RocwooD RS400 User manual

RS400
Electric Pressure Washer
Operating Instructions
Original instructions
WARNING: Do not use the machine without reading the instruction sheet.

Safety and Warning Information
Automatic ON/OFF:
The motor on this pressure washer does
not run continuously. It only runs when the
trigger of the spray gun is squeezed. After
following the start up procedures in this
manual, turn the pressure washer ON and
squeeze the trigger for activation. See
“Operating Instruction” section in this
manual for further details.
WARNING! The electrical supply
connection must be made by a qualified
person and comply with IEC 60364-1. The
electric supply to this machine should
include either a residual current device that
will interrupt the supply if the leakage
current to earth exceeds 30 mA for 30 ms or
a device that will prove the earth circuit.
WARNING! The operating method to be
followed in the event of accident or
breakdown to prevent unsafe situations.
e.g. Contact with detergents - rinse with an
abundance of clean water.
WARNING!The motor of this pressure
washer will NOT run unless the trigger is
squeezed.
Safety Guidelines
This manual contains important information.
This information is provided for SAFETY
and to PREVENT EQUIPMENT
PROBLEMS. To help recognize this
information, observe the following symbols.
DANGER!Danger indicates an
imminently hazardous situation
which, if not avoided, WILL result in
death or serious injury.
WARNING!Warning indicates a
potentially hazardous situation
which, if not avoided, COULD result
in death or serious injury.
CAUTION: Caution indicates a
potentially hazardous situation
which, if not avoided, MAY result in
minor or moderate injury.
NOTE: Information that requires
special attention.
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING! When using the machine the
following precautions should always be
considered:
1. Read all instructions before use.
2. To reduce the risk of injury, close
supervision is necessary when a machine is
used near children.
3. ALWAYS disconnect power before
disassembling or repairing the unit of the
machine.

4. Follow all safety codes as well as the
Occupational Safety and Health Act
(OSHA).
5. Ensure safety devices are operating
properly before using the machine. DO
NOT remove or modify any part of the gun
or unit of the machine.
6. Know how to stop the machine and bleed
pressure quickly. Be thoroughly familiar with
the controls.
7. Stay alert – watch what you are doing.
8. Do not operate the machine when
fatigued or under the influence of alcohol or
drugs.
9. Keep operation area clear of all persons.
10. Do not overreach or stand on unstable
surfaces. Keep good footing and balance at
all times.
11. Follow the maintenance instructions
specified in the manual.
12. Use cleaning agent supplied or
recommend by the manufacturer.
13. Only use the machine on stable ground.
Be careful not to damage the machine
during transportation.
14. In the event of an accident please
always switch off the machine and pull out
the plug from socket outlet, and disconnect
from the water supply.
15. The machine is not intended to be
connected to the potable water mains. If
necessary, please use only inlet hose-set
approved by IEC 61770.
Risk of injection or severe injury. Keep
clear of nozzle. Do not discharge
streams at people. This machine is to be
used only by trained operators. Always
remove lance from gun before cleaning
debris from tip.
• Keep clear of nozzle. NEVER direct high
pressure spray at any person, animal or
yourself.
• Always wear safety glasses or goggles
and protective clothing when operating or
performing maintenance.
• Never put hands or fingers over the spray
tip while operating the unit.
• Never try to stop or deflect leaks with any
body part.
• Always engage the trigger safety latch in
the safe position, even when spraying is
stopped for a moment.
• Always follow detergent manufacturer’s
label recommendations for proper use of
detergents. Always protect eyes, skin, and
respiratory system from detergent use.

WARNING!
SERVICING OF A DOUBLE-
INSULATED MACHINE
In a double-insulated machine, two systems
of insulation are provided instead of
grounding. No grounding means are
provided for a double-insulated machine,
nor should grounding means be added to
the machine. Servicing a double-insulated
machine requires extreme care and
knowledge of the system, and should be
done only by qualified service personnel.
Replacement parts for a double-insulated
machine must be identical to the original
parts. A double-insulated machine is
marked with the words “Double Insulation
"or “Double Insulated.” Machine may also
be marked with symbol shown in Figure 1.
WARNING!Do not use pressure
that exceeds the operating
pressure of any of the parts (hoses,
fittings, etc.) in the pressurized system.
Ensure all equipment and accessories
are rated to withstand the maximum
working pressure of the unit.
WARNING!Explosion hazard.
Never spray flammable liquids or use
pressure washer in areas containing
combustible dust, liquids or vapors.
Never operate the machine in a closed
building or in or near an explosive
environment.
WARNING!Do not spray electrical
apparatus and wiring.
• Never disconnect the high pressure
discharge hose from the machine while the
system is pressurized. To depressurize
machine, turn power and water supply off,
then press gun trigger 2~3 times.
• Never permanently engage the trigger
mechanism on the gun.
• Never operate the machine without all
components properly connected to the
machine (handle, gun/wand assembly,
nozzle, etc.).
WARNING! Equipment damage.
• ALWAYS turn water supply “ON” before
turning pressure washer “ON.” Running
the pump dry causes serious damage.
• Do not operate the pressure washer with
the inlet water screen removed. Keep
screen clear of debris and sediment.
• NEVER operate pressure washer with
broken or missing parts. Check equipment
regularly and repair or replace worn or
damaged parts immediately.

•Use only the nozzle supplied with this
machine.
•Never leave the wand unattended while
the machine is running.
•Never attempt to alter factory settings.
Altering factory settings could damage the
unit and will void the warranty.
•Always hold the gun and wand firmly
when starting and operating the machine.
•NEVER allow the unit to run with the
trigger released (off) for more than one (1)
minute. The resulting heat buildup will
damage the pump.
•The pressure washer is not designed to
pump hot water. NEVER connect it to a hot
water supply as it will significantly reduce
the life of the pump.
•NEVER store the pressure washer
outdoors or where it could freeze. The
pump will be seriously damaged.
•Release the trigger when changing from
high to low pressure modes. Failure to do
so could result in damage.
•Be aware of the recoil caused by the
water jet when the machine is switched on.
CAUTION: Keep the hose away from
sharp objects. Bursting hoses may cause
injury. Examine the hose regularly and
replace it if damaged.
Do not attempt to mend a damaged
hose.
EXTENSION CABLES
The use of an extension cable is not
recommended. Use only extension cables
intended for outdoor use. These are
identified by the mark “Acceptable for
use with outdoor machines; store indoors
while not in use.” Use only extension cables
having an electrical rating equal to or more
than the rating of the machine. Do not use
damaged extension cables.Examine
extension cable before using and replace it if
damaged. Do not abuse extension cable.
Do not pull on the cable to disconnect. Keep
cable away from heat and sharp edges.
Always disconnect cable from receptacle
before disconnecting machine from
extension cable.
DANGER!Failure to follow these
instructions can result in serious injury,
including death.
WARNING!To reduce the risk of
electrocution, keep all connections dry and
off the ground. Do not touch plug with wet
hands.
Machines shall not be used by children.
Children should be supervised to ensure
that they do not play with the machine.
This machine is not intended for use by
