Robot Coupe R 201 User manual

R 201 • R 201 Ultra

11
SUMMARY
WARRANTY
IMPORTANT WARNING
INTRODUCTION TO YOUR NEW
R 201 • R 201 Ultra BOWL CUTTER /
VEGETABLE PREPARATION ATTACHMENT
SWITCHING ON THE MACHINE
•Advice electrical connections
•Control panel
ASSEMBLY
•Bowl cutter attachment
•Vegetable preparation attachment
EXAMPLES
•Bowl cutter attachment
•Vegetable preparation attachment
OPTIONS
CLEANING
•Motor base
•Bowl cutter attachment
•Vegetable preparation attachment
•Blade
MAINTENANCE
•Blade
•Motor seal
•Bowl locating plates
TECHNICAL SPECIFICATIONS
•Weight
•Dimensions
•Working height
•Noise level
•Electrical data
SAFETY
STANDARDS
TECHNICAL DATA
•Exploded views
•Electrical and wiring diagrams

12
ROBOT-COUPE S.N.C., LIMITED WARRANTY
Your new ROBOT-COUPE appliance is
warranted to the original buyer for a
period of one year from the date of sale if
you bought it from ROBOT-COUPE S.N.C.
If you bought your ROBOT-COUPE product
from a distributor your product is covered
by your distributor’s warranty (Please
check with your distributor terms and
conditions of the warranty).
The ROBOT-COUPE S.N.C. limited warranty
is against defects in material and/or
workmanship.
The ROBOT-COUPE S.N.C. warranty is
given expressly and in lieu of all other
warranties, expressed or implied, for
merchantability and for fitness toward a
particular purpose and constitutes the only
warranty made by ROBOT-COUPE S.N.C.
France.
THE FOLLOWING ARE NOT
COVERED BY THE ROBOT-COUPE
S . N . C . WARRANTY:
1-Damage caused by abuse, misuse,
dropping, or other similar damage caused by
or resulting from failure to follow assembly,
operating, cleaning, user maintenance or
storage instructions.
2-Labour to sharpen and/ or replacements
for blades which have become blunt, chipped or
worn after a normal or excessive period of use.
3-Materials or labour to replace or repair
scratched, stained, chipped, pitted, dented or
discoloured surfaces, blades, knives, attachments
or accessories.
4-Any alteration, addition or repair that has
not been carried out by the company or an
approved service agency.
5-Transportation of the appliance to or from
an approved service agency.
6-Labour charges to install or test new
attachments or accessories (i.e., bowls, discs,
blades, attachments) which have been arbitrarity
replaced.
7-The cost of changing direction-of-rotation
of three-phase electric motors (Installer is respon-
sible).
8-SHIPPING DAMAGES. Visible and latent
defects are the responsibility of the freight
carrier. The consignee must inform the carrier
and consignor immediately, or upon discovery in
the case of latent defects.
KEEP ALL ORIGINAL CONTAINERS AND
PACKING MATERIALS FOR CARRIER
INSPECTION.
Neither ROBOT-COUPE S.N.C. nor its affiliated
companies or any of its distributors, directors,
agents, employees, or insurers will be liable for
indirect damage, losses, or expenses linked to
the appliance or the inability to use it.

13
WARNING: In order to limit accidents such as electric shocks, personal injury or fire, and in order to limit material damage due to
misuse of the appliance, please read these instructions carefully and follow them strictly. Reading the operating instructions will
help you get to know your appliance and enable you to use the equipment correctly. Please read these instructions in their entirely
and make sure that anyone else who may use the mixer also reads them beforehand.
IMPORTANT WARNING
UNPACKING
• Carefully remove the equipment from the packa-
ging and take out all the boxes or packets contai-
ning attachments or specific items.
• WARNING - some of the tools are very sharp
e.g. blade, discs... etc.
INSTALLATION
• We recommend you install your machine on a
perfectly stable solid base.
CONNECTION
• Always check that your mains supply corresponds
to that indicated on the rating plate on the motor
unit and that it can take the amperage.
• The machine must be earthed.
HANDLING
• Always take care when handling the blades or
discs - they are very sharp.
ASSEMBLY PROCEDURES
• Follow the various assembly procedures carefully
(see page 14) and make sure that all the attachments
are correctly positioned.
USE
• Never try to override the locking and safety
systems.
• Never introduce any object into the container
where the food is being processed.
• Never push the ingredients down with your hand.
• Do not overload the appliance.
• Never switch the appliance on while it is empty.
CLEANING
• As a precaution, always unplung your appliance
before cleaning it.
• Always clean the appliance and its attachments at
the end of each cycle.
• Never place the motor unit in water.
• For parts made of aluminum alloys, use cleaning
fluids suitable for aluminum.
• For plastic parts , do not use detergents that are
too alkaline (i.e., containing too much caustic soda
or ammonia...).
• Robot-Coupe can in no way be held responsible
for the user’s failure to follow the basic rules of clea-
ning and hygiene.
MAINTENANCE
• Before opening the motor housing, it is absolutely
vital unplung the appliance.
• Check the seals and washers regularly and
ensure that the safety devices are in good working
order.
• It is particularly important to maintain and check
the attachments since certain ingredients contain
corrosive agents e.g. citric acid.
• Never operate the appliance if the power cord
or plug has been damaged in any way or if the
appliance fails to work properly or has been damaged
in any way.
• Do not hesitate to contact your local Maintenance
Department if something appears to be wrong.
KEEP THESE INSTRUCTIONS
IN A SAFE PLACE
WARNING

14
INTRODUCTION TO YOUR
NEW R 201 • R 201 Ultra
BOWL CUTTER/VEGETABLE
PREPARATION ATTACHMENT
The R 201/R 201 Ultra is perfectly geared to
professional needs. It can perform any number of
tasks, which you will gradually discover as you use it.
This food processor consists of a bowl cutter and
a vegetable preparation lid with ejection into
the bowl. In cutter mode, it can be used to process
meat, vegetables, fine stuffing, mousse, grinding,
kneading,… in less than 5 minutes for even the
longest tasks. In the vegetable preparation version,
the device has a wide range of discs for thin slicing,
grating and julienne vegetables.
Its numerous functions will open the door to a whole
new culinary world.
Thanks to its simple design, all components requi-
ring frequent handling for maintenance or cleaning
can be fitted and removed in a trice
To make things easier for you, this manual gives a
breakdown of all the various fitting operations.
This manual contains important information designed
to help the user get the most out of his or her R 201/
R 201 Ultra bowl cutter/vegetable preparation device.
We therefore recommend that you read it carefully
before using your machine.
We have also included a few examples to help you
get the feel of your new machine and appreciate its
numerous advantages.
SWITCHING ON
THE MACHINE
• ADVICE ON ELECTRICAL CONNECTIONS
Before plugging in, check that your power supply
corresponds to that indicated on the machine’s
identification plate.
The R 201/R 201 Ultra is fitted with various types
of motors : 230 V / 50 Hz /1
115V/60Hz/1
220V/60HZ/1
The machine comes with a single phase plug
connected to a power cord.
• CONTROL PANEL
R 201
Red switch = Off switch
Green switch = On switch
R 201 Ultra
Red switch = Off switch
Green switch = On switch
Black switch = Pulse switch
ASSEMBLY
• BOWL CUTTER
ATTACHMENT
1) With the motor base
facing you, make sure
that the bowl is straight
in relation to the motor
shaft, with the safety pin
moved slightly to the left.
3) Engage the blade on
the motor shaft and
lower it right to the
bottom of the bowl.
Make sure that it is
correctly positioned, by
rotating it in the bowl.
2) Turn the bowl to the
right until the motor base
connectors are securely
positioned in their soc-
kets. The safety pin
should now be straight in
front of you, in contact
with the front of the mo-
tor base.
4) Place the lid on the
bowl so that the large
feed-hopper is facing
you. Rotate to the right
until it locks.
Once contact is made, your device is ready for use.
WARNING
THIS APPLIANCE MUST BE PLUGGED INTO
AN EARTHED SOCKET (RISK OF ELECTROCUTION).

15
• VEGETABLE SLICER ATTACHMENT
Follow the same procedure as for the cutter attach-
ment for points 1) and 2).
3) Fit the extension piece
onto the motor shaft.
4) Fit the disc of your
choice onto the extension
piece.
5) Place the lid on the bowl so that the large feed-
hopper is facing you. Close the lid by rotating to the
right until it locks.
EXAMPLES
• BOWL CUTTER ATTACHMENT
The cutter will enable you to perform all your
cutting tasks in minimum time; we recommend
therefore, that you keep a close eye on the mixture
in order to obtain the desired results.
The pulse control allows you to stop and start the
machine for high-precision control when working
with certain types of ingredients.
The cutter version has numerous other applications.
The above quantities and times are approximate
and may vary according to the quality of the
ingredients and recipes.
• VEGETABLE PREPARATION ATTACHMENT
The vegetable preparation attachment consists of
two hoppers:
-one large hopper for cutting vegetables such as
cabbage, celeriac, etc.
-a cylindrical hopper for long vegetables and
high-precision cutting.
KNEAD
Shortcrust pastry/shortbread 1 4
Pizza dough 1 4
GRIND
Dried fruit 0.5 4
Ice 0.5 4
Breadcrumbs 0.5 5
SLICERS
S1 carrot / cabbage / cucumber / onion / potato / leek
S2/S3 lemon / carrot / mushroom / cabbage / potato / cucumber /
zucchini / onion / leek / bell pepper
S4/S5 eggplant / beet root / carrot / mushroom / cucumber / bell pepper /
radish / lettuce / potato / leek / tomato
S6 eggplant / beet root / carrot / mushroom / cucumber / bell pepper /
radish / lettuce / potato / leek
RIPPLE CUT SLICER
S2 beet root / potato / carrot
Max.
USES
processing Processing
quantity time
(in kg) (in mn)
CHOP
• MEAT
Hamburgers/steak tartare 0.7 3
Sausagemeat/tomatoes 0.8 3
Terrine/pâté 0.8 4
• FISH
Brandade 0.9 5
Terrines 0.9 5
• VEGETABLES
Garlic/parsley/onion/shallots 0.2 / 0.5 3
Soup / purées 1 4
• FRUIT
Compotes /purées 1 4
EMULSIFY
Mayonnaise / ailloli /
remoulade sauce 13
Snail or salmon butter 0.8 4

16
OPTIONS
Aserrated blade is avai-
lable as an option and is
mainly intended for knea-
ding and grinding.
Aslightly serrated blade is
also available. This blade
has the same function as a
straight blade. It has been
conceived for a longer las-
ting cut performance but
with no sharpening possibi-
lity.
We advise you to use this blade mainly to chop
parsley.
CLEANING
MAINTENANCE
• BLADE
We strongly recommend that the blades (smooth
ones) are sharpened daily using sharpening stone
supplied with machine
The quality of the cut depends mainly on the
sharpness of your blades and the degree of wear.
The blades are actually wearing parts, which
should be replaced occasionally to ensure consistent
quality in the final product.
• MOTOR SEAL
The gasket on the motor shaft should be lubricated
regularly using a food safe lubricant.
In order to keep the motor completely watertight, it
is advisable to check the gasket regularly for wear
and tear and replace if necessary.
The gasket can be easily replaced without having to
remove the motor, so we strongly advise you to
ensure that it is in good running order.
• BOWL LOCATING PLATES
If these plates wear out, the bowl will no longer be
securely attached to the motor base.
This makes it awkward to use since the bowl can
come loose during processing.
There is no risk to the user however, because the
safety system will automatically stop the machine.
It is advisable therefore to change these plates in
order to ensure maximum ease of use.
WARNING
IMPORTANT
G9 cabbage / cheese
Parmesan / chocolate
Radish 0.7 mm
Radish 1 mm
• MOTOR BASE
Never immerse the motor base in water. Clean
using a damp cloth or sponge.
• BOWL CUTTER ATTACHMENT
After removing the lid, remove the bowl from
the motor base by rotating it to the left. Pull up to
disengage, leaving the blade in the bowl in order to
prevent any spillage when working with liquids.
If the food has a solid consistency, remove the blade
and empty the bowl.
Replace the bowl, place the blade back on the shaft
and switch on the machine in order to remove any
mixture which may have stuck to the blade.
If you wish, you can rinse the bowl by filling it with
hot water and switching on for a few minutes.
• VEGETABLE PREPARATION ATTACHMENT
After removing the lid, by rotating to the left, pull
out the disk by raising it by the edges. Next remove
the extension piece, then pull out the bowl by rota-
ting in a clockwise direction.
Next clean all the parts.
Whatever the attachment, we recommend that you
clean it by hand using washing-up liquid rather
than in a machine. This will help your machine to
last longer.
• BLADE
After cleaning the blade, always dry the blades
well.
GRATERS
G 1,5 celeriac / cheese
G2 carrot / celeriac / cheese
G3 carrot
G6 cabbage / cheese
JULIENNE
J 2x2 carrot / celeriac / potato
J 2x4 carrot / beet root / zucchini / potato
J 2x6 carrot / beet root / zucchini / potato
J 4x4 eggplant / beet root / zucchini / potato
J 6x6 eggplant / beet root / celeriac / zucchini / potato
J 8x8 celeriac / potato
Check that your detergent is suitable for
cleaning plastic parts. Some washing agents
are too alkaline (e.g. high levels of caustic
soda or ammonia) and totally incompatible
with certain types of plastic, causing them to
deteriorate rapidly.
As a precaution, always unplug your appliance
before cleaning it (risk of electrocution).

17
SAFETY
The R 201 / R 201 Ultra is fitted with an electro-
mechanical safety system.
As soon as you open the lid, the motor stops.
To restart the machine, simply close the lid.
In order to avoid splash when processing liquid
preparation in the cutter bowl, we recommend you
to stop the machine before opening the lid.
The R 201 / R 201 Ultra is fitted with a thermal
cut-out which automatically stops the motor if the
machine is left on for too long or overloaded.
If this happens, allow the machine to cool comple-
tely before restarting.
REMENBER
WARNING
TECHNICAL
SPECIFICATIONS
• WEIGHT
net weight gross weight
R 201 complete
(with 2 discs) 10 kg 12 kg
R 201 Ultra complete
(with 2 discs) 10 kg 12 kg
• DIMENSIONS (in mm)
Speed Power Intensity
Motor (rpm) (watts) (Amp.)
230 V / 50Hz 1500 550 14.3
115V/60Hz 1800 550 18.0
220V/60Hz 1800 550 14.3
• WORKING HEIGHT
We recommend that you position the food processor
on a stable worktop so that the upper edge of the
large feed hopper is at a height of between 1.20 m
and 1.30 m.
• NOISE LEVEL
The equivalent continuous sound level when the
food processor is operating on no-load is less than
70 dB(A).
• ELECTRICAL DATA
single-phase machine
STANDARDS
MACHINES IN COMPLIANCE WITH:
• The following European directives and related na-
tional legislation:
- Modified "machinery" directive 98/37/EEC,
- "Low voltage" directive 73/23/EEC,
- "EMC" directive 89/336/EEC,
- "Materials and parts in food contact" directive
89/109/EEC,
- Commission Directive 2002/72/EC of 6 August
2002 relating to plastic materials and articles
intended to come into contact with foodstuffs.
• The following European harmonized standards
and standards setting out health and safety rules:
-EN292-1and-2,
- EN 60204 -1 (1998),
- For Food Processors and blenders : EN 12852,
- For Vegetable cutting machine : EN 1678.
The blades are extremely sharp. Handle with
care.
Never try to override the locking and safety
systems.
Never introduce any object into the container
where the food is being processed.
Never push the ingredients down with your
hand.
Do not overload the appliance.
Never switch the appliance on while it is
empty.

76

77

78

79

81

82

83

Réf. : 401 822-02/2008
MADE IN FRANCE BY ROBOT-COUPE S.N.C.
Export Department
Tel.:[phone]-Fax:[phone]
48, rue des Vignerons - BP 157
94305 Vincennes Cedex - France
http://www.robot-coupe.com - email : [email protected]
We reserve the right to alter at any time without notice the technical specifications of this appliance.
None of the information contained in this document is of a contractual nature. Modifications may be made at any time.
© All rights reserved for all countries by: ROBOT-COUPE s.n.c.
