbers
150mm
di meter round outlet
1688 1634 and
1635
1634 and
1688
Extra lengths and/or bends may be required, depending on the length required and whether there is any
structural material in the run e.g. rafters.
Please note that this chart is designed as a guide. Please consult Robinhood customer ser ices if unsure.
For NZ phone [phone] or www.robinhood.co.nz. For AUS phone [phone] or www.robinhood.com.au.

4
Pre-Inst ll tion - continued
Inst ll tion position
A Vertical height from bottom of Rangehood to Fixing Plate mounting screws
302mm.
B Set height from the hob surface to the underside face of the rangehood at 750mm for electric hob or gas
hob.
Please check that the length of your chimney assembly will reach your ceiling before securing the rangehood to
the wall.
Be ad ised that the chimney height is such that the optimum height for installation is 750mm abo e the hob.
Should you wish to ha e the unit lower, or you ha e a ceiling higher than the typical 2.4 meter (8 foot), then
please choose the desired chimney extension kit from page 8.
Minimum height from the hob surface to the underside face of the rangehood
600mm electric hob - chimney extension kit required, see page 8
650mm gas hob – chimney extension kit required, see page 8
Notes: If the instructions for the g s hob specify gre ter dist nce, this h s to be t ken into ccount.
Any inst ll tion bove 750mm will compromise the perform nce.
C Distance between mounting screw holes on Fixing Plate
115mm.
+
+
+

5
Inst ll tion
Mounting to a stud is recommended. Howe er, if fitted to other wall linings (plasterboard, concrete etc) suitable
fixings will be required. Before drilling any holes check that the wall and ceiling are clear of any electrical cables,
pipes etc.
1. Pre drill pilot holes in the positions gi en (Pg 4 - Installation position). Fix the mounting bracket using the
screws supplied or appropriate wall fixings, check with a spirit le el to ensure bracket is le el. Tighten screws.
2. Mark the position of the decorati e chimney at the ceiling and wall. Cut the cornice moulding away if
required, to enable the chimney to sit flush against the wall and ceiling. If a chimney extension kit is
required, see page 8, Chimney extensions.
3. Only if ducting - Mark and check, then cut out the hole in the ceiling / wall to fit the ducting (160mm
dia max).
4. Using the screws supplied, fix the top chimney bracket to the wall, checking that is central about the
canopy.
Wall stud
Fixing screw
Rear wall
Fixing plate

6
Inst ll tion - continued
5. Using screws supplied, fix the lower chimney bracket onto lower chimney.
6. Remo e the protecti e plastic co ering from all parts including the filters. Hang the rangehood onto the
mounting bracket.
7. Connect to the power supply and switch on the power to the rangehood. Check the functions and
operations of the switches. Connect and secure the ducting (use duct tape if required).
8. Place the two chimney pieces onto the canopy top. Extend the upper chimney to the ceiling and secure in
place with the top chimney bracket using two screws supplied.
Recircul tion mode
1. This unit can be installed to operate in recirculation mode where ducting is not a chosen/desired or practical
option. There are recirculation grilles fitted on each side of the upper chimney which allow the cleansed air
to return to the kitchen. Ensure that the side outlet grilles are not obstructed. E en a partial obstruction
will restrict the efficiency of the rangehood.
2. Replace aluminium filters with charcoal filters (see Pg 7 Parts and Accessories list).

7
Oper ting instructions
Controls
Light
The light can be operated independently from the fan and is controlled in accordance with the graphics printed
abo e.
F n
The fan is operated by turning the power switch on. It can be run at three different speeds (Speed 1 / Speed 2 /
Speed 3) depending on the cooking requirements and is controlled in accordance with the graphics printed abo e.
Cle ning nd M inten nce
Gener l M inten nce
Switch off the c nopy before cle ning or m inten nce. To pre ent surface damage ne er use abrasi e
or oil based liquid cleaners. To clean the surfaces of the appliance, use mild detergent and warm water. In
areas of high humidity and coastal en ironments cleaning should be carried out frequently.
W rning: build up of oil m y occur if the comp ct c nopy is not cle ned regul rly.
Filter M inten nce
To maintain efficiency, the filters should be remo ed regularly (approximately monthly), and washed using hot
soapy water or the dishwasher. Note - some discolour tion of the fr me m y occur if w shed in the
dishw sher.
Rangehoods fitted with charcoal filters are designed to remo e grease and odours from cooking apours prior to
the cleansed air re-entering the kitchen (when the rangehood is in recirculation mode). Charcoal filters should be
replaced e ery two to four months depending on use.
Note: Fully saturated charcoal filters can become a barrier to air mo ement therefore limiting rangehood
performance. In the e ent of fire, grease laden filters could be flammable and therefore regular replacement is
recommended. In ducted installations, con entional aluminium filters are recommended.
Repl cement of H logen L mps
To replace a lamp, first disconnect the rangehood from the power supply. Use a small blade screwdri er to prise
off the lamp co er. Care must be taken to a oid the lamp lens falling on to the hob top. The halogen bulb is a
push fit into the lamp body. Insert the replacement lamp into the lamp holder and replace the lens and lamp
co er.
P rts nd Accessories list
oCharcoal filter 2536 (2 pack - 600 Model)
2537 (3 pack - 900 Model)
oLight bulb 12V 20W 104467
oChimney extensions 2611 (10 ft/3048mm)
2612 (12 ft/3658mm)
For any other problems please call help line on NZ 0800 760 667 or AUS 1800 648 556
Lights On/Off
Po
wer
On/Off
Speed 1 Speed 2 Speed 3

8
Note: When the m ximum chimney height is to be used, there will be minimum of 25mm overl p
required for top nd bottom chimney ssembly.
Chimney extensions

9
Product pprov ls nd r tings
Product pprov l number A/10933EA
Product r ting 190W M x. t 240v 50Hz
Electric l pproved to IEC 60335.1:2001; EN 60335.1:2002
EMC tested to EN55014.1/2, EN61000.3.2/3
Perform nce tested GB/T17713
Import nt s fety inform tion
•
••
•This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they ha e been gi en super ision
or instruction concerning use of the appliance by a person responsible for their safety.
•
••
•Young children should be super ised to ensure that they do not play with the appliance.
•
••
•There shall be adequate entilation of the room when the rangehood is used at the same time as
appliances burning gas or other fuels.
•
••
•You must read the details concerning the method and frequency of cleaning.
•
••
•There is a fire risk if cleaning is not carried out in accordance with the instructions.
•
••
•Do not flambé under the rangehood.
•
••
•Exhaust air must not be discharged into an existing flue which is used for exhausting fumes from
appliances burning gas or other fuels.
•
••
•The minimum distance between the hob surface and the lowest part of the rangehood is 600mm.
This distance shall be at least 650mm, if the rangehood is installed o er a gas hob. If the
instructions for the gas hob specify a greater distance, this has to be taken into account.
•
••
•Attention should be gi en to ensure that any applicable regulations concerning the discharge of
exhaust air is fulfilled.
•
••
•If the supply cord of this equipment is damaged, it must only be replaced by the manufacturer or its
ser ice agent or a similarly qualified person in order to a oid a hazard.

10
W rr nty Certific te (New Ze l nd)
Terms nd Conditions
The following conditions apply in respect of the warranty gi en in this certificate:
1. Robinhood Limited (“Robinhood”) warrants the following products against manufacturing defects and faulty materials,
under normal use and subject to the exclusions in this certificate, for a period of:
under normal use and subject to the exclusions in this certificate, for a period of:
R ngehood – 24 months from date of original purchase for domestic use.
Uniduct – 12 months from date of original purchase for domestic use.
Ironing centre – 12 months from date of original purchase for domestic use.
“Original purchase”, when used in this certificate, means purchase by the customer directly from Robinhood Limited or
one of its appro ed suppliers.
2. This warranty is limited to the repair or replacement, at Robinhood’s option, within the warranty period of any
component part which Robinhood at its discretion determines to contain faulty materials or a manufacturing defect in
breach of this warranty. This warranty is subject to terms and conditions set out in this certificate.
3. The warranty only applies within New Zealand.
4. The customer must produce the original in oice or other purchase documentation as proof of the original purchase
date.
W rr nty exclusions
1. The warranty does not apply where, in the opinion of Robinhood:
The defect is caused by misuse, wear and tear, dirt, fire or accidental damage.
The product has been repaired or ser iced by an unauthorized person.
The product was not installed in accordance with Robinhood instructions.
The product was purchased o erseas or was not designed for use in New Zealand.
The product was not used, cleaned or cared for in accordance with Robinhood’s instructions.
The product was used outdoors.
2. In addition, this warranty does not extend to damage or defects which in Robinhood’s opinion, directly or indirectly
arise from or are due to:
Exposing the product to acidic or corrosi e materials or chemicals such as dyes, sol ents, denture cleaner or acetone;
Using inappropriate household cleaning products such as abrasi e cream or powder cleansers, furniture polish, bleach,
mentholated spirits, drain cleaners, sugar soap, metal pads and strongly alkaline or acidic cleaners;
Heat damage, including from washing the product at high temperatures;
Impact or mishandling the product, including the impact caused by objects scraped along, thrown or dropped on the
product surface or excessi e weight being placed on the product;
Structural or support changes in or affecting the building or the application where the product has been installed;
Failure to clean or maintain the product as recommended; or
any other causes specified in the product information as being excluded from this warranty.
3. Variations with the colour or gloss within the product or any ageing or fading of colour, shine or gloss le el o er time
are not co ered by this warranty. The warranty does not co er isual imperfections or blemishes in the surface and
edges of the product that were not brought to your supplier’s attention at the time you inspected the product.
4. Costs incurred on installation or remo al of a product, or any reinstallation of a product, or any associated costs, are
not co ered by this warranty.
5. Robinhood will not be liable for consequential or indirect loss or damage whatsoe er and howe er arising out of or in
connection with the supply, performance or remo al of the product, including (but not limited to) loss of profit, loss of
re enue, loss of contract, lost of goodwill or increased cost of workings, e en if due to the negligence of Robinhood or
any of its appro ed suppliers, employees or agents.
6. Charcoal filters and light bulbs are not co ered by this warranty
7. This warranty and the statements contained in this certificate or other Robinhood documents gi en to you do not
exclude, restrict or modify the application of any term implied into this warranty by statute, pro ided that (to the
extent any statutory pro ision permits Robinhood to limit its liability for a breach of an implied condition or warranty)
Robinhood’s liability for such breach is limited to the payment of the cost of replacing the product, repairing the
product or acquiring an equi alent product.
8. Subject to clause 5, the obligations of Robinhood under this warranty are limited to those set out in this certificate,
and this warranty is expressly instead of all other warranties, express or implied, including any implied warranty of
merchantability or fitness for a particular purpose and notwithstanding any course of dealing between the parties or
custom and usage in trade to the contrary.
Should warranty ser ice be required, please contact Robinhood:
Free Phone: [phone]
Free Fax: [phone]
Email: [e-mail]
Website: www.robinhood.co.nz
Terms and conditions are subject to change without notice.

11
W rr nty Certific te (Austr li )
Terms nd Conditions
The following conditions apply in respect of the warranty gi en in this certificate:
1. Robinhood Limited (“Robinhood”) warrants the following products against manufacturing defects and faulty materials,
under normal use and subject to the exclusions in this certificate, for a period of:
under normal use and subject to the exclusions in this certificate, for a period of:
R ngehood – 24 months from date of original purchase for domestic use.
Uniduct – 12 months from date of original purchase for domestic use.
Ironing centre – 12 months from date of original purchase for domestic use.
“Original purchase”, when used in this certificate, means purchase by the customer directly from Robinhood Limited or
one of its appro ed suppliers.
2. This warranty is limited to the repair or replacement, at Robinhood’s option, within the warranty period of any
component part which Robinhood at its discretion determines to contain faulty materials or a manufacturing defect in
breach of this warranty. This warranty is subject to terms and conditions set out in this certificate.
3. The warranty only applies within Australia.
4. The customer must produce the original in oice or other purchase documentation as proof of the original purchase
date.
W rr nty exclusions
1. The warranty does not apply where, in the opinion of Robinhood:
The defect is caused by misuse, wear and tear, dirt, fire or accidental damage.
The product has been repaired or ser iced by an unauthorized person.
The product was not installed in accordance with Robinhood instructions.
The product was purchased o erseas or was not designed for use in Australia.
The product was not used, cleaned or cared for in accordance with Robinhood’s instructions.
The product was used outdoors.
2. In addition, this warranty does not extend to damage or defects which in Robinhood’s opinion, directly or indirectly
arise from or are due to:
Exposing the product to acidic or corrosi e materials or chemicals such as dyes, sol ents, denture cleaner or acetone;
Using inappropriate household cleaning products such as abrasi e cream or powder cleansers, furniture polish, bleach,
mentholated spirits, drain cleaners, sugar soap, metal pads and strongly alkaline or acidic cleaners;
Heat damage, including from washing the product at high temperatures;
Impact or mishandling the product, including the impact caused by objects scraped along, thrown or dropped on the
product surface or excessi e weight being placed on the product;
Structural or support changes in or affecting the building or the application where the product has been installed;
Failure to clean or maintain the product as recommended; or
any other causes specified in the product information as being excluded from this warranty.
3. Variations with the colour or gloss within the product or any ageing or fading of colour, shine or gloss le el o er time
are not co ered by this warranty. The warranty does not co er isual imperfections or blemishes in the surface and
edges of the product that were not brought to your supplier’s attention at the time you inspected the product.
4. Costs incurred on installation or remo al of a product, or any reinstallation of a product, or any associated costs, are
not co ered by this warranty.
5. Robinhood will not be liable for consequential or indirect loss or damage whatsoe er and howe er arising out of or in
connection with the supply, performance or remo al of the product, including (but not limited to) loss of profit, loss of
re enue, loss of contract, lost of goodwill or increased cost of workings, e en if due to the negligence of Robinhood or
any of its appro ed suppliers, employees or agents.
6. Charcoal filters and light bulbs are not co ered by this warranty
7. This warranty and the statements contained in this certificate or other Robinhood documents gi en to you do not
exclude, restrict or modify the application of any term implied into this warranty by statute, pro ided that (to the
extent any statutory pro ision permits Robinhood to limit its liability for a breach of an implied condition or warranty)
Robinhood’s liability for such breach is limited to the payment of the cost of replacing the product, repairing the
product or acquiring an equi alent product.
8. Subject to clause 5, the obligations of Robinhood under this warranty are limited to those set out in this certificate,
and this warranty is expressly instead of all other warranties, express or implied, including any implied warranty of
merchantability or fitness for a particular purpose and notwithstanding any course of dealing between the parties or
custom and usage in trade to the contrary.
Should warranty ser ice be required, please contact Robinhood:
Free Phone: [phone]
Free Fax: [phone]
Email: [e-mail]
Website: www.robinhood.com.au
Terms and conditions are subject to change without notice.
New Ze l nd
Robinhood Ltd
Telephone: [phone]
Facsimile: 0800 276 246
Email: [e-mail]
www.robinhood.co.nz
Austr li
Robinhood PTY Ltd
Telephone: [phone]
Facsimile: 1800 628 577
Email: [e-mail]
www.robinhood.com.au
