Rockwell Automation Allen-Bradley CENTERLINE 600 User manual

CENTERLINE 600 A One-High
Cabinet, Standard and
Arc-Resistant Enclosure
Bulletin Numbers 1512A, 1512AT, 1512DM, 1512DO, 1512M, 1562E,
1912B, 1912L
User Manual Original Instructions

2Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021
CENTERLINE 600 A One-High Cabinet, Standard and
Important User Information
Read this document and the documents listed in the additional resources section about installation, configuration, and
operation of this equipment before you install, configure, operate, or maintain this product. Users are required to familiarize
themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards.
Activities including installation, adjustments, putting into service, use, assembly, disassembly, and maintenance are required to
be carried out by suitably trained personnel in accordance with applicable code of practice.
If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be
impaired.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use
or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and
requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or liability for
actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or software
described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation, Inc., is
prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
Labels may also be on or inside the equipment to provide specific precautions.
WARNING: Identifies information about practices or circumstances that can cause an explosion in a hazardous environment,
which may lead to personal injury or death, property damage, or economic loss.
ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property
damage, or economic loss. Attentions help you identify a hazard, avoid a hazard, and recognize the consequence.
IMPORTANT Identifies information that is critical for successful application and understanding of the product.
SHOCK HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that dangerous
voltage may be present.
BURN HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that surfaces may
reach dangerous temperatures.
ARC FLASH HAZARD: Labels may be on or inside the equipment, for example, a motor control center, to alert people to
potential Arc Flash. Arc Flash will cause severe injury or death. Wear proper Personal Protective Equipment (PPE). Follow ALL
Regulatory requirements for safe work practices and for Personal Protective Equipment (PPE).

Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021 3
Table of Contents
Preface
Summary of Changes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
About This Publication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Download Firmware, AOP, EDS, and Other Files . . . . . . . . . . . . . . . . . . . . 7
Additional Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 1
General Information Starter Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Recommended Torque Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Recommended Line and Load Cable Sizes . . . . . . . . . . . . . . . . . . . . . . . . . 10
Environmental Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chapter 2
Installation – Standard
Enclosure
Door Opening Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Opening the Low Voltage Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Opening the Medium Voltage Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Anchoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Joining Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Access to the Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Rear Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Side Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Front Access – Top Incoming Line Cables and Power Bus . . . . . . . . 19
Front Access – Bottom Incoming Line Cables. . . . . . . . . . . . . . . . . . . 22
Load Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Chapter 3
Installation – Arc-Resistant Door Opening Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Opening the Low Voltage Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Opening the Medium Voltage Door. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Anchoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Joining Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Access to the Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Rear Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Side Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Front Access to Power Bus (Bottom Entry/Exit). . . . . . . . . . . . . . . . . 34
Front Access – Top Incoming Line Cables (Top Entry/Exit) . . . . . . 35
Load Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Chapter 4
Common Installation Bus Splicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Insulated Power Bus Splicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Ground Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Incoming Line Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021
Hi-Pot and Insulation Resistance Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Start-up Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Contactor Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Preliminary Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Testing Contactor Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Chapter 5
Maintenance Recommended Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Tool Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Door Interlock Circumvention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Power Lock-out Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Fuse Removal and Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Bolt-on Fuse Removal/Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Clip-on Fuse Removal/Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Contactor Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Remove the Contactor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Contactor Interlock Rod Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
To Reduce the Gap Distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
To Increase the Gap Distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Isolation Switch Mechanism Inspection and Maintenance . . . . . . . . . . 59
Isolation Blade Switch Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Isolation Switch Mechanism Grounding Adjustment . . . . . . . . . . . . . . . 64
Auxiliary Contacts Inspection and Replacement . . . . . . . . . . . . . . . . . . . 65
Auxiliary Contacts Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Adjusting the Normally Open (ISa) Contacts . . . . . . . . . . . . . . . . . . . 66
Adjusting the Normally Closed (ISb) Contacts . . . . . . . . . . . . . . . . . . 67
Adjusting the Change-of-State Point . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Emergency Circumvention Procedure for Power Cell Entry . . . . . . . . . 69
Installing Z-clip with Isolation Switch Handle in the
OFF Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Installing Z-clip with Isolation Switch Handle in the
ON Position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Chapter 6
Spare Parts Spare Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Appendix A
ArcShield Unit Information Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
ArcShield Design. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Exhaust Systems: Chimney or Plenum Option . . . . . . . . . . . . . . . . . . . . . 74
Plenum Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Plenum Exhaust Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Additional Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Chimney Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Chimney Exhaust Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021 5
Appendix B
ArcShield Plenum Installation
Instructions
Recommended Torque Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Plenum Bracing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
General Plenum Layout for ArcShield Line-up . . . . . . . . . . . . . . . . . . . . . 81
STEP 1 – Mounting a Single Plenum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Cabinet Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Plenum Placement on Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
STEP 2 – Alignment of Side by Side Plenums. . . . . . . . . . . . . . . . . . . . . . . 84
STEP 3 – Sequence of Final Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
STEP 4 – Closing the Front of the Plenum Sections . . . . . . . . . . . . . . . . . 86
STEP 5 – Extension and Elbow Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . 86
STEP 6 – Mounting Extension/Elbow to Plenum Line-up. . . . . . . . . . . . 87
STEP 7 – Additional Mounting Support . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Appendix C
ArcShield Chimney Installation
Instructions
Recommended Torque Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
General Plenum Layout for ArcShield Line-up . . . . . . . . . . . . . . . . . . . . . 92
Cabinet Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Chimney Placement on Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Appendix D
Integrated Protective
Maintenance Grounding Device
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
IPMG Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Operating Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
IPMG Positioning Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Key Interlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Auxiliary Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
IPMG Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

6Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021
Notes:

Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021 7
Preface
Summary of Changes This publication contains the following new or updated information. This list
includes substantive updates only and is not intended to reflect all changes.
About This Publication This manual pertains to the CENTERLINE® 1500, 600 A medium voltage motor
control center. This MCC structure provides one complete medium voltage
controller unit.
The installation section provides instructions for both the standard enclosure
type and the arc resistant structure type (ArcShield™).
The product Bulletin numbers that are primarily covered by this document are:
• 1512A 600 A FVNR controller
• 1512AT 600 A Transformer Feeder
This document can be used as a reference guide for the following Bulletin
numbers:
• 1512DM 600 A VFD Input Contactor Units
• 1512DO 600 A VFD Output Contactor Units
• 1512M 600 A VFD Output Bypass Starter
• 1562E 600 A MV SMC Flex Solid-State Reduced Voltage Starter Input
Section
• 1912B 600 A Synchronous Controller (Stator)
• 1912L 600 A Brushless Synchronous Controller (Stator)
Download Firmware, AOP,
EDS, and Other Files
Download firmware, associated files (such as AOP, EDS, and DTM), and access
product release notes from the Product Compatibility and Download Center at
rok.auto/pcdc.
Topic Page
Added specific information around using stress cones 23, 36
Added 3000 A power bus graphic 40
Added section on isolation switch maintenance 59
Added attention statement around connecting arc-resistant equipment 73
IMPORTANT This document is to be used for all Bulletin 1512 and Bulletin 1912
unit types, including arc resistant (ArcShield) units. See
Appendix A, Appendix B, and Appendix C for specific ArcShield
information.
ATTENTION: Refer to the information in Appendix A, Appendix B, and
Appendix C to correctly install and maintain ArcShield arc resistant units.
Failure to do so may negate the arc resistant benefits that are provided by
ArcShield, exposing personnel to risk of serious injury or death.

8Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021
Preface
Additional Resources These documents contain additional information concerning related products
from Rockwell Automation.
You can view or download publications at rok.auto/literature.
Resource Description
Medium Voltage Contactor 800 A, 2400…7200V (Series F) User Manual,
publication 1502-UM054 Provides information on handling, installing, maintaining, and troubleshooting 800 A
medium voltage contactors.
EtherNet/IP Network Devices User Manual, ENET-UM006 Describes how to configure and use EtherNet/IP devices to communicate on the EtherNet/IP
network.
Ethernet Reference Manual, ENET-RM002 Describes basic Ethernet concepts, infrastructure components, and infrastructure features.
System Security Design Guidelines Reference Manual, SECURE-RM001 Provides guidance on how to conduct security assessments, implement Rockwell
Automation products in a secure system, harden the control system, manage user access,
and dispose of equipment.
Industrial Components Preventive Maintenance, Enclosures, and Contact
Ratings Specifications, publication IC-TD002 Provides a quick reference tool for Allen-Bradley industrial automation controls and
assemblies.
Safety Guidelines for the Application, Installation, and Maintenance of
Solid-state Control, publication SGI-1.1
Designed to harmonize with NEMA Standards Publication No. ICS 1.1-1987 and provides
general guidelines for the application, installation, and maintenance of solid-state control in
the form of individual devices or packaged assemblies incorporating solid-state
components.
Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 Provides general guidelines for installing a Rockwell Automation industrial system.
Product Certifications website, rok.auto/certifications. Provides declarations of conformity, certificates, and other certification details.

Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021 9
Chapter 1
General Information
Starter Identification A nameplate is attached to the right-side flange of the structure (see Figure 1).
See the nameplate for information such as series number, section number,
NEMA enclosure type, unit ratings, and bus ratings.
Figure 1 - Typical Structure Nameplate
A nameplate is also found in the low voltage compartment (see Figure 2) with
specific unit motor application information.

10 Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021
Chapter 1 General Information
Figure 2 - Typical Unit Nameplate
See these nameplates whenever you contact Rockwell Automation for
assistance. Be prepared to provide such information as series number,
structure series, unit series, diagram schematic, and catalog number.
Recommended Torque
Values
When reinstalling components, or when reassembling the cabinet, tighten the
following bolt sizes to the specified torque values:
Recommended Line and
Load Cable Sizes
Table 1 - Torque Values for Hardware
1/4 in. hardware 8 N•m (6 lb•ft)
5/16 in. hardware 15 N•m (12 lb•ft)
3/8 in. hardware 27 N•m (20 lb•ft)
1/2 in. hardware 65 N•m (48 lb•ft)
Table 2 - Recommended Maximum Line and Load Cable Sizes
Standard Cabinet Arc Resistant Cabinet
Line cables (2) 500 MCM or (1) 750 MCM per phase (1) 500 MCM or (2) 4/0 per phase
Load cables (1) 500 MCM or (2) 250 MCM per phase (1) 500 MCM or (2) 250 MCM per phase

Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021 11
Chapter 1 General Information
Environmental Conditions The controller must accept nominal plant power of 2400V, 3300V, 4200V,
4800V, 5500V, 6600V, 6900V (+5/-15%), or 7200V (+0/-15%), 3 PH,
50/60 Hz (± 3%).
The standard controller must operate in an ambient temperature range of
0…40 °C (32…104 °F) with a relative humidity of up to 95% (noncondensing).
Higher ambient temperature conditions are supported with factory assistance.
Store the equipment in an environment with an ambient temperature range of
-40…+85 °C (-40…+185 °F).
If storage temperature fluctuates or if humidity exceeds 85%, space heaters
must be used to prevent condensation. The equipment must be stored in a
heated building which has adequate air circulation.
Rockwell Automation products are built using materials that comply with
Class 1: Industrial Clean Air sulfur environments as defined in IEC Standard
60654-4 (Operating Conditions for Industrial-Process Measurement and
Control Equipment), and G1 as defined in ISO-S71.04-1985 (Environmental
Conditions for Process Measurement and Control Systems: Airborne
Contaminants).
High Altitude Application
The equipment operates at altitudes from 0…1000 m (0…3300 ft) above sea
level, without derating. For applications above 1000 m (3300 ft), the maximum
current and basic impulse levels (BIL) of the controllers shall be derated, and
vacuum contactors may be compensated for operation at the specified altitude
(see publication 1500-SR020).
WARNING: Do not store the equipment outside.

12 Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021
Chapter 1 General Information
Notes:

Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021 13
Chapter 2
Installation – Standard Enclosure
Door Opening Procedure Opening the Low Voltage Doors
Low voltage doors are identified as LV in Figure 3.
1. To access the low voltage compartment, use a screwdriver and turn both
of the 1/4-turn fasteners, which are located on the low voltage door, 90° in
a counterclockwise direction.
2. The door is now released and will swing open.
3. Reverse the procedure to secure the doors.
Figure 3 - Standard Cabinet
Refer to Access to the Power Bus on page 17 for the procedure to open the
swing-out low voltage panel behind the low voltage door.
IMPORTANT For information on the installation site preparation, see
publication MV-QS050.
ATTENTION: Use suitable personal protective equipment (PPE) per
local codes or regulations. Failure to do so may result in severe burns,
injury, or death. Refer to the standards such as NFPA 70E, Standard
for Electrical Safety in the Workplace and CSA Z462, Workplace
Electrical Safety Standard for safety guidance when working in and
around electrical equipment.
1/4 Turn Fasteners for Upper Low Voltage Door
1/4 Turn Fasteners for Lower Low Voltage Door

14 Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021
Chapter 2 Installation – Standard Enclosure
Opening the Medium Voltage Doors
The medium voltage doors are identified as MV in Figure 4.
Figure 4 - MV Door Locking Bolt and Isolation Switch Location
Refer to Access to the Power Bus on page 17 for the procedure to open the
swing-out low voltage panel behind the low voltage door (for standard cabinet
only).
1. Electrically open the contactor by pressing the STOP button on the
starter or at the remote control location.
2. Move the isolation switch handle to the OFF position.
3. Unscrew the locking 3/8-1.75 bolts for both MV doors.
The doors are now released and will swing open to the left.
4. Reverse the procedure to close the door
ATTENTION: Medium voltage components may be located behind the
swing-out low voltage panel (standard cabinets only). Complete the
power lockout procedure (See Power Lock-out Procedure on page 49)
before attempting to open the swing-out low voltage panel. Failure to
do so may result in severe burns, injury, or death.
ATTENTION: Complete the Power Lockout procedure (See Power
Lock-out Procedure on page 49) before beginning any service
procedures to the unit. Failure to do so may result in severe burns,
injury, or death.
IMPORTANT The medium voltage doors have their own isolation switch handle
and interlocking safeguards. The top MV door must be opened
before the lower MV door can be opened.
Isolation Switch
Door Locking Bolts for Upper
Medium Voltage Door
Door Locking Bolts for Lower
Medium Voltage Door

Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021 15
Chapter 2 Installation – Standard Enclosure
Anchoring Place the controller in the desired installation location. The floor must be flat
and level. The mounting surface for the equipment must be flat and within
±1 mm per meter. Installing metal shims is an acceptable method of
compensating for mounting surfaces that are out of tolerance. Mounting
surfaces that are not flat may inhibit proper set-up and operation of the latches
and interlocks. Use four M12 (1/2 in.) floor mounting bolts to securely fasten
the controller to the mounting surface. See Figure 6 as an example of the
location of the mounting holes in the cabinet.
IMPORTANT Verify that the swing-out low voltage panel is in its original
position before attempting to close the MV door. When
closing the medium voltage door, confirm all door locking
bolts on the right side of the MV door are in place and
tightened until the door is flush with the flange. Do not
overtighten the bolts. If the door is not securely fastened, it
is not be possible to move the isolation switch handle to the
ON position.
ATTENTION: Complete the Power Lock-out procedure
(See Power Lock-out Procedure on page 49) before beginning
any service procedures to the unit. Failure to do so may result
in severe burns, injury or death.
Refer to Dimension Drawing provided with order documentation
for additional details that are related to cabinet floor plan.
IMPORTANT Pre-determined cabinets have been designed for Uniform
Building Code (UBC) seismic zone 1, 2A, 2B, 3 and 4, and IBC
(International Building Code) seismic activity without overturning
or lateral movement, provided they are securely mounted
according to UBC, IBC, and local building codes. This can include
concrete pad design, steel floor design, and the sizing of cabinet
anchors. Concrete floor cutouts must not be next to floor anchor
bolts and must be sized to seismic load. Consult the factory if
floor mounting must be reviewed by an accredited engineer. Many
jurisdictions require an engineer from the local area to review the
design. Seismic qualification does not indicate that the
equipment will function properly after a seismic event.

16 Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021
Chapter 2 Installation – Standard Enclosure
Figure 5 - Standard Top Entry/Exit Locations
Figure 6 - Standard Bottom Entry/Exit Locations and Mounting Locations
Seismic Applications
•For installation on concrete – the minimum depth and radius of the
concrete which support the cabinet anchors is dependent on seismic
loads. See important information above.
•For installation on a metal structure – the metal plate depth and cabinet
anchoring method is dependent on seismic loads.
Joining Sections
• A - Line Cable Conduit Opening
5.68 x 9.00 [144 x 229]
• B - Load Cable Conduit Opening
9.00 x 10.00 [229 x 242]
• C - Control Wire Conduit Opening
3.00 x 3.00 [76 x 76]
0 [0]
4.65 [118]
16.04 [407]
30.00 [762]
36.00 [914]
0 [0]
3.62 [92]
5.41 [137]
6.62 [168]
36.00 [914]
A
B
C
A
B
C
D
E
• A - Line Cable Conduit Opening
5.68 x 9.00 [144 x 229]
• B - Load Cable Conduit Opening
9.00 x 10.00 [229 x 242]
• C - Control Wire Conduit Opening
3.00 x 5.00 [76 x 127]
• D - Non-removable Sill Channels
1.00 x 3.00 [25 x 76]
• E - Mounting Holes for 0.5 in. [12 mm]
Diameter Anchor Bolts
0 [0]
4.70 [119]
9.32 [237]
21.15 [537]
30.00 [762]
33.00 [838]
36.00 [914]
0 [0]
2.31 [59]
4.62 [117]
6.38 [162]
7.68 [170]
33.69 [856]
36.00 [914]
Joining hardware can be found in a package that is mounted to
the front of the shipping skid. See publication MV-QS050 for level
floor surface requirements.
IMPORTANT For arc resistant cabinets, see Chapter 3 for special instructions.

Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021 17
Chapter 2 Installation – Standard Enclosure
1. Position the left side section on a level surface and secure the section in
place with M12 (1/2 in.) floor mounting bolts (refer to Anchoring on
page 15).
2. When joining NEMA/EEMAC Type 12 sections, apply a continuous 3 mm
(1/8 in.) wide bead of silicon sealer around the perimeter of one section.
3. Remove the side bus access covers if applicable.
4. Position the right section against the left section. Verify that the surface
is level.
5. Secure the sections together using the 1/4-20 self-tapping screws (12 lb•ft
[15 N•m]). Thread the screw through the 7 mm (0.281 in.) clearance hole
to the corresponding 6 mm (0.219 in.) pilot hole. To access the front
clearance holes of the left-side cabinet, open the medium voltage doors.
To access the rear clearance holes, remove the rear covers of the starter. If
rear access is not available, refer to Front Access – Top Incoming Line
Cables and Power Bus on page 19 or Front Access – Bottom Incoming
Line Cables on page 22.
6. Secure the right section to the floor using M12 (1/2 in.) floor mounting
bolts (refer to Anchoring on page 15).
Figure 7 - Joining Sections
Access to the Power Bus
Rear access is the preferred access method for attaching line cables and for
making bus splice connections. However, these procedures can be done with
front-only access. Front access requires more time and disassembly of the
equipment to complete this procedure.
ATTENTION: The mounting surface for the equipment must be flat
and within ±1 mm per meter. Installing metal shims is an acceptable
method of compensating for mounting surfaces that are out of
tolerance. Mounting surfaces that are not flat may inhibit proper set-
up and operation of the latches and interlocks.
Front
Front
Side Bus
Access Cover
0.219 Pilot
Holes (5x)
0.281 Pilot
Holes (5x)
0.281 Pilot
Holes (5x)
0.219 Pilot
Holes (3x)
ATTENTION: This procedure requires contact with medium voltage
components. To avoid shock hazards, lock out incoming power
before working on the equipment (See Power Lock-out Procedure on
page 49). Verify with a hot stick or appropriate voltage measuring
device that all circuits are voltage free. Failure to do so may result in
severe burns, injury, or death.

18 Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021
Chapter 2 Installation – Standard Enclosure
Rear Access
1. Remove the hardware securing the center rear bus access cover
(Figure 8).
2. Remove the center rear bus access cover.
3. Once the rear bus cover is removed, you will see the three busbars
(Figure 9).
Figure 8 - Access to Power Bus from Side and Rear of Cabinet
Figure 9 - Rear Power Bus Access, Rear Panel Removed
Side Access
A side bus access cover is on each side of the controller.
1. Remove the hardware from the appropriate side bus access cover.
2. Remove the side bus access cover.
3. Once the side bus access cover is removed, you will see the three busbars.
(Figure 10).
Side Bus
Access Cover
Center Rear Bus
Access Cover

Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021 19
Chapter 2 Installation – Standard Enclosure
Figure 10 - Side Power Bus Access, Right Side Access Panel Removed
Front Access – Top Incoming Line Cables and Power Bus
Complete the Power Lockout Procedure (See Power Lock-out Procedure on
page 49) for both medium voltage power cells and the power bus.
1. Open the low voltage cell door (refer to Opening the Low Voltage Doors
on page 13).
2. Open the medium voltage cell doors (refer to Opening the Medium
Voltage Doors on page 14).
3. Remove the three door hinge pins on each medium voltage compartment
door.
4. With two people, carefully set the doors carefully aside.
5. Remove the two 1/4-20 self-tapping screws from the upper low voltage
panel upright supports (Figure 11).

20 Rockwell Automation Publication 1512A-UM101B-EN-P - December 2021
Chapter 2 Installation – Standard Enclosure
Figure 11 - Low Voltage Panel
6. Remove the two 1/4-20 self-tapping screws from the lower low voltage
panel upright supports (Figure 12).
7. Pull on right-hand side of low voltage panel. Swing low voltage panel to
the front and left of cabinet.
Remove self-tapping screws
from center vertical channel
The power MV cell doors must be removed before rotating
the low voltage panel.
