Installation Instructions
ControlLogix Power Supplies
Catalog Numbers 1756-PA72 Series C, 1756-PB72
Series C, 1756-PA75 Series B, 1756-PB75 Series B,
1756-PH75 Series B, 1756-PC75 Series B
About the Power Supplies
ControlLogix power supplies are used with the 1756 chassis to provide 1.2V, 3.3V, 5V, and
24V DC power for all modules installed in the chassis. The non-redundant power supplies are
mounted on the left end of the chassis, where they are plugged directly into the backplane.
Topic Page
Important User Information 2
Environment and Enclosure 3
Safety-related Programmable Electronic Systems 4
North American Hazardous Location Approval 4
European Hazardous Location Approval 5
Before You Begin 5
Install the Power Supply 6
Ground the Power Supply at Protective Earth Ground 8
Connect the Power 10
Remove the Protective Label 11
Activate the Power Supply 12
Determine the Input Power Requirements/Transformer Sizing 12
Status Indicators 14
Specifications 15
Additional Resources 23

2ControlLogix Power Supplies
Publication 1756-IN613A-EN-P - December 2008
Important User Information
Solid state equipment has operational characteristics differing from those of electromechanical equipment.
Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (Publication
SGI-1.1 available from your local Rockwell Automation sales office or online at
http://literature.rockwellautomation.com) describes some important differences between solid state
equipment and hard-wired electromechanical devices. Because of this difference, and also because of the
wide variety of uses for solid state equipment, all persons responsible for applying this equipment must
satisfy themselves that each intended application of this equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages
resulting from the use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many
variables and requirements associated with any particular installation, Rockwell Automation, Inc. cannot
assume responsibility or liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits,
equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell
Automation, Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
WARNING Identifies information about practices or circumstances that can cause an explosion in
a hazardous environment, which may lead to personal injury or death, property
damage, or economic loss.
IMPORTANT Identifies information that is critical for successful application and understanding of
the product.
ATTENTION Identifies information about practices or circumstances that can lead to personal injury
or death, property damage, or economic loss. Attentions help you identify a hazard,
avoid a hazard and recognize the consequences.
SHOCK HAZARD
Labels may be on or inside the equipment (for example, drive or motor) to alert people
that dangerous voltage may be present.
BURN HAZARD
Labels may be on or inside the equipment (for example, drive or motor) to alert people
that surfaces may reach dangerous temperatures.

ControlLogix Power Supplies 3
Publication 1756-IN613A-EN-P - December 2008
Environment and Enclosure
Prevent Electrostatic Discharge
ATTENTION This equipment is intended for use in a Pollution Degree 2 industrial environment, in
overvoltage Category II applications (as defined in IEC publication 60664-1), at altitudes
up to 2000 m (6562 ft) without derating.
This equipment is considered Group 1, Class A industrial equipment according to
IEC/CISPR Publication 11. Without appropriate precautions, there may be potential
difficulties ensuring electromagnetic compatibility in other environments due to
conducted as well as radiated disturbance.
This equipment is supplied as open-type equipment. It must be mounted within an
enclosure that is suitably designed for those specific environmental conditions that will
be present and appropriately designed to prevent personal injury resulting from
accessibility to live parts. The enclosure must have suitable flame-retardant properties to
prevent or minimize the spread of flame, complying with a flame spread rating of 5VA,
V2, V1, V0 (or equivalent) if non-metallic. The interior of the enclosure must be accessible
only by the use of a tool. Subsequent sections of this publication may contain additional
information regarding specific enclosure type ratings that are required to comply with
certain product safety certifications.
In addition to this publication, see:
•Industrial Automation Wiring and Grounding Guidelines, for additional installation
requirements, Allen-Bradley publication 1770-4.1.
•NEMA Standards publication 250 and IEC publication 60529, as applicable, for
explanations of the degrees of protection provided by different types of enclosure.
ATTENTION This equipment is sensitive to electrostatic discharge, which can cause internal damage
and affect normal operation. Follow these guidelines when you handle this equipment:
•Touch a grounded object to discharge potential static.
•Wear an approved grounding wriststrap.
•Do not touch connectors or pins on component boards.
•Do not touch circuit components inside the equipment.
•Use a static-safe workstation, if available.
•Store the equipment in appropriate static-safe packaging when not in use.

4ControlLogix Power Supplies
Publication 1756-IN613A-EN-P - December 2008
Safety-related Programmable Electronic Systems
North American Hazardous Location Approval
ATTENTION Personnel responsible for the application of safety-related programmable electronic
systems (PES) shall be aware of the safety requirements in the application of the system
and shall be trained in using the system.
The following information applies when operating
this equipment in hazardous locations. Informations sur l’utilisation de cet équipement en environnements dangereux.
Products marked "CL I, DIV 2, GP A, B, C, D" are suitable for use in
Class I Division 2 Groups A, B, C, D, Hazardous Locations and
nonhazardous locations only. Each product is supplied with
markings on the rating nameplate indicating the hazardous
location temperature code. When combining products within a
system, the most adverse temperature code (lowest "T" number)
may be used to help determine the overall temperature code of
the system. Combinations of equipment in your system are subject
to investigation by the local Authority Having Jurisdiction at the
time of installation.
Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne conviennent
qu'à une utilisation en environnements de Classe I Division 2
Groupes A, B, C, D dangereux et non dangereux. Chaque produit
est livré avec des marquages sur sa plaque d'identification qui
indiquent le code de température pour les environnements
dangereux. Lorsque plusieurs produits sont combinés dans un
système, le code de température le plus défavorable (code de
température le plus faible) peut être utilisé pour déterminer le
code de température global du système. Les combinaisons
d'équipements dans le système sont sujettes à inspection par les
autorités locales qualifiées au moment de l'installation.
WARNING EXPLOSION HAZARD -
• Do not disconnect equipment
unless power has been removed
or the area is known to be
nonhazardous. Do not disconnect
equipment unless power has
been removed or the area is
known to be nonhazardous.
• Do not disconnect connections to
this equipment unless power has
been removed or the area is
known to be nonhazardous.
Secure any external connections
that mate to this equipment by
using screws, sliding latches,
threaded connectors, or other
means provided with this product.
• Substitution of components may
impair suitability for Class I,
Division 2.
• If this product contains batteries,
they must only be changed in an
area known to be nonhazardous.
AVERTISSEMENT RISQUE D’EXPLOSION –
• Couper le courant ou s'assurer
que l'environnement est classé
non dangereux avant de
débrancher l'équipement.
• Couper le courant ou s'assurer
que l'environnement est classé
non dangereux avant de
débrancher les connecteurs. Fixer
tous les connecteurs externes
reliés à cet équipement à l'aide
de vis, loquets coulissants,
connecteurs filetés ou autres
moyens fournis avec ce produit.
• La substitution de composants
peut rendre cet équipement
inadapté à une utilisation en
environnement de Classe I,
Division 2.
• S'assurer que l'environnement est
classé non dangereux avant de
changer les piles.

ControlLogix Power Supplies 5
Publication 1756-IN613A-EN-P - December 2008
European Hazardous Location Approval
Before You Begin
Before you attempt to install a power supply, make sure you have the required tools.
Required Tools
•1/8” slotted screwdriver
•1/4” slotted (#2) or Phillips screwdriver
•Torque screwdriver
•Needle-nose pliers
•Crimping tool
1756-PB72 Series C, 1756-PB75 Series B (only)
European Zone 2 Certification (The following applies when the product bears the Ex or EEx
Marking)
This equipment is intended for use in potentially explosive atmospheres as defined by European Union
Directive 94/9/EC and has been found to comply with the Essential Health and Safety Requirements
relating to the design and construction of Category 3 equipment intended for use in potentially explosive
atmospheres, given in Annex II to this Directive.
Compliance with the Essential Health and Safety Requirements has been assured by compliance with
EN 60079-15 and EN 60079-0.
WARNING •This equipment must be installed in an enclosure providing at least IP54 protection
when applied in Zone 2 environments.
•This equipment shall be used within its specified ratings defined by Allen-Bradley.
•Provisions shall be made to prevent the rated voltage from being exceeded by
transient disturbances of more than 40% when applied in Zone 2 environments.
•This equipment must be used only with ATEX certified backplanes.
•Secure any external connections that mate to this equipment by using screws, sliding
latches, threaded connectors, or other means provided with this product.
•Do not disconnect equipment unless power has been removed or the area is known to
be nonhazardous.
ATTENTION This equipment is not resistant to sunlight or other sources of UV radiation.

6ControlLogix Power Supplies
Publication 1756-IN613A-EN-P - December 2008
Install the Power Supply
The chassis series you have determines what power supply you can use. The following table
lists the chassis that is to be installed with a respective power supply.
Follow these steps to install the power supply.
1. Align the power-supply circuit board with the card guides on the left side of the
chassis.
2. Guide the extended tab on the power-supply circuit board into the notch of the
chassis.
Chassis Compatibility
Power Supply Cat. No. Chassis Cat. No.
1756-PA72 Series C 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17
Series A, B
1756-PB72 Series C
1756-PA75 Series B
1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17
Series B only
1756-PB75 Series B
1756-PC75 Series B
1756-PH75 Series B
20264a-M
43614
Notch

ControlLogix Power Supplies 7
Publication 1756-IN613A-EN-P - December 2008
3. Slide the power supply in until it is flush with the back of the chassis.
4. Fasten the power supply to the chassis.
44144
44145

8ControlLogix Power Supplies
Publication 1756-IN613A-EN-P - December 2008
Ground the Power Supply at Protective Earth Ground
The following steps describe how to connect the equipment-protective earth ground from
the power supply to the chassis.
1. Connect the equipment-protective earth ground from the power supply to the chassis.
2. Connect the protective-earth ground from the chassis to the system earth ground.
3. Tighten the nut on the equipment-protective earth ground terminal stud to a torque
of 1.4 N•m (12 lb•in).
Item Description
1 Wiring terminal block
2 Protective earth-ground terminal stud
3 Nut with captive star washer
4Equipment grounding conductor (ground lug with 2.1 mm2[14 AWG] wire) protective earth ground
from wiring terminal block to chassis
5 Nut with captive star washer
6Equipment grounding conductor (ground lug with 2.1 mm2[14 AWG] wire) protective earth ground
from chassis to ground bus
6
4
1
2
3
5
44146

ControlLogix Power Supplies 9
Publication 1756-IN613A-EN-P - December 2008
Verify the Grounding Configuration
Before continuing, verify that the Protective and Functional Earth grounds are connected to
the system. We recommend that you use a ground bus to reduce the electrical resistance at the
connection.
For more information on grounding the wiring to the ControlLogix chassis, refer to the
ControlLogix Chassis–Series B Installation Instructions, publication 1756-IN080.
TIP Keep wire lengths as short as possible.
20231a-M
Functional Earth Ground
Earth Ground
Protective Earth Ground

10 ControlLogix Power Supplies
Publication 1756-IN613A-EN-P - December 2008
Connect the Power
Use 2.5 mm2(14 AWG) 75 °C (167 °F) copper wire with 1.2 mm (3/64-in.) insulation to
connect power. Follow these steps for each wire (high side (L1), low side (L2/N), and
ground) to connect power.
1. Turn the screw counterclockwise to open the wiring terminal.
WARNING If you connect or disconnect wiring while the field-side power is on, an electrical arc can
occur. This could cause an explosion in hazardous location installations. Be sure that
power is removed or the area is nonhazardous before proceeding.
IMPORTANT The third terminal from the top (between low side and ground) is not used on the 1756
power supplies.
43894
1756-PA72 Series C, 1756-PA75 Series B
43632
1756-PB72 Series C, 1756-PB75 Series B,
1756-PH75 Series B, 1756-PC75 Series B
1
2
4
5
3a
3b
(AC Power Supplies)
(DC Power Supplies)

ControlLogix Power Supplies 11
Publication 1756-IN613A-EN-P - December 2008
2. Insert the wire into the terminal.
3. Turn the screw clockwise to tighten the terminal on the wire.
4. Tighten the terminals to a torque of 0.8 N•m (7 lb•in).
Remove the Protective Label
Remove the plastic label from the top of the power supply.
Power Supply Connections
Item Description
1 L1 - High side of line power
AC Power Supplies2 L2/N- Low side of line power
3 a Protective earth-ground terminal
3 b Protective earth-ground terminal
DC Power Supplies4DC+
5DC-
ATTENTION Make sure the chassis is mounted and all panel fabrication is complete before you
remove the protective label. This label protects the power supply from metal shavings
falling inside the power supply and damaging it during operation.
20264b-M

12 ControlLogix Power Supplies
Publication 1756-IN613A-EN-P - December 2008
Activate the Power Supply
Flip the power switch to the up position to turn the power supply on.
Determine the Input Power Requirements/Transformer Sizing
These graphs show the input power requirements for the power supplies, given the power
they are providing to the modules in the chassis.
The vertical axis of each graph shows the backplane power consumed by all of the modules in
the chassis; the horizontal axis shows input power requirements of the power supply.
43615
43895
1756-PA72 Series C, 1756-PA75 Series B (AC)
1756-PB72 Series C, 1756-PB75 Series B (DC)
43896
Real Power (Watts)
Backplane Power
Load (Watts)
Apparent Power (Watts) = Transformer Load
(VA) = Real Power (Watts)
Backplane Power
Load (Watts)

ControlLogix Power Supplies 13
Publication 1756-IN613A-EN-P - December 2008
To use the graphs, complete this procedure.
1. Add all of the backplane power, that is, Watts, for all of the modules in the chassis.
2. Find the number from step 1 on the vertical axis.
3. Follow that value to the right until it intersects the line on the graph.
4. Find the associated input-power rating consumed by the power supply on the
horizontal axis.
For example, if the power consumption of all of the modules in the chassis is 30 Watts, a
1756-PH75 series B power supply consumes approximately 42 Watts of Real Power.
Real Power (Watts)
1756-PH75 Series B, 1756-PC75 Series B
43618
Backplane Power
Load (Watts)

14 ControlLogix Power Supplies
Publication 1756-IN613A-EN-P - December 2008
Status Indicators
ControlLogix power supplies have a green status indicator that remains ON during normal
operation.
If the indicator turns OFF during operation, follow these steps.
1. Verify that the line voltage is within the specified range.
2. If the indicator remains OFF, cycle line power OFF.
3. Loosen the screws holding the power supply to the chassis.
See page 7 for the location of the screws on the power supply.
4. Slide the power supply out so that the rear connector is disconnected.
5. Reapply input power.
6. If the indicator:
•turns ON:
a. Verify that the module loads in the system are within the output rating of the
power supply.
b. Power down the power supply.
c. Reinstall the power supply in the chassis.
•turns OFF, return the power supply to your local Rockwell Automation
distributor.
Item Description
1 Status indicator
44148
1

ControlLogix Power Supplies 15
Publication 1756-IN613A-EN-P - December 2008
Specifications
AC Power Supplies
1756-PA72 Series C, 1756-PA75 Series B - Technical Specifications
Attribute 1756-PA72 Series C 1756-PA75 Series B
Dimensions (HxWxD), approx. 140 x 112 x 145 mm (5.5 x 4.4 x 5.7 in.)
Weight, approx. 0.95 kg (2.10 lb)
Module location Left side of 1756 chassis
Chassis 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17
Chassis compatibility Series A
Series B
Series B
Input voltage range 85…265V AC
Input voltage, nom 120/240V AC
Input frequency range 47…63 Hz
Apparent input power 100VA
Input power, max 100VA 100 W
Output power, max(1) 75 W @ 60 °C (140 °F)
Power dissipation 85.3 BTU/hr
Power consumption 25 W @ 60 °C (140 °F)
Hold up time(2) 5 cycles @ 85V AC, 50/60 Hz
6 cycles @ 120V AC, 50/60 Hz
6 cycles @ 200V AC, 50/60 Hz
6 cycles @ 240V AC, 50/60 Hz
Inrush current, max 20 A
Current capacity at 1.2V 1.5 A
Current capacity at 3.3V 4 A
Current capacity at 5.1V 10 A 13 A
Current capacity at 24V 2.8 A
Overcurrent protection, max(3) 15 A, user-supplied
Fusing(4) Non-replaceable fuse is soldered in place
Transformer load, max 100VA
Isolation voltage 250V (continuous), reinforced insulation type
Type tested at 3500V DC for 60 s, Power Input to Backplane.
Wire size 2.5 mm2 (14 AWG) solid or stranded copper wire rated at 75 °C (167 °F), or greater,
1.2 mm (3/64 in.) insulation max

16 ControlLogix Power Supplies
Publication 1756-IN613A-EN-P - December 2008
Wire category 1(5) on power ports
North American temp code T4
Mounting screw torque 0.8 N•m (7 lb•in)
(1) The combination of all output power (1.2V, 3.3V, 5.1V, and 24V) cannot exceed 75 W.
(2) The hold up time is all the time between input voltage removal and DC power failure.
(3) Use time-delay type overcurrent protection in all ungrounded conductors.
(4) This fuse is intended to guard against fire hazard due to short circuit conditions.
(5) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication 1770-4.1.
1756-PA72 Series C, 1756-PA75 Series B - Environmental Specifications
Attribute 1756-PA72 Series C 1756-PA75 Series B
Operating temperature
IEC 60068-2-1 (Test Ad, Operating
Cold)
IEC 60068-2-2 (Test Bd, Operating
Dry Heat)
IEC 60068-2-14 (Test Nb,
Operating Thermal Shock)
0…60 °C (32…140 °F)
Nonoperating temperature
IEC 60068-2-1 (Test Ab,
Unpackaged Nonoperating Cold)
IEC 60068-2-2 (Test Bb,
Unpackaged Nonoperating Dry
Heat)
IEC 60068-2-14 (Test Na,
Unpackaged Nonoperating
Thermal Shock)
-40…85 °C (-40…185 °F)
Relative humidity
IEC 60068-2-30 (Test Db,
Unpackaged Nonoperating Damp
Heat)
5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Operating shock
IEC 60068-2-27 (Test Ea,
Unpackaged Shock)
30 g
Nonoperating shock
IEC 60068-2-27 (Test Ea,
Unpackaged Shock)
50 g
Emissions
CISPR 11 Group 1, Class A
ESD immunity
IEC 61000-4-2 6 kV contact discharges 8 kV air discharges
1756-PA72 Series C, 1756-PA75 Series B - Technical Specifications
Attribute 1756-PA72 Series C 1756-PA75 Series B

ControlLogix Power Supplies 17
Publication 1756-IN613A-EN-P - December 2008
Radiated RF immunity
IEC 61000-4-3 10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
Conducted RF immunity
IEC 6100-4-6 10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
EFT/B immunity
IEC 61000-4-4 ±4 kV at 5 kHz on power ports
Surge transient immunity
IEC 61000-4-5 ±1 kV line-line (DM) and ±2 kV line-earth (CM) on power ports
Oscillatory surge withstand
IEEE C37.90.1 3 kV
Enclosure type rating None (open style)
Voltage variation
IEC 61000-4-11 30% dips for 1 period at 0° and 80° on AC supply ports
60% dips for 5 and 50 periods on AC supply ports
±10% fluctuations for 15 min on AC supply ports
>95% interruptions for 250 periods on AC supply ports
1756-PA72 Series C, 1756-PA75 Series B - Certifications(1)
Certifications(2) 1756-PA72 Series C 1756-PA75 Series B
UL UL Listed Industrial Control Equipment. See UL File E65584
CSA Certified Process Control Equipment. See CSA File LR54689C
CSA Certified Process Control Equipment for Class I, Division 2 Group A,B,C,D
Hazardous Locations. See CSA File LR69960C
FM Approved Equipment for use in Class 1 Division 2 Group A,B,C,D Hazardous
Locations
CE European Union 2004/108/EC EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN61000-6-2; Industrial Immunity
EN61000-6-4; Industrial Emissions
EN61131-2; Programmable Controllers (Clause 8, Zone A,B, C)
European Union 2006/95/EC LVD, complaint with:
EN 61131-2; Programmable Controllers (Clause 11)
C-Tick Australian Radio Communications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
TÜV TÜV Certified for Functional Safety:
up to and including SIL 2 (1756-PA75 only)
(1) When product is marked.
(2) See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification
details.
1756-PA72 Series C, 1756-PA75 Series B - Environmental Specifications
Attribute 1756-PA72 Series C 1756-PA75 Series B

18 ControlLogix Power Supplies
Publication 1756-IN613A-EN-P - December 2008
DC Power Supplies
1756-PB72 Series C, 1756-PB75 Series B, 1756-PC75 Series B, 1756-PH75 Series B -
Technical Specifications
Attribute 1756-PB72
Series C
1756-PB75
Series B
1756-PC75
Series B
1756-PH75
Series B
Dimensions (HxWxD),
approx. 140 x 112 x 145 mm (5.5 x 4.4 x 5.7 in.)
Weight, approx. 0.95 kg (2.10 lb)
Module location Left side of 1756 chassis
Chassis 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17
Chassis compatibility Series A
Series B
Series B
Input voltage range 18…32V DC(1) 30…60V DC 90…143V DC
Input voltage, nom 24V DC 48V DC 125V DC
Input power, max 95 W
Output power, max 75 W @ 60 °C (140 °F)(2)
Power dissipation 68.2 BTU/hr
Power consumption 20 W @ 60 °C (140 °F)
Hold up time 35 ms @ 18V DC(3)
40 ms @ 24V DC
40 ms @ 32V DC
50 ms @ 30…60V
DC(3) 50 ms @ 30…143V
DC(3)
Inrush current, max 30 A 20 A
Current capacity at
1.2V 1.5 A
Current capacity at
3.3V 4 A
Current capacity at
5.1V 10 A 13 A
Current capacity at
24V 2.8 A
User-supplied
overcurrent
protection, max
15 A(4)
Fusing Non-replaceable fuse is soldered in place(5)
Isolation voltage 250V (continuous), reinforced insulation type
Type tested at 3500V DC for 60 s, power input to backplane
Wire category 1(6) on power ports
Wire size 2.5 mm2 (14 AWG) solid or stranded copper wire rated at 75 ° C (167 °F), or greater, 1.2 mm
(3/64 in.) insulation max

ControlLogix Power Supplies 19
Publication 1756-IN613A-EN-P - December 2008
North American temp
code T4
IEC temp code T4 N/A
Mounting screw
torque 0.8 N•m (7 lb•in)
(1) Input may drop to 16V for a maximum of two minutes each hour for motor starting.
(2) The combination of all output power (1.2V, 3.3V, 5.1V, and 24V) cannot exceed 75 W.
(3) The hold up time is the time between input voltage removal and DC power failure.
(4) Use time-delay type overcurrent protection in all ungrounded conductors.
(5) This fuse is intended to guard against fire hazard due to short circuit conditions.
(6) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication 1770-4.1.
1756-PB72 Series C, 1756-PB75 Series B, 1756-PC75 Series B, 1756-PH75 Series B -
Environmental Specifications
Attribute 1756-PB72
Series C
1756-PB75
Series B
1756-PC75
Series B
1756-PH75
Series B
Operating
temperature
IEC 60068-2-1 (Test
Ad, Operating Cold)
IEC 60068-2-2 (Test
Bd, Operating Dry
Heat)
IEC 60068-2-14 (Test
Nb, Operating
Thermal Shock)
0…60 °C (32…140 °F)
1756-PB72 Series C, 1756-PB75 Series B, 1756-PC75 Series B, 1756-PH75 Series B -
Technical Specifications
Attribute 1756-PB72
Series C
1756-PB75
Series B
1756-PC75
Series B
1756-PH75
Series B

20 ControlLogix Power Supplies
Publication 1756-IN613A-EN-P - December 2008
Nonoperating
temperature
IEC 60068-2-1 (Test
Ab, Unpackaged
Nonoperating Cold)
IEC 60068-2-2 (Test
Bb, Unpackaged
Nonoperating Dry
Heat)
IEC 60068-2-14 (Test
Na, Unpackaged
NonoperatingThermal
Shock)
-40…85 °C (-40…185 °F)
Relative humidity
IEC 60068-2-30 (Test
Db, Unpackaged
Nonoperating Damp
Heat)
5…95% noncondensing
Vibration
IEC 60068-2-6 (Test
Fc, Operating)
2 g @ 10…500 Hz
Operating shock
IEC 60068-2-27 (Test
Ea, Unpackaged
Shock)
30 g
Nonoperating shock
IEC 60068-2-27 (Test
Ea, Unpackaged
Shock)
50 g
ESD immunity
IEC 61000-4-2
6 kV contact discharges
8 kV air discharges
Emissions
CISPR 11
Group 1, Class A
1756-PB72 Series C, 1756-PB75 Series B, 1756-PC75 Series B, 1756-PH75 Series B -
Environmental Specifications
Attribute 1756-PB72
Series C
1756-PB75
Series B
1756-PC75
Series B
1756-PH75
Series B
