QUICK START
ARMORSTART®DISTRIBUTED
MOTOR CONTROLLER —
SAFETY VERSION
Getting Started
BULLETIN 280D/281D
Introduction This guide provides the basic information required to start up your
ArmorStart®Distributed Motor Controller. Factory default settings
and information regarding installing, programming, and DeviceNet™
Node Commissioning are described here. For detailed information on
specific product features or configurations, refer to the ArmorStart
user manual, publication 280-UM004*-EN-P.
This guide is intended for qualified service personnel responsible for
setting up and servicing these devices. You must have previous
experience with and a basic understanding of electrical terminology,
configuration procedures, required equipment, and safety precautions.
You should understand DeviceNet network operations, including how
slave devices operate on a network and communicate with a
DeviceNet master. You should also be familiar with RSNetWorx™
for DeviceNet. You must use RSNetWorx for DeviceNet Revision
3.21 Service Pack 2 or later. This software package is referred to
often in this manual. Rockwell Automation product EDS files are
available on the internet at: http://www.ab.com/networks/eds.
Note: The Bulletin 280D/281D Safety ArmorStart is suitable for
safety applications up to Safety Category 4PL e (TÜV
assessment per ISO 13849-1:2008). TÜV compliance letter is
available upon request.

2
Publication 280D-QS002A-EN-P - July 2009
Installation The ArmorStart Distributed Motor Controller is convection cooled.
Operating temperature must be kept between -20…40°C (-4…104°F).
Dimensions Dimensions are shown in millimeters (inches). Dimensions are not intended
to be used for manufacturing purposes. All dimensions are subject to
change.
Figure 1 Dimensions for Bulletin 280D Safety Product, IP67/NEMA Type 4 with
Conduit Entrance

Publication 280D-QS002A-EN-P - July 2009
3
Dimensions are shown in millimeters (inches). Dimensions are not intended
to be used for manufacturing purposes. All dimensions are subject to
change.
Figure 2 Dimensions for Bulletin 280D Safety Product, IP67/NEMA Type 4 with
ArmorConnect™ Connectivity
ArmorStart device with a 10 A short circuit protection rating ArmorStart device with a 25 A short circuit protection rating

4
Publication 280D-QS002A-EN-P - July 2009
Dimensions are shown in millimeters (inches). Dimensions are not intended
to be used for manufacturing purposes. All dimensions are subject to
change.
Figure 3 Dimensions for Bulletin 281D Safety Product, IP67/NEMA Type 4 with
Conduit Entrance

Publication 280D-QS002A-EN-P - July 2009
5
Dimensions are shown in millimeters (inches). Dimensions are not intended
to be used for manufacturing purposes. All dimensions are subject to
change.
Figure 4 Dimensions for Bulletin 281D Safety Product, IP67/NEMA Type 4 with
ArmorConnect Connectivity
ArmorStart device with a 10 A short circuit protection rating ArmorStart device with a 25 A short circuit protection rating

6
Publication 280D-QS002A-EN-P - July 2009
Wiring Power and Ground Wiring
Table 1 provides the power and ground wire capacity and the tightening
torque requirements. The power, control, ground, and safety monitor
terminals will accept a maximum of two wires per terminal.
Table 1 Power and Ground Wire, Size and Torque Specifications
Terminal Designations for
Conduit Entrance
As shown in Figure 5, the ArmorStart Distributed Motor Controller contains
terminals for power, control, safety monitor inputs, and ground wiring.
Access can be gained by removing the terminal access cover plate.
Figure 5 ArmorStart Power, Control, and Safety Monitor Input Terminals
Terminals Wire Size Torque Wire Strip Length
Power
and
Ground
Primary Terminal:
1.3…5.3 mm2
(#16 …#10 AWG)
Secondary Terminal:
0.8…5.3 mm2
(#18 …#10 AWG)
Primary Terminal:
10.8 lb•in
(1.2 N•m)
Secondary Terminal:
4.5 lb•in
(0.5 N•m)
0.35 in. (9 mm)

Publication 280D-QS002A-EN-P - July 2009
7
Table 2 Power, Control, Safety Monitor, and Ground Terminal Designations
Terminal Designations No. of Poles Description
SM1 2 Safety Monitor Input
SM2 2 Safety Monitor Input
A1 (+) 2 Control Power Input
A2 (-) 2 Control Power Common
PE 2 Ground
1/L1 2 Line Power Phase A
3/L3 2 Line Power Phase B
5/L5 2 Line Power Phase C

8
Publication 280D-QS002A-EN-P - July 2009
Figure 6 Safety System Overview
Configuration of the
1732DS-IBXOBV4 Safety I/O
Note: To comply with TÜV, the 1732DS-IBXOBV4 Safety I/O module
must be configured as indicated below:
Configure the output that is connected to the I/O output cable assembly for:
• Dual (bipolar mode)
• Safety Pulse Test
Configure the input that is connected to the I/O Input cable assembly as
follows:
• Channel = Single
• Mode = Pulsed Test Input from test output X
• Source = Pulsed output from X
Safety PLC Program The program must:
• Force the output contactors to the open state when a safety-related stop
is demanded.
• Force the output contactors to remain in the open state if the SM
feedback is open after a safety-related stop is executed (see Notes).
Note: The program must inhibit the contactor closure to satisfy safety
Category 4 of 13849-1.
Note: The SM feedback logic should be implemented only after a
safety-related stop for the Bulletin 280D/281D controllers. It
should be ignored during normal operation. One of the series
contactors is used for the normal stop/start function for these
controllers. Therefore, a malfunctioning contactor circuit cannot be
distinguished from a normal running state.
DeviceNet Media
I/O input
I/O output
Aux. Power
ArmorConnect
The 1732DS Safety I/O module outputs to
provided 24V DC power for control power
to the ArmorStart - A1/A2 control power
The 1732DS Safety I/O module inputs will monitor the status of the safety-rated contactors inside the ArmorStart.
input
Three-Phase Power Media

Publication 280D-QS002A-EN-P - July 2009
9
ArmorStart Safety with ArmorConnect Connectivity
Three-Phase Power Receptacle
ArmorStart devices with 10 A short
circuit protection rating
ArmorStart devices with 25 A short
circuit protection rating
A1/A2 -24V DC
1732DS Safety
I/O Module Output
Control Power from
Ground
Terminal
Safety Monitor
Input from
1732DS Safety
I/O Module Input
Three-Phase Power Receptacle
A1/A2 -24V DC
1732DS Safety
I/O Module Output
Control Power from
Ground
Terminal
Safety Monitor
Input from
1732DS Safety
I/O Module Input
Ground
Terminal
Safety Monitor
Input from
1732DS Safety
I/O Module Input
A1/A2 -24V DC
Control Power from
1732DS Safety
I/O Module Output
ArmorStart devices with conduit entrance
Three-Phase Power Receptacle

10
Publication 280D-QS002A-EN-P - July 2009
Terminal Designations
ArmorConnect Cable Ratings
The ArmorConnect Power Media cables are rated per UL Type TC
600V 90 °C Dry 75 °C Wet, Exposed Run (ER) or MTW 600V 90 °C or
STOOW 105 °C 600V - CSA STOOW 600V FT2. For additional
information regarding ArmorConnect Power Media see the ArmorStart
User Manual.
Branch Circuit Protection Requirements for ArmorConnect™
Three-Phase Power Media
When using ArmorConnect Three-Phase Power Media, only fuses can be
used for the motor branch circuit protective device, for the group motor
installations. The recommended fuse types are the folowing: Class CC, T, or
J type fuses. For additional information, see the ArmorStart User Manual.
Group Motor Installations for USA and Canada Markets
The ArmorStart Distributed Motor controllers are listed for use with each
other in group installations per NFPA 79, Electrical Standard for Industrial
Machinery. When applied according to the group motor installation
requirements, two or more motors, of any rating or controller type, are
permitted on a single branch circuit. Group Motor Installation has been
successfully used for many years in the USA and Canada.
Wiring and Workmanship Guidelines
In addition to conduit and seal-tite raceway, it is acceptable to utilize cable
that is dual rated Tray Cable, Type TC-ER and Cord, STOOW, for power
and control wiring on ArmorStart installations. In the USA and Canada
installations, the following guidance is outlined by the NEC and NFPA 79.
Terminal
Designations Description Color Code
SM1 Safety Monitor Input Brown
SM2 Safety Monitor Input White
A1 (+) Control Power Input Brown
A2 (-) Control Power Common Blue
PE Ground Green/Yellow
1/L1 Line Power - Phase A Black
3/L2 Line Power - Phase B White
5/L3 Line Power - Phase C Red

Publication 280D-QS002A-EN-P - July 2009
11
In industrial establishments where the conditions of maintenance and
supervision ensure that only qualified persons service the installation, and
where the exposed cable is continuously supported and protected against
physical damage using mechanical protection, such as struts, angles, or
channels, Type TC tray cable that complies with the crush and impact
requirements of Type MC (Metal Clad) cable and is identified for such use
with the marking Type TC-ER (Exposed Run)* shall be permitted between
a cable tray and the utilization equipment or device as open wiring. The
cable shall be secured at intervals not exceeding 1.8 m (6 ft) and installed in
a “good workman-like” manner. Equipment grounding for the utilization
equipment shall be provided by an equipment grounding conductor within
the cable.
*Historically cable meeting these crush and impact requirements were
designated and marked “Open Wiring”. Cable so marked is equivalent to the
present Type TC-ER and can be used.
While the ArmorStart is intended for installation in factory floor
environments of industrial establishments, the following must be taken into
consideration when locating the ArmorStart in the application: Cables,
including those for control voltage including 24V DC and communications,
are not to be exposed to an operator or building traffic on a continuous
basis. Location of the ArmorStart to minimize exposure to continual traffic
is recommended. If location to minimize traffic flow is unavoidable, other
barriers to minimize inadvertent exposure to the cabling should be
considered. Routing cables should be done in such a manner to minimize
inadvertent exposure and/or damage.
Additionally, if conduit or other raceways are not used, it is recommended
that strain relief fittings be utilized when installing the cables for the control
and power wiring through the conduit openings.
The working space around the ArmorStart may be minimized as the
ArmorStart does not require examination, adjustment, servicing or
maintenance while energized. In lieu of this service, the ArmorStart is
meant to be unplugged and replaced after proper lockout/tag-out procedures
have been employed.
Since the ArmorStart is available with a factory installed HOA keypad
option this may require the ArmorStart to be selected and installed as
follows if the application requires frequent use of the hand operated
interface by the equipment operator:
1. They are not less than 0.6 m (2 ft) above the servicing level and are
within easy reach of the normal working position of the operator.
2. The operator is not placed in a hazardous situation when operating
them.
3. The possibility of inadvertent operation is minimized.

12
Publication 280D-QS002A-EN-P - July 2009
If the operated interface is used in industrial establishments where the
conditions of maintenance and supervision ensure that only qualified
persons operate and service the ArmorStart's operator interface, and the
installation is located so that inadvertent operation is minimized then other
installation locations with acceptable access can be provided.
DeviceNet Network Installation
The ArmorStart Distributed Motor Controller contains the equivalent of
30 in. (0.76 m) of DeviceNet drop cable's electrical characteristics and
therefore 30 in. of drop cable must be included in the DeviceNet drop cable
budget for each ArmorStart in addition to actual drop cable required for the
installation.
Other DeviceNet System Design Considerations
The separation of the control power and DeviceNet power is recommended
as a good design practice. This minimizes the load on the DeviceNet supply,
and prevents transients which may be present on the control power system
from influencing the communication controls.

Publication 280D-QS002A-EN-P - July 2009
13
LED Status Indication The LED Status Indication provides 4 status LEDs and a Reset button. The
LEDs provide status indication for the following:
• POWER LED
The LED is illuminated solid green when control power is present and
with the proper polarity
• RUN LED
This LED is illuminated solid green when a start command and control
power are present
•NETWORKLED
This bi-color (red/green) LED indicates the status of the
communication link
•FAULTLED
Indicates Controller Fault (trip) condition
The “Reset Button” as a local trip reset.
Figure 7 LED Status Indication and Reset
DeviceNet Node Commissioning Establishing a DeviceNet Node Address
The ArmorStart is shipped with a default node address of 63 and Autobaud
enabled. Each device on a DeviceNet network must have a unique node
address or MAC ID which can be set to a value from 0…63. Keep in mind
that most DeviceNet systems use address 0 for the master device (Scanner)
and node address 63 should be left vacant for introduction of new slave
devices. The ArmorStart offers two methods for node commissioning as
shown in the following pages.
Node Commissioning using Software
To set the node address of the ArmorStart using software or other handheld
tools, leave the hardware rotary switches in their default position (99) or
insure that they are set to something greater then (63). With the hardware
switches set, use the software or handheld tool to change the address.
When using software to node commission a device, it may be necessary to
have the EDS file stored on the computer. The EDS file defines how the
software such as RSNetWorx for DeviceNet will communicate to the
ArmorStart. Rockwell Automation product EDS files are available on the
internet at: http://www.ab.com/networks/eds. You must use RSNetWorx
for DeviceNet Revision 3.21 Service Pack 2 or later.

14
Publication 280D-QS002A-EN-P - July 2009
Node Commissioning using Hardware
The ArmorStart is shipped with the hardware rotary switches set to a value
of (99). If the switches are set to a value of (64) or above, the device will
automatically configure itself to the software node address. If the switches
are set to a value of (63) or less, the device will be at the node address
designated by the switch configuration.
To set an address using the hardware rotary switches, simply set the
switches to the desired node address. To access the node address rotary
switches, three-phase and control power should be turned off. Then remove
the starter module from the base unit. The rotary node address switches are
located on the back side of the starter module. Change the switches to the
desired node address. Re-install the starter module to the base unit. Reapply
power and the device will re-start at the new address.
Figure 8 Rotary Node Address Configuration
System Configuration Information
The following information is provided to identify the default method for
setting up communication to the ArmorStart. Additional configuration
information and advanced settings help can be found in the
ArmorStart User Manual, Publication 280-UM001*-EN-P.
Using Automap feature with default Input and Output (I/O) assemblies
The Automap feature available in all Rockwell Automation scanners will
automatically map the information as shown below. If manual mapping is
LSD
LSD
MSD
MSD
See Detail A
Detail A

Publication 280D-QS002A-EN-P - July 2009
15
required, the information below can be used to map a device based on the
default configuration.
Table 3 Default I/O Messaging Data
Default Input and Output (I/O) Assembly Formats
The I/O assembly formats for the ArmorStart are identified by the value in
parameter 11 (Consumed IO Assy.) and parameter 12 (Produced IO Assy.).
These values determine the amount and arrangement of the information
communicated to the master scanner. The tables below identify the default
information produced and consumed by DOL (Bulletin 280) and Reversing
(Bulletin 281) devices. For additional formats and advance configurations
please reference the user manual:
Defaults for Standard Distributed Motor Controllers
Table 4 Instance 160 - Default Consumed data for Standard Distributed Motor
Controller Output information arrangement (1 byte)
Table 5 Instance 161 - Default Produced data for Standard Distributed Motor
Controller Input information arrangement (2 bytes)
Setting the Motor FLA and Overload Trip Class
The product should now be configured and communicating on the network.
The last step is to program the proper motor FLA setting (parameter #106)
and overload trip class (parameter #107). This can be accomplished by
using software such as RSNetWorx for DeviceNet or a handheld DeviceNet
tool.
Default
Message type Polled
Consumed data size 1 byte (Rx)
Produced data size 2 bytes (Tx)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0UserOut
B
UserOut
A
Not
Used
Not
Used
Not
Used
Fault
Reset Run Rev Run Fwd
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0Not
Used
Not
Used
Not
Used Ready Running Rev
Running
Fwd Warning Tripped
1Not
Used
Not
Used
140M
On
HOA
Status User In 3 User In 2 User In 1 User In 0

16
Publication 280D-QS002A-EN-P - July 2009
Use the software to access the device parameters screen. By default the
motor FLA is set to the minimum FLA setting for the device and the
overload trip class is set to 10. Set these parameters to the desired values
and download to the device.
Select FLA setting (parameter #106) and enter a value that corresponds to
the FLA of the motor connected to the ArmorStart. Make sure the Single
radio button is selected and then select Download to Device.
Select Overload Class (parameter #107) and choose the overload trip class
to be used with the motor connected to the ArmorStart. The ArmorStart can
be set up for trip class 10, 15, or 20. Make sure the Single radio button is
selected and then select Download to Device.
The proper motor protection is now in place.
Figure 9 RSNetWorx Parameter Screen

Publication 280D-QS002A-EN-P - July 2009
17
Quick Reference
Troubleshooting
There are four LEDs on the front of the ArmorStart that can provide an
indication as to the health of the device. The following is a brief explanation
of the operation of each LED.
Table 6 LED Status Indication
Table 7 Network LED Status Indication
LED Definition
Power This LED will be illuminated solid green when control power is present and
with the proper polarity.
Run This LED will be illuminated solid green when a start command and control
power is present.
Network This bi-color LED is used to indicate the status of the DeviceNet network. See
the Network Status LED table below for additional information.
Fault
This LED is used to indicate the fault status of the ArmorStart. When the unit is
faulted, the unit will respond with a specific blink pattern to identify the fault.
See the Fault LED table below for additional information.
Network Status LED Definition Possible Causes
Off The device has not completed the initialization, is not on an
active network, or may not be powered up.
Check to make sure the product is properly wired and
configured on the network.
Flashes green-red-off While waiting to detect the network baud rate, the LED will
flash this pattern about every 3 seconds.
If the product stays in this state it means that there is no set
baud rate. Insure that at least one device on the network
has a set baud rate.
Solid Green The device is operating in a normal condition, and is
communicating to another device on the network.
No action required.
Flashing Green The device is operating in a normal condition, is on-line, but
with no connection to another device. This is the typical
state for new devices.
The device may need to be mapped to a master scanner,
placed in a scanlist, or have another device communicate to
it.
Flashing Red Recoverable fault has occurred. Check to make sure the PLC and scanner are operating
correctly and that there are no media/cabling issues. Check
to see if other networked devices are in a similar state.
Solid Red The device has detected a major error that has rendered it
incapable of communicating on the network (Duplicate
MAC ID, Bus-off, media issue).
Troubleshooting should be done to ensure that the network
is correct (terminators, lengths, etc.) and there is not a
duplicate node problem. If other devices on the network
appear to be operating fine and power cycling the device
does not work, contact Technical Support.
Flashing Red and Green The device is in a communication faulted state. Power cycling the device may resolve the problem;
however, if the problem continues, it may be necessary to
contact Technical Support.

18
Publication 280D-QS002A-EN-P - July 2009
Fault LED indications for
Bulletin 280D and 281D
ArmorStart Distributed Motor
Controllers Table 8 Controller Fault LED Definitions
Blink
Pattern Definitions Possible Causes or Remedies
1
Short Circuit The motor circuit protector has tripped, or the internal wiring protection algorithm has detected an unsafe
current range. Try to reset the protector if tripped. If the condition continues, check the power wiring. This
fault cannot be disabled.
2Overload trip The load has drawn excessive current and based on the trip class selected, the device has tripped. Verify
that the load is operating correctly and the ArmorStart is properly set-up. This fault cannot be disabled.
3Phase Loss The ArmorStart has detected a missing phase. Verify that three-phase voltage is present at the line side
connections. This fault can be disabled and is disabled by default.
4 Reserved Not Used
5 Reserved Not Used
6
Control Power The ArmorStart has detected a loss of the control power voltage. Check control voltage, wiring, and proper
polarity. Also, check and replace the control voltage fuse ,if necessary. This fault can be disabled and is
disabled by default.
7
I/O Fault This error indicates a shorted sensor, shorted input device, wiring input mistakes, or a blown output fuse. If
this fault occurs, the offending problem should be isolated or removed prior to restarting the system. This
fault can be disabled and is disabled by default.
8 Over Temperature This fault is generated when the operating temperature has been exceeded. This fault cannot be disabled.
9Phase Imbalance The ArmorStart has detected a voltage imbalance. Check the power system and correct if necessary. This
fault can be disabled and is disabled by default.
10 DNet Power Loss DeviceNet power has been lost or has dropped below the 12V threshold. Check the state of the network
power supply and look for DeviceNet media problems. This fault can be disabled and is disabled by default.
11 Reserved Not Used
12 Reserved Not Used
13
EEPROM Fault This is a major fault, which renders the ArmorStart inoperable. Possible causes of this fault are transients
induced during EEprom storage routines. If the fault was, initiated by a transient, power cycling should
clear the problem otherwise replacement of the ArmorStart may be required. This fault cannot be disabled.
14
Hardware Fault This fault indicates that a serious hardware problem exists. Check for a base/starter module mismatch. If
no mismatch exists, the Armor Start may need to be replaced. (Hdw Flt is the factory-enabled default
setting.) This fault cannot be disabled.

Publication 280D-QS002A-EN-P - July 2009
19
Bulletin 280/281 Parameters
Table 9 Starter Display and Parameter Settings
Table 10 FLA Setting Ranges and Default Values (with indicated setting precision)
Parameter Name String Path (hex) Min Max Dflt Type Value
Starter Display
101 Phase A Current 002C – 01 – 08 0 32767 — INT xxx.x Amps
102 Phase B Current 002C – 01 – 09 0 32767 — INT xxx.x Amps
103 Phase C Current 002C – 01 – 0A 0 32767 — INT xxx.x Amps
104 Average Current 002C – 01 – 05 0 32767 — INT xxx.x Amps
105 % Therm Utilized 002C – 01 – 07 0 100 — USINT xxx %
Starter Settings
106 FLA Setting 002C – 01 – 03 See Table 10 below Min I INT xxx.x Amps
107 OL Trip Class 002C – 01 – 04 0 3 1 BYTE
1 = 10
2 = 15
3 = 20
108 OL Reset Level 0029 – 01 – 131 0 100 75 BYTE xxx %
FLA Current Range (A) Default Value
Minimum Value Maximum Value
0.5 2.5 0.5
1.1 5.5 1.1
3.2 16.0 3.2

20
Publication 280D-QS002A-EN-P - July 2009
Figure 10 Bulletin 280D ArmorStart Safety Product with Conduit Entrance
Figure 11 Bulletin 281D ArmorStart Safety Product with Conduit Entrance
LED Status
Indication
Motor
Connection
DeviceNet
Connection
(Mini/M18)
Local Disconnect
2 Outputs
(Micro/M12)
4 Inputs
(Micro/M12)
Ground Terminal
A1/A2 - 24V DC Control Power from
1732DS Safety I/O Module output
Safety Monitor input from
1732DS Safety I/O Module input
LED Status
Indication
Motor
Connection
DeviceNet
Connection
(Mini/M18)
Local Disconnect
2 Outputs
(Micro/M12)
4 Inputs
(Micro/M12)
Ground Terminal
A1/A2 - 24V DC Control Power from
1732DS Safety I/O Module output
Safety Monitor input from
1732DS Safety I/O Module input
